OWNER'S MANUAL
POWER-VENT
HIGH-EFFICIENCY FIREPLACE
BAY WINDOW MANTIS MODELS
BF28(B,C,G)M(K)(N,P)-5
BP28(B,C,G)M(K)(N,P)-5
BI28(B,C,G)M(N,P)-5
FIREPLACE MANTIS MODELS
FF28BM(K)(N,P)-3
FW28BM(K)(N,P)-3
FI28BM(N,P)-3
Young children should be carefully supervised when
they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to
accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the
house. To restrict access to a fireplace or stove,
install an adjustable safety gate to keep toddlers,
young children and other at risk individuals out of
the room and away from hot surfaces.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by state or local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mantis BF28 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Empire Comfort Systems Mantis BF28 Series

  • Page 1 ™ EMPIRE EMPIRE OWNER’S MANUAL Comfort Systems WARNING HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. POWER-VENT HIGH-EFFICIENCY FIREPLACE BAY WINDOW MANTIS MODELS BF28(B,C,G)M(K)(N,P)-5 BP28(B,C,G)M(K)(N,P)-5 BI28(B,C,G)M(N,P)-5 WARNING: If not installed, operated and maintained in accordance with the manufacturer’s instructions, this product could expose you to substances in fuel FIREPLACE MANTIS MODELS or from fuel combustion which can cause death or serious illness.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE IMPORTANT SAFETY INFORMATION ..................3 SAFETY INFORMATION FOR USERS OF LP-GAS ..............4 OPERATING ThE FIREPLAcE ..................... 5 hOw TO START ThE FIREPLAcE ....................6 hOw TO chANGE BURNERS – SwITchING BURNERS ............6 hOw TO TURN ThE FIREPLAcE OFF ..................7 hOw TO OPERATE EcONOMY MOdE ..................
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE Safety markings are frequently used in this manual to designate a degree or level of serious- ness and should not be ignored. WARNING indicates a potentially hazardous situation that if not avoided, could result in personal injury or death. CAUTION indicates a potentially hazardous situation that if not avoided, may result in mi- nor or moderate injury or property damage. WARNING WARNING This appliance must be installed and repaired by Installation and repair should be done by a QUALI- a qualified service person who is familiar with the FIED SERVICE PERSON. The appliance should proper installation and operation of the Mantis Pow- be inspected before use and at least annually by er-Vent High Efficiency Fireplace. Installers who are...
  • Page 4: Safety Information For Users Of Lp-Gas

    SAFETY INFORMATION FOR USERS OF LP-GAS LP-Gas (Propane) is a flammable gas which can cause fires members of your household. Someday, there may not be a and explosions. In its natural state, propane is odorless and minute to lose, everyone’s safety will depend on knowing ex- colorless.
  • Page 5: Operating The Fireplace

    Operating the Fireplace If electrical power is present, the Power light on the front con- trol panel will be illuminated. If the Power light is not illumi- nated, verify the fireplace is plugged in and the breaker and Before you start the main power switch are on.
  • Page 6: How To Start The Fireplace

    How to Start the Fireplace If operating both of the fireplace’s burners, after the first burn- er is lit, the second igniter will start to glow red, the burner light Turn burner switches to the “ON” position. Adjust the remote will turn off, and the burner will light. Once the burner is lit, the thermostat to the desired temperature or press “ON”...
  • Page 7: How To Turn The Fireplace Off

    How to Turn the Fireplace Off Remote Transmitter and Receiver To turn the fireplace off, simply switch the burner switch or switches The remote control transmitter operates on (2) 1.5V AAA batteries. to the “OFF” position, turn the remote off, or adjust the temperature It is recommended that ALKALINE batteries be used for maximum set point down.
  • Page 8: Remote Receiver

    Remote Receiver Replace the Remote Control Batteries The remote receiver operates on 4 AA-size 1.5V batteries. Slide open the battery compartment panel located on the back of It is recommended that ALKALINE batteries be used for maximum the remote control. battery life and performance. The remote receiver has a 3-position slide switch for selecting the MODE of operation: ON/REMOTE/OFF •...
  • Page 9: Remote Setup - Programming The Remote

    Remote Setup - Setting the Temperature Units Slide open the battery compartment panel located on the bottom of the remote receiver. To change the temperature units press the ON key and the OFF key on the remote at the same time. LEARN BUTTON Note: The factory setting for the temperature units is degrees Fahrenheit.
  • Page 10: Remote Operation - Thermostat Mode

    Remote Operation - Thermostat Mode Remote Function - Lock-Out To operate the remote in Thermostatic mode, press the MODE key This remote control includes a “LOCK-OUT” feature that allows until the LCD screen shows the word ROOM. you to “LOCK-OUT” operation of the fireplace, from the TRANS- MITTER.
  • Page 11: Humidifier Operation

    If the glass needs to be replaced, contact a qualified service per- son. Only glass approved by Empire Comfort Systems Inc. can be used, any other product will void the warranty. Then, release the four door latches, two on each side of the fire- To clean inside the glass door, the door will need to be removed.
  • Page 12: How To Remove The Glass Door - Fireplace Models

    Finally, hold the glass frame and carefully pull the glass door to- Second, release the two door latches on the underside of the fire- wards you. DO NOT damage or remove the gasket from the door. box. Next, hold the bottom of the glass door and lift, keeping a firm grip on the door.
  • Page 13: Service And Maintenance

    Service and Maintenance For Fireplace Models equipped with louverless FHK surrounds, the entire surround must be removed from the fireplace. This is Although most service should be conducted by a qualified service accomplished by lifting and removing the surround from the sup- person, there are several things that can be checked to ensure port bracket hooks.
  • Page 14: Warranty

    WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and oper- ated safely, in accordance with the instructions in the owner’s manual.
  • Page 15: Appliance Maintenance History

    APPLIANCE MAINTENANCE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 30067-0-0512 Page 15...
  • Page 16 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com...
