CHRYNAV1 Advent Integrated Navigation
This interface is designed to integrate Navigation into select
Chrysler and Dodge 8.4" or 4.3" monitors.
The following items are supplied with the CHRYNAV1
•
CAN Module #33814180
•
LVDS Video Cable #31414180
•
Power T-Harness #37514180
•
CAN to NAV #30314180
•
Switch #31414170
•
Speaker Wire Harness #31914180
•
Installation Guide
INSTALLATION MANUAL
What's in the Box
NOTE: Not all parts are used in every installation.
•
Aux Audio # 31514170
•
Aux Video # 33914170
•
GPS Antenna #34914170
•
USB Update Cable #32714170
•
Map SD Card #35014170
•
External Speaker #33514190
Advertisement
Table of Contents
Related Manuals for Advent CHRYNAV1
Summary of Contents for Advent CHRYNAV1
- Page 1 CHRYNAV1 Advent Integrated Navigation This interface is designed to integrate Navigation into select Chrysler and Dodge 8.4” or 4.3” monitors. INSTALLATION MANUAL What’s in the Box The following items are supplied with the CHRYNAV1 • CAN Module #33814180 • Aux Audio # 31514170 •...
- Page 2 Prior to Installation: Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation. Read entire instructions thoroughly before starting. This document covers such items as:- •...
- Page 3 Installation: NOTE: Disconnect the vehicle battery before starting your installation. Removal of the LCD Touch Panel and Radio control center is required for installation. Vehicle Specific instructions are available on- line at www.voxxuniversity.com. After the components are removed, connect the following: Using the Supplied T-harness Power Cable, disconnect the matching cable from the main Radio/CD unit.
- Page 4 DIP Switch Settings: Up is OFF; Down is ON for Dip Switches. 10. Check the DIP Switch settings: Dip 1: UP External RGB input. Not used Dip 2: UP Video Input 1 Off Dip 3: UP Video Input 2 Off Dip 4: DOWN OEM High Resolution Monitor On Dip 5: UP...
-
Page 5: Specifications
For Navigation operation see the included quick start guide or download a full user’s manual from WWW.ADVENTPRODUCTS.COM f the picture is not centered or does not fill the screen correctly you can adjust the picture size. Access the settings menu by pressing the Menu button on the side of the Nav Interface Module. - Page 6 Vehicle Specific Instructions, Tech Tips, and Installation notes can be found at WWW.AUDIOVOXUNIVERSITY.COM...
- Page 7 NOTES...
- Page 8 Voxx Electronics Corporation Hauppauge, NY 11788 Technical Assistance: 1-800-323-4815 WWW.ADVENTPRODUCTS.COM © 2014 Printed in China 128-9395...
