Page 1: Installation Guide
PART No. 5500040-16 LINKSTREAM Installation Guide... - Page 2 Perle Systems Ltd, 2002. No part of this document may be copied without written permission from Perle Systems. The Perle policy is one of continuous development and consequently the equipment may vary in detail from the description and specification in this publication.
-
Page 3: Table Of Contents
Approvals/RFC list Specification This Installation/User Guide has been designed to assist in the installation of LINKSTREAM in standard configurations. If the more advanced features of the LINKSTREAM are required then the LINKSTREAM Range Reference Manual is available. Please contact your supplier for details. -
Page 4: Getting To Know Your Linkstream
This User Guide gives quick set up information. For more DOCUMENTATION detailed information, the LINKSTREAM Range Reference Manual is available. The LINKSTREAM is a stand alone product combining INTRODUCTION the functions of a terminal server and router in the same STAND ALONE unit. -
Page 5: Linkstream Construction
SECTION 1.0 GETTING TO KNOW YOUR LINKSTREAM LINKSTREAM The LINKSTREAM consists of a stand alone case of metal CONSTRUCTION construction with an internal power supply. Up to two expansion cards can be fitted to provide additional user channels, up to a maximum of 24. -
Page 6: Reset Button
GETTING TO KNOW YOUR LINKSTREAM SECTION 1.0 FRONT PANEL There are also two recessed push buttons on the front BUTTON panel: RSET This performs a 'warm start' to the system in that it clears down all queues and restarts the system with existing configuration parameters. -
Page 7: Optional Upgrades
This rear panel switch is for each serial link Select 'ISDN' for ISDN. Select 'LINK' for serial link connector. The ISDN function within LINKSTREAM has been designed to offer the same operation to the user whether the internal ISDN module is installed or an external Terminal Adaptor is connected to the LINK0 or LINK1 interface. -
Page 8: Connecting To Your Linkstream
CONNECTING TO YOUR LINKSTREAM POWER CONNECTION On power up, the LEDs on the front panel illuminate while the LINKSTREAM performs system checks. Once successfully completed the RUN LED flashes at a constant rate (approx. once every second). If the RUN LED does not flash at a constant rate, or the ATTN LED is on, then do not continue with the installation. -
Page 9: Modem Controls
LINKSTREAM Range Reference Manual. ISDN CONNECTION An optional ISDN2e Terminal Adaptor (TA) can be installed in LINKSTREAM. This can be used to replace one or both of the WAN links with an ISDN interface running at 64Kbps on each link. -
Page 10: Ethernet (Lan) Connection
Ethernet port. CONNECTION Care should be taken when connecting the Ethernet port of the LINKSTREAM to your network. Ensure that you follow the usual precautions as laid down in the Ethernet guidelines. If unsure of connection procedures for Ethernet then contact your supplier for advice. -
Page 11: Command Line Interface
SECTION 3.0 COMMAND LINE INTERFACE COMMAND LINE INTERFACE The LINKSTREAM presents a Command Line Interface to INTRODUCTION the user when attached to any of the channels. The unit is activated by pressing any key and will respond with Welcome to LINKSTREAM LINKSTREAM >... -
Page 12: Configuring Your Linkstream
Product Type Site Name Prepared by Date It is advisable to fill out this worksheet before attempting to configure a LINKSTREAM using the Quick Setup Menu. IP traffic only? yes___/no___ If no, then Quick Setup cannot be used. Leased Line? yes___/no___ If no, then Quick Setup cannot be used. - Page 13 Connect a terminal or PC running a suitable VT100 emulator package such as Procomm or Hyperterminal, set to 9600 baud, 8 data bits, 1 stop bit, to the LINKSTREAM console port. Activate the console port by typing <cr> so the LINKSTREAM> prompt appears.
-
Page 14: Cold Start
CONFIGURING YOUR LINKSTREAM SECTION 4.0 CONFIGURING YOUR LINKSTREAM CONFIGURATION This section gives a brief overview of the LINKSTREAM using the Node Manager. Full details of all configuration screens are given in the LINKSTREAM Range Reference Manual. COLD START The LINKSTREAM can be completely restarted using the cold start mechanism. - Page 15 They are therefore only active on certain screens. CTRL-F go Forwards to next page. CTRL-B go Backwards to the previous page. Other control characters, specific to certain screens, are described in the LINKSTREAM Range Reference Manual. LINKSTREAM USER GUIDE Page 15...
-
Page 16: Node Manager Screen Structure
CONFIGURING YOUR LINKSTREAM SECTION 4.0 GENERAL INFORMATION NODE MANAGER The diagram below gives the overall structure of the SCREEN STRUCTURE screens within the Node Manager, showing the pathways CONFIGURATION through the system. LOGON P P P P P a a a a a g g g g g e no. -
Page 17: Statistics Screen Structure
SECTION 4.0 CONFIGURING YOUR LINKSTREAM NODE MANAGER SCREEN STRUCTURE STATISTICS -Continued LOGON MAIN MENU CONFIGURATION STATISTICS (2) DISPLAY NODE STATISTICS (1) SYSTEM STATISTICS WEEKLY CALL STATISTICS TODAYS CALL STATISTICS RADIUS STATISTICS DISPLAY IP STATISTICS (2) IP STATISTICS ICMP STATISTICS UDP STATISTICS... -
Page 18: Manual Configuration
CONFIGURING YOUR LINKSTREAM SECTION 4.0 MANUAL CONFIGURATION Network 128.16 NB Factory default settings IP Addr. = 128.16.0.64 Default Gateway = 128.18.0.2 Link 0 = 128.18.0.1 PPP/ISDN DNS table:128.16.0.64 Local 128.17.0.64 Remote Link 0 = 128.18.0.2 Default Gateway = 128.18.0.1 IP Addr. = 128.17.0.64 Network 128.17... -
Page 19: Internet Parameters
SECTION 4.0 CONFIGURING YOUR LINKSTREAM LOGON Node: No Name Mon 01 Jan 199 00:00 MAIN MENU INTERNET PARAMETERS ==================== CONFIGURATION INTERNET PROTOCOL Default Gateway: 128.18.0.2 Global RIP status: Enabled CONFIGURATION IP Checksum: Enabled IP Options: Enabled IP Default TTL: SYSTEM INTERNET... -
Page 20: Ethernet Configuration
Enter IP address of the unit. Set to 128.16.0.64 (local end). Enter 'Y' to 'Accept:' to save displayed values. After setting the above, LINKSTREAM will need rebooting. This can be achieved by either pressing the RSET button or via the system reset screen. -
Page 21: Isdn Call Parameter
SECTION 4.0 CONFIGURING YOUR LINKSTREAM LOGON Node: Local Mon 01 Jan 199- 00:00 MAIN MENU ISDN CALL PARAMETERS ===================== CONFIGURATION Interface: Serial Link 0 NETWORK INTERFACE CONFIGURATION Link Protocol Status: None ISDN Mode: Dial In or Out Dialling Mode: ATD Signal ISDN PARAMETERS Prime Number: .... -
Page 22: Ppp Interface - Lcp/Pap Parameters, Ipcp Parameters
CONFIGURING YOUR LINKSTREAM SECTION 4.0 LOGON Node: Local Mon 01 Jan 199- 00:00 MAIN MENU PPP INTERFACE - LCP/PAP PARAMETERS =================================== CONFIGURATION Interface: Serial Link 0 NETWORK INTERFACE Status: Enabled CONFIGURATION PPP LCP PARAMETERS Echo Interval: Echo Fails: MRU Size:... -
Page 23: Configure Session Parameters, System Reset
- Previous Menu ------------------------------------------------------------------------------------------------------------------ SYSTEM MSG: You have now successfully set up your local LINKSTREAM. Before configuring the remote unit, perform a system reset. This screen is entered to reboot the system and requires a confirmation response. LINKSTREAM USER GUIDE... -
Page 24: General Information
SAFETY NOTICE CAUTION The LINKSTREAM has a component containing a lithium battery, on the base card. There is a danger of explosion if this is incorrectly replaced. Replace only with the same type. Dispose of used batteries properly and do NOT cut open or expose to a naked flame or to temperatures outside the range of -20 to +60 degrees C. -
Page 25: Specification
Basic rate (2B+D) ISDN connection providing the S-Bus interface onto the ISDN/2E network, presented as an 8-way RJ45 socket. Provides 2 x 64Kbps synchronous channels for connection to the trunk interfaces of the LINKSTREAM. CONSOLE PORT Speeds 50bps - 57.6Kbps.
