Section 1 - Getting to Know the Axius System
• Engine operating hours
• And more
Typical SmartCraft SC100 System Link Gauge tachometer (speedometer similar)
For basic operation information on the SmartCraft instruments, refer to the manual provided with your gauge.

System Link Digital Gauges (If Equipped)

Some instrumentation packages include gauges that augment the information provided by VesselView and the SmartCraft
tachometer and speedometer. The owner and operator should be familiar with all the instruments and their functions on the boat.
Because of the large variety of instrumentation and manufacturers, have your boat dealer explain the gauges and normal readings
that appear on your boat.
The following type of digital gauge may be included with your power package.
Item
a Oil pressure
b Water temperature
c Voltmeter
d Fuel level

Switches

• "OFF" In the "OFF" position, all electrical circuits are off. The engine will not operate with the key switch in the "OFF" position.
Page 4
a
d
Typical multi-function digital gauge
Gauge
Four position key switch
44348
b
c
44347
Indicates
Engine oil pressure
Engine operating temperature
Battery voltage
Quantity of fuel in tank
38160
CMD-4082082 / 90-8M0052072 FEBRUARY 2011
