USE, CARE, AND INSTALLATION GUIDE
Read all Instructions before Installing and operating this appliance
MODEL: EURO KITCHEN 198 Series Island -Mounted
IMPORTANT SAFETY NOTICE
WARNING
Installation
The installation in this manual is intended for qualified installers, service technicians or persons
with similar qualified background. DO NOT attempt to install this appliance yourself. Injury could
result from installing the unit due to lack of appropriate electrical and technical background.
All electrical wiring must be properly installed, insulated and grounded. Overly accumulated
grease in old duct work should be cleaned out or duct work should be replaced if necessary to
avoid the possibility of a grease fire. Check all joints on duct work to insure proper connection
and all joints should be properly taped.
Operations
Read all instructions in this manual before operating the appliance. Save these instructions for
future reference.
Always leave safety grills and filters in place. Without these components, operating blowers
could catch on to hair, fingers and loose clothing.
NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch
fire. The risk of self combustion is higher when the oil has been used several times.
Cleaning
The saturation of greasy residue in the blower and filters may cause increased inflammability.
Keep unit clean and free of grease and residue build-up at all times to prevent possible fires.
Filters must be cleaned periodically and free from accumulation of cooking residue (see
cleaning instructions inside). Old and worn filters must be replaced immediately. Do not operate
blowers when filters are removed. Never disassemble parts to clean without proper instructions.
Disassembly is recommended to be performed by qualified personnel only. Call our service
center for removal instructions.
Euro-Kitchen, Inc. declines all responsibility in the event of failure to observe the
instructions given here for installation, maintenance and suitable use of the product.
Euro-Kitchen, Inc. further declines all responsibility for injury due to negligence and the
warranty of the unit automatically expires due to improper maintenance.
Advertisement
Table of Contents
Related Manuals for Euro Kitchen Appliances 198 series
Summary of Contents for Euro Kitchen Appliances 198 series
- Page 1 USE, CARE, AND INSTALLATION GUIDE Read all Instructions before Installing and operating this appliance MODEL: EURO KITCHEN 198 Series Island -Mounted IMPORTANT SAFETY NOTICE WARNING Installation The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background.
-
Page 2: Table Of Contents
CONTENTS INSTALLATION Mount heights & clearance ------------------------------------ 1 Ducting ------------------------------------------------------------ 1,2 Mounting the hood ---------------------------------------------- 3,4 Duct cover -------------------------------------------------------- 4 MAINTENANCE Cleaning ----------------------------------------------------------- 5 Lights replacement --------------------------------------------- 5 WARRANTY Coverage & exceptions --------------------------------------- 6... -
Page 3: Installation
INSTALLATION MOUNT HEIGHTS & CLEARANCE Minimum mount height between range top to hood bottom should be no less than 24.5". Maximum mount height should be no higher than 27.5" It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fire hazard;... -
Page 4: Ducting
INSTALLATION DUCTING WARNING: FIRE NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use Metal ductwork only. Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct Tape. Some Ducting Options:... -
Page 5: Mounting The Hood
INSTALLATION INSTALLATION Add Blockings Fasten Upper Chimney Cover. Fasten Support Frame Mounting the Range Hood 1. Add and secure blockings (minimum 2x4 studs) onto ceiling joist. 2. Fasten mounting telescopic support frame directly onto ceiling joist or stud blockings. 3. Adjust height requirement and fasten Install Chimney Cover support frame. - Page 6 INSTALLATION INSTALLATION Mounting Hood onto Support Frame...
-
Page 7: Maintenance
MAINTENANCE CLEANING Surface Maintenance: Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent (e.g. comet powder scrub, EZ-Off oven cleaner), or steel wool/scoring pads which will scratch and damage surface. For heavier soil use liquid degreaser such as 'Formula 409' or 'Fantastic' brand cleaner. After cleaning, you may use non abrasive stainless steel polish/ cleaners such as 3M or ZEP, to polish and buff out the stainless luster and grain. - Page 8 WARRANTY TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please keep a copy of your dated proof of purchase (sales slip) in order to obtain service under warranty. One Year Service Repair Warranty: For one year from date of original purchase, we will provide free of charge, service labor to repair any failed parts or components due to manufacturing defects.
- Page 9 Should you have any questions regarding warranty issue, please feel free to contact us at: EURO-KITCHEN AUTHORIZED DEALER Carlson's Appliance 700 Colorado Ave Santa Monica, CA 90401 Toll Free: 800-601-8799 info@carlsonsappliance.com http://www.carlsonsappliance.com...
