  • Page 1: Owners Manual

    VOLVO C30 Owners Manual Web Edition...
  • Page 3 DEAR VOLVO OWNER THANK YOU FOR CHOOSING VOLVO We hope you will enjoy many years of driving pleasure in your Volvo. In order to increase your enjoyment of the car, we recommend that The car has been designed for the safety and comfort of you and your you familiarise yourself with the equipment, instructions and mainte- passengers.

  • Page 4: Table Of Contents

    01 Safety 02 Instruments and controls Important information....... 10 Seatbelts........... 18 Overview, left-hand drive cars....42 Volvo and the environment....... 13 Airbag system........... 21 Overview, right-hand drive cars....44 Airbags............22 Driver's door control panel....... 46 Activating/deactivating the airbag*... 24 Combined instrument panel......
  • Page 5 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..86 Front seats ..........102 Remote control key with key blade..122 Manual climate control, AC....... 88 Interior lighting........107 Active locks..........125 Electronic climate control, ECC*....
  • Page 6 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 138 General............ 186 Cleaning..........202 Refuelling..........140 Tyre pressure.......... 190 Touching up paintwork ......206 Alcoguard * ........... 144 Warning triangle* and spare wheel * ..192 Rustproofing...........
  • Page 7 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 210 General............ 238 Type designation........272 Self-maintenance........211 Audio functions........240 Dimensions and weights......274 Bonnet and engine compartment... 212 Radio functions........244 Engine specifications......277 Oils and fluids.........
  • Page 8 Table of contents 12 Alphabetical Index Alphabetical Index........288...
  • Page 9 Table of contents...

  • Page 10: Introduction

    Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of the ard or an option/accessory, contact a Volvo text being slightly larger and printed in grey. Introduction dealer.
  • Page 11 Introduction Important information warning is ignored, may result in serious per- Information Procedure lists sonal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the owner's Risk of property damage manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration.
  • Page 12 We page. therefore recommend that you always contact an authorised Volvo workshop before installing accessories which are connected to or affect Recording data the electrical system.

  • Page 13: Volvo And The Environment

    Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- Fuel consumption many cases the exhaust emissions are well ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
  • Page 14 • Always dispose of environmentally hazar- The interior of a Volvo is designed to be plea- and by servicing and maintaining the car dous waste, such as batteries and oils, in sant and comfortable, even for people with according to the instructions in the owner's an environmentally safe manner.
  • Page 15 Introduction Volvo and the environment ronmentally sound manner. Almost all of the car can be recycled. The last owner of the car is therefore requested to contact a dealer for referral to a certified/approved recycling facility. The owner's manual and the...
  • Page 16 Seatbelts....................18 Airbag system..................21 Airbags....................22 Activating/deactivating the airbag*............24 Side airbags (SIPS bags)................ 26 Inflatable Curtain (IC)................28 WHIPS..................... 29 When the systems deploy............... 31 Crash mode.................... 32 Child safety..................... 33 Option/accessory, for more information, see Introduction.
  • Page 17 S A F E T Y...

  • Page 18: 01 Safety

    WARNING The seatbelt locks and cannot be with- drawn: Never modify or repair the seatbelt yourself. Volvo recommends that you contact an • if it is pulled out too quickly authorised Volvo workshop. If the seatbelt •...
  • Page 19 01 Safety Seatbelts Seatbelts and pregnancy such that they can easily maintain control of the Child seats are not covered by the seatbelt vehicle as they drive (which means that they reminder system. must be able to easily operate the foot pedals Rear seat and steering wheel).
  • Page 20 01 Safety Seatbelts Seatbelt tensioner Seatbelt guide All the seatbelts are equipped with seatbelt tensioners. A mechanism in the seatbelt ten- sioner tightens the seatbelt in the event of a sufficiently violent collision. The seatbelt then provides more effective restraint for occu- pants.

  • Page 21: Airbag System

    The symbol indi- cates a fault in the seatbelt tensioner sys- The warning symbol in the combined instru- tem, SIPS, SRS or the IC system. Volvo rec- ment panel illuminates when the remote con- ommends that you contact an authorised trol key is turned to key position I, II or III.

  • Page 22: Airbags

    01 Safety Airbags Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could not the seatbelts on the driver's side and cause malfunction and result in serious per- passenger side are used.
  • Page 23 01 Safety Airbags Airbag on the driver's side WARNING The car has an airbag to supplement the pro- Never place a child in a child seat or on a tection afforded by the seatbelt on the driver's booster cushion in the front seat if the airbag side.

  • Page 24: Activating/Deactivating The Airbag

    Check that the switch is in the required posi- Switch location recommends that you visit an authorised tion. Volvo recommends that the key blade is Volvo workshop as soon as possible The airbag is activated. With the switch in used to change position.
  • Page 25 01 Safety Activating/deactivating the airbag* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag for the front passenger Activated airbag (passenger seat): When the remote control key is turned to seat is deactivated (see preceding illustration). key position II or III the warning symbol for Never place a child in a child seat or on a the airbag is displayed on the combined...

  • Page 26: Side Airbags (Sips Bags)

    • Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
  • Page 27 01 Safety Side airbags (SIPS bags) Front passenger seat, left-hand drive. The SIPS bag system consists of side airbags and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated. The airbag inflates between the occupant and the door panel and thereby cushions the initial impact.

  • Page 28: Inflatable Curtain (Ic)

    This could compromise the intended pro- on the inside of the car during a collision. WARNING tection. Volvo recommends that you only ever use Volvo genuine parts that are The inflatable curtain is a supplement to the approved for placement in these areas. seatbelts.

  • Page 29: Whips

    Never modify or repair the seat or WHIPS the seat with as little space as possible system yourself. Volvo recommends that The WHIPS system is a supplement to the between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
  • Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.

  • Page 31: When The Systems Deploy

    Do not • Always contact a doctor. attempt to start the car since the airbags may deploy. Recovering the car. Volvo rec- ommends that you have it conveyed to an authorised Volvo workshop.

  • Page 32: Crash Mode

    If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE is shown after CRASH conveyed to an authorised Volvo workshop.

  • Page 33: Child Safety

    In the event of questions when fitting child beams under the seat. Sharp edges can dam- Volvo recommends that children travel in rear- safety products, contact the manufacturer age the straps. facing child seats until as late an age as pos- for clearer instructions.
  • Page 34 01 Safety Child safety Label Airbag WARNING WARNING Never place a child in a child seat or on a Booster cushions/child seats with steel booster cushion in the front seat if the airbag braces or some other design that could rest on the seatbelt buckle's opening button is activated must not be used, as they could cause the...
  • Page 35 Weight Rear seat Front seat Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the ISOFIX fixture system. secured with the ISOFIX fixture system. max. 10 kg...
  • Page 36 Rear seat Front seat Group 1 Volvo rear-facing/turnable child seat (Volvo Convertible Child Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's seatbelt Seat) - rear-facing child seat, secured with the car's seatbelt 9 –...

  • Page 37: Child Safety

    Type approval: E5 03139 For information on activated/deactivated airbag, see page 24. To install a rear-facing child seat in the rear seat, Volvo recommends that you contact an authorised Volvo dealer to have the mounting points installed. ISOFIX fixture system for child seats*...
  • Page 38 The upper mounting points are primarily intended for use with front-facing child seats. Volvo recommends that small children should sit in rear-facing child seats to as late an age as possible.
  • Page 39 01 Safety...
  • Page 40 Overview, left-hand drive cars..............42 Overview, right-hand drive cars.............. 44 Driver's door control panel..............46 Combined instrument panel..............47 Indicator and warning symbols............... 48 Information display.................. 52 Electrical socket..................54 Lighting panel..................55 Left-hand stalk switch................58 Right-hand stalk switch ................. 61 Cruise control*..................
  • Page 41 I N S T R U M E N T S A N D C O N T R O L S...

  • Page 42: 02 Instruments And Controls

    02 Instruments and controls Overview, left-hand drive cars...
  • Page 43 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Reading lamp, right-hand side Bonnet release Seatbelt reminder and passenger seat air- bag indicator Control panel Interior rearview mirror Direction indicators, main beam, trip com- Display for climate control and infotain- puter ment system Lighting, fuel filler flap opener...

  • Page 44: Overview, Right-Hand Drive Cars

    02 Instruments and controls Overview, right-hand drive cars...
  • Page 45 02 Instruments and controls Overview, right-hand drive cars Electrical socket, cigarette lighter Reading lamp, right-hand side Blind Spot Information System, BLIS No function Switch, optional equipment No function Parking brake Sunroof controls Control panel Ignition switch Glovebox Windscreen wipers and washers, head- lamp washers Door handle Cruise control...

  • Page 46: Driver's Door Control Panel

    02 Instruments and controls Driver's door control panel Driver's door control panel Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side...

  • Page 47: Combined Instrument Panel

    02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Button for trip meter – Used to measure thousands of revolutions per minute (rpm). short distances. Short presses on the but- Direction indicators, left. ton switches between the two trip meters Indicator and warning symbols.

  • Page 48: Indicator And Warning Symbols

    02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
  • Page 49 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system STC or DSTC tance from an authorised Volvo workshop. No function...
  • Page 50 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
  • Page 51 02 Instruments and controls Indicator and warning symbols ± Stop the car in a safe place and check the have the brake system checked. Volvo rec- High speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car is moving faster than page 217.

  • Page 52: Information Display

    Specification Message Specification STOP SAFELY Stop the car in a safe TIME FOR REGU- Time for regular manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
  • Page 53 157. run the engine at information on idling speed until the If shown repeatedly checking the oil message clears. For then Volvo recom- level, see page 214. more information, mends that an see page 157. authorised Volvo SOOT FILTER...

  • Page 54: 12 V Electrical Socket

    02 Instruments and controls Electrical socket 12 V electrical socket WARNING NOTE Always leave the plug in the socket when Cigarette lighter does not work in this the socket is not in use. socket. It is designed for 12 V. For the socket to supply Cigarette lighter* current, the remote control key must be in at Activate the lighter by pushing in the button.

  • Page 55: Lighting Panel

    Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
  • Page 56 02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 130. Regulations for use of fog lamps vary from Instrument lighting country to country.
  • Page 57 02 Instruments and controls Lighting panel event of a malfunction. The function is only active in twilight or darkness and only when the car is moving. The function can be deactivated/activated with the headlamp control. Headlamp pattern with function deactivated (left) and activated (right) respectively.

  • Page 58: Left-Hand Stalk Switch

    02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see ± Move the stalk switch up or down to page 55, for main beam to be switched on.
  • Page 59 02 Instruments and controls Left-hand stalk switch Trip computer* car is stationary, " --.- " appears on the display. NOTE During the period for regeneration fuel con- If a warning message interrupts while you sumption may increase, see page 142. are using the trip computer, this message AVERAGE must be acknowledged.
  • Page 60 02 Instruments and controls Left-hand stalk switch MPH ACTUAL SPEED. Current speed is displayed in mph. Resetting 1. Select --- KM/H AVERAGE SPEED --.- L/100 KM AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.

  • Page 61: Right-Hand Stalk Switch

    02 Instruments and controls Right-hand stalk switch Windscreen wipers Single sweep Windscreen/headlamp washer Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
  • Page 62 If the rear window wiper is already on at normal speed, no change is made. The function for intermittent wiping for reverse can be deactivated. Volvo recommends that Move the stalk switch forward to start rear win- The rain sensor automatically activates the you contact an authorised Volvo workshop.
  • Page 63 02 Instruments and controls Right-hand stalk switch Activating the rain sensor: selected, or the sensitivity to rain when the rain sensor is selected. ± Press the button (B), see page 61. A display symbol shows that the rain sensor is active.

  • Page 64: Cruise Control

    02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
  • Page 65 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the previously set speed. CRUISE appears on the combined instrument panel. Disengaging ± Press CRUISE to disengage the cruise control. CRUISE ON clears on the com- bined instrument panel.

  • Page 66: Keypad In The Steering Wheel

    02 Instruments and controls Keypad in the steering wheel* Button functions in order to enable control of the phone system with the arrow keys. To return to Audio only, press EXIT. With the ENTER button you can select, acti- vate and deactivate options in menus. The but- ton can also be used to access the folder struc- ture and start the playback of audio files if a disc with audio files is inserted in the CD player/...

  • Page 67: Steering Wheel Adjustment, Hazard Warning Flashers

    02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.

  • Page 68: Parking Brake

    02 Instruments and controls Parking brake Parking brake (handbrake) How to apply the parking brake 1. Fully depress the foot brake pedal. 2. Pull the lever firmly. 3. Release the foot brake pedal and make sure that the car is at a standstill position. 4.

  • Page 69: Power Windows

    02 Instruments and controls Power windows Operation Driver's door obstructed by an object, the movement will stop. The power windows are operated using the controls in the doors. The ignition key must be WARNING in position I or II for the power windows to operate.
  • Page 70 02 Instruments and controls Power windows Passenger seat Passenger seat. The control in the front passenger door oper- ates that window only.

  • Page 71: Windows, Rearview And Door Mirrors

    02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with compass* Calibrating the compass The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The upper right-hand corner of the rearview The compass is set for the geographical area the rearview mirror and dazzle the driver.
  • Page 72 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the 1– number for the required magnetic zone ( ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display returns to showing the character 6.
  • Page 73 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* NOTE The mirrors can be retracted for parking/driving The door mirrors will not be extended auto- in narrow spaces. This can be carried out in matically during unlocking if they were ignition position I and II.
  • Page 74 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot", see page 165.

  • Page 75: Power Sunroof

    02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING Open: If there are children in the car: ± Press the rear edge of the control (5) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
  • Page 76 02 Instruments and controls Power sunroof* closed position as long as the button is If you need to interrupt closing: Wind deflector kept depressed. ± Press the lock button again. WARNING WARNING The sunroof's pinch-protection function Make sure that children or other passengers only operates during automatic closing, not are not in danger of becoming trapped in manual closing.

  • Page 77: Personal Preferences

    02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
  • Page 78 02 Instruments and controls Personal preferences ± Select On/Off depending on whether or not Lock confirm. light door handle button on cars with the keyless you wish the recirculation timer to be system: The hazard warning flashers can provide feed- active.
  • Page 79 02 Instruments and controls Personal preferences • 30 seconds • 60 seconds • 90 seconds Information • VIN number… - (Vehicle Identification Number) is the car's unique identity num- ber. • Number of keys… - The number of keys registered for the car is shown.

  • Page 80: Homelink

    02 Instruments and controls HomeLink * General The original remote controls can of course be NOTE used in parallel with HomeLink . HomeLink is designed to be inoperable if the car is locked from the outside. WARNING Save the original remote controls for future If HomeLink is used to operate a garage programming (e.g.
  • Page 81 02 Instruments and controls HomeLink * • 2. Position the original remote control Glow not constant: The indicator lamp Programming individual buttons flashes quickly for approx. 2 seconds 5-30 cm from HomeLink . Monitor the indi- To reprogram an individual button, proceed in and then changes over to a constant cator lamp.
  • Page 82 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
  • Page 83 02 Instruments and controls...
  • Page 84 General information on climate control........... 86 Manual climate control, AC..............88 Electronic climate control, ECC*............. 91 Air distribution..................94 Fuel-driven engine block heater and passenger compartment heater*............. 95 Fuel-driven auxiliary heater* (diesel)............98 Option/accessory, for more information, see Introduction.
  • Page 85 C L I M A T E C O N T R O L...

  • Page 86: 03 Climate Control

    Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.

  • Page 87: Climate Control

    03 Climate control General information on climate control Air vents in the dashboard ECC* Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the sun- The temperature you select corresponds to the roof (if fitted).

  • Page 88: Manual Climate Control, Ac

    03 Climate control Manual climate control, AC Control panel Functions 2. Recirculation Recirculation can be used to 1. Fan Recirculation shut out bad air, exhaust Increase or decrease the fan fumes, etc. from the passen- Defroster speed by turning the knob. ger compartment.
  • Page 89 03 Climate control Manual climate control, AC Timer 4. Air distribution 6. and 7. Heated front seats* The timer function reduces the risk of icing, The airflow can be distributed misting and bad air (if recirculation is selected). to the windows, dashboard See page 77, for activating/deactivating the vents or floor by pressing the function.
  • Page 90 03 Climate control Manual climate control, AC on the button. Automatic switching off discon- nects the rear window and door mirrors after 12 – 20 minutes depending on outside tem- perature. During cold weather the defrosting* also con- tinues after 20 minutes in order to keep the rear window and door mirrors free of ice and mist.

  • Page 91: Electronic Climate Control, Ecc

    03 Climate control Electronic climate control, ECC* Control panel AUTO Functions 2. Fan Turn the knob to increase or 1. AUTO decrease fan speed. If AUTO The AUTO function automat- is selected then fan speed is Recirculation/Air quality system ically regulates climate con- regulated automatically.
  • Page 92 03 Climate control Electronic climate control, ECC* • 3. Recirculation The air quality system consists of a multi-filter The defroster functions for the front, side and rear windows can be used to demist and a sensor. The filter separates gases and The function is selected to the windows.
  • Page 93 03 Climate control Electronic climate control, ECC* A symbol on the display above the climate con- 7 and 8. Heated front seats* on the button. Automatic switching off discon- trol panel and an illuminated light in the relevant nects the rear window and door mirrors after To activate front seat heating: button indicate which function has been 12 –...

  • Page 94: Air Distribution

    03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.

  • Page 95: Fuel-Driven Engine Block Heater And Passenger Compartment Heater

    03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
  • Page 96 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been Direct start is activated, the infor- stopped by the car's PED LOW BAT- mation symbol in the combined electronics in order...
  • Page 97 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will After setting TIMER 1 a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.

  • Page 98: Fuel-Driven Auxiliary Heater* (Diesel)

    03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
  • Page 99 03 Climate control...
  • Page 100 Front seats ................... 102 Interior lighting..................107 Storage spaces in the passenger compartment ........110 Rear seat....................114 Cargo area.................... 116...
  • Page 101 I N T E R I O R...

  • Page 102: 04 Interior

    04 Interior Front seats Seating position, manual seat Backrest rake: turn the wheel. Seating position, power seat* Control panel for power seat*. Lever (2) is not available on all seat models. WARNING Adjust the position of the driver's seat and adjust the seatbelt, see page 18, before set- ting off, never while driving.
  • Page 103 04 Interior Front seats An overload protection is deployed if one of the Emergency stop Entry to rear seat, manual seat seats is blocked. If this happens, turn off the If the seat accidentally begins to move, press ignition and wait a short time before adjusting any of the buttons to stop the function.
  • Page 104 04 Interior Front seats Push the seat forward Push the seat backward: Lift the handle Release the seatbelt from the seatbelt Lift the handle and fold back the backrest. Fold the backrest forward to the locked guide, see also page 20. position.
  • Page 105 04 Interior Front seats 3. Continue to lift of the handle, and push the seat forward to the desired position and release the handle. Entry to rear seat, power seat Push the seat forward Lift the handle. Hold down the front section of the button. If the seat is set in a higher position - then Fold the backrest forward to the locked it will be lowered automatically to avoid the...
  • Page 106 Floor mats* Volvo supplies floor carpets which are espe- cially produced for your car. WARNING The floor mat at the driver's seat must be Lift the handle and fold back the backrest.

  • Page 107: Interior Lighting

    04 Interior Interior lighting Reading lamps and interior lighting Roof lighting Glovebox lighting The reading lamps are switched on or off by Glovebox lighting is switched on and off pressing the relevant button in the roof con- respectively when the lid is opened or closed. sole.
  • Page 108 04 Interior Interior lighting Automatic lighting Passenger compartment lighting comes on and remains on for 5 minutes if one of the doors Using the switch (2), see page 107, three posi- is open. tions can be selected for the lighting the pas- senger compartment: If any lighting is switched on manually and the car is locked then it will be switched off auto-...
  • Page 109 04 Interior Interior lighting...

  • Page 110: Storage Spaces In The Passenger Compartment

    04 Interior Storage spaces in the passenger compartment Storage spaces...
  • Page 111 04 Interior Storage spaces in the passenger compartment Storage compartment in door panel. Glovebox Coat hanger Storage pocket on front edge of front seat cushions (trim dependent). Ticket clip Coat hanger, only for light garments. Glovebox Storage compartment (e.g. for CD discs and cup holder, *) and storage compart- ment behind the centre console.
  • Page 112 04 Interior Storage spaces in the passenger compartment Storage under the front armrest Cup holder in centre console In the deeper compartment there is space for 10 normal CD cases. The cases must be stored There is a storage space under the armrest. There is space for a double cup holder under vertically on the top edge for all 10 to have There is also a smaller storage space in the...
  • Page 113 04 Interior Storage spaces in the passenger compartment Storage compartment behind the gear Bottle holder* Ashtray* lever A bottle holder for larger bottles is located on An ashtray is located towards the rear of the the rear of the tunnel console. tunnel console.

  • Page 114: Rear Seat

    04 Interior Rear seat Head restraint, rear Lowering the rear seat backrest shows that the backrest is no longer locked in place. IMPORTANT 2. Fold the backrest forward. There must be no objects on the rear seat Raising the backrest when the backrest is to be folded down.
  • Page 115 04 Interior Rear seat long load. The armrest folds down when one of WARNING the backrests is folded down. Place the belt straps over the backrests For securing loads, see page 181. before folding them back to their secured positions. NOTE When the backrest has been raised, the red indicator (A) should no longer be showing.

  • Page 116: Cargo Area

    04 Interior Cargo area Soft cargo cover* Hanging up the cargo cover when not in Hard cargo cover* 1. Unhook the hooks from the rear load retaining eyelets (D). 2. Press the rail together and remove it from the rear bracket (C). Place the rail at the front of the cargo area floor.
  • Page 117 04 Interior Cargo area The cargo cover hatch can be raised during Raising the floor hatch loading. NOTE The cargo cover has no load-securing func- tion. Never load anything on top of the cargo cover. For securing loads, see page 181. Removing the cargo cover 1.
  • Page 118 04 Interior Cargo area Safety net* Removing the safety net Load retaining eyelets* 1. Slacken the tension from the straps. 2. Undo the hooks from the eyes at the seat- belt floor mounting on both sides. 3. Detach the net from the mounting points in the roof panels.
  • Page 119 04 Interior...
  • Page 120 Remote control key with key blade............122 Active locks................... 125 Keyless drive*..................126 Battery in remote control key..............129 Locking and unlocking ................. 130 Alarm* ....................133 Option/accessory, for more information, see Introduction.
  • Page 121 L O C K S A N D A L A R M...

  • Page 122: 05 Locks And Alarm

    The car is supplied with two remote control If you lose a remote control key, take the car keys. and the other remote control keys to a Volvo workshop - an authorised Volvo workshop is The remote control keys contain detachable recommended.

  • Page 123: Locks And Alarm

    05 Locks and alarm Remote control key with key blade 30, 60 or 90 seconds. For information on Detachable key blade Slide the spring-loaded catch to the side. setting the delay time, see page 78. Pull out the key blade at the same time. Tailgate –...
  • Page 124 05 Locks and alarm Remote control key with key blade Turn the key blade 90 degrees clockwise. NOTE The keyhole is horizontal in the locked When the driver's door is unlocked using the position. key blade and is opened, the alarm is trig- gered.

  • Page 125: Active Locks

    05 Locks and alarm Active locks Active locks for remote control key with key blade. Active locks for remote control key with- out key blade.

  • Page 126: Keyless Drive

    05 Locks and alarm Keyless drive* • Keyless lock and ignition system Remote control key max. 1.5 m from the the READ button has been pressed. Never leave any remote control key in the In order to open a door or the tailgate, a remote control key must be no more than approx.
  • Page 127 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
  • Page 128 05 Locks and alarm Keyless drive* Centre console, under the rear section NOTE Door handle, right-hand rear When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered.

  • Page 129: Battery In Remote Control Key

    05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information symbol and display show...

  • Page 130: Locking And Unlocking

    05 Locks and alarm Locking and unlocking Locking/unlocking the car from Rapid closing Locking/unlocking the car from inside outside Press and hold (at least 2 seconds) on the remote control key's lock button to close all For cars with the Keyless system, see windows and sunroof* at the same time.
  • Page 131 05 Locks and alarm Locking and unlocking Locking Temporary deactivation Deadlocks * ± Press the lower section of the central lock- When deadlocked, the doors cannot be ing button opened from the inside if they are locked with the remote control key. Press and hold (at least 2 seconds) to also close all windows and the sunroof* at the The deadlocks are activated with the remote...
  • Page 132 05 Locks and alarm Locking and unlocking ENTER The next time the remote control key is turned to key position II the system is reset to zero and Navigation the instrument panel display shows the mes- sage Full guard at which the deadlocks func- If someone is going to stay in the car but the tion and the alarm's movement and tilt detec- doors must be locked from the outside, then...

  • Page 133: Alarm

    – the alarm has been triggered. If there is a fault in the alarm system, a message appears on the display. At which point you should contact a workshop - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 134 05 Locks and alarm Alarm* Automatic re-arming of the alarm Remote control key not working Reduced alarm level This function prevents the car being left with To avoid inadvertently triggering of the alarm - alarm disarmed unintentionally. for example when leaving a dog in the car or during a ferry crossing - the movement and tilt If the car is unlocked with the remote control detectors can be temporarily switched off.
  • Page 135 05 Locks and alarm Alarm* 4. Open one of the doors. A siren should sound and all direction indicators should flash. 5. Deactivate the alarm by unlocking the car with the remote control key. Test of alarm for bonnet 1. Sit in the car and deactivate the movement detector.
  • Page 136 General....................138 Refuelling....................140 Alcoguard * ..................144 Starting the engine ................148 Starting the engine – Flexifuel............... 150 Keyless drive*..................152 Manual gearbox..................153 Automatic gearbox................154 Brake system..................159 DSTC – Stability and traction control system* ........161 Park Assist*...................
  • Page 137 S T A R T I N G A N D D R I V I N G...

  • Page 138: 06 Starting And Driving

    - in particular with a heavy load. model. Check with your nearest Volvo dealer warm one. regarding the options for your car. For supplementary information about over- •...
  • Page 139 06 Starting and driving General Do not overload the battery IMPORTANT The electrical functions in the car load the bat- Engine damage can occur if water enters tery to varying degrees. Avoid having the the air filter. remote control key in key position II when the In greater depths, water can enter the trans- engine is switched off.

  • Page 140: Refuelling

    06 Starting and driving Refuelling Opening the fuel filler flap 3. Take out the cap. General information on fuel 4. Hang up the cap on the inside of the fuel WARNING filler flap. Always avoid inhaling fuel vapour and get- NOTE ting fuel splashes in the eyes.
  • Page 141 Mixing different types of fuel or the use of adjusted. These adjustments create optimal nents, and do not replace components with fuel not recommended invalidates Volvo's conditions for efficient combustion of harmful parts that are not specifically designed for use...
  • Page 142 IMPORTANT specified in the Service and Warranty Booklet damage that is not covered by the Volvo or if you suspect that the car has been filled warranty. The sulphur content must be a maximum of with contaminated fuel.
  • Page 143 06 Starting and driving Refuelling called "regeneration" is started in order to burn way. The car should then be driven for approx- away the particles and empty the filter. This imately 20 minutes more. requires the engine to have reached normal NOTE operating temperature.

  • Page 144: Alcoguard

    06 Starting and driving Alcoguard * General information on the Alcolock Functions Operation The function of the Alcolock is to prevent the Battery car from being driven by individuals under the Alcolock indicator lamp (4) shows battery sta- influence of alcohol. Before the engine can be tus: started the driver must take a breath test that verifies that he/she is not under the influence...
  • Page 145 . If calibration is not carried out without a new breath test. within these 30 days then normal engine star- ting will be blocked - only starting with the An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 146 This setting can be nect the power supply cable from the glovebox changed afterwards at a workshop and wait until indicator lamp (6) is green. An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 147 Test failed - take a INVALID TEST new breath test. ALCOGUARD Blowing too short - blow for longer. BLOW LONGER ALCOGUARD Blowing too hard - blow more gently. BLOW SOFTER An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.

  • Page 148: Starting The Engine

    06 Starting and driving Starting the engine ± Before starting the engine Turn the ignition key to the start position NOTE III and just release it - the starter motor ± Apply the parking brake. The idling speed can be noticeably higher then works automatically until the engine than normal for certain engine types during Note that if the car is equipped with an alcolock...
  • Page 149 06 Starting and driving Starting the engine II – Driving position 2. Hold the steering wheel in this position. Reinsert the key and make a new attempt The remote control key's to start the car. position when driving. The whole electrical system is engaged.

  • Page 150: Starting The Engine - Flexifuel

    III. connections must only be carried out by a 3. When the engine has started, ease the workshop - an authorised Volvo workshop accelerator pedal gradually as the engine is recommended. speed increases.
  • Page 151 06 Starting and driving Starting the engine – Flexifuel NOTE IMPORTANT Points to remember for carrying reserve After the fuel mixture in the tank has been fuel: changed an adaptation should be made by driving at an even speed for about 15 •...

  • Page 152: Keyless Drive

    06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key ± Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine ± Press in and turn the ignition dial to key position III.

  • Page 153: Manual Gearbox

    06 Starting and driving Manual gearbox Gear positions Gear shift indicator - GSI* GSI - Gear Shift Indicator - advises the driver of the opti- mum time to change gear. The indication is given with an arrow for up and down shift- ing respectively in the lower information display of the combined instrument panel, see page 47.

  • Page 154: Automatic Gearbox

    06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions (+/-) NOTE The driver can also change gear manually The brake pedal must be depressed in order using the Geartronic automatic gearbox. The to be able to disengage the gear lever from car engine-brakes when the accelerator pedal the P position.
  • Page 155 06 Starting and driving Automatic gearbox Kick-down Mechanical gear selector inhibitor Automatic gear selector inhibitor When the accelerator pedal is pressed all the Cars with an automatic gearbox have special way to the floor (beyond the position normally safety systems: regarded as full acceleration) a lower gear is Keylock immediately engaged.
  • Page 156 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor Cold start Automatic gearbox, Powershift * When starting in low temperatures, the gear changes can sometimes feel hard. This is due to the gearbox oil's viscosity at low tempera- tures.
  • Page 157 06 Starting and driving Automatic gearbox To bear in mind Overheating during slow driving in queues can Text message and action be avoided by driving in stages: Stop the car The transmission's double clutch has overload In some situations the display can show a mes- and wait with your foot on the brake pedal until protection that is activated if it becomes too sage at the same time as a symbol is illumi-...
  • Page 158 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake TRANSM. OVERHEAT PARK SAFELY Significant pulling in the car's traction.

  • Page 159: Brake System

    06 Starting and driving Brake system Brake servo Dampness can affect braking Bear in mind that driving with a trailer puts an additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
  • Page 160 - an author- 10 km/h the brake light returns from flashing to ised Volvo workshop is recommended. the normal constant glow - while at the same time the hazard warning flashers are activated,...

  • Page 161: Dstc - Stability And Traction Control System

    06 Starting and driving DSTC – Stability and traction control system* General Spin Control The stability system is activated automatically each time the car is started. The function prevents the driving wheels from The stability and traction control system, STC/ spinning against the road surface during accel- DSTC (Dynamic Stability and Traction Control) System operation during skidding and accel-...
  • Page 162 Constant glow after starting the engine or > If the message remains when the engine while driving means that there is a fault in is restarted, drive to a workshop. An the STC/DSTC system. authorised Volvo workshop is recom- mended. Option/accessory, for more information, see Introduction.

  • Page 163: Park Assist

    Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
  • Page 164 Front parking assistance is active at speeds attention, contact a workshop - an authorised below 15 km/h. The system is deactivated at Volvo workshop is recommended. higher speeds. When the speed is below 10 km/h the system is reactivated. IMPORTANT...

  • Page 165: Blis* - Blind Spot Information System

    06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
  • Page 166 06 Starting and driving BLIS* – Blind Spot Information System Activating/deactivating ton to clear the text message. For more infor- WARNING mation on messages, see page 52. BLIS does not work in sharp bends. BLIS system message BLIS does not work when the car is revers- ing.
  • Page 167 BLIS SERVICE must only be performed by a workshop - an REQUIRED authorised Volvo workshop is recom- mended. Here are several examples of situations where the BLIS indicator lamp may illuminate even if Low sun in the camera.

  • Page 168: Towing And Recovery

    06 Starting and driving Towing and recovery Start assistance WARNING IMPORTANT Use a donor battery if the battery is discharged The steering lock remains in the position it Note that the car must always be towed with and the engine does not start. Do not tow the was in when the power was cut off.
  • Page 169 06 Starting and driving Towing and recovery ± Move the gear selector to position N and release the parking brake.
  • Page 170 06 Starting and driving Towing and recovery Towing eye turning it outwards. Then turn out the The towing eye is screwed into a threaded Finish by refitting the cover onto the cover completely and remove it. socket behind a cover on the right-hand side bumper.
  • Page 171 06 Starting and driving Towing and recovery NOTE On certain cars with fitted towbar the towing eye cannot be secured in the rear mounting. In which case, secure the tow rope in the towbar. For this reason it is advisable to store the towbar's towball in the car, see page 175.

  • Page 172: Start Assistance

    06 Starting and driving Start assistance Starting with a donor battery 3. If the donor battery is in another car, switch WARNING off the engine in the other car and ensure The battery can generate oxyhydrogen gas, that the cars do not touch one another. which is highly explosive.

  • Page 173: Driving With A Trailer

    • Avoid driving with a trailer on inclines of If the towing bracket is fitted by an authorised more than 12%. Volvo workshop, then the car is delivered with Overheating • For safety reasons, the maximum permit- the necessary equipment for driving with a...
  • Page 174 06 Starting and driving Driving with a trailer Automatic gearbox hitched trailer. Always use the parking brake. Overheating • Block the wheels with chocks when park- When driving with a trailer in hilly terrain in a hot ing a car with hitched trailer on a hill. climate there may be a risk of overheating.

  • Page 175: Towing Equipment

    If the car is equipped with a detachable towbar, the installation instructions for the loose sec- tion must be followed carefully, see page 177. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions care- fully.
  • Page 176 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Option/accessory, for more information, see Introduction.

  • Page 177: Detachable Towbar

    06 Starting and driving Detachable towbar* Fitting the towbar 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
  • Page 178 06 Starting and driving Detachable towbar* 5. Check that the indicator window shows green. 4. Insert the towbar until you hear a click. 7. Check that the towbar is secure by pulling it up, down and back. WARNING 6. Turn the key anticlockwise to locked posi- tion.
  • Page 179 06 Starting and driving Detachable towbar* Removing the towbar 8. Safety cable. 2. Push in the locking wheel and turn it 1. Insert the key and turn it clockwise to the anticlockwise until you hear a click. WARNING unlocked position. Be sure to attach the trailer's safety cable to the correct place.
  • Page 180 06 Starting and driving Detachable towbar* 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. comes to a stop. Hold it in this position while pulling the towbar rearward and upward. WARNING Secure the towbar safely if it is stored in the car, see page 175.

  • Page 181: Loading

    For more detailed infor- for your car by Volvo. surface of the tailgate. mation on weights, see page 274. Carefully follow the mounting instructions sup- •...

  • Page 182: Adjusting Headlamp Pattern

    On cars equipped with Xenon lamps, head- dazzling oncoming motorists. lamp replacement must be performed at a workshop - an authorised Volvo workshop The correct pattern will also better illuminate is recommended. The lamp must be han- the verge.
  • Page 183 06 Starting and driving...
  • Page 184 General....................186 Tyre pressure..................190 Warning triangle* and spare wheel * ............ 192 Changing wheels................... 194 Emergency puncture repair* ..............196 Option/accessory, for more information, see Introduction.
  • Page 185 W H E E L S A N D T Y R E S...

  • Page 186: 07 Wheels And Tyres

    07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not pressure and speed rating are important for differ from those specified on the vehicle reg- how the car performs.
  • Page 187 A suitable dis- cially the studs, a longer service life. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo recom- NOTE mends that you contact an authorised Volvo Tread wear indicators.
  • Page 188 1. Tighten the wheel nuts of model (1) to washer. Only use wheel rims that are tested and 110 Nm. Tighten the wheel nuts of model approved by Volvo and which are included in (2) to 130 Nm. NOTE the Volvo genuine accessories range.
  • Page 189 The spare wheel (Temporary spare) is only Volvo recommends that you contact an author- intended for use temporarily and must be ised Volvo workshop for checking if you are replaced by an ordinary wheel as soon as pos- uncertain about tread depth.

  • Page 190: Tyre Pressure

    07 Wheels and tyres Tyre pressure • Recommended tyre pressure Tyre pressure for the car's recommended Inadequately inflated tyres increase fuel con- tyre size sumption, shorten tyre lifespan and impair the car's roadholding. Driving on tyres with tyre • ECO pressure pressure that is too low can also result in the •...
  • Page 191 07 Wheels and tyres Tyre pressure Tyre pressure table Variant Tyre size Speed Load, 1 - 3 persons Max. load (km/h) Rear (kPa) Front (kPa) Rear ECO pres- Front (kPa) (kPa) sure 195/65 R15 0–160 205/55 R16 160+ 2.0F 205/50 R17 0–160 215/45 R18 160+...

  • Page 192: Warning Triangle* And Spare Wheel

    Spare wheel* and jack * NOTE triangle*. Place the warning triangle in a suita- Volvo recommends only using the jack* that The car's original jack* ble place with regard to the traffic. belongs to the car model in question, which The original jack* must only be used for chang- 1.
  • Page 193 07 Wheels and tyres Warning triangle* and spare wheel * Putting the spare wheel* and jack* into the cargo area Wheel wrench*. Jack* and handle, secured with a tension- ing strap. The spare wheel is bolted down with the rim side down using the through-bolt. Tools - returning into place Tools and jack* must be returned into place in the correct manner after use.

  • Page 194: Changing Wheels

    3. Place chocks in front of and behind the NOTE wheels which will remain on the ground. Volvo recommends only using the jack* that Use heavy wooden blocks or large stones. belongs to the car model in question, which is indicated on the jack's label.
  • Page 195 07 Wheels and tyres Changing wheels 6. There are two jacking points on each side Standard wheel nuts and domed wheel of the car. There is a recess in the plastic nuts with rotating washers (tightening tor- cover at each point. Crank the foot of the que: 110 Nm).

  • Page 196: Emergency Puncture Repair

    It consists of a compressor used. Volvo recommends that you visit an and a bottle with sealing fluid. The kit works as authorised Volvo workshop for inspection of 1.
  • Page 197 07 Wheels and tyres Emergency puncture repair* Overview Sealing punctured tyres 3. Check that the switch is in position 0 and locate the cable and the air hose. NOTE Do not break the bottle's seal before use. The seal is broken automatically when the bottle is screwed in.
  • Page 198 8. Flick the switch to position I. gauge. to the cargo area. 3. If it is below 1.3 bar then the tyre is insuf- 7. Volvo recommends that you drive to the IMPORTANT ficiently sealed. The journey should not be nearest authorised Volvo workshop for the Risk of overheating.
  • Page 199 07 Wheels and tyres Emergency puncture repair* Inflating the tyres IMPORTANT NOTE The car's original tyres can be inflated by the Risk of overheating. The compressor must Leave the container at a collection point for compressor. not run for more than 10 minutes. storing dangerous waste.
  • Page 200 Cleaning....................202 Touching up paintwork ................ 206 Rustproofing..................207...
  • Page 201 C A R C A R E...

  • Page 202: 08 Car Care

    08 Car care Cleaning Washing the car Chromed wheels NOTE Wash the car as soon as it becomes dirty. Use Outside lighting such as headlamps, fog IMPORTANT car shampoo. Dirt and road salt can lead to lamps and rear lamps may temporarily have corrosion.

  • Page 203: Car Care

    Wash and dry the car thoroughly before you weather. Volvo's cleaning agents can also be used for begin polishing or waxing. Clean off asphalt stains on the mat after vacuuming. Exterior plastic, rubber and trim and tar stains using tar remover or white spirit.
  • Page 204 (or more if solution of 2 dl water and 25g salt.) 1. Pour a small amount of the protective necessary). The Volvo Leather Care kit is avail- cream on the felted cloth and massage in Group 2 (fats, oils, sauces and chocolate) able from your Volvo dealer.
  • Page 205 Do not scrape or rub stains. Never use strong stain removers. Cleaning seatbelts Use water and a synthetic detergent. A special textile cleaning agent is available from your Volvo dealer. Make sure the seatbelt is dry before allowing it to retract.

  • Page 206: Touching Up Paintwork

    08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.

  • Page 207: Rustproofing

    The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
  • Page 208 Volvo service..................210 Self-maintenance.................. 211 Bonnet and engine compartment............212 Oils and fluids..................213 Wiper blades..................218 Battery....................220 Replacing bulbs ................... 222 Fuses..................... 228...
  • Page 209 M A I N T E N A N C E A N D S E R V I C E...

  • Page 210: 09 Maintenance And Service

    It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.

  • Page 211: Self-Maintenance

    NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that voltage in the ignition system is highly dan- tures around freezing. belongs to the car model in question. If a gerous.

  • Page 212: Bonnet And Engine Compartment

    09 Maintenance and service Bonnet and engine compartment Opening the bonnet 1. Pull the handle on the far left under the Engine compartment Brake and clutch fluid reservoir (right-hand instrument panel. (In right-hand drive cars drive) Washer fluid reservoir (4-cyl.) the handle is on the far right.) You will hear Filler opening for engine oil Coolant expansion tank...

  • Page 213: Oils And Fluids

    Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 279.

  • Page 214: Maintenance And Service

    3. Check the oil level using the dipstick. The Volvo uses different systems for warning of low level must be between the MIN and MAX oil level or low oil pressure. Certain variants marks.
  • Page 215 09 Maintenance and service Oils and fluids Washer fluid, topping up WARNING NOTE Do not spill oil onto the hot exhaust manifold The oil level is only updated by the system due to the risk of fire. during driving. The system cannot detect changes when oil is filled or drained.
  • Page 216 • Mix the coolant with approved quality overpressure. tap water. In the event of any doubt about water quality, used ready-mixed coolant in accordance with Volvo rec- NOTE ommendations. The engine must only be run with a well- • When changing coolant/replacing cool- filled cooling system.
  • Page 217 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.

  • Page 218: Wiper Blades

    09 Maintenance and service Wiper blades Wiper blades Replacing the wiper blades, windscreen 1. Turn up the wiper arm. 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
  • Page 219 09 Maintenance and service Wiper blades > Check that it is firmly installed and fold back the wiper arm.

  • Page 220: Battery

    09 Maintenance and service Battery Battery care Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
  • Page 221 09 Maintenance and service Battery 8. Remove the battery. Avoid sparks and naked flames. Fitting the battery 1. Fit the battery into position. 2. Fit the clamp securing the battery. 3. Reinstall the front wall of the battery box. Risk of explosion. 4.

  • Page 222: Replacing Bulbs

    - an authorised Volvo workshop is recommended. The lamp must be han- Removing the lamp housing dled with extreme caution because it is 5.
  • Page 223 09 Maintenance and service Replacing bulbs on or the remote control key inserted into the Main beam ignition switch. Dipped beam Fitting a new bulb 1. Remove the entire lamp housing. 1. Fit the new bulb. It can only fit in one posi- tion.
  • Page 224 09 Maintenance and service Replacing bulbs Position/parking lamps Direction indicators Side marker lamps 1. Twist the bulb holder anticlockwise and 1. Twist the bulb holder anticlockwise and 1. Twist the bulb holder anticlockwise and withdraw it. Replace the bulb. remove it. withdraw it.
  • Page 225 (A or B). NOTE If an error message remains after a faulty bulb has been replaced then we recom- mend that you visit an authorised Volvo 1. Switch off all lights and turn the remote workshop. control key to position 0.
  • Page 226 09 Maintenance and service Replacing bulbs Location of the bulbs in the rear lamp Number plate lighting Cargo area Brake light 1. Switch off all lights and turn the remote 1. Insert a screwdriver and gently turn so that control key to position 0. the lamp housing comes loose.
  • Page 227 09 Maintenance and service Replacing bulbs Passenger compartment lighting in Vanity mirror lighting* Fitting the mirror glass cargo area 1. First, press the three lugs at top edge of mirror glass back into position. 2. Then press the three lower lugs back into position.

  • Page 228: Fuses

    Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
  • Page 229 Volvo workshop. • 1–6 are of the "Midi Fuse" type and must only be replaced by a workshop. Volvo rec- ommends an authorised Volvo workshop. On the inside of the cover are tweezers to assist removing and fitting fuses.
  • Page 230 09 Maintenance and service Fuses Radiator fan 50 A ABS pump 40 A Supply to infotainment sys- 30 A Power steering (excl. 1.6 litre ABS valves 20 A engine) 80 A Windscreen wipers 30 A Engine functions 30 A Supply to passenger com- Supply to passenger com- Ventilation fan 40 A...
  • Page 231 09 Maintenance and service Fuses Engine control module ECM Lambda-sond and vacuum (5-cyl. petrol), Transmission pump (5-cyl. petrol), engine (TCM) (5-cyl auto) 10 A control module (5-cyl. diesel), diesel filter heater (4-cyl. die- Transmission (TCM) (4-cyl. sel) 20 A auto.) 15 A Ignition coils (petrol), injectors Heated fuel filter, PTC ele-...
  • Page 232 09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
  • Page 233 09 Maintenance and service Fuses Phone, audio system, SRS system 10 A Keyless control module 20 A RTI*, Bluetooth * 15 A Reserve – Remote control module, SRS system, engine con- siren control module 10 A Additional heater for the trol module ECM (5-cyl.) 10 A passenger compartment,...
  • Page 234 09 Maintenance and service Fuses Seat heating (passenger Reserve – side) 15 A Reserve – Sunroof 20 A Reserve – Reserve – Reversing lamp RDAR Infotainment system Reserve – Infotainment control Supply to front right door 25 A module (ICM), climate control 10 A Supply to front left door...
  • Page 235 09 Maintenance and service...
  • Page 236 General....................238 Audio functions..................240 Radio functions..................244 CD functions ..................249 Menu structure – audio system............. 252 Phone functions*................... 253 Menu structure – phone*............... 260 Bluetooth handsfree* ................263 Option/accessory, for more information, see Introduction.
  • Page 237 I N F O T A I N M E N T S Y S T E M...

  • Page 238: 10 Infotainment System

    10 Infotainment system General • Infotainment system system can be easily operated using the con- EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the trol panel or the steering wheel keypad*, see menu system.

  • Page 239: Infotainment System

    10 Infotainment system General Dolby Surround Pro Logic II Dolby Surround Pro Logic II distributes the two stereo audio channels to left, centre, right and rear speakers. This provides a more real- istic sound quality than that provided by stand- ard two-channel stereo.

  • Page 240: Audio Functions

    10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- The AUX and USB inputs enable the connec- cle speed, see page 242. tion of an external audio source, e.g. an iPod or MP3 player. Audio source selection If you choose to connect an iPod , MP3 player Repeatedly pressing AM/FM switches or a USB memory stick to the USB connection...
  • Page 241 10 Infotainment system Audio functions • Select TUNING (4) clockwise or anticlock- For information on USB and iPod in combi- NOTE wise. nation with Performance audio, see the acces- The system supports removable media • sory manual for USB and iPod Music Inter- Use the right or left-hand button (6) of the which is compatible with USB 2.0 and the navigation control to scroll to the desired...
  • Page 242 10 Infotainment system Audio functions • FADER – Balance between the front and Activating/deactivating surround sound tional frequencies can be selected using rear speakers. the left/right navigation button. 1. Press MENU and then ENTER. • BALANCE – Balance between the left and 6.
  • Page 243 10 Infotainment system Audio functions This calibration takes into account loudspeak- ers, amplifiers, passenger compartment acoustics, listener position etc. for each com- bination of car model and audio system. There is a also a dynamic calibration that takes into account the position of the volume control, radio reception and vehicle speed.

  • Page 244: Radio Functions

    10 Infotainment system Radio functions Radio controls Tuning Storing stations Ten station presets can be stored per wave- Automatic tuning length. FM has two memories for presets: 1. Select wavelength using AM/FM (1). . Preset stations are selected 2. Give a brief press on using the preset buttons (2) or the steering wheel keypad.
  • Page 245 10 Infotainment system Radio functions • Selecting an auto-stored preset Scanning Automatically switches to a stronger trans- mitter if reception in the area is poor. Allowing the radio to remain in Auto mode pro- SCAN (4) automatically searches through a vides access to the autostored presets.
  • Page 246 10 Infotainment system Radio functions For further programme interruption settings, 3. Scroll to Advanced radio settings… Activating/deactivating News see EON and REG see page 247. The pro- press ENTER. 1. Press MENU and then ENTER. gramme functions are modified via the menu 4.
  • Page 247 10 Infotainment system Radio functions 2. Press MENU and then ENTER. Display of programme type Automatic frequency update – AF The programme type of the current station can The AF function selects one of the strongest 3. Scroll to and press ENTER. be shown on the display.
  • Page 248 10 Infotainment system Radio functions Enhanced Other Networks – EON Resetting RDS functions The EON function is especially useful in urban Resets all radio settings to the original factory areas with many regional radio stations. It settings. allows the distance between the car and the 1.

  • Page 249: Cd Functions

    10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Start playback (CD changer*) when volume is increased.
  • Page 250 10 Infotainment system CD functions cally when all files in the current folder have Activating/deactivating, random (CD NOTE been played back. changer) It is only possible to scroll between random If a normal music CD is being played: Press left/right on the navigation button if the CD tracks on the current disc.
  • Page 251 10 Infotainment system CD functions Using low quality CD discs could result in poor or non-existent sound. IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.

  • Page 252: Menu Structure - Audio System

    10 Infotainment system Menu structure – audio system Overview FM MENU Disc text Audio settings… News Audio settings… USB MENU* CD MENU Playlist PTY… For CD changer* with CD disc Random… selected. Radio text News Random… Advanced radio settings… News Audio settings…...

  • Page 253: Phone Functions

    10 Infotainment system Phone functions* Phone system components. Option/accessory, for more information, see Introduction.
  • Page 254 (3G only). Combined 3G/GSM cards Volvo recommends that an authorised Missed calls are shown in the display. work. Contact your network operator if a Volvo workshop carries out phone system IDIS be disconnected using menu function 6.5, replacement SIM card is required. servicing.
  • Page 255 10 Infotainment system Phone functions* Extra SIM card Phone controls Steering wheel keypad Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
  • Page 256 10 Infotainment system Phone functions* On/Off Activating from standby mode Call waiting ± Press PHONE. A two-tone signal during a phone call indicates A handset appears in the display when the that there is another incoming call. Answer? phone system is active or in standby mode shown in the display.
  • Page 257 If the phone book contains a live caller's con- see menu 6.4.3, on page 260. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the p q r s 7 ß...
  • Page 258 10 Infotainment system Phone functions* 6. Scroll to SIM card Phone memory 4. Enter the first few letters of the item and 6. Enter the first few letters of the item and press ENTER, or simply press ENTER. press ENTER, or simply press ENTER. press ENTER.
  • Page 259 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Press ENTER to dial. Reading SMS network operator with the phone's IMEI num- 1. Press MENU. ber. This is a 15 digit serial number that is pro- NOTE 2.

  • Page 260: Menu Structure - Phone

    10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial… 4.6.2. When busy Call register… 2.4.1. Active 4.6.3. Not answered 1.1. Last 10 missed calls 2.4.2. Select numbers 4.6.4. Not reachable 1.2. Last 10 received calls 2.5. Erase SIM 4.6.5.
  • Page 261 10 Infotainment system Menu structure – phone* 6.2.3. Automatic 1.4.1. All calls 2.4. Speed dial A number stored in the phone book can be 6.3. Edit PIN code 1.4.2. Missed calls stored as a speed dial number. 6.4. Sounds and volume… 1.4.3.
  • Page 262 10 Infotainment system Menu structure – phone* operator for information on message settings. 4.6.2 When busy 6.1.2. Manual select Normally, these settings should not be altered. 4.6.3. Not answered 6.2. SIM security 3.3.1. SMSC number Select if the PIN code should be on, off or if the 4.6.4.

  • Page 263: Bluetooth Handsfree

    Volvo recommends that you seek assis- Connect mobile phone tance from an authorised Volvo dealer or A mobile phone is connected in different ways visit www.volvocars.com for information on depending on whether or not it has been con- compatible phones.
  • Page 264 10 Infotainment system Bluetooth handsfree* 4. Choose one of the mobile phones in the the mobile phone can be controlled from the NOTE audio system display. audio system. Some mobile phones require that the 5. Enter the number series shown in the audio changeover from handsfree is confirmed To call system display via the mobile phone key-...
  • Page 265 10 Infotainment system Bluetooth handsfree* Ring volume More on registering and connecting NOTE Go to Phone Menu… Phone settings… A maximum of five mobile phones can be reg- With certain mobile phones the connection istered. Registration is performed once per Sounds and volume…...
  • Page 266 List is empty compatible with the voice recognition func- tion. Volvo recommends that you contact an shown when copying is finished. tion is made under Phone Menu… authorised Volvo dealer or visit Bluetooth…...
  • Page 267 10 Infotainment system Bluetooth handsfree* twice for the second etc. Continue pressing for Bluetooth… Menu structure - Bluetooth more characters, see the table on page 257. handsfree with built-in phone 3.1. Change phone Call register… A short press on EXIT deletes an input char- 3.1.1.
  • Page 268 10 Infotainment system Bluetooth handsfree* Phone settings… 6.1. Sounds and volume… 6.1.1. Ring volume 6.1.2. Ring signals… 6.1.3. Mute radio 6.2. Synchronise phone book Option/accessory, for more information, see Introduction.
  • Page 269 10 Infotainment system...
  • Page 270 Type designation................... 272 Dimensions and weights............... 274 Engine specifications................277 Engine oil....................278 Fluids and lubricants................280 Electrical system................... 282 Type approval..................284 Symbols in the display................285...
  • Page 271 S P E C I F I C A T I O N S...

  • Page 272: 11 Specifications

    11 Specifications Type designation...
  • Page 273 S40 and V50: The label is visible when the right rear door is opened. C30 and C70: The label is visible when the right door is opened. Label for parking heater.

  • Page 274: Dimensions And Weights

    11 Specifications Dimensions and weights Dimensions Weights Dimensions Dimensions Kerb weight includes the driver, the fuel tank Wheelbase 2640 Rear track 1531 90% full and all fluids. The weight of passengers and accessories, Length 4266 Load width, floor and towball load (when a trailer is hitched, see Load length, floor, folded 1486 Width...
  • Page 275 11 Specifications Dimensions and weights Max. total weight NOTE WARNING Max. train weight (car+trailer) The documented kerb weight applies to The car's driving characteristics change cars in the standard version - i.e. a car with- depending on how heavily it is loaded and Max.
  • Page 276 11 Specifications Dimensions and weights Engine Maximum weight, braked trailer (kg) Maximum towball load (kg) 2.0F 1350 1350 others 1500 Maximum weight, unbraked trailer (kg) Maximum towball load (kg)

  • Page 277: Engine Specifications

    11 Specifications Engine specifications Overview Engine Engine Output Output Torque No. of Bore Stroke Swept Compres- code (kW/ (hp/rpm) (Nm/ cylin- (mm) (mm) volume sion ratio rpm) rpm) ders (litres) B4164S3 74/6000 100/6000 150/4000 81.4 1.596 11.0:1 2.0F B4204S4 107/6000 145/6000 185/4500 83.1...

  • Page 278: Engine Oil

    Choose a fully synthetic engine oil for adverse Volvo Car Corporation disclaims all war- driving conditions. It provides extra protection ranty liability if engine oil of the prescribed for the engine.
  • Page 279 11 Specifications Engine oil Engine oil grade Engine var- Engine code Recommended oil grade Volume between Volume, incl. oil filter iant MIN-MAX (litres) (litres) B4164S3 Oil grade: ACEA A5/B5 Viscosity: SAE 5W–30 2.0F B4204S4 B4204S3 D4162T D5204T Oil grade: ACEA A5/B5 Viscosity: SAE 0W-30/5W–30 B5254T7 SAE 0W-30 applies for Europe, SAE 5W-30 applies for other markets...

  • Page 280: Fluids And Lubricants

    Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Manual gearbox...
  • Page 281 Petrol: see page 141 Petrol: T5 approx. 62 Diesel: D2, D3 and D4 approx. 52 Diesel: see page 142 Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Contact an authorised Volvo workshop for the correct information.

  • Page 282: Electrical System

    11 Specifications Electrical system General The battery capacity is dependent upon the capacity as the original battery (see the label equipment level in the vehicle. If the starter on the battery). The car has a voltage-regulated AC alternator. battery is replaced, therefore, you must ensure The electrical system is single-pole and uses that you switch to a battery with the same the chassis and engine casing as a conductor.
  • Page 283 11 Specifications Electrical system Lighting Output (W) Type Front direction indicators PY24WSW Rear direction indicators PY21WSV Cargo area lighting, number plate lighting Vanity mirror* Tubular lamp Front position/parking lamps W5W BV LL Side marker lamps, front WY5W Fog lamps Glovebox lighting Tubular lamp Option/accessory, for more information, see Introduction.

  • Page 284: Type Approval

    11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...

  • Page 285: Symbols In The Display

    11 Specifications Symbols in the display General Symbols in the display Symbol Meaning Page There are a variety of different symbols in the Indicator and warning symbols in the Stability system, 49, 161, display in the car. The symbols are divided into combined instrument panel STC or DSTC* warning, indicator and information symbols.
  • Page 286 11 Specifications Symbols in the display Information symbols in the centre Symbol Meaning Page Symbol Meaning Page console display Low oil pressure 48, 50 Left direction indi- Symbol Meaning Page cators Surround sound (only Premium Sound) Seatbelt reminder 18, 50 Right direction indicators News...
  • Page 287 11 Specifications Symbols in the display Information symbols in the roof console display Symbol Meaning Page Seatbelt reminder Airbag, passen- 24, 25 ger seat, acti- vated Airbag, passen- ger seat, deacti- vated...

  • Page 288: Alphabetical Index

    12 Alphabetical Index Air quality system, ECC......92 Auto climate..........91 Air vents............. 87 Automatic car washes......202 Alarm............133 Automatic gearbox electronic climate control..... 93 alarm indicator........133 manual gear positions (Geartronic)..154 manual climate control....88, 89 arming..........133 towing and recovery......
  • Page 289 12 Alphabetical Index Bioethanol E85........141 Checks fluids and oils........214 Blind spot (BLIS)........165 Calls Children............. 33 Blind Spot Information System, BLIS 74, 165 functions during a call....256, 259 child seats and side airbags....26 Bluetooth incoming..........264 location in the car.........
  • Page 290 12 Alphabetical Index Coat hanger..........111 Diesel: engine preheater......49 During a call, functions......259 Cold start..........156 Diesel particle filter........142 automatic gearbox......156 Dipstick, electronic........215 Collision Direction indicators........58 crash mode........... 32 Disc text........... 250 ECC, electronic climate control....87 inflatable curtain, IC......
  • Page 291 12 Alphabetical Index Engine oil......... 214, 278 Flexifuel............ 150 changing..........228 adverse driving conditions....278 adaptation........... 151 general..........228 capacities........... 278 relay/fuse box in the passenger com- Floor hatch..........117 filter............. 213 partment..........232 Floor mats..........106 oil grade..........278 Fluids, capacities........
  • Page 292 12 Alphabetical Index Headlamp pattern adjustment Infotainment system Key blade......... 123, 127 Active Bending Lights (ABL) ....182 menus..........238 active locks......... 125 Headlamps..........55 Instrument lighting........56 Keyless drive......126, 152, 284 starting the car........152 Head restraint.......... 114 Instrument overview left-hand drive........
  • Page 293 12 Alphabetical Index headlamp levelling........ 55 Load retaining eyelets......118 Manual gear positions (Geartronic)..154 home safe lighting......58, 73 Locking............ 127 Max. roof load ......... 274 in passenger compartment....107 unlocking..........130 Memory function in seats......103 lighting panel, passenger compart- Locking/unlocking........
  • Page 294 12 Alphabetical Index Mobile phone Parking assistance........163 controls..........255 connect..........265 parking assistance sensors....164 entering text........257 handsfree..........263 handsfree..........263 Parking brake........50, 68 register phone........263 incoming calls........264 Parking heater making calls........264 battery and fuel........95 on/off..........
  • Page 295 12 Alphabetical Index PTY – Programme type......246 door............73 Remote control key system, type appro- electrically retractable......73 val............284 Puncture, see Tyres......192, 194 interior........... 71 Resetting the door mirrors......73 Putting calls on hold........ 256 Recirculation Reverse gear inhibitor......153 A/C............
  • Page 296 12 Alphabetical Index Seats Stability and traction control system..161 Symbols........... 162 head restraints, rear......114 indicator symbols......49, 50 Stains............203 lowering the rear backrest....114 warning symbols........48 Standby, phone........256 manual setting........102 Symbols and display messages Start assistance........
  • Page 297 12 Alphabetical Index Towbar, see Towing equipment....175 specifications........186 speed ratings........186 Towing............. 168 tread wear indicators......187 Warning lamp towing eye.......... 170 winter tyres......... 189 stability and traction control system. . 161 Towing capacity........274 Warning symbol, airbag system....21 Towing equipment........
  • Page 298 12 Alphabetical Index Windscreen wipers........61 rain sensor..........62 Winter tyres..........189 Wiper rear window.......... 62 Wiper blades..........218 cleaning..........218 replacing, rear window....... 218 replacing, windscreen......218...
  • Page 300 Kdakd 8Vg 8dgedgVi^dc IE &&+&- :c\a^h]! 6I &%'%! Eg^ciZY ^c HlZYZc! <ŽiZWdg\ '%&%! 8deng^\]i © '%%%"'%&% Kdakd 8Vg 8dgedgVi^dc...

Table of Contents
