- Page 1 SPLIT TYPE WALL MOUNTED ON/OFF AIR CONDITIONER USER MANUAL AND INSTALLATION MANUAL MODELS: SC009 SC012 SC018 SC022...
-
Page 3: Before Using The Appliance
BEFORE USING THE APPLIANCE To make the most out of your new appliance, please read the user instructions carefully and keep them handy for future consultation. SAFETY PRECAUTIONS • The Installation and service/repair must be • Never block the air inlet or outlet of indoor and performed by a qualified technician, in outdoor unit. -
Page 4: Safeguarding The Environment
SAFEGUARDING THE ENVIRONMENT • This appliance has been made of recyclable or SCRAPPING OF APPLIANCE • By ensuring that this product is disposed of re-usable material. Scrapping must be carried correctly, you will help to prevent potentially out in compliance with local waste disposal negative consequences for the environment and regulations. -
Page 5: Product Description
PRODUCT DESCRIPTION Indoor unit Outdoor unit 1. Air Intake 11. Air Intake 2. Front Panel 12. Pipes and Power Connection Cord 3. Display panel Drain Hose (Note: Condensate water drains at 4. Air Outlet Cooling or DRY operation.) 14. Air Outlet 5. - Page 6 CONTROL PANEL DISPLAY INDICATORS DESCRIPTION Temperature indicator (1) Displays set and room temperature. Running indicator (2) It lights up in red when connecting to power supply. It lights up in white or green during operation. Heating indicator (3) It lights up during heating mode.(For heating model only.) Cooling indicator (4) It lights up during cooling mode.
- Page 7 REMOTE CONTROL FUNCTIONS AND INDICATORS 1. ON/OFF BUTTON Starts and/or Stops the appliance by pressing this button. 2-3. TEMPERATURE SETTING BUTTONS Used to set temperature. Used to set time for clock. Used to set time in timer mode. 4. MODE BUTTON Used to select the operation mode.
- Page 8 INDICATOR SYMBOLS ON RC DISPLAY Cooling indicator indicator Dehumidifying indicator Sleep indicator Fan only indicator Around U indicator Heating indicator(For heating model only.) Jet indicator Auto fan speed Signal transmission High fan speed Display set timer Display current time Medium fan speed °F Temperature display Low fan speed...
-
Page 9: Remote Control
STORAGE AND TIPS FOR USING THE REMOTE CONTROL How to insert the batteries 1. Unscrew the screw on the battery cover. Gently press down on the battery cover and push in the direction of the arrow to remove, as shown. 2. -
Page 10: Operating Mode Description
OPERATING MODE DESCRIPTION General Operation: 1. Turning on Press button, when the appliance receives the signal, the RUNNING indicator on indoor unit dispaly lights up. During mode changes wait a few seconds and repeat the operation if the appliance does not respond at once. 2. -
Page 11: Airflow Direction Control
AIRFLOW DIRECTION CONTROL 5. Airflow direction control Horizontal airflow is automatically adjusted to a certain angle in accordance with the operation mode after turning on the appliance. The direction of airflow can be also adjusted to your own requirement by pressing the Swing button of the remote control. - Page 12 MODE AND FUNCTION DESCRIPTIONS 6th SENSE MODE Press the button, will display, the appliance enters 6th sense mode directly. In this mode, temperature and fan speed will be automatically set based on the actual room temperature. Indoor Operation mode temperature 22°C or below FAN or keep previous mode 22°C-26°C...
- Page 13 JET mode •JET mode is used to start or stop fast cooling. will display on remote control under this mode. The appliance will blow at super high fan speed to cool or heat your room quickly and effectively. • In JET mode, you can set temperature and airflow direction Note: •...
- Page 14 AUTO CLEAN function • Pressing this button in COOL or DRY mode, the icon is displayed and the AUTO CLEAN function is set. After turning off the appliance, the indoor fan will keep running for 10 minutes to eliminate moisture in indoor unit. In this period, you can press this button to stop indoor fan directly.
- Page 15 TIMER function It is convenient to set the timer on by pressing the TIMER ON button to achieve a comfortable room temperature at the time you get home. You can also set timer off automatically to enjoy a good sleep at night by pressing TIMER OFF button. How to set TIMER ON TIMER ON button can be used to set the timer programming as wished in order to switch on the...
- Page 16 CHILD LOCK function EMERGENCY OPERATION Press buttons simultaneously to lock or Under emergency situation or when remote unlock the buttons of remote control. control is missing, you can control the unit by pressing the on/off swith located on the indoor If the remote control is locked, icon will be unit.
-
Page 17: Maintenance
MAINTENANCE Clean front panel of Indoor Unit 1. Disconnect from the power supply Turn off the appliance first before disconnecting from power supply. 2. Open the front panel Open the front panel as shown by the arrow (Fig. A). 3. Clean the front panel Wipe it with a soft and dry cloth. -
Page 18: Troubleshooting
Authorized Service Center, and tell customer service about the indicated error code. Note: If the problems still have, turn off the appliance and disconnect from power supply, then contact the nearest Whirlpool Authorized Service Center. Do not attempt to move, repair, disassemble, or modify the appliance by yourself. -
Page 19: Installation Service
Required Capacity of air Type Model break switch SC009 Split On/off SC012 SC018 SC022 4. Make sure that the power supply cord is long enough to allow the right connection. Do not use any extension cord for power supply. -
Page 20: Installation Instructions
INSTALLATION INSTRUCTIONS Installation diagram Distance from ceiling should be over 150mm Distance from wall should be over 150mm Distance from the wall Indoor unit should be over 150mm Distance from floor should be over 2500mm Outdoor unit Air intake distance from the wall should be over Air intake distance from 300mm... - Page 21 Length (m) the connecting tube over 5m (g/m) 3~15 SC009/SC012/SC018/ SC022 Note: If addition of refrigerant has to be charged, type R410a to be used ONLY. Otherwise, air conditioner with any malfunction occurs, it will be out of warranty scope.
-
Page 22: Indoor Unit Installation
INDOOR UNIT INSTALLATION 1. Installing the Mounting Plate • Select a location to install the mounting plate Mark on the middle Gradienter according to the indoor unit location and piping direction. • Adjust the mounting plate horizontally with a gradienter or plumb line. •... - Page 23 IMPORTANT: Piping Joints Thermal Insulation: Wrap the piping joints with thermal insulating materials and then wrap with a vinyl tape. Wrapped with vinyl type Thermal insulation Thermal Insulation piping: a. Place the drain hose under the piping. b. Insulation material: polythene foam over 6mm in Large pipe Thermally thickness.
- Page 24 4. Connecting the Cable • Indoor Unit 1) Open the front panel, remove the covering plate by loosening the screw. Covering plate 2) Connect the power connecting cord to the indoor unit by connecting the wires to the terminals on the connecting board individually as follows.
-
Page 25: Outdoor Unit Installation
Power cord Power connecting cable (Btu/h) supply (Note) H05VV-F, 3G 1.0 mm² H05RN-F, 3G 1.0 mm² To indoor SC009 Split On/off H05VV-F, 3G 1.0 mm² H05RN-F, 3G 1.0 mm² To indoor SC012 H05VV-F, 3G 1.5 mm² H07RN-F, 3G 1.5 mm²... -
Page 26: Air Purging
AIR PURGING Air containing moisture remaining in the refrigeration cycle may cause a malfunction on the compressor. After connecting the indoor and outdoor units, evacuate air and moisture from refrigerant cycle using a vacuum pump, as shown below. Note: Because the system pressure is high and also to protect the environment, be sure not to discharge the refrigerant to the air directly. -
Page 27: After Sales Service
AFTER SALES SERVICE Before contacting the Customer Care Centre: If repair work has to be carried out, contact the Customer Care Centre (Use of original spare 1. Try to solve the problem yourself based on the parts and a proper repair is guarenteed). descriptions given in the "Troubleshooting".
