DE-620R User Manual
DUALi Inc.
Document Version: 1.0
Last Revised Date: 19 JAN. 2010
Copyright ⓒ 2009 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use
this document in part or as a whole for any purposes other than those for which this document is disclosed. This
document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
Any unauthorized use, copy, disclosure or distribution constitutes infringement of DUALi's intellectual property
rights.
Release Date: 25 November 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE-620R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Duali DE-620R

  • Page 1 Last Revised Date: 19 JAN. 2010 Copyright ⓒ 2009 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
  • Page 2 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
  • Page 3 DE-620R User Manual Revision History  2010.01.19(Ver. 1.0) : First Release Version: 1.0 DUALi Inc. (http://www.duali.com)
  • Page 4: Table Of Contents

    Introduction ............................ 5 Hardware Specification ...................... 6 Structure ............................7 The Structure of equipment ....................7 The block diagram of DE-620R ..................7 Description of Surface ........................8 The picture of device surface .................... 8 Communication Cable ....................... 8 The size of terminal ......................8 Description of Electricity ........................
  • Page 5: Introduction

    DE-620R is a Smartcard reader which supports14443 TYPE-A/B, Mifare series& ISO15693 protocol It also supports Contact cards (1 X ID1 type contact slot, 1 X SIM type slots) which comply with ISO 7816. DE-620R is available as USB interface only.
  • Page 6: Hardware Specification

    DE-620R User Manual Hardware Specification Smart Card Interface Contactless Smart Card (ISO 14443 A/B), MIFARE, ISO15693 1 Contact Card and 1 SAM Card (ISO7816, T=0,T=1) Host Interface USB 2.0 Full Speed (12Mbps), also support USB 1.1 Host Communication PC/SC or Proprietary(USB)
  • Page 7: Structure

    DE-620R User Manual Structure The Structure of equipment - DE-620R itself contains all circuits include antenna, 1 SAMs and connectors. (USB ) Host PC (DE-620R) The block diagram of DE-620R Smart Card Socket SAM Socket (SAM1) (ST-ARM 32-bit RC531 RF IC...
  • Page 8: Description Of Surface

    DE-620R User Manual Description of Surface The picture of device surface - DUALi mark on top surface could be removed. Communication Cable Mini USB cable The size of terminal 68(W) * 120(L) * 30(H)mm DE-620R : Description of Electricity The Description of power...
  • Page 9: Rf Characteristics

    DE-620R User Manual RF Characteristics Frequency band - Tolerance of the carrier frequency: 13.56 MHz +/- 0.01% = +/- 1.356 kHz. - Frequency bandwidth: +/- 7 kHz. It is comply with FCC limits for 13.56MHz frequency band Description of Function Protocol Specification Refer to protocol specification for detail function.
  • Page 10 ‣ Warranty and Repair service - DUALi Inc. warrants to the original consumer or other end user that this product, DE-620R, is free from defects in materials and workmanship for a period of 1 year from the date of purchase.
