Dragon BT
User Manual
DUALi Inc.
Document Version: 1.63
Last Revised Date: 18
Copyright ⓒ 2015 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use
this document in part or as a whole for any purposes other than those for which this document is disclosed. This
document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
Any unauthorized use, copy, disclosure or distribution constitutes infringement of DUALi's intellectual property
rights.
Release Date: 25 November 2009
6
th
Feb 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dragon BT and is the answer not in the manual?

Questions and answers

Related Manuals for Duali Dragon BT

Summary of Contents for Duali Dragon BT

  • Page 1 Feb 2020 Copyright ⓒ 2015 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
  • Page 2 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
  • Page 3 Dragon BT User Manual Revision History  2014.12.30(Ver.1.00): First release  2015.01.26(Ver.1.10): Change battery ADC value to percentage (%).  2015.02.12(Ver.1.20): Booting Pi-bi-beep sound twice when HID mode is enabled Added Android device connection  2015.02.13(Ver.1.30): NDEF Tag Read Function(0xE7) add ...

  • Page 4: Table Of Contents

    Dragon BT User Manual CONTENTS OVERVIEW ..............................5 COMPONENT CONFIRMATION ........................ 6 HARDWARE SPECIFICATION ........................7 3.1 B ..........................7 ASIC SPECIFICATIONS 3.2 B .......................... 8 LUETOOTH SPECIFICATION DESCRIPTION OF PARTS ......................... 9 OPERATION ............................. 10 5.1 B ............................. 10...
  • Page 5 Dragon BT User Manual 7.4 SPP/ HID ........................... 34 MODE CHANGE 7.5 HID ........................34 OUTPUT ONFIGURATION 7.6 B ............................ 34 UZZER IBRATION 7.7 S ......................... 34 LEEP MODE TIME CHANGE 7.8 M ..........................35 IFARE CARD READING 8. WARRANTY & SERVICE ..........................36 Version 1.63...

  • Page 6: Overview

    Dragon BT User Manual 1. Overview Dragon BT is compact hand held type NFC reader which sends reading data from NFC tags to Host (PC/Smart phone/Tablet PC). It is ideal for organizations where frequented, but intermittent, use of personal computers, tablet PCs and Smartphones.

  • Page 7: Component Confirmation

    Dragon BT User Manual 2. Component confirmation  1 Dragon BT  1 micro USB cable (option)  SDK – SDK PROGRAM, DRVIER, APK sample download link Dragon BT Mini USB cable (Option) Version 1.63 DUALi Inc. (http://www.duali.com)

  • Page 8: Hardware Specification

    Dragon BT User Manual 3. Hardware Specification 3.1 Basic specifications ITEM Specification NOTE STM32F103CBT6 Cortes-M3(ARMv7),48MHz, 32bit RISC Program Memory 128KByte FLASH Data Memory 20KByte SRAM RF Chip SIC9410 (MIFARE, ISO14443, ISO15693, FeliCa, NFC Tag) Display 4 STATUS LED (Power, Battery, RF, Bluetooth)

  • Page 9: Bluetooth Specification

    Dragon BT User Manual 3.2 Bluetooth specification ITEM Specification Note Enhanced Data Rate) specification Bluetooth v.2.1 + EDR ( Class Bluetooth class 2 radio Transmit Power +3dBm Receiver Sensitivity -86dBM Range 30 meters line-of-sight (Recommend to use within 10 m)

  • Page 10: Description Of Parts

    Dragon BT User Manual 4. Description of Parts The following describes Dragon BT reader operation. 1) LED Indicator ▪ Power: Blinks when it acts. Normal mode – Blinks every time when it tries to read card Stand- by mode low battery (under 30%) – Blinks twice every 3 seconds Stand- by mode –...

  • Page 11: Operation

    Dragon BT User Manual 5. Operation 5.1 Basic Operation Reader automatically reads UID of supported cards and uploads data through connected Bluetooth interface (SPP or HID) when it is booted. Reader stops automatic UID reading when it received any command from host device through USB or Bluetooth (SPP).

  • Page 12: Pairing With Pc (Hid Mode)

    Dragon BT User Manual 5.4 Pairing with PC (HID mode) Make sure Dragon BT is in HID mode (Production default is HID mode). When Dragon BT is in SPP mode, please convert reader into HID mode (refer to Chapter.7.4) ...
  • Page 13 Dragon BT User Manual From Bluetooth setting menu, make sure the function is On. Click + Add Bluetooth or other device, then available device will be shown on the list. Version 1.63 DUALi Inc. (http://www.duali.com)
  • Page 14 Dragon BT User Manual Select Dragon BT, and click to pair. The message will be shown when deice is successfully paired When Dragon BT is connected as Keyboard emulation mode (HID Mode), the icon will look like keypad. Version 1.63 DUALi Inc.

  • Page 15: Pairing With Pc (Spp Mode)

    Dragon BT User Manual When Dragon BT is connected via Bluetooth, it’ll forward Card’s UID into any open window like below image.  Caution: Dragon BT automatically works as vendor reader while it’s connected to PC via USB, so do not connect USB cable when it operate as Bluetooth interface.
  • Page 16 Dragon BT User Manual The message will be shown when deice is successfully paired When Dragon BT is connected as SPP mode, the icon will look like above. Version 1.63 DUALi Inc. (http://www.duali.com)
  • Page 17 Dragon BT User Manual  How to check comport communication Control panel -> Hardware and sound -> Devices and Printers Click right button of mouse and select Properties In Hardware tap, confirm the Comport number. <Dualcard program> When using Dualcard, please select same COM Port and click [Connect] button It takes about 1sec to get connection unlike standard serial communication Version 1.63...
  • Page 18 1) When Dragon BT reboots it’s looking for reconnection in HID mode.  Once Dragon BT paired with previously connected device, LEDs become normal. 2) When Dragon BT restarted after change mode from HID -> SPP. Dragon BT is looking for reconnection.

  • Page 19: Pairing With Smart Phone (Android Os Phone, Spp And Hid)

    Execute provided “DragonBT” apk on Smart phone. When phone’s Bluetooth is off, please [Allow] to turn on and select Dragon BT. If it is your first time pairing, following message box will pop up. Click [Pair]. Once the device is paired, you’ll see connected device name on top of apk.
  • Page 20 Android device, Dragon BT need to set HID capable mode Dragon BT is on HID capable mode when it beeps twice while booting. Dragon beeps only once while booting means HID isn’t capable. Please change mode setting refer to chapter “5.HID Set and confirm operation (0xEE)”...
  • Page 21 Dragon BT User Manual While Dragon BT is connected, connection status will be displayed and Dragon BT is ready to receive card information Open any window or notepad on smartphone, and touch NFC tags into Dragon BT Cardtype & UID will be displayed automatically in HID mode ...
  • Page 22 Dragon BT User Manual To re-pair Dragon BT, following message pops up. Click F from “Input Device” from Setting and try pairing again. Version 1.63 DUALi Inc. (http://www.duali.com)

  • Page 23: How To Connect Pc (Usb) And Update Firmware

    To communicate via USB interface with host, please install USB driver in provided SDK. Install driver refer to manual, and connect Dragon BT in PC. Once it’s connected to DualCard.exe, it’s capable to be controlled by this software same as the DUALi devices.
  • Page 24 Dragon BT User Manual Click [F/W file Down] to start downloading. Once download completed without error, “Download OK: ‘updated firmware version’” will be shown. Press button and retry download within 10 second if download was failed at first trial. (Or, keep button pressed while download process bar is increasing) Version 1.63...

  • Page 25: How To Operate / Led Indication

    Power LED becomes blue and device is ready  Dragon BT is default set is HID communication.  While booting Dragon BT, it beeps 1time it means the device in “SPP” mode, when it beeps 2 times, Dragon BT is in “HID” mode ...
  • Page 26 Dragon BT User Manual Flow chart Version 1.63 DUALi Inc. (http://www.duali.com)

  • Page 27: Command Set

     0x00 (response data) means SPP mode  0x01 (response data) means HID mode (Keyboard emulation mode) While Dragon BT set HID mode and connected Host, it detects card automatically and displays CARD ID(UID) into any open window (works as keyboard emulation mode) Version 1.63...

  • Page 28: Mifare Card Read Setting (0Xe2)

    Dragon BT User Manual 6.2 MIFARE card read setting (0xE2) This command is used to read specific block of MIFARE card instead of UID DATA in HID mode. LENH LENL DATA 0x02 0x00 0x0B 0xE2 Data[0..9] Data Value Description 0x00...

  • Page 29: Data Transmit Option Setting (0Xe3)

    Dragon BT User Manual 6.3 Data Transmit Option setting (0xE3) LENH LENL DATA 0x02 0x00 0x0_ 0xE3 Data[0..1] Data[0] Data[1] Description 0x00 Hexadecimal to ASCII Transmit 0x21 0x01 Integer type ASCII Transmit 0x02 Hexadecimal itself Transmit 0x00 Normal order Transmit...

  • Page 30: Battery Info Get (0Xe4)

    Dragon BT User Manual 6.4 Battery Info Get (0xE4) To check Battery Level, send 0x E4 (Command) Response data: 0x63(=99%) means battery is full, 0x00(=0%) means it’s out of battery. 6.5 Device Name Info Get(0xE5) To check Device name, send 0xE5(Command) 0x 00(Data). it only confirms device name from “DRAGON-BT0”...

  • Page 31: Ndef Format Tag Read (0 X E7)

    Data[1] : action time[ms] 6.7 Card Read Control(0xEF) This command controls stop/start of reading card. Please send the stop reading command to Dragon BT to use it as vender reader (connect to Dual card program or NFC manager program) LENH...

  • Page 32: Auto Reconnection Explanation (Bluetooth Pairing)

    In this case user need to delete the Bluetooth connection from the device and add Dragon BT again. For some PC /OS version, the PC ask whether to reconnect Dragon BT. The user should approve reconnection within 20sec. Otherwise Dragon BT delete the previous pairing information after 20sec so it could connect with new device.

  • Page 33: Pc Control Program

    It is designed for non-professional user to easily check/control Dragon BT configuration 7.1 Device connect To use this program, connect Dragon BT via Micro USB cable into PC while its power is on. Find Dragon from the device list and click [Connect] button In case you can’t find device name on list, kindly check following and retry...

  • Page 34: Battery Remains

    Dragon BT User Manual (Some cables are only for charge purpose, so not able to communicate. You can use Smartphone USB cable) 7.2 Battery remains Click [Battery INQ] button, it shows the battery remains. Version 1.63 DUALi Inc. (http://www.duali.com)

  • Page 35: Device Name Setting

    To apply this change, reset Dragon BT 7.4 SPP/ HID mode change Select the communication mode and click [set]. To apply this change, reset Dragon BT 7.5 HID output Configuration User is able to configure output format of Data in HID mode (HID/Integer/ASCII), End Character and order 7.6 Buzzer/Vibration...

  • Page 36: Mifare Card Reading

    Dragon BT User Manual 7.8 Mifare card reading User is able to configure Mifare read in case they want to use specific block Version 1.63 DUALi Inc. (http://www.duali.com)

  • Page 37: Warranty & Service

    Dragon BT User Manual 8. Warranty & service DUALi Inc. warrants to the original consumer or other end user that this product, Dragon BT, is free from defects in materials and workmanship for a period of 1 year from the date of purchase.
  • Page 38 Dragon BT User Manual  Do not expose directly to water, alcohol, benzene, etc for cleaning.  Do not expose directly to flammables.  Do not place or keep the device near flammables.  Keep the device away from excessive humidity and dust.
