Dragon
User Manual
DUALi Inc.
Document Version: 1.0
Last Revised Date: 3
Copyright ⓒ 2012 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use
this document in part or as a whole for any purposes other than those for which this document is disclosed. This
document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
Any unauthorized use, copy, disclosure or distribution constitutes infringement of DUALi's intellectual property
rights.
rd
May 2012
Advertisement
Table of Contents
Related Manuals for Duali Dragon
Summary of Contents for Duali Dragon
- Page 1 May 2012 Copyright ⓒ 2012 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
- Page 2 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
- Page 3 Dragon User Manual Revision History 2012.05.03(Ver. 1.0) : First Distribution(JMN, HTY) Version: 1.0 DUALi Inc. (http://www.duali.com)
-
Page 4: Table Of Contents
Dragon User Manual Contents Introduction ..........................5 Hardware Specification ....................6 Structure...........................7 The Structure of equipment..................... 7 The block diagram of Dragon..................7 Description of Surface ......................8 The picture of device surface ..................8 Communication Cable.....................8 The size of terminal ......................8 Description of Electricity......................9 The Description of power .................... -
Page 5: Introduction
Dragon User Manual Introduction Dragon is contact-less Smartcard reader which supports14443 TYPE-A/B, Mifare series, Felica and NFC (ISO18092)protocol at the same type. It also supports Contact cards (1 X SIM type slots) which comply with ISO 7816 for secured data transmission. Dragon is available as USB interface. -
Page 6: Hardware Specification
1 SIM slot for SAM Card (ISO7816, T=0,T=1) Host Interface USB 2.0 Full Speed (12Mbps) as default / RS232 (Optional, contact to DUALi for more information) Host Communication PC/SC or Vendor Protocol (must be decided with order) ARM 32-bit Cortex-M3(48MHz) -
Page 7: Structure
Dragon User Manual Structure The Structure of equipment - Dragon itself contains all circuits include antenna, 1 SAMs and connectors. (USB) Host PC Dragon The block diagram of Dragon SAM Socket (SAM1) Smart Card Socket (ST-ARM 32-bit PN512 RF IC... -
Page 8: Description Of Surface
The picture of device surface - N mark on top of the surface could be removed or replaced to requested logo for OEM. Communication Cable Direct USB cable The size of terminal Dragon :62(W) * 95(L) * 13(H)mm Version: 1.0 DUALi Inc. (http://www.duali.com) -
Page 9: Description Of Electricity
Dragon User Manual Description of Electricity The Description of power Input power : 5V (USB Bus Powered) The using electric current Normal 5V, 100mA under 5V, 250mA under The Description of USB communication USB V2.0 FULL SPEED (12Mbps) Description of Function Protocol Specification Refer to protocol specification for detail function. - Page 10 ‣ Warranty and Repair service - DUALi Inc. warrants to the original consumer or other end user that this product, Dragon, is free from defects in materials and workmanship for a period of 1 year from the date of purchase (shipment date).
