Perle 1700 User And System Administration Manual

1700 series bridge / routers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Perle 1700 Series
Perle 1700 Series
Perle 1700 Series
Perle 1700 Series
Bridge / Routers
User And System
Administration Guide
Part number 5500071-14
© Copyright 2002 by Perle Systems Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1700 and is the answer not in the manual?

Questions and answers

Related Manuals for Perle 1700

Summary of Contents for Perle 1700

  • Page 1 Perle 1700 Series Perle 1700 Series Perle 1700 Series Perle 1700 Series Bridge / Routers User And System Administration Guide Part number 5500071-14 © Copyright 2002 by Perle Systems Ltd.

  • Page 2: Federal Communications Commission (Fcc)

    Federal Communications Commission (FCC) Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 3: Using This Manual

    This Installation and Applications Guide provides the basic information required to initially set-up and configure the P1730 & PRO Bridge/Router. This guide is organized into the following sections: Installation “ ” provides instructions for installing the P1730 & P1705. Typical Applications & How to Configure Them “...

  • Page 4: Table Of Contents

    INSTALLATION Unpack the Router... 1 Select a Site ... 1 Identify the Reset Switch ... 2 Identify the Connectors ... 3 P1705... 3 P1730... 3 Connect to the Console... 4 Make the Link Connection(s)... 4 Power Up the Bridge/Router... 5 Managing the P1705 &...
  • Page 5 Contents Configure Remote Site Profiles ...38 Configure Remote Site Profiles for ISDN PPP... 39 Configure Remote Site Profile for Frame Relay ... 41 Configure Remote Site Profiles for Leased Line PPP ... 44 Configure Remote Site Profiles for Frame Relay with ISDN backup... 46 Configure Remote Site Profiles for PPPoE...
  • Page 6 Processor settings for the ISDN Link Modules ... 79 Changing the Termination Straps on the ISDN S/T Interface ... 80 Connecting to the ISDN-U Link Module ... 80 Performing a Software Upgrade ... 81 APPENDIX D INTERFACE PINOUTS Pinout Information ... 2.83 Link Clocking Information...

  • Page 7: Installation

    Installation The P1705 & P1730 are flexible Ethernet Bridge/Routers that may be configured to service Local Area Networks and Wide Area Network connections over leased lines, ISDN circuits, and frame relay permanent virtual circuits. The P1705 supports a single LAN and one or two WAN links (one ISDN BRI interface or two other WAN modules).

  • Page 8: Identify The Reset Switch

    Identify the Reset Switch The small hole under the front right corner of the faceplate is used in case a hardware reset is required. The end of a paper clip is sufficient to toggle the small switch behind the hole. Figure 1-1 Location of the Reset Hole on Router Front View...

  • Page 9: Identify The Connectors

    Applications Identify the Connectors P1705 The P1705 may be ordered with a 10Base2, 10Base5, or 10BaseT LAN interface. If this P1705 has an ISDN U or S/T Module, it must only be installed in the slot 1 (leftmost position when viewed from the rear of the unit). The slot 2 position may be unused and covered with a blank panel or may contain another type of module.

  • Page 10: Connect To The Console

    Applications LAN 2 module Link 2 module LAN/Console module MDI-X MDI MDI-X MDI 10/100 BT LAN 10 BT LAN RS-232/V.24 CONSOLE Power connector Figure 1-4 Rear View of the P1730 with Dual LAN connections and a single WAN module Connect to the Console Connection to the bridge/router operator’s console is made through the DB25 connector labeled CONSOLE on the back of the bridge/router.

  • Page 11: Power Up The Bridge/Router

    Power Up the Bridge/Router Once the LAN and Link connections are made and the console is connected to a terminal, you are ready to power-up the router. Connect the AC power cord to the back of the router and plug the cord into the AC wall outlet. Observe the LEDs as the bridge/router powers up.

  • Page 12: Conventions

    Conventions Throughout this section, P1705 & P1730 menu options are shown that are required for the various configuration choices. The appropriate menu options are shown in each instance in the following format: Configuration Option Name Location: Main The configuration option is shown as well as the options location within the menu system.

  • Page 13: Login To Bridge/Router And Enter The Required Configuration

    Login to Bridge/Router and Enter the Required Configuration At the login screen type a 1 and the default password to enter the menu system of the Router. The default password is “BRIDGE” (case sensitive) and should be changed if security is desired. With the options of the built-in menu system, the router may be configured to operate within your environment.

  • Page 14: Setting The T1/E1Parameters (T1/E1 Wan Only)

    Setting the T1/E1Parameters (T1/E1 WAN only) The parameters required for a T1 or E1 connection may be obtained from your service provider. These may then be entered via the T1/E1 set-up menu to configure the router for that service. T1/E1 Selection: Location: Main T1/E1 Set Up Set the service mode to which this P1705 &...
  • Page 15 E1 service does not require line build out selection. Set Link Interface Type: Location: Main T1/E1 Set Up T1 long-haul LBOs: L0db, L7.5db, L15db, L22.5db Short haul LBOs: S0to110ft, S110to220ft, S220to330ft, S330to440ft, S440to550ft, S550to660ft AT&T standard TR64211long-haul connection: TL0db AT&T standard TR64211 short-haul connection: TS0to110ft, TS110to220ft, TS220to330ft, TS330to440ft, TS440to550ft, TS550to660ft If fractional T1/E1 service is being provided, you will need to specify the channels/timeslots to be used.

  • Page 16: Mandatory Configuration

    Mandatory Configuration The P1705 & P1730 requires a minimum amount of mandatory configuration in order to operate. The following table identifies the configuration parameters that must be defined for proper operation under the operational states shown in the table. Bridge none ISDN - U ISDN Switch Type...

  • Page 17: Identify The Status Leds

    Identify the Status LEDs The four three colour Light Emitting Diodes (LEDs) on the front of the router are depicted in Figure 1-1. The meanings of these LEDs are found in the following chart. Green Green (flashing) Yellow (flashing) POWER Green Yellow Green...

  • Page 18: Typical Applications & How To Configure Them

    Typical Applications & How to Configure Them The P1705 & P1730 are flexible Ethernet Bridge/Routers. This section will describe how to set-up the P1705 & P1730 routers using each of its networking functions. Note that depending on the model of unit and what interface modules are installed, some of the configuration examples may not apply;...

  • Page 19: Bridging And Routing

    Applications Bridging and Routing Should You Bridge or Route? When connecting two networks together, the first question to ask is “should I bridge or route”? The decision to bridge or to route may be decided by how the existing networks have been already set-up.

  • Page 20: Bridging

    Bridging An Ethernet bridge intelligently forwards Ethernet data packet traffic between connected networks. The traffic may be across the Wide Area Network (illustrated below) or, in the case of the P1730, may be between two LANs connected to the same P1730. Network #1 Windows for Workgroups Computers Figure 2 -1 Networks Bridged across a WAN link...

  • Page 21: Ip Routing

    IP Routing An Ethernet IP router is used to intelligently route Internet Protocol (IP) traffic to another network. The networks may be connected across a WAN link (illustrated below) or two LANs connected to the same dual LAN P1730. Router IP Address 199.169.1.10 IP Network Address 199.169.1.0...

  • Page 22: Ip Addressing

    Applications IP Addressing Devices on an IP network are located by their IP addresses, which is a 32 bit number divided into four 8 bit fields. The IP address identifies both the network and the host device (also known as a node) on that network. The address is usually written as the four decimal values for the fields (between 0 and 255) separated by decimal points;...

  • Page 23: Masks

    Applications Masks The portion of the IP address to use as the network address is specified by using a mask; a mask is the contiguous number of bits to be used for the network address all set to 1. When the mask is logically ANDed with an IP address, the result is the network address.
  • Page 24 The P1705 & P1730 allows mask sizes from 8 to 32 bits. The subnet mask size determines how many bits of the host field of the original IP network address will be used for the creation of subnets. In this example, specifying a mask size of 26 will produce a subnet size of 2 bits.

  • Page 25: Ip Default Gateway

    IP Default Gateway An IP default gateway is an IP router that is resident on the local IP network that this router is connected to and is used to route IP frames for destination networks that do not exist in the routing table. When an IP frame is received that is destined for a network that is not listed in the routing table of the router, the router will send the IP frame to the default gateway.

  • Page 26: Ipx Routing

    IPX Routing The P1705 & P1730 are pre-configured to operate as an IPX router. When installed in an IPX network, the router will learn the IPX network numbers from connected networks. It will then route the IPX frames to the appropriate destination IPX network. The IPX routing scenario may consist of one of the two following configurations.

  • Page 27: Novell Servers In One Location Only

    to the IPX frames they receive from the network. Manual entries may be made in the routing tables by adding static IPX routes. Novell Servers in One Location Only Some Novell LAN installations require that a remote LAN that consists of only Novell IPX clients be connected to a central LAN that contains the Novell servers and some more clients.
  • Page 28 The following steps must be performed on the router connected to LAN #2. IPX Routing Disabled Location: Main Disabling IPX routing allows the IPX frame types to be modified. Configuration: IPX Routing does not need to be disabled in order to change the defined Note network numbers on a PPP router.

  • Page 29: Novell Server With Dual Lans

    IPX Forwarding Enabled Location: Main Configuration IPX forwarding must be re-enabled to allow the router to forward IPX frames onto the WAN to the partner router IPX routers. The IPX Forwarding function enables or disables the forwarding of IPX traffic when IPX routing is enabled.

  • Page 30: Ppp Overview

    Applications PPP Overview Point to Point Protocol (PPP) is a connection protocol that allows control over the set-up and monitoring of network communications. It is used in procedures for user authentication (name and password), connection management (spoofing, bandwidth on demand, multilink), and compression.

  • Page 31: Unnumbered Links

    Unnumbered Links An unnumbered link does not use network addressing on the WAN link. The WAN connection is roughly equivalent to an internal connection with each of the two end point routers operating as half of a complete router that is connected between the two endpoint LANs.

  • Page 32: Multilink Operation

    Applications Multilink Operation Multilink operation defines the use of more than one link to connect between two PPP routers. The MultiLink Operation option of the remote site profile for a connection is enabled by default. When a Multilink connection is established, the Multilink (MP) options within the PPP set- up and Advanced PPP set-up menus will determine the operation of the Multilink connection.

  • Page 33: Basic Wan Configurations

    Basic WAN Configurations Basic ISDN Connections If this P1705 & P1730 are configured as an ISDN bridge/router, it may establish WAN connections to other bridge/routers via ISDN (Integrated Services Digital Network) connections. Before the P1705 & P1730 can establish an ISDN connection to another ISDN router, the ISDN information must be defined.
  • Page 34 The following steps must be performed to configure the P1705 & P1730: The default switch type for ISDN S/T interface modules is NET3, the default switch type for ISDN U interface modules is NI-1. If the type of service your provider uses matches the default setting for the interface module, the following step may be skipped, otherwise, the switch type must be set.
  • Page 35 Once the ISDN switch type and directory numbers have been configured, the router must be reset for the new values to take effect and for the ISDN BRI interface to register with the central switch. Soft Reset Location: Main Once the router has restarted it is ready to establish ISDN connections. With the ISDN numbers and switch type defined, an ISDN call may be placed to another properly configured bridge/router.

  • Page 36: Ppp Isdn Manual Call Quick Connections

    Applications PPP ISDN Manual Call Quick Connections The PPP P1705 & P1730 should be configured with a remote site profile entry for each router that will be called (see section 2.3.1). A manual direct dial connection may be performed to establish an initial connection to a remote site router. Once the connection is established and working properly, the remote site configuration for that router should be entered into the router.

  • Page 37: Ipx Router Manual Call Connection

    IPX Router Manual Call Connection To establish an IPX PPP direct dial connection, enter the ISDN phone number of the remote site PPP router in the manual dial option. Refer to the Configure as an Ethernet IPX Router section 2.3.1 for more information on IPX configuration required. Manual Call Location: Main Configuration...

  • Page 38: Basic Frame Relay Configuration

    Basic Frame Relay Configuration North American P1705 & P1730 with at least one non-ISDN interface are configured to have frame relay enabled for that interface by default. P1705 & P1730 shipped outside of North America with at least one non-ISDN interface will have frame relay disabled on that interface as a default setting.

  • Page 39: Auto Learning The Frame Relay Configuration

    Configuration: The default configuration for P1705 & P1730 shipped outside North America is to have frame relay disabled. To run frame relay on these routers, it must first be enabled. Selecting the Frame Relay option will toggle the setting from disabled to enabled. Frame Relay enable Location: Main The router will request confirmation of the change, enter “yes”.

  • Page 40: Manual Configuration - Lmi Type

    If during this learning process the maximum number of remote sites has been reached, the router will prompt you that there are no remote sites available. A new remote site cannot be auto-created unless one of the existing remote sites is manually deleted.

  • Page 41: Quick Start Frame Relay

    Quick Start Frame Relay Since the P1705 & P1730 auto-learns the frame relay configuration, only a couple of parameters need to be configured before the unit is fully operational as an IP router for frame relay. Upon initial start up, the P1705 & P1730 are pre-configured to query the frame relay service to auto-learn the LMI type and the PVC DLCI numbers.

  • Page 42: Basic Leased Line Configuration

    Basic Leased Line Configuration The P1705 & P1730 establishes PPP (Point to Point Protocol) WAN connections to other PPP Leased Line routers or to other vendors PPP leased line routers via direct leased line connections. Either 1 or 2 links may be used to connect to other PPP routers. Configuration: The default configuration for P1705 &...

  • Page 43: Bridge Connection

    The following steps must be performed on each of the routers in the network. Local IP Address Location: Main Configuration This is the IP address and subnet mask for the link of this router in the unnumbered IP connection. Usually the clocking signal is received from the link (see Appendix D - Link Clocking Information).

  • Page 44: Configure Remote Site Profiles

    Configure Remote Site Profiles Remote Site Profiles allow the router to have different sets of configuration parameters for each of the remote site routers that may be called or that may call this router. This allows complete control over the configuration of each possible connection. Each remote site profile is assigned an identification number when it is created, whether it is created automatically under auto-learning or manually by the user editing the remote site profile.

  • Page 45: Configure Remote Site Profiles For Isdn Ppp

    Configure Remote Site Profiles for ISDN PPP If this router is configured to have at least one ISDN switched circuit, the ISDN call parameters must be defined so that the router knows what ISDN phone number to dial when a connection to this remote site is required and what security parameters to use when establishing a connection.
  • Page 46 1 b) Defining this remote site profile within the IP Address connect table, which will cause a call to be made when a packet for this IP address is routed, Location: Main 1 c) Defining the Auto-Call option within the Edit Remote Site menu of this remote site profile.

  • Page 47: Configure Remote Site Profile For Frame Relay

    Configure Remote Site Profile for Frame Relay Each of the PVC’s on the frame relay service must be configured within an individual remote site profile on the router. This is usually done automatically through the auto- learning process. When the frame relay router first starts up it will query the frame relay service to try to determine the PVC configurations.
  • Page 48 The DLCI number defined here is the Data Link Connection Identifier value provided by your frame relay service provider. This value must be set if auto-learning is disabled. Each Remote Site PVC must be defined to exist on one of the two physical WAN links available on this router.
  • Page 49 Location: Main The EIR value specifies the indicated data rate that may be available for this PVC. This value must be set to the same as the value provided by the Frame Relay network provider. When EIR = 0, no excess burst data is allowed to be transmitted.

  • Page 50: Configure Remote Site Profiles For Leased Line Ppp

    Configure Remote Site Profiles for Leased Line PPP Remote Site Profiles allow the router to have different sets of configuration parameters for each of the possible remote site PPP routers that may be connected to this router. This allows greater control over the configuration of each possible PPP connection. Each remote site profile is named with an alias.
  • Page 51 Now that the remote site profile is created, a link number must be assigned as the primary link number. The primary link number is the link interface that the router will use to attempt to establish a connection to the remote site PPP router. Primary Link Number Location: Main Configuration...

  • Page 52: Configure Remote Site Profiles For Frame Relay With Isdn Backup

    Configure Remote Site Profiles for Frame Relay with ISDN backup Frame Relay operation is set-up as described in section 2.3.2 The PVC on both partner routers must be disabled during this set-up procedure, then re-enabled when ready to start. ISDN call set-up is done as described in section 2.3.1. Recovery operation is set-up on the secondary activation menu.

  • Page 53: Configure Remote Site Profiles For Pppoe

    Configure Remote Site Profiles for PPPoE Remote Site Profiles allow for the router to be configured to support PPP over Ethernet (PPPoE) client on the router. The PPPoE feature on the Perle routers provide a PPPoE client support on Ethernet interfaces to a bridging DSL modem to the Internet. This feature will create a PPP tunnel to an ISP located somewhere on the ATM network side of the xDSL modem.
  • Page 54 Location: Main Configuration WAN Set-up Remote Site Set-Up Edit Remote Site Protocol Set-Up Access to some web pages is a common problem experienced when running a PPPoE client on a router. By design, PPPoE packets can support a maximum MTU of up 1492 bytes. Normally when a connection is established over common PPP, the TCP protocol negotiates its maximum data size using the mss option (default 1460).
  • Page 55 Normally your ISP provider will provide you with an outgoing username and password and to authenticate with their services. The PPPoE remote site configuration needs to have the security section configured with this ISP parameters to authenticate the PPPoE connection. Location: Main Configuration WAN Set-Up...

  • Page 56: Advanced Features

    Advanced Features Configure Dynamic Host Configuration Protocol The P1705 & P1730 use Dynamic Host Configuration Protocol (DHCP) to allow users in a small office environment to be added and removed from a network with all of the network information (i.e. IP address, DNS, subnet mask, etc.) being configured automatically. DHCP configures devices (DHCP clients) from a central DHCP server.
  • Page 57 DNS Set-Up Location: Main Configuration -IP address external DNS server External DNS Server (Secondary) Internet Service Provider Figure 2 -10 Local + External DNS Server Configuration The configuration options described here are only for initial set-up and configuration purposes. For more complete information on all of the configuration parameters available please refer to the PPP Menus Manual file on the accompanying CD-ROM.

  • Page 58: Network Address Translation And Port Translation

    Network Address Translation and Port Translation The P1705 & P1730 provide support for Network Address Translation (NAT). Network Address Translation is a technique that translates private IP address on a private network to valid global IP addresses for access to the Internet. Network Address Port Translation (NAPT) translates both the IP address and the port number.
  • Page 59 Private Network Addresses: e-mail server 1.1.1.2 telnet server 1.1.1.3 server 1.1.1.4 1.1.1.6 Figure 2 -11 NAPT Configuration Internet Service Provider 1.1.1.8 Global IP Address: 199.87.65.43 NAPT mapping: 1.1.1.2 = 199.87.65.43 (25) 1.1.1.3 = 199.87.65.43 (23) 1.1.1.4 = 199.87.65.43 (80)

  • Page 60: Security

    Security The router provides a number of means of providing security on incoming and outgoing traffic on a network. These methods include access password authentication, firewall limiting access to only designated device addresses, private network address translation (NAT) and filtering for both incoming and outgoing traffic. Configure PPP Security The PPP P1705 &...
  • Page 61 Remote Site Security Parameters Entry Location: Main Configuration WAN Set up Outgoing PAP Password The outgoing entries in the security database define the user names and passwords/secrets that this authentication request is sent from the remote partner router. The incoming entries define the passwords/secrets that this router expects to receive from the remote partner in response to authentication requests.

  • Page 62: Configure Firewall

    Configure Firewall The P1705 & P1730 provide Firewall security for restricting access between any two networks connected through the router. Firewalls are set-up on a per connection basis for the LAN and remote sites. The direction of filtering is from the perspective of the router; incoming traffic is from the network in question to the router, outgoing is from the router to the network.
  • Page 63 First the firewall on the ISP connection (remote site 1) of the WAN is set-up. The firewall option is set to “inbound” to have this WAN firewall filter traffic from the ISP to the router while allowing unrestricted access out to the Internet. Firewall Location: Main Configuration...
  • Page 64 Then an entry is placed in the firewall table to allow the devices in the branch office remote site to have unlimited TCP access to devices in the head office. Firewall Table Entry Location: Main Configuration Finally, holes are provided in the LAN firewall to allow Internet access to the FTP and WWW servers Firewall Location: Main...

  • Page 65: Network Address Translation

    Applications Network Address Translation Using private addresses on a network and NAT/NAPT for interactions over an internetwork connection hides the internal address from the rest of the world. Access is restricted to only those services that are specifically designated to be available. Please see section 2.4.2 for more information on Network Address Translation.

  • Page 66: Bandwidth On Demand

    Bandwidth On Demand The router may be set to activate its secondary link when the load on the primary link exceeds a user-defined threshold. Set the traffic loads for enabling and disabling the secondary circuit Location: Main Configuration The up and down stability timers are the delay times that the primary link must be above the threshold before the secondary is activated or below threshold before it is brought down.

  • Page 67: Qos - Priority Queuing

    QOS - Priority Queuing Priority Queuing (PQ) allows the users to configure the router to allow specific traffic bound for an outgoing interface to be prioritized into high, medium, normal and low queues. Packets sent to the high priority queue are serviced first, followed by the packets on the medium queue and so on.
  • Page 68 To assign a Priority List to a LAN interface Location: Main Configuration Lan Set-up QOS Set-up Queuing Strategy To assign a Priority List to a Remote Site Connection Location: Main Configuration Wan Set-up Remote Site Set-up Edit Remote Site Protocol Set-up QOS Set-up Priority Priority List Number...

  • Page 69: Simple Network Time Protocol (Sntp)

    Simple Network Time Protocol (SNTP) The Simple Network Time Protocol (SNTP) feature on the Perle Routers support the client side of the protocol as described in RFC 2030. The router will be able to obtain its time from a NTP or SNTP server and then can be synchronized amongst other network devices. Additionally, the router can also be configured to support various time variations features such as local time zone and adjustments for daylight savings time.
  • Page 70 IP Address (XXX.XXX.XXX.XXX) Secondary IP Address IP Address (XXX.XXX.XXX.XXX) Version The time zone and daylight savings time configuration is setup within the device setup menu. To configure for Eastern Standard Time (EST) and have daylight saving time implemented for this year only, implement the following steps: Location: Configuration Access Set-up...

  • Page 71: Introduction To Filtering

    Introduction to Filtering Introduction to Filtering The P1705 & P1730 provide programmable filtering which gives you the ability to control under what conditions Ethernet frames are forwarded from one network to another. There are many reasons why this might need to be accomplished, some of which are security, protocol discrimination, bandwidth conservation, and general restrictions.

  • Page 72: Pattern Filtering

    Pattern Filtering Pattern filtering is provided in three separate sections: Bridge Pattern Filters, IP Router Pattern Filters, and IPX Router Pattern Filters. When the router is operating as an IP/IPX Bridge/Router, each of the frames received is passed on to the appropriate internal section of the router.

  • Page 73: Popular Filters

    Example: ~12-80 brackets Used in pattern filters to separate portions of filter patterns for specific operators. Example: 12-80&(14-24|14-32) This filter pattern will be checked in two Popular Filters Shown here are some of the more commonly used pattern filters. Bridge Bridge pattern filters are applied to Ethernet frames that are bridged only.

  • Page 74: Banyan

    Banyan IP Router IP router pattern filters are applied to IP Ethernet frames that are being routed. When the router is operating as an IP router, all IP routed frames will be checked against the defined IP router pattern filters. IP routed frames are unaffected by the bridge pattern filters and the IPX router pattern filters.

  • Page 75: Appendix A Menu Trees

    Appendix A Menu Trees The menu trees on the following pages are a graphical representation of the hierarchy of the built-in menu system of the P1705 & P1730. Each of the menus are shown with the options of the menus being displayed below the specific menu name.

  • Page 76: Menu Tree

    MAIN Configuration 1] 1] Terminal Set-Up Access Set-Up 1. Terminal Set-Up menu 2. Device Set-Up menu 3. Telnet Set-Up menu 4. Load FLASH Set-Up menu 5. Console 6. Hardware Status 7. TFTP access LAN Set-Up Bridge-STP Set-Up 1. Bridge set-up menu 1.
  • Page 77 Continued from previous page Application Set-Up SNMP Set-Up 1. Edit Community menu 1. SNMP set-up menu 2. Message Size 2. DHCP set-up menu 3. Show Communities 3. Firewall set-up menu 4. Remove Community 4. NAT exports 5. Syslog 6. Time to live Edit Community 7.

  • Page 78: Appendix B Octet Locations On Ethernet Frames

    Appendix B Octet Locations on Ethernet Frames This appendix provides octet locations for the various portions of three of the common Ethernet frames. When creating pattern filters these diagrams will assist in the correct definition of the patterns. The offset numbers are indicated by the numbers above the frame representations.

  • Page 79: Octet Locations On A Bridged Novell Netware Frame

    Octet Locations on a Bridged Novell Netware Frame ETHERNET Type Codes Type Code 0800 0801 0804 0805 0806 0807 6001 6002 6003 6004 6005 6006 6007 8035 803D 803F 809B 80D5 80F3 8137-8138 814C Description DOD IP X.75 Internet Chaosnet X.25 Level 3 XNS Compatibility DEC MOP Dump/Load...

  • Page 80: Octet Locations On An Ip Routed Tcp/Ip Frame

    Octet Locations Octet Locations on an IP Routed TCP/IP Frame Octet Locations on an IPX Routed Novell Netware Frame...

  • Page 81: Octet Locations On A Bridged Xns Frame

    Configuration Pages Octet Locations on a Bridged XNS Frame...

  • Page 82: Appendix C Servicing Information

    Opening of the case and changing of modules is only to be performed by qualified service personnel. Always disconnect the power cord from the rear panel of the bridge/router. The bridge/router case does not need to be opened to change LAN or WAN interface modules.

  • Page 83: Identifying The Internal Components

    Servicing Information Identifying the Internal Components The major components of concern are shown in the following illustration. Primary LAN Link 2 Link 1 & Console Interface Module Interface Module LAN 2 (ISDN BRI, DSU, Interface Module G.703, RS232, V.35, RS422 or V.11) (ISDN BRI, DSU, G.703, RS232, V.35, RS422 or V.11)

  • Page 84: To Clear A "Lost" Password

    To Clear a “Lost” Password Remove power from the bridge/router. Remove the screw securing the LAN / Console module to the rear of the bridge/router. Be sure to grip the module only by the flange at the bottom of the metal panel.

  • Page 85: Installing The Isdn Link Modules

    Installing the ISDN Link Modules If there is an ISDN module plus another type of WAN interface module or if there is a single ISDN module, the ISDN U or S/T Module must only be installed in the Slot 1 position. The slot 2 position may contain another type of WAN module or may be unused and covered with a blank panel.

  • Page 86: Changing The Termination Straps On The Isdn S/T Interface

    Changing the Termination Straps on the ISDN S/T Interface The ISDN S/T link interface module has two configurable straps that control whether the ISDN LINE is set to terminated or unterminated. Jumper straps W5 and W6 are factory installed to configure the module as TERMINATED. The TERMINATED position is used when the bridge/router is the only ISDN device connected to the ISDN circuit.

  • Page 87: Performing A Software Upgrade

    Performing a Software Upgrade Execute the Network (TFTP) command from the Load FLASH Set-Up menu. Enter “none” to connect locally or enter the remote site ID number or alias to connect to a remote site. Start the TFTP application to be used for transfers to the router. (The IP address of the router may be found in the Internet Set-Up menu.).
  • Page 88 In the following diagram of a cluster of routers, when upgrading the three routers in the diagram, the upgrade order should be Router C, then Router B, and finally Router A. A TFTP software load to router C would be performed as follows: Using TFTP, get config.txt from each router and save.

  • Page 89: Appendix D Interface Pinouts

    Servicing Information Appendix D Interface Pinouts Pinout Information Each link interface available is described with detailed information on pin designation. Standard interface cables will provide correct connections to modems, datasets, or DSU/CSUs. When connecting two bridge/routers back-to-back without modems, a null-modem cable is required to crossover the pins on the links.
  • Page 90 These modules may have either the UP/DOWN switch type or the ON/OFF slide switch type. Each type is illustrated below. Figure D-1 Rear View of ATL-CSU/DSU Link Module with UP/DOWN Switches Figure D-2 View of ATL-CSU/DSU Link Module with Sliding ON/OFF Switches When connecting two bridge/routers back-to-back with CSU/DSU link modules, a null-modem cable is required to crossover the pins on the links.

  • Page 91: Console Pinouts

    Console Pinouts The connector shown here and pinouts described here correspond to the connector labeled “Console” on the back of the P1705 & P1730. DB25 Female DCE Contact CCITT IEEE Number Circuit Circuit Number Desig. 108.2 Figure D-3 Console Pinouts The connecting cable must be a shielded cable.

  • Page 92: V.24 & Rs232C Link Pinouts

    V.24 & RS232C Link Pinouts The connector shown here and pinouts described here correspond to the connector labeled “RS232 / V.24” on the back of the P1705 & P1730. DB25 Female DTE Contact CCITT Circuit Number Circuit Number 108.2 Transmit Signal Element Timing (DTE Source) The connecting cable must be a shielded cable.

  • Page 93: V.11/X.21 Link Pinouts

    V.11/X.21 Link Pinouts The connector shown here and pinouts described here correspond to the connector labeled “V.11/x.21” on the back of the P1705 & P1730. DB15 Female DTE X.21 Contact Circuits Number Reference T (A) C (A) R (A) I (A) S (A) Ground T (B)

  • Page 94: Rs442 & Rs530 Link Pinouts

    RS442 & RS530 Link Pinouts The connector shown here and pinouts described here correspond to the connector labeled “RS530” on the back of the P1705 & P1730. DB25 Female DTE Contact Number Circuit Shield BA (A) BB (A) CA (A) CB (A) CC (A) CF (A)

  • Page 95: V.35 Link Pinouts

    V.35 Link Pinouts The connector pinouts described here correspond to the connector labeled “V.35” on the back of the P1705 & P1730. DB25 M.34 Contact Contact Number Number Data Channel Received Line Signal Detector Transmitter Signal Element Timing (A) DTE Transmitter Signal Element Timing (B) DTE The connecting cable must be a shielded cable.

  • Page 96: Rs232 Null-Modem Cable Configuration

    RS232 Null-Modem Cable Configuration DB25 MALE Shield Transmitted Data Received Data Request To Send Data Set Ready DTE Ready Signal Ground Received Line Signal Detector (CD) Transmit Timing DCE Source Receiver Timing DCE Source Transmit Timing DTE Source Figure D-9 RS232 Null-Modem Cable The connecting cable must be a shielded cable.

  • Page 97: V.35 Null-Modem Cable Configuration

    V.35 Null-Modem Cable Configuration DB25 MALE Protective GND Transmitted Data (A) Transmitted Data (B) Received Data (A) Received Data (B) Transmitter Signal Element Timing (A) Transmitter Signal Element Timing (B) Receiver Signal Element Timing (A) Receiver Signal Element Timing (B) Transmitter Signal Element Timing (A) Transmitter Signal Element Timing (B) Data Terminal Ready...

  • Page 98: Rs530 Null-Modem Cable Configuration

    RS530 Null-Modem Cable Configuration DB25 MALE Shield Transmitted Data (A) Transmitted Data (B) Received Data (A) Received Data (B) Request To Send (A) Request To Send (B) Clear To Send (A) Clear To Send (B) DCE Ready (A) DCE Ready (B) DTE Ready (A) DTE Ready (B) Signal Ground...

  • Page 99: Rs530 To Rs449 Conversion Cable

    RS530 To RS449 Conversion Cable DB25 MALE Receiver Signal Element Timing (DCE Source) (A) Receiver Signal Element Timing (DCE Source) (B) Transmit Signal Element Timing (DCE Source) (A) Transmit Signal Element Timing (DCE Source) (B) Transmit Signal Element Timing (DTE Source) (A) Transmit Signal Element Timing (DTE Source) (B) Figure D-12 RS530 to RS449 Conversion Cable The connecting cable must be a shielded cable.

  • Page 100: V.11/X.21 Null-Modem Cable Configuration

    V.11/X.21 Null-Modem Cable Configuration Figure D-13 V.11/X.21 Null-Modem Cable The connecting cable must be a shielded cable. Circuits which are paired (contain an (A) and (B) reference) should be connected to twisted pairs within the connecting cable. This cable is needed when it is necessary to connect two units back-to-back and a set of modems is not available.
