Panther - Gas Stoves
Model No. 553
OWNER'S GUIDE
This appliance meets the requirements of the European Gas Directive
This guide is intended to help you care for your morsø gas stove.
It gives sufficient details to enable your gas stove to be operated and maintained
Please read carefully before using your gas stove and keep for future reference
Please keep your Owner Guide in a safe place together
with the Installation Instructions
MORSØ JERNSTØBERI A/S . DK-7900 NYKØBING MORS
E-Mail: stoves@morsoe.com · Website: www.morsoe.com
Distributed by: Morsø UK
Valley Drive · Swift Valley · Rugby, Warks CV21 1TW · England


Advertisement

loading
Need help?

Need help?

Do you have a question about the 553 and is the answer not in the manual?

Questions and answers

Related Manuals for Morso 553

Summary of Contents for Morso 553

  • Page 1 Panther - Gas Stoves Model No. 553 OWNER’S GUIDE This appliance meets the requirements of the European Gas Directive This guide is intended to help you care for your morsø gas stove. It gives sufficient details to enable your gas stove to be operated and maintained...
  • Page 2 As supplied, this appliance is for use with natural gas (G0) When coverted using conversion kit no. 5553 this appliance is for use with propane gas (G3) This appliance is for use in the United Kingdom (GB) and the Republic of Ireland (IE) only.
  • Page 3 IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY .
  • Page 4 the supply of gas to the fire if, for any reason, the flames go out. If this device does operate or if the fire is turned off accidentally or intention- ally, always wait three minutes before attempting to relight. 0. This stove must never be used with the windows open or with either glass panel damaged or removed.

  • Page 5: Operating Your Stove

    OPERATING YOUR STOVE The Flame Sensing & Flue Blockage Safety System. For your safety, this appliance is fitted with a flue blockage safety device that will shut down the appliance in the event of abnormal flue conditions. This device is NOT a substitute for an independently mounted Carbon Monoxide detector.
  • Page 6 Figure 2 Figure 3 To Turn Off the Main Burner Only Turn the right hand control knob to the pilot position marked To Turn Off the Main Burner and Pilot - Turn the right hand control knob to the pilot position marked .

  • Page 7: Cleaning Your Stove

    CLEANING YOUR STOVE Turn the stove off and allow it to cool before attempting any cleaning. Note that it will retain heat for some time after it has been turned off. Cast Iron Surfaces Regular dusting with a dry cloth is all that should normally be necessary. Any light stains should be removed with a damp cloth.
  • Page 8 pieces held away from your face so that you avoid inhaling the dust. We do not recommend the use of a normal domestic vacuum cleaner which may blow dust back into the air. We suggest that you remove the coals in the reverse order to that shown in the fuel bed refitting instructions.
  • Page 9 Figure 6 Figure 7 Figure 8...

  • Page 10: Maintenance And Servicing

    Figure 9 MAINTENANCE & SERVICING Regular maintenance In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the flue is kept clear of any form of obstruction. In the United Kingdom it is the law that a landlord must have any gas appli- ance, flue and pipework which is situated in a tenant’s premises checked for safety at least every twelve months by a competent person (In the U.K., a CORGI registered installer).
  • Page 11 Description Part No. Complete set of ceramic coals 57579 Rear base coal piece 57589 Left front base coal 5709 Right front base coal 5709 Bag of 3 top coal pieces 57599 Complete set of ceramic walls 57609 Ceramic left side wall 5769 Ceramic right side wall 5769...
  • Page 12 Morsø Jernstøberi A/S - 0..006 - 746300...
