- Page 1 USERS GUIDE ASP-882A 8x8 Series HDMI 2.0a Matrix Manual Number: 161115 Firmware Version: 31.19.15...
-
Page 2: Safety Instructions
Power outlet: To prevent electric shock, be sure the electrical plug used on the product power cord matches the electrical outlet used to supply power to the Aurora product. Use only the power adapter and power connection cables designed for this unit. -
Page 3: Table Of Contents
User Guide TABLE OF CONTENTS PACKAGE CONTENTS ......................1 INTRODUCTION ........................2 About ..............................2 Features ..............................2 Front ASP-882A ............................ 3 Rear ASP-882A............................. 4 APPLICATION ........................... 5 ASP-882A Application ........................... 5 OPERATION ..........................6 LCD Readout ............................6 Routing ..............................8 EDID .............................. -
Page 4: Package Contents
PACKAGE CONTENTS Please make sure the following items are included within your package. Contact your dealer if any items are missing or damaged. ASP-882A x 1 Rack Ears x 2 12v DC Desktop Power Supply x 1 Note: Go to www.auroramm.com... -
Page 5: Introduction
INTRODUCTION About The ASP-882A is an 8x8 4K HDMI Matrix offering the power and flexibility you need at a cost effective price. Route Ultra High Definition video sources and multi-channel digital audio from any of the eight (8) HDMI inputs to the any of the eight (8) HDMI outputs at the same time. The front keypad and LCD display are designed for easy operation and quick status of. -
Page 6: Front Asp-882A
User Guide Front ASP-882A Front Power – Power switch for turning the unit on or off. When first turned on all Input and Output LEDs will light for 1 second to show operation of LED working. LCD Display – Top row shows the input routed to relative Output number below. -
Page 7: Rear Asp-882A
User Guide Rear ASP-882A Rear Connections Inputs 1-8 – Eight HDMI 2.0a inputs for a variety of sources up to 4K60Hz resolutions. Outputs 1-8 – Eight HDMI 2.0a outputs for a variety of destinations up to 4K60Hz resolutions. -
Page 8: Application
User Guide APPLICATION ASP-882A Application HDMI cables or HDMI extenders Blu-ray disc player HDMI projector HDTV HDMI camcorder 8x HDMI Output 8x HDMI Input HDMI monitor PC or Laptop... -
Page 9: Operation
User Guide OPERATION LCD Readout The LCD will reflect what Output is routed to which input when in an idle state. 1-1 If the input/output is not routed, will show “0” 1-2 Press ENTER will turn to next page to check other status as per 1-3 to 1-8. 1-3 Output Connections shows each output with active connected display. - Page 10 User Guide 1-6 Subnet Mask 1-7 Gateway 1-8 MAC Address 1-9 Firmware Revision 1-10 Will revert to mapping if do not press any button for 3 seconds The LCD will also show various states of operation and displaying information depending on the mode of operation.
-
Page 11: Routing
User Guide Routing The ASP-882A has 3 ways of making a route for optimal flexibility. Technique 1 Press ROUTE, all the input / output buttons will light for connected HDMI inputs. Press desired input, then the output(s) will light that it is routed to. -
Page 12: Edid
User Guide EDID 1) Press EDID, the LCD will state current mode of operation. 1-1 Press EDID for 3 seconds, will be able to change the mode between Auto mode/Manual mode. 2) In Manual mode – EDID Learning 2-1 Press the output that needs to be learned. 2-2 The LCD will show “Device ID”... -
Page 13: Presets
User Guide Presets SAVE 1) Press SAVE for 3 seconds, the button will light, and the operation will be started. 2) Select from input & output number 1~8 as customized mapping 1~16 sets. The LCD will show the mapping status of the pressed button. 3) Press ENTER to complete the operation. -
Page 14: Firmware Update
31.19.15 or higher. If not it is highly recommend to use the LAN update method using the ASP Manager Utility. USB Method 1. Store the uncompressed firmware file on the USB stick. Latest firmware can be found on the Aurora customer portal located at www.auroramm.com 2. -
Page 15: Pc Control Software
PC Control Software ASP Matrix Manager The ASP-882A has a utility called ASP Matrix Manager which allows the setup via RS-232 and Ethernet Mapping (Routing) of Outputs to Inputs, EDID management, Rename (Labeling displayed on LCD), System (IP Address Setup), and Firmware (Updating). It is available for download from the Aurora customer portal www.auroramm.com... - Page 16 User Guide EDID The EDID tab allows for full EDID management to all the inputs. Custom EDID files can be loaded from this tab or pulled from a device to be saved for other units.
- Page 17 User Guide Rename The Rename tab allows the labeling of Input, Output and Preset buttons on the front LCD.
- Page 18 User Guide System The System tab is for the setup of the units IP settings, factory defaults, and firmware versions.
- Page 19 Firmware The Firmware page allows the updating of firmware from the LAN or USB. Latest firmware can be found on the Aurora customer portal located at www.auroramm.com Important! Make certain unit has valid IP address if using Update from Net. If unit is set to DHCP make certain there is a DHCP server connected or set to a static.
-
Page 20: Serial Commands
User Guide SERIAL COMMANDS RS-232 & Telnet Commands Baud Rate: 9600 8N1 DB9 Female (Pins 2-TX, 3-RX, 5-GND), Straight through Cable to PC ! is the start character to active a command ? is the start character to query status ~ is the start character of the response /x0D (<cr>... - Page 21 User Guide x= HDMI Input 1-8 EDID Write !EDWx-y0 y1…y255<cr> y0-y255 = EDID Data in ASCII HEX representation x= HDMI Input 1-8 y0-y255 = EDID Data in ASCII HEX representation Response: ~EDIDx-y0 y1…y255<cr> EDID Read ?EDRx<cr> y0-y255 = EDID Data in ASCII HEX representation x1-x8 = output relative to input.
- Page 22 User Guide VCC Output 1 = Toggle Output VCC5V 100ms Toggle !VCCOUTx<cr> Response: ~VCCOUTx <cr> x = 1-8 y = Label Name Input Label !LINx-y<cr> Response: ~LINx-y<cr> x = 1-8 Input Label y = Label Name Query ?LINx<cr> Response: y<cr> x = 1-8 y = Label Name Output Label...
-
Page 23: Appendix 1
User Guide APPENDIX 1 Troubleshooting Problem Solution a. Check 12v power supply is plugged in rear of unit 1. LED is not lit on any LEDs or b. Check to see if Wall supply is plugged into wall outlet. buttons c. -
Page 24: Appendix 2
Power supply 12v 7.5A DC Power consumption 57Watts Operation temperature 0~40C [32~104F] Storage temperature -20~60C [-4~140F] Relative humidity 20~90% RH [no condensation] 1x ASP-882A Package Contents 1x 12v Desktop Power Supply 2x Rack Mount Ears Specifications subject to change without notice. -
Page 25: Appendix 3 Warranty
Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after. - Page 26 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
