- Page 1 ELS PA10 User Guide and Reference Manual 6122 S. Eastern Ave Los Angeles, CA 90040 www.AmericanAudio.us 9/13...
-
Page 2: Table Of Contents
All Rights Reserved. All content, trademarks and logos are copyright by their respective owners. The Blue- tooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is under license. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 2 © ®... -
Page 3: Els Pa10
To prevent electromagnetic inter- ference with electrical appliances such as radios and televisions, use shielded cables and connectors for connections. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 3 © ®... - Page 4 EQUIPMENT GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM Fig. A (NEC ART 250, PART H) NEC — NATIONAL ELECTRICAL CODE American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 4 © ®...
-
Page 5: Safety Precautions
7. Never disassemble or modify your unit in 18. Always have the trim controls set to their any way, doing so will void your manufactures lowest level during initial power-up to prevent warranty. speaker damage. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 5 © ®... -
Page 6: Unpacking
American Audio customer support. ® Do not discard the packing carton in the trash. Please recycle when ever possible. ELS PA10 SET-UP PRECAUTIONS Please be sure to make any connections before plugging the player in to an electrical outlet. All fader and volume controls should be set to zero or minimum position, before the player is switched on. If the player has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch on the player immediately. The arising condensation of water might damage your device. Leave the device switched off until it has reached room temperature. Operating Determinations: • When installing this player, please make sure that the device is not exposed or will not be ex- posed to extreme heat, moisture or dust! • Do not operate the player in extremely hot (more than 30°/100°F) or extremely cold (less than 5°C/40°F) surroundings. • Keep the unit out of direct sunlight and away from heaters. • Operate the player only after becoming familiar with its' functions. Do not permit operation by persons not qualified for operating the unit. Most damages are the result of unprofessional opera- tion. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 6 © ®... -
Page 7: Controls And Functions
P R T MO D E S T O P P L AY V O L + V O L - MO D E P O W E R American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 7 © ®... - Page 8 - Do not plug instrument outputs into the Mic input jacks with Phantom Power on, unless you know for sure it is safe to do so. 5. LEFT/RIGHT SPEAKER OUTPUTS - These are the powered speaker outputs designed for each of American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 8 © ®...
- Page 9 3 meters from your audio installation. 1. PLAY/PAUSE BUTTON 2. VOLUME - 3. VOLUME + 4. NEXT 7. PREVIOUS 8. EQ SELECT 9. USB/SD MODE American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 9 © ®...
-
Page 10: Cable & Mixer Storage
CLOSE Check to make sure the connection is secure before picking up the system and transporting. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 10 © ®... -
Page 11: Connectors
Black/LOW D. STANDARD PHONE Shield/GND Unbalanced (XLR) high impedance: most hi-fi equipment. White(Black)/HIGH E. SHIELD/GND Unbalanced PHONE Shield/GND high impedance: most (Standard Phone) hi-fi equipment. Connector and cable configurations are recommended for use with the M 4 bus series. These cables are based on the use of auxillary equipment that is isolated from the AC power mains. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 11 © ®... -
Page 12: Set Up
S N : A C L IN E I N P U T 1 1 0 V ~2 4 0 V 5 0 / 6 0 H z American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 12 © ®... - Page 13 Stick drives. ELS PA10 MOUNTING Pole Mounting – The ELS PA10 also include a pole mount option. The pole mount socket located on the bottom of the speaker may be used to secure the speaker to a speaker tri-pod, such as the American Audio SPS-1B or the SPS-2B. Always be sure to follow the guidelines listed below when ® pole mounting your speaker; • Always be sure the stand is designed to support the weight of the speaker • In outdoor situations that are prone to windy conditions and strong wind gust, be sure to use sandbags as additional tri-pod support, this will greatly reduce the risk of tipping • Do not stack speakers on top of each other when mounting on a tri-pod. Only one speaker should be mounted to a tri-pod at one time. • Always position the tri-pod legs away from foot traffic • Extend the tri-pod legs to their fully extended position to avoid accidental tipping • Observe and follow all safety guidelines and regulations specified by the tri-pod’s manufac- turer • Be sure the tri-pod is situated on a flat, level, and stable surface • Always tighten all tri-pod locks American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 13 © ®...
-
Page 14: Cleaning
I hear noise in mix Check your power a 60Hz hum, could come from ungrounded equipment. Turn all the faders down one at a time and the stereo return knob. If the noise goes away it’s that channel or the source. Disconnect the source from the mixer bring up that fader if the noise is gone it your source, If it is the source try bringing down its out put volume. I have no power Make sure your power supply is properly hooked up to the unit. Check the fuse, be sure it hasn’t popped. I can’t hear the mix on my headphones or my control room monitors Check the phones / control room knob, Select the proper source. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 14 © ®... -
Page 15: Warranty
® chantability or fitness, are limited in duration to the warranty period set forth above. And no warran- ties, whether expressed or implied, including warranties of merchantability or fitness, shall apply to this product after said period has expired. The consumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly provided above; and under no circumstances shall American Audio be liable for any loss or damage, direct or consequential, arising out of the use of, or inability ® to use, this product. G. This warranty is the only written warranty applicable to American Audio Products and supersedes ® all prior warranties and written descriptions of warranty terms and conditions heretofore published. American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 15 © ®... -
Page 16: Specifications
8 ohm, Both Channels Driven W/ THD <1% INPUT IMPEDANCE: (Channels 1-4) “Mic” 2k ohm Line 33k ohm MAX. INPUT LEVEL: -7dBu LINE INPUT LEVEL: 30dBu STEREO INPUT LEVEL: 26dBu RETURN INPUT IMPEDANCE: 47k ohm EQ SPECIFICATIONS: HIGH: 10kHz +/-6dB LOW: 100Hz +/-6dB American Audio - www.americanaudio.us - ELS PA10 Instruction Manual Page 16 © ®... - Page 17 ELS PA10 NOTES ©American Audio® World Headquarters: 6122 S. Eastern Ave. Los Angeles, CA 90040 USA Tel: 323-582-3322 Fax: 323-582-2941 Web: www.americanaudio.us E-mail: info@americandj.com American DJ Europe Junostraat 2 6468 EW Kerkrade Netherlands service@americandj.eu / www.americandj.eu Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99...
