DRAGON BT User's Guide
(Specification)
DUALi Inc.
Document Number: EP01-14-004
Document Version: 1.0
Last Revised Date: 10 NOV 2014
Copyright ⓒ 2010 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this
document in part or as a whole for any purposes other than those for which this document is disclosed. This document
is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc. Any
unauthorized use, copy, disclosure or distribution constitutes infringement of DUALi's intellectual property rights.
Advertisement
Table of Contents
Related Manuals for Duali DRAGON BT
Summary of Contents for Duali DRAGON BT
- Page 1 Last Revised Date: 10 NOV 2014 Copyright ⓒ 2010 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
- Page 2 DRAGON BT Specification DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
- Page 3 DRAGON BT Specification Revision History 2014.11.10(Ver. 1.0) : Release 2015.05.14(Ver. 1.0) : Revised...
-
Page 4: Table Of Contents
DRAGON BT Specification CONTENTS INTRODUCTION ............................5 ..........................5 RODUCT VERVIEW ..........................5 ASIC PECIFICATION ........................6 LUETOOTH PECIFICATION COMPONENTS CONFIRMATION ......................7 ........................7 ARDWARE PECIFICATION ............................7 IMENSION POWER ..............................8 ......................... 8 OWER PECIFICATION (3.7V B )....................8... -
Page 5: Introduction
1 Introduction 1.1 Product Overview DRAGON BT is compact hand held type NFC reader which sends out reading data from NFC tags to Host (Smart Phone/ Tablet PC). It is ideal for organizations where frequented, but intermittent, use of personal computers, tablet PCs and Smartphones. -
Page 6: Bluetooth Specification
DRAGON BT Specification 1.3 Bluetooth Specification ITEM Specification Note specification Enhanced Data Rate) Bluetooth v.2.1 + EDR ( Class Bluetooth class 2 radio Transmit Power +3dBm Receiver Sensitivity -86dBM Range 30 meters line-of-sight Antenna ACX AT3216) Integrated chip antenna (... -
Page 7: Components Confirmation
DRAGON BT Specification 2 Components Confirmation 2.1 Hardware Specification Main Board(CPU + RF + Bluetooth) Loop Antenna <DRAGON-BT : Front> <DRAGON_BT : Back> <LED> 2.2 Dimension - 103mm * 65mm * 12mm... -
Page 8: Power
DRAGON BT Specification 3 Power 3.1 Power Specification Charging : 5V MICRO USB DC Board : 3.7V Battery DC 3.2 Current Consumption (3.7V Battery) - Basic Current Consumption: 50mA - Maximum Current Consumption: 110mA (During Vibration or BEEP) 3.3 Cable... -
Page 9: Function
DRAGON BT Specification 4 Function 4.1 BUZZER & Vibrator Sensor Sending status to user 4.2 LED Status of Power & Battery RED LED : When connected with USB (Charging) BLUE LED : When power ON GREEN LED : When RF is running 4.3 Battery... -
Page 10: Environment
DRAGON BT Specification 5 Environment 5.1 Usage Environment - Usage Temperature: -10 ~ 60 ℃ - Usage Humidity: 30 ~ 90 % (Relative Humidity) 5.2 Storage Environment - Storage Environment: -20 ~ 70 ℃ - Storage Humidity: 30 ~ 90 % (Relative Humidity) 5.3 Warning... -
Page 11: Certification
- It should conform to environment regulation and need to get RoHS as occasion demands This product is CE marked according to the provision of the R&TTE Directive (99/5/EC). Here by DUALi Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
