Welcome
You have selected one of the finest marine power packages available. It incorporates numerous design features to assure
operating ease and durability.
With proper care and maintenance, you will thoroughly enjoy using this product for many boating seasons. This manual is
a supplement to the Operation, Maintenance, and Warranty Manual included with your engine package and provides
information about the Axius propulsion system. To ensure maximum performance and carefree use, we ask that you
thoroughly read this manual.
This manual contains specific instructions for using and maintaining your product. Keep this manual with the product for
ready reference whenever you are on the water.
Thank you for purchasing one of our products. We sincerely hope your boating will be pleasant!
Warranty Message
The product you have purchased comes with a limited warranty from Mercury Marine or Cummins MerCruiser Diesel;
the terms of the warranty are set forth in the Warranty sections of the Operation, Maintenance and Warranty Manual
included with your power package. The warranty statement contains a description of what is covered, what is not covered,
the duration of coverage, how to best obtain warranty coverage, important disclaimers and limitations of damages and
other related information. Please review this important information.
Read This Manual Thoroughly
IMPORTANT: If you do not understand any portion of this manual, contact your dealer for a demonstration of actual starting
and operating procedures.
Notice
Throughout this publication, and on your power package, dangers, warnings, cautions, and notices, accompanied by the
International Hazard Symbol
service or operation that may be hazardous if performed incorrectly or carelessly. Observe them carefully.
These Safety Alerts alone cannot eliminate the hazards that they signal. Strict compliance with these special instructions
while performing the service, plus common sense operation, are major accident prevention measures.
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Indicates a situation which, if not avoided, could result in engine or major component failure.
IMPORTANT: Identifies information essential to the successful completion of the task.
NOTE: Indicates information that helps in the understanding of a particular step or action.
Trademark and Copyright Information
The description and specifications contained herein were in effect at the time this guide was approved for printing. Mercury
Marine, whose policy is one of continuous improvement, reserves the right to discontinue models at any time, or to change
specifications or designs, without notice and without incurring obligation.
Mercury Marine, Fond du Lac, Wisconsin, USA. Printed in USA.
© 2011, Mercury Marine
!
, may be used to alert the installer/user to special instructions concerning a particular
DANGER
!
WARNING
!
CAUTION
!
NOTICE
