Duali DE-960 User Manual

Hide thumbs Also See for DE-960:
Table of Contents

Advertisement

Quick Links

Download this manual
DE-960
User Manual
DUALi Inc.
Document Version: 1.10
Last Revised Date: 8
Copyright ⓒ 2016 DUALi Inc. All rights reserved. You are strictly prohibited to
copy, disclose, distribute, or use this document in part or as a whole for any
purposes other than those for which this document is disclosed. This document is
copyrighted and contains confidential information and other intellectual property
rights of DUALi Inc. Any unauthorized use, copy, disclosure or distribution
constitutes infringement of DUALi's intellectual property rights.
Release Date: 25 November
2009
th
. JUN 2017
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE-960 and is the answer not in the manual?

Questions and answers

Related Manuals for Duali DE-960

Summary of Contents for Duali DE-960

  • Page 1 Last Revised Date: 8 . JUN 2017 Copyright ⓒ 2016 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
  • Page 2 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
  • Page 3 Revision History 2016.12.16 (Ver. 1.00) : First Release   2017.06.08 (Ver. 1.10) : Entering user/Admin setting mode, factory reset option, Certification information added. DE-960 User Manual Document Version: 1.10...

  • Page 4: Table Of Contents

    KEY Push Buzzer option set ....................16 RF Scan option set ........................17 Function configuration (KEY setting) ..................18 Enter admin setting mode ....................18 10.1 Enter user setting mode ......................18 10.2 KEY Mode setting ........................19 10.3 DE-960 User Manual Document Version: 1.10...
  • Page 5 KEY Push Buzzer setting ...................... 20 10.5 Wiegand Length setting ......................20 10.6 Wiegand Data Foward / Reverse setting ............... 21 10.7 Factory reset ..........................21 10.8 Certifications ............................22 Warranty & Service ..........................23 DE-960 User Manual Document Version: 1.10...

  • Page 6: Introduction

    1 Introduction DE-960 is refined design of proximity reader which supports contactless (ISO14443 A/B type, Mifare™, FeliCa®). It supports 32/34/64/66-bit Wiegand format with a host communication which is the most widespread system. It’s applicable to various system such as access control, time attendance, parking management or e-ID system.

  • Page 7: Hardware Specification

    Remote Reader Module - 10 feet (3m) Cable Distance Wiegand Interface - 500 feet (152m) Recommended cable is ALPHA 1295C (22AWG) 5-conductor stranded with overall shield or equivalent Certification KC, CE, FCC, IP65 Compatible DE-960 User Manual Document Version: 1.10...

  • Page 8: Appearance & Installation

    Φ4mm Flat head screw Connect the power and communication Place the wall mount bracket on the wall cable to DE-960’s terminal block. In and fix it tightly with screw (Φ4mm Flat case you don’t use the cable as it is head) –...

  • Page 9: Connection Diagram

    Please refer to the below diagram for the connection. PIN NAME COLOR PIN NUMBER PWR_IN PWR_GND BLACK RS232_RX GRAY RS232_TX JADE WGD_D0 GREEN WGD_D1 WHITE PWR_GND BLUE BROWN BEEP YELLOW TAMPER VIOLET RS485+ ORANGE RS485- SKY BLUE DE-960 User Manual Document Version: 1.10...

  • Page 10: Operation & Usage

    RED LED ON RED LED OFF BLUE LED OFF BLUE LED ON 6. Buzzer Control : Reader makes beep sound when BEEP Signal(BROWN) with 0V. BUZZER OFF BUZZER ON BUZZER OFF DE-960 User Manual Document Version: 1.10...

  • Page 11: Output Format

    Mifare® card – Card serial number(4bytes)+0x00(4bytes) Last Bit 66 : Odd parity of bit 34 ~ bit 65(Data[33-64]) <32bit> Data[0-31] : ID number(transmission data) <64bit> Data[0-63] : FeliCa™ card – IDM data(8bytes) Mifare® card – Card serial number(4bytes)+0x00(4bytes) DE-960 User Manual Document Version: 1.10...

  • Page 12: Wiegand Output Timing And Level

    8 Wiegand output timing and level 63uS 1.99mS DE-960 User Manual Document Version: 1.10...

  • Page 13: Function Configuration (Communication Setting)

    (115,200bps, 8 data, no parity, 1 stop bit) LENH LENL DATA[0] 0x02 0x00 0x02 0xE1 0- BLUE LED LENL ^ CMD ^ DATA[0] 1- RED LED ON DE-960 User Manual Document Version: 1.10...

  • Page 14: Mifare Key Type, Block Number, Id Position, Wiegand Format Option Set

    ID Position: 0 ~ 0xFF Wiegand Data length: 0x04  Wiegand 32bit DATA[10] Wiegand Length 0x07  Wiegand 56bit Else anything: Wiegand 64bit Cf. Wiegand 34Bit, 48Bit, 66Bit is following Wiegand Parity option of command 0xE0 bit2. DE-960 User Manual Document Version: 1.10...

  • Page 15: Key Mode Option Set

    0x02 DATA[1] DATA[2] LENL ^ CMD ^ DATA[0] ( ^ : exclusive oring) DATA[x] State Description DATA[1] MINIMUM Length Set password minimum length (Range: 1~11) DATA[2] MAXIMUM Length Set password maximum length (Range: DATA[1]~12) DE-960 User Manual Document Version: 1.10...

  • Page 16: Key Timeout Option Set

    (115,200bps, 8 data, no parity, 1 stop bit) LENH LENL DATA 0x02 0x00 0x02 0xE3 0x05 DATA[1] LENL ^ CMD ^ DATA[0] ( ^ : exclusive oring) DE-960 User Manual Document Version: 1.10...

  • Page 17: Rf Scan Option Set

    TYPE-A / MIFARE Scan Off Bit7 TYPE-A / MIFARE Scan ON TYPE-B Scan Off Bit6 TYPE-B Scan ON FELICA Scan Off Bit5 FELICA Scan ON Bit4 15693 Scan Off Bit3 15693 Scan ON Bit2 ~ Bit0 DE-960 User Manual Document Version: 1.10...

  • Page 18: Function Configuration (Key Setting)

    10 Function configuration (KEY setting) 10.1 Enter admin setting mode Using DE-960 Touch KEY, you can enter admin setting mode. <How to enter Admin setting mode> 1. Press “*” “*” (two times) “5” “#”, buzzer sounds and it enters “Admin password input mode”...

  • Page 19: Key Mode Setting

    Buffer Mode Input KEY Buffer mode Press option number and “#” to save option to flash memory. Then DE-960 will reboot. Press“*” to return to setting menu. It would be set to 1 (Direct Mode + PIN) If you press other buttons except 1~4.

  • Page 20: Key Push Buzzer Setting

    ALL Buzzer OFF Buzzer all turns off about KEY Press option number and “#” to save option to flash memory. Then DE-960 will reboot. Press“*” to return to setting menu. It would be set to 1 (ALL Buzzer ON) If you press other buttons except 1~3.

  • Page 21: Wiegand Data Foward / Reverse Setting

    Wiegand Data Sending Reverse “# Press option number and “#” to save option to flash memory. Then DE-960 will reboot. Press“*” to return to setting menu. It would be set to 1 (Data Send Forward) if you press other buttons except 1~2.

  • Page 22: Certifications

    - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. *Please contact our service team for the technical/ sales supports DE-960 User Manual Document Version: 1.10...

  • Page 23: Warranty & Service

    12 Warranty & Service ‣ Warranty and Repair service - DUALi Inc. warrants to the original consumer or other end user that this product, DE-960, is free from defects in materials and workmanship for a period of 1 year from the date of purchase.
  • Page 24 *Please contact our service team for the technical/ sales supports. DUALi Inc. 1-309 Innoplex, 552 Wonchoen-dong, Youngtong-gu, Suwon, Gyeonggi-do, Korea (zip: 443-380) Tel : +82 31-213-0074 Fax : +82 31-213-0078 E-mail : lab@duali.com Web-site : http://www.duali.com DE-960 User Manual Document Version: 1.10...
