  • Page 1 6513WU Motherboard Reference Part Number : 5615 7027 0001 R00 (Jul. 2000)
  • Page 2 Trademarks All brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this guide is subject to change without notice.
  • Page 3 Caution Texts Concerning Lithium Batteries DANISH ADVARSEL! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. NORWEGIAN ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
  • Page 4 Class B Regulations U. S. A. Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Important Safety Instructions • Read all of these instructions. • Follow all warnings and instructions marked on the product. • Unplug this product from the wall outlet before installing an add-on card inside this product. • Do not use this product near water. •...

  • Page 6: Table Of Contents

    - If the product exhibits a distinct change in performance, indicating a need for service. Table of Contents Preface ...................... 9 Chapter 1 Introduction ..............10 Features..................10 Specifications ................10 CPU, Memory, and Main Components ........10 Interfaces and Controllers ............11 Chapter 2 System Components............
  • Page 7 Appendix A Software Drivers and Utilities......... 33 Installation Instructions for Windows 95/98/2000 ....... 33 Chipset Driver ................ 33 Audio Driver ................33 Video Driver ................34 Installation Instructions for Windows NT 4.0....... 34 Audio Driver ................34 Video Driver ................34...
  • Page 8 List of Figures Figure 2-1. Major Components of System Board ......12 Figure 3-1. Connector and Jumper Locations......15 Figure 4-1. Inserting CPU............18 Figure 4-2. Installing CPU ............19 Figure 4-3. DIMM Module Locations ........... 20 Figure 4-4. Installing DIMM Module ..........20 List of Tables Table 2-1.

  • Page 9: Preface

    Preface This manual contains basic information necessary for both the end user and service personnel. Although most of the information you need are contained in this manual, we recommend you to contact an authorized dealer for service purposes. Making personal alterations to the system can violate the effectivity of your warranty.

  • Page 10: Chapter 1 Introduction

    Chapter 1 Introduction This chapter introduces the specifications and the features of the motherboard. Features • 66/100/133 FSB Socket 370 CPU Support • Plug and Play support For automatic resource assignment, your system is PnP version 1.01a compliant. • Audio subsystem The audio subsystem allows you to easily record, play, and edit music and voice.

  • Page 11: Interfaces And Controllers

    • ROM BIOS 2Mb flash EEPROM, supporting audio, video, security, setup, and power management Interfaces and Controllers • Intel 810e chipset The chipset consists of the Intel 82810e Graphics Memory Controller Hub (GMCHe), the Intel 82801AA I/O Controller Hub (ICH), and the Intel 82802AB FirmWare Hub (FWH).

  • Page 12: Chapter 2 System Components

    Chapter 2 System Components This chapter introduces the components of the motherboard. Major Components ESS1989 Audio PCI Slots PCI1 PCI2 PCI3 PCI4 82810e Clock gen. GMCHe 82801AA DIMM Sockets DIMM1 DIMM2 82802AB 47U332 BIOS Super I/O Battery Figure 2-1. Major Components of System Board...

  • Page 13: Table 2-1. Major Components Description

    Reference Description Name Clock Synthesizer: • CK100 + CKBF • Supports 2.5V/3.3V CPU clock swing • Power-on default CPU/SDRAM clock frequencies • Serial data interface IO Controller Hub (ICH) Controller provides: Intel 82801AA • PCI-to-ISA bridge (ICH) • Low Pin Count (LPC) I/F •...
  • Page 14 (Continued) Reference Description Name Graphics Memory Controller Hub (GMCHe) Controller Intel 82810e provides: (GMCHe) • Processor Interface: - Supports Celeron or Pentium III (Socket 370) at 66/100/133MHz FSB - GTL+ Compliant host bus • DRAM Interface: - Supports SDRAM DRAM - Supports 512MB memory using x8, x16, x32, x64 x128 and x256 16/64-bit SDRAM •...

  • Page 15: Chapter 3 Connector And Jumper Definition

    Chapter 3 Connector and Jumper Definition This chapter defines the connectors and jumpers on the motherboard. PCI1 PCI2 PCI3 PCI4 DIMM1 DIMM2 Figure 3-1. Connector and Jumper Locations...

  • Page 16: Connector Definitions

    Connector Definitions Internal Connectors Connector Definition ATX power Button Board Suspend LED HDD LED 11-13 Power LED 15-16 Power button CPU fan CPU socket System fan Battery DIMM1~2 DIMM sockets PCI1~4 PCI slots Table 3-1. Internal Connector Definition External Connectors Connector Definition upper...

  • Page 17: Jumper Settings

    Jumper Settings NOTE: Jumpers not described in this chapter are reserved for factory use only. Do not change the default settings. Jumper Definition Setting CMOS setting 1-2: Normal 2-3: Clear CMOS On-board audio 1-2: Enabled select 2-3: Disabled * To clear the RTC and CMOS RAM, set JP1 to 2-3 for one second, and set it back to 1-2 again.

  • Page 18: Chapter 4 Cpu And Memory Installation

    Chapter 4 CPU and Memory Installation NOTE: To avoid damage during installation, you are advised to ask your dealer for help. NOTE: Static electricity can destroy electronic devices. Whenever you handle any option outside of its protective packaging, first discharge any static electricity from your body by touching a protective grounding device or unpainted metal on the rear panel of the system unit.

  • Page 19: Figure 4-2. Installing Cpu

    4. Press the arm downwards to the horizontal position. You will feel some resistance while doing so. This is normal as the pressure starts to secure the CPU in place. Figure 4-2. Installing CPU...

  • Page 20: System Memory Installation

    System Memory Installation 1. Locate the DIMM sockets (DIMM1-2) on the motherboard. DIMM Sockets DIMM1 DIMM2 Figure 4-3. DIMM Module Locations 2. Align the DIMM module with the socket and firmly insert the DIMM into the socket. Then, push the plastic clips to snap it into place. Figure 4-4.

  • Page 21: Chapter 5 The Setup Program

    Chapter 5 The SETUP Program This chapter tells you how to configure your system using the SETUP program. Introduction The SETUP program allows you to enter the system configuration information. This information is needed by the system to identify the type of devices installed and to set up special features.

  • Page 22: Moving Around And Making Selections

    Moving Around and Making Selections In general, you use the arrow keys to highlight items and the [PageUp]/[+] and [PageDown]/[−] keys to change entries. Description of keyboard usage is listed below. You can also find keyboard instructions on the menu screen. Description [ ], [ ] Move the highlight to the previous or next item.

  • Page 23: Standard Cmos Features

    Standard CMOS Features The “Standard CMOS Features” category includes all the items in a standard, AT-compatible BIOS (Basic Input/Output System). The followings describe in sequence all the items of this category. Date/Time The date and time might be incorrect when you start up your computer for the first time.

  • Page 24: Advanced Bios Features

    Advanced BIOS Features The “Advanced BIOS Features” category includes all the items of your system’s special enhanced features. The followings describe in sequence all the items of this category. Virus Warning This item helps prevent computer viruses by monitoring the boot sector and partition table of the hard disk drive.

  • Page 25: Swap Floppy Drive

    First/Second/Third Boot Device, Boot Other Device This item sets the sequence of booting, i.e., which drive to search first for the operating system. Swap Floppy Drive This feature allows you to exchange the drive names of the two floppy disk drives, if installed.

  • Page 26: Advanced Chipset Features

    Security Option This item allows you to limit the access to the system and SETUP, or just to SETUP. NOTE: Security takes effect only if a password is set. (See “Set Supervisor/User Password” in this chapter.) OS Select for DRAM > 64MB This item allows you to access the memory that is over 64MB in OS/2.

  • Page 27: Integrated Peripherals

    Integrated Peripherals The “Integrated Peripherals” category allows you to configure the on-board device controllers. The followings describe in sequence all the items of this category. On-Chip Primary/Secondary PCI IDE The item allows you to enable or disable the built-in IDE hard disk controller. Select Disabled only if you are using higher performance or specialized controller card instead of the onboard IDE controller.

  • Page 28: Onboard Fdc Controller

    Onboard FDC Controller This item allows you to enable or disable the on-board floppy disk drive controller. Select Disabled only if you want use a separate floppy disk drive controller card. Onboard Serial Port 1 This item sets the I/O address and interrupt request line (IRQ) for the on-board serial port (COM1).

  • Page 29: Power Management Setup

    Power Management Setup The “Power Management Setup” category allows you to configure you system to save energy. The followings describe in sequence all the items of this category. ACPI Function This item enables or disables ACPI (Advanced Configuration Power Interface) - a power management standard used by Windows 98 and Windows NT 5.0.
  • Page 30 Soft-Off by PWR-BTTN This item defines the Power/Suspend Button of the system.

  • Page 31: Pnp/Pci Configurations

    Power On by Ring If an external modem is connected to the system, this feature allows an incoming call to power up the system in soft-off mode. Resume by Alarm This feature allows a network activity to power up the system in soft-off mode. ** Reload Global Timer Events ** This group of items specify the I/O event that will reset the timer for entering a low power mode.

  • Page 32: Load Fail-Safe / Optimized Defaults

    Load Fail-Safe / Optimized Defaults If you select “Load Fail-Safe Defaults” or “Load Optimized Defaults” from the main menu, some default values will be loaded to the option setup menus such as Advanced BIOS Features, Advanced Chipset Features, Integrated Peripherals, Power Management Setup, and PnP/PCI Configuration menus. The “Fail-Safe”...

  • Page 33: Exiting Setup

    NOTE: If you forget your password and wish to cancel it, ask your dealer to reset the CMOS RAM for you. Exiting Setup To exit the SETUP program, you can choose “Save & Exit Setup” or “Exit Without Saving” from the main menu. After finished with your settings, you must save and exit SETUP so that the settings can take effect.

  • Page 34: Appendix A Software Drivers And Utilities

    Windows 95/98/2000, follow these steps: 1. Insert the driver and utility CD into the CD-ROM drive. 2. Run the SETUP.EXE program in the \6513wu\Audio\Ess1989\Win9598 or \6513wu\Audio\Ess1989\Win2000 directory on the driver and utility CD. 3. Follow the on-screen instructions.

  • Page 35: Video Driver

    1. In Windows NT, select “Control Panel”, “Display”, and then “Settings”. 2. Select “Display Type” and then “Change”. 3. Select “Hard Disk”. 4. Insert the CD into the CD-ROM drive. 5. Specify the path \6513wu\Vga\Nt4 on the CD, and click on “OK”. 6. Follow the on-screen instructions.
