Mercury Axius Manual

Joystick piloting for sterndrives
Hide thumbs Also See for Axius:
Table of Contents

Advertisement

Quick Links

Models Affected
The content in this manual applies to Axius Joystick Piloting for Sterndrives as implemented on the following MerCruiser
power packages:
Engine Configuration
4.5L V6
6.2L V8
Welcome
You have selected one of the finest marine power packages available. It incorporates numerous design features to
assure operating ease and durability. With proper care and maintenance, you will thoroughly enjoy using this product for
many boating seasons.
This manual is a supplement to the operations manual provided with your engine, and provides additional information
about using and maintaining the Axius Joystick Piloting for Sterndrives propulsion system. To ensure maximum
performance and carefree use, we ask that you thoroughly read this manual.
The serial numbers are the manufacturer's keys to numerous engineering details that apply to your power package.
When contacting your authorized Mercury MerCruiser dealer about service, always specify model and serial numbers.
Keep this manual with the product for ready reference whenever you are on the water.
Thank you for purchasing one of our products. We sincerely hope your boating will be pleasant.
Mercury Marine
Warranty Message
The product you have purchased comes with a limited warranty from Mercury Marine. The terms of the warranty are
set forth in the Warranty section of the Operation, Maintenance and Warranty Manual included with your power
package. The warranty statement contains a description of what is covered, what is not covered, the duration of
coverage, how to best obtain warranty coverage, important disclaimers and limitations of damages, and other related
information. Be certain to review this important information.
Mercury Premier Service
Mercury evaluates the service performance of its dealers and assigns its highest rating of "Mercury Premier" to those
demonstrating an exceptional commitment to service.
Earning a Mercury Premier Service rating means a dealer:
•
Achieves a high 12‑month service Customer Satisfaction Index (CSI) score for warranty service.
•
Possesses all of the necessary service tools, test equipment, manuals, and parts books.
•
Employs at least one certified or master technician.
•
Provides timely service for all Mercury Marine customers.
•
Offers extended service hours and mobile service, when appropriate.
•
Uses, displays, and stocks an adequate inventory of genuine Mercury Precision Parts.
•
Offers a clean, neat shop with well‑organized tools and service literature.
Read This Manual Carefully
The operator (driver) is responsible for the correct and safe operation of the boat, the equipment aboard and the
safety of all occupants aboard. We strongly recommend that the operator read this Operation, Maintenance and
Warranty Manual and thoroughly understand the operational instructions for the power package and all related
accessories before the boat is used.
IMPORTANT: If you do not understand any portion of this manual, contact your dealer for a demonstration of actual
starting and operating procedures.
Engine Horsepower
200
250
300
350
WARNING
!
Sterndrive Model
Bravo Three
Bravo Three
Bravo Three
Bravo Three
