2 1000 Series Product Features

All 1000 Series Models Feature:

Mechanical Temperature Control. Provides ability to set the
temperature.
Vinyl-clad cabinet. Textured, rich appearance. More resistant to
scratching, peeling and flaking.
Integrated handle. Does not add depth to the cabinet when
built in. Black and white models only.
Field-reversible doors. Flexible installation options. All models
with black and white doors are field-reversible. Stainless steel
models with glass doors are field-reversible. Stainless steel models
with solid doors must be order right- or left-hand hinged.
Adjustable leveling legs. Achieve a more precise under counter
fit. Durable, strong legs will not bend when unit is installed.
Defrost Type: Automatic (cycle) Defrost.
For indoor use only.
Wine Captain® Model and Beverage
Center Features:
Low-E coated, gas filled thermal glass door. Allows for
effective product presentation. Protects wine and other products
from potentially harmful ultraviolet light rays.
Wood trimmed wine racks. Wood can be stained or replaced
with a solid surface material to match surrounding décor.
Stainless steel model. Offers a bold stainless steel handle,
stainless steel wrap door with black "cap" on top and bottom of
the door.
Flat recessed grille. Blends with the other models and
integrates with surrounding cabinetry.
Wine Captain® Model Features:
Capacity. 24" Wine Captain Model up to 48 Bottles.
Triple temperature zones. Maintains wine at their proper
serving temperature. Top Approximately 55°F (Red). Middle
Approximately 50°F (White). Bottom Approximately 45°F
(Sparkling). Safely stores one, two or three types of wine.
3/4 extension slide-out coated wine racks. Allow for easy
access to all wine bottles. Four or eight wine bottle capacity
(0.75 L) on each rack.
Stable temperatures. Stable, consistent temperatures provide
longer-term storage capability.
Built-in. Provides custom look. No additional clearance required
around sides, top or rear of unit for ventilation. Do not obstruct
front grille.

Beverage Center Features:

Capacity. 24" Beverage Center 5.6 cubic feet
Dual temperature zones. Maintain two distinct temperature
zones. Cooler at the top of the cabinet for storage of fine wines
and coldest at the bottom to store your favorite beverages.
Two full-size, removable glass shelves. Generous storage area
for beverages.
3/4 extension slide-out coated wine racks. Allow for easy
access to beverages.
Built-in or freestanding. Provides custom look when built-in
with no additional venting clearance required on sides, top or rear.
Do not obstruct the grille.

Refrigerator and Freezer Features:

Capacity. 29 Model Refrigerator Capacity 3.3 cubic feet.
75F Model Freezer 5.22 cubic feet.
Recessed interior light. Automatically illuminates when door is
opened. Does not interfere with product access or storage.
Adjustable tempered glass shelves. Sleek, streamlined
interior. Allows flexible shelf locations to meet varying food and
beverage storage needs. Three in Refrigerator, four in freezer.
Two adjustable in-door storage shelves. Easy access storage
area, right where you need it. Adjustable to allow flexible storage
options.
Door will accept a 1/4" panel. Ability to match surrounding
décor and cabinets. Black and white models only.
Built-in or freestanding. Provides custom look when built-in
No additional venting required on sides, top or rear. Do not
obstruct the grille.
Flat recessed grille on Refrigerator. Blends with the other
models and integrates with surrounding cabinetry.
Model 29 Refrigerator is Energy Star qualified. Saves energy,
saves money, saves our natural resources.
All features and specifications are subject to change.
U-Line 1000 Series Product Features
3
