Mantis series power-vent high-efficiency fireplace
Table of Contents

Advertisement

Available languages

Available languages

EMPIRE
EMPIRE
Comfort Systems
WARNING
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
WARNING: If the information in these instructions
are n ot f ollowed e xactly, a fi re o r e xplosion m ay r esult
causing property damage, personal injury or loss
of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
HOT GLASS
WILL
CAUSE BURNS.
DO NOT TOUCH
GLASS
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
OWNER'S MANUAL
POWER-VENT
HIGH-EFFICIENCY FIREPLACE
BAY WINDOW MANTIS MODELS
BF28(B,C,G)M(K)(N,P)-5
BP28(B,C,G)M(K)(N,P)-5
BI28(B,C,G)M(N,P)-5
FIREPLACE MANTIS MODELS
FF28BM(K)(N,P)-3
FW28BM(K)(N,P)-3
FI28BM(N,P)-3
Young children should be carefully supervised when
they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to
accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the
house. To restrict access to a fireplace or stove,
install an adjustable safety gate to keep toddlers,
young children and other at risk individuals out of
the room and away from hot surfaces.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by state or local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
Page 1

Advertisement

Table of Contents
loading

Summary of Contents for Empire Comfort Systems Mantis

  • Page 1 CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. POWER-VENT HIGH-EFFICIENCY FIREPLACE BAY WINDOW MANTIS MODELS BF28(B,C,G)M(K)(N,P)-5 BP28(B,C,G)M(K)(N,P)-5 BI28(B,C,G)M(N,P)-5 WARNING: If not installed, operated and maintained in accordance with the manufacturer’s instructions, this product could expose you to substances in fuel FIREPLACE MANTIS MODELS or from fuel combustion which can cause death or serious illness.
  • Page 2: Important Safety Information

    More frequent clean- not familiar with the installation of the Mantis and ing may be required due to excessive lint from have questions, should contact Empire Comfort Sys- carpeting, bedding materials, etc. It is impera- tems, Inc. prior to installing the appliance to avoid...
  • Page 3: Safety Information For Users Of Lp-Gas

    SAFETY INFORMATION FOR USERS OF LP-GAS LP-Gas (Propane) is a flammable gas which can cause fires members of your household. Someday, there may not be a and explosions. In its natural state, propane is odorless and minute to lose, everyone’s safety will depend on knowing ex- colorless.
  • Page 4: Operating The Heater

    Operating the Heater How to Start the Heater – Both Burners Operating Before you start 1. Turn both Front and Rear burner switches to the “ON” position and adjust the remote thermostat to the de- sired temperature or press “ON” on the remote. Both 1. Verify there is electrical power to the unit.
  • Page 5: How To Change Burners - Switching Burners

    The blower speed will be indicated on front control panel. Humidifier Operation The Mantis Power-Vent High-Efficiency Fireplace has an auto- matic humidifier designed into the heater. As the heater operates, condensate is created and collected inside the heater. The con- densate is then transferred to a pan where it evaporates into the air stream.
  • Page 6: How To Operate Economy Mode

    If the glass needs to be replaced, contact a qualified service person. Only glass approved by Empire Comfort Systems Inc. can be used, any other product will void the warranty. To clean inside the glass door, the door will need to be re- moved.
  • Page 7 Bay Window Mantis Models - Continued How to Clean the Glass Door - Fireplace Mantis Models Second, open the panels on the right and left sides. First, remove the lower louvered panel by lifting up, then pulling out. Next, release the two door latches on the left and the two door latches on the right side of the firebox.
  • Page 8 Fireplace Mantis Models Continued How to Replace the Remote Control Batteries Next, hold the bottom of the glass door and lift, keeping a Slide open the battery compartment panel located on the firm grip on the door. back of the remote control. BATTERY COMPARTMENT How to Replace the Remote Receiver Batter- 1.
  • Page 9: Service And Maintenance

    Service and Maintenance Although most service should be conducted by a qualified service person, there are several things that can be checked to ensure safe and comfortable operation. The area surrounding the heater should be free from any types of combustible materials, and the filter should be checked and cleaned on a monthly basis.
  • Page 10: Appliance Service History

    APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 10 29007-0-0911...
  • Page 11 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 29007-0-0911 Page 11...
  • Page 12 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com...
  • Page 13: Manuel D'utilisation

    ™ EMPIRE EMPIRE MANUEL D’UTILISATION Comfort Systems AVERTISSEMENT LA VITRE CHAUDE PEUT CAUSER DES BRÛLURES. NE TOUCHEZ PAS À LA VITRE JUSQU’À CE QU’ELLE SOIT REFROIDIE. NE PERMETTEZ JAMAIS AUX ENFANTS DE TOUCHER LA VITRE. VENTILATION MÉCANIQUE FOYER À HAUTE EFFICACITÉ MODÈLES DE FENÊTRE EN BAIE BF28(B,C,G)M(K)(N,P)-4 BP28(B,C,G)M(K)(N,P)-4 AVERTISSEMENT : Si l’installation, l’usage et l’entretien de ce...
  • Page 14: Renseignements Importants Sur La Sécurité

    TECHNICIEN QUALIFIÉ. L’appareil devrait être inspecté avant fonctionnement du foyer de ventilation mécanique à haute l’utilisation et au moins une fois par an par un technicien efficacité Mantis. Les installateurs qui ne sont pas familiers qualifié. Un nettoyage plus fréquent peut être nécessaire en avec l’installation de Mantis et qui ont des questions, doivent raison des peluches provenant des tapis, matériaux de litière, communiquer avec Empire Comfort Systems, Inc. avant...
  • Page 15 RENSEIGNEMENTS SUR LA SÉCURITÉ POUR LES UTILISATEURS DE GAZ DE PÉTROLE LIQUÉFIÉS (GPL) Le propane est un gaz inflammable qui peut causer des incendies les membres de votre famille. Un jour, il n’y aura pas une minute à et des explosions. Dans son état naturel, le propane est inodore et perdre, la sécurité...
  • Page 16: Avant De Commencer

    Fonctionnement du radiateur Comment mettre en marche le radiateur - les deux brûleurs en marche Avant de commencer Mettez les deux interrupteurs de brûleur, avant et arrière, en position ON et réglez la télécommande à thermostat sur 1. Vérifiez que l’appareil est alimenté. la température souhaitée ou mettez la télécommande sur Si la puissance électrique est présente, le voyant d’alimentation ON.
  • Page 17: Fonctionnement De L'humidificateur

    La vitesse de la soufflante sera indiquée sur le panneau de commande avant. Fonctionnement de l’humidificateur Le foyer de ventilation mécanique à haute efficacité Mantis comprend un humidificateur automatique intégré dans le radiateur. Pendant que le radiateur fonctionne, le condensat est créé...
  • Page 18 Si la vitre doit être remplacée, contactez un technicien qualifié. Seule la vitre approuvée par l’Empire Comfort Systems Inc. peut INTERRUPTEUR être utilisée, tout autre produit annule la garantie.
  • Page 19 Modèles de fenêtre en baie - suite Comment nettoyer la porte vitrée - modèles de devanture plate Deuxièmement, ouvrez les panneaux des côtés à la droite et à la gauche. Premièrement, enlevez le panneau d’aérage en le soulevant, ensuite soulevez-le. Ensuite, relâchez les deux loquets de chaque côté de la porte de la chambre de combustion. Tenez soigneusement le châssis du verre et tirez la porte vitrée vers vous.
  • Page 20 Modèles de devanture plate - suite Ensuite, tenez le bas de la porte vitrée et soulevez-le, en gardant une prise ferme sur la porte. COMPARTIMENT DES PILES Comment changer les piles du récepteur de télécommande 1. Déposez le panneau à persiennes inférieur du radia- teur. 2.
  • Page 21 Service et maintenance Bien que la plupart des services devraient être effectués par un technicien qualifié, il y a plusieurs choses qui peuvent être vérifiées pour assurer un fonctionnement sûr et confortable. Les alentours du radiateur doivent être exempts de tous types de matériaux combustibles, et le filtre doit être vérifié...
  • Page 22: Maintenance Historique De L'appareil

    MAINTENANCE HISTORIQUE DE L’APPAREIL Date Nom du distributeur Nom du technicien de service Entretien effectué/notes Page 10 29007-0-0911...
  • Page 23 MAINTENANCE HISTORIQUE DE L’APPAREIL Date Nom du distributeur Nom du technicien de service Entretien effectué/notes 29007-0-0911 Page 11...
  • Page 24 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 Si vous avez une question générale sur nos produits, veuillez nous faire parvenir un courriel à info@empirecomfort.com. Si vous avez une question sur l’entretien ou sur la réparation, veuillez communiquer Comfort Systems avec le marchand.
