- Page 1 Parts and Operations Manual Manuel de pièces et d’opérations Clean and Fast Washroom Cart Code: 50932 Serial #:_______________________ Date of Purchase:________________ More info : www.dustbane.ca 11-2010...
- Page 2 THANK YOU FOR CHOOSING OUR PRODUCTS Hydro Systems manufactures quality chemical proportioners. Please use this equipment carefully and observe all warnings and cautions. protective clothing and eyewear when working in the vicinity of chemicals or other WEAR materials, when fi lling or emptying equipment or changing metering tips. re-assemble equipment according to instruction procedures.
- Page 3 Overview: The ICS 8900 is a battery powered, portable, self-contained unit designed to make daily maintenance of your facility easier. This unit includes the following features: Spray attachment with two nozzles (solution and rinse) Battery Charger On/Off Switch Battery Life Indicator Storage for spray bottle Sign hanger...
- Page 4 Fig. B Initial Set-up Fig. B Initial Set-up Remove any items sitting on the cart top. Remove cart top by lifting near the Remove any items sitting on the cart top. chemical bottles. See Fig. B. Remove cart top by lifting near the Remove tubing from checkvalve/meter- chemical bottles.
- Page 5 Fig. D Initial Setup (cont.) Water fi ll port The spray attachment is in the accessory box. Attach it to the discharge hose. Remove the black cap from the water fi ll port Chemical “A” (it rotates COUNTER CLOCKWISE to open). Fill the tank with cool, clear tap water.
- Page 6 Normal Operation: The power switch is lighted when it is in the “ON” position. The pump will run when the trigger on the spray attachment is pulled and stop when it is released. The rollover valve on the outlet of the spray attachment selects between the two attached spray nozzles.
-
Page 7: Troubleshooting
Troubleshooting: The spray is weak or there is no spray. The pump does not operate at full fl ow if there is air in the system. Air can enter the system from several sources: Out of water - fi ll the water reservoir and prime the system. Out of chemical - replace the chemical container and prime the system. - Page 8 Parts List Parts List Part Number Description Ref. Part N. Description Quantity 10092250 Pump Replacement Kit H10092250 Pump Replacement Kit Part Number Description 10091845 Spray Attachment H10091845 Spray Attachment 10092253 Battery 10092250 Pump Replacement Kit H10092253 Battery 10092254 Battery Charger 10091845 Spray Attachment 10092211...
