Aurora ASP-44-4K User Manual

4x4 4k hdmi matrix
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USERS GUIDE
ASP-44-4K
4x4 4K HDMI Matrix
i
Manual Number: 150217

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASP-44-4K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aurora ASP-44-4K

Summary of Contents for Aurora ASP-44-4K

  • Page 1 USERS GUIDE ASP-44-4K 4x4 4K HDMI Matrix Manual Number: 150217...

  • Page 2: Safety Instructions

     Power outlet: To prevent electric shock, be sure the electrical plug used on the product power cord matches the electrical outlet used to supply power to the Aurora product. Use only the power adapter and power connection cables designed for this unit.

  • Page 3: Table Of Contents

    User Guide TABLE OF CONTENTS PACKAGE CONTENTS ......................1 INTRODUCTION ........................2 About ..............................2 Features ..............................2 Front ASP-44-4K ........................... 3 Rear ASP-44-4K ........................... 4 APPLICATION ........................... 5 ASP-44-4K Application ......................... 5 OPERATION ..........................6 Routing ..............................6 EDID ..............................6 Presets ..............................

  • Page 4: Package Contents

    User Guide PACKAGE CONTENTS Please make sure the following items are included within your package. Contact your dealer if any items are missing or damaged.  ASP-44-4K x 1  1 12v DC Desktop Power Supply Note: Go to www.auroramm.com...

  • Page 5: Introduction

    INTRODUCTION About The ASP-44-4K is an 4x4 4K HDMI Matrix offering the power and flexibility you need at a cost effective price. Route Ultra High Definition video sources and multi-channel digital audio from any of the four (4) HDMI inputs to the any of the four (4) HDMI outputs at the same time. The front...

  • Page 6: Front Asp-44-4K

    User Guide Front ASP-44-4K Front  LCD Display – Top row shows the input routed to relative Output number below.  Power LED – When power is applied to the unit and the rear switch is set to the on position the LED will illuminate.

  • Page 7: Rear Asp-44-4K

     Outputs 1-4 – Four HDMI outputs for a variety of destinations up to 4K resolutions.  DC12V – Connect the included 12v DC desktop style power supply.  OFF/ON – Power switch for turning the ASP-44-4K on or off.

  • Page 8: Application

    User Guide APPLICATION ASP-44-4K Application HDMI cables or HDMI extenders Blu-ray disc player HDMI projector HDTV HDMI camcorder 4x HDMI Output 4x HDMI Input HDMI monitor PC or Laptop...

  • Page 9: Operation

    User Guide OPERATION Routing To route a source to a source to a destination(s): Step 1. Press Input Step 2. Press desired input number correlating to the rear of the unit’s HDMI input. If no route is required then do not press a number. If a number has been pressed and you wish to deselect press the same number again.

  • Page 10: Web Server

    WEB SERVER Web Browser Control The ASP-44-4K has a built in Web Control Interface. By typing into a browser’s address bar the IP address of the ASP-44-4K a password screen will appear. Factory default is ten zeros 0000000000. Once entered the routing page will appear. It will allow the routing of sources and the recalling and saving of presets.

  • Page 11: Serial Commands

    User Guide SERIAL COMMANDS RS-232 & Telnet Commands Baud Rate: 9600 8N1 DB9 Female (Pins 2-TX, 3-RX, 5-GND), Straight through Cable to PC ! is the start character to active a command ? is the start character to query status ~ is the start character of the response /x0D (<cr>...
  • Page 12 User Guide y0-y255 = EDID Data in ASCII HEX representation x1-x4 = output relative to input. Example: !EDL312x<cr> 0 = Clear EDID X = ignore (do nothing) F = Factory EDID default In this example Input 1 gets output 3 EDID Input 2 gets output 1 EDID Input 3 gets output 2 EDID Input 4 is ignored and left alone...
  • Page 13 User Guide is not required. Note 3: If an input has no HDCP then the output should not have HDCP either unless the force HDCP command is enable.

  • Page 14: Appendix 1

    User Guide APPENDIX 1 Troubleshooting Problem Solution a. Check 12v power supply is plugged in rear of unit 1. LED is not lit on any LEDs or b. Check to see if Wall supply is plugged into wall outlet. buttons c.

  • Page 15: Appendix 2 Technical Specifications

    1RU Rack Mount 19” x 1.75” Power supply 12v 3A DC Power consumption 20 Watts [max] Operation temperature 0~40C [32~104F] Storage temperature -20~60C [-4~140F] Relative humidity 20~90% RH [no condensation] 1x ASP-44-4K Package Contents 1x 12v Desktop Power Supply Specifications subject to change without notice.

  • Page 16: Appendix 3 Warranty

    Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after.
  • Page 17 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
