- Page 1 USERS GUIDE DXM G4 Series DXM-88-G4 ● DMX-1616-G4 User Manual Revision: 190204...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS PACKAGE CONTENTS INTRODUCTION Description Safety Instructions PRODUCT SERIES DESCRIPTION Matrix Technical Parameters Cards Technical Parameters Card Options Main Control Card HDBaseT card HDMI card DVI card Optic card SDI card CVBS card YPBPR card VGA Card SYSTEM CONNECTION DIAGRAM BASIC OPERATION... -
Page 3: Package Contents
INTRODUCTION Description The Aurora DXM-G4 Series Matrix is a modular multi-format matrix for 4K Ultra-HD video signal and audio management. The device supports flexible video I/O configurations: • DXM-G4 Series Matrix 8C: Slot 1 to 6 for in- or output cards, Slot 7+8 for output cards •... -
Page 4: Product Series Description
User Guide PRODUCT SERIES DESCRIPTION Matrix Technical Parameters Type MVP-8C (N) MVP-16C MVP-32C 3Urack 5.5Urackmounte Size 2Urack mounted mounted Port number The 25~32 are The 7~8 are The 13~16 are fixation output fixation output fixation output channel； Maximum AV channel； channel；... - Page 5 User Guide Type MVP-8C (N) MVP-16C MVP-32C Port define PIN 1:TX PIN 2:GND PIN 3:RX 9600～115200（default），8 data bits， Baud rate 1 stop bit，none， Control ASCII code protocol LAN port RJ-45 LAN data rate 10/100BaseT，half/full duplex Ethernet support ICMP，ARP，IP，TCP，UDP，DHCP，HTTP protocol Update port RJ45 Update way browser...
-
Page 6: Cards Technical Parameters
User Guide Cards Technical Parameters Seaml Status Resolution Video Control Audio EDID/ Card version Type signal signal/ embedd switch HDCP HDTV VESA type Sale ● ● ● ● ● MVPS-I-HDMI HDMI × × Sale ● ● ● ● ● MVPS-O-HDMI HDMI ×... -
Page 7: Card Options
User Guide Card Options Note: Please insert the cards only when power cable is NOT connected to main power supply. Carefully align and position the cards before tightening the modules with 2 screws. Please insert or extract cables carefully with power switched off. The last Slot is reserved for the LAN / RS232 Communication module ‘CTRL’. - Page 8 User Guide Technical Parameters The board type HDBT1 input HDBT2 input HDBT1 output HDBT2 output number/Signal A HDBaseT audio and video signals and control signals types The connector RJ-45 8P line terminal type Recommend the STP CAT6/CAT6A and above cable type 1080P Maximum transmission ≤...
-
Page 9: Hdmi Card
User Guide HDMI card 1 Port HDMI input card with analog audio embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type HDMI input HDMI output number/Signal A HDMI signal A HDMI signal... -
Page 10: Dvi Card
User Guide DVI card 1 Port DVI input card with analog audio embedding. 1 Port DVI output card with analog audio de-embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type MVPS-I1-DVI... -
Page 11: Optic Card
User Guide Optic card 1 Port OPTIC input card with analog audio embedding. 1 Port OPTIC output card with analog audio de-embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type MVPS-I1-Optic... -
Page 12: Sdi Card
User Guide SDI card 1 Port SDI input card with analog audio embedding. 1 Port SDI-S output card with analog audio de-embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type MVPS-I1-3GSDI... -
Page 13: Cvbs Card
User Guide CVBS card 1 Port CVBS input card with analog audio embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical parameters The board type MVPS-I1-CVBS number/Signal 1 channel CVBS signal types The connector type... -
Page 14: Ypbpr Card
User Guide YPBPR card 1 Port YPBPR input card with analog audio embedding. 1 Port YPBPR output card with analog audio de-embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type MVPS-I1-YPBPR... -
Page 15: Vga Card
User Guide VGA Card 1 Port input card with analog audio embedding. 1 Port VGA-S output card with analog audio de-embedding. LEDs: STA (Status) : Green if signal is active PWR (Power) : Red if board electricity works accordingly Technical Parameters The board type MVPI-1-VGA MVPI-1-VGA-S... -
Page 16: System Connection Diagram
User Guide SYSTEM CONNECTION DIAGRAM BASIC OPERATION Capacitive Touch Screen The DXM G4 series use a 5” capacitive touch screen, which have a resolution of 800x480, the layout of system is shown below: Each particular function button on the interface is shown in the table below. button function... - Page 17 User Guide Video settings Audio settings EDID management System settings Switches the selected input to all outputs Close the selected outputs Save the actual switching state Restore a switching state Symbol for output with slot number Symbol for input with slot number Audio and video synchronization when switching Opens main interface There are four sub-menus in the main menu, which can be selected: Video, Audio, EDID...
-
Page 18: Video Control
User Guide Video Control The keypad can be used for uninterrupted switching between image input and external outputs. Switch signal from one input to one or more output ports In the video menu select the input by touch. Now press the output/outputs you want switch to this source to. - Page 19 User Guide At the main menu, select the EDID Management icon. Choose the Output you want to copy the EDID from and select the input you want to write this EDID to. Now this input will present that EDID to connected source. On the Screen this Information is shown at the Input symbol.
-
Page 20: System Configuration
User Guide System configuration IP Configuration In the main menu select System settings, ‘NETWORK’ to configure the LAN Settings. At Server Port you can define the Port for the TCP Connection. Please find the commands at RS232 protocol. With activated DHCP the IP Address will be requested from an existing DHCP Server automatically. -
Page 21: General Settings
User Guide General Settings Show Unit Information Firmware version, Hardware version, MAC adress... -
Page 22: Web Server
User: ‘user‘ Password: ‘123456‘ To access the product web server, connect the PC LAN port directly to the Aurora DXM-G4 Series Matrix LAN port with a straight RJ45 cable. After making the connection, go to network connection of the PC and revise the IP property to static IP as below. Once done, open a web... -
Page 23: Video Port Management
User Guide Video Port Management The Video Management page offers direct, trouble-free switching from any input (source) to one or more outputs (sinks): for switching, user can select the input (once selected, it will stay highlighted) and then click on the output tab (or tabs) to switch. Once switched, the output tab will indicate the input port info once switched. -
Page 24: Hdcp Management
User Guide The power supply of each input/output card can be switched on/off individually for each card via Web GUI. In the menu item Video Management right-click on the view, S1 '. There you can switch the supply voltage of the card on and off via pull-down (default: ON). HDCP Management The HDCP capability of each input card can be switched individually for each card in the Web GUI. -
Page 25: Edid Management
User Guide separately according to input and output card. First select the desired source and then the sink/sink. Now the two RS232 connections are internally routed. (1)Please switch the Input’s TX to the output’s RX. (2)Then switch the input’s RX to the output’s TX. Note: Bidirectional transmission is only possible with a point-to-point connection. - Page 26 User Guide Firmware updates can be done with the button ‘System update’ in the right upper corner.
-
Page 27: Rs232 And Ip Protocol
User Guide RS232 AND IP PROTOCOL Your DXM G4 series platform can be controlled by external control devices/system controller through RS232 connection, TCP/IP over Ethernet. The default RS232 settings are: ● Baud 115200bps ● 8 data bits ● 1 stop bit ●... - Page 28 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response the input1's internal audio switch to a = input(1 ~ matrix Switch the single max) + V/E channel input of the > output2's > < b c = output(1 ~ matrix audio to the single Tatob,c internal...
- Page 29 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response a = (mode) 0 : VE -> VE 1 : VE -> EV 2 : V -> VE (default) Set the > < Set the audio and >...
- Page 30 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response Set the > > < Set the Socket Server Socket PORT:a a = Server port PORT:1001 PORT:1001 port Server port <CR> <CR> <CR> to the 1001 > >...
- Page 31 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response Query the status of Query the status of < the sound the sound when CSOUND NULL CSOUND CSOUND:1 when command is sent <CR> <CR> <CR> command is sent Switch a = output(1 ~ matrix switch EDID of the...
- Page 32 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response can check out the central control board is Checking whether < online by the central control NULL COM:1 sending board is online or not <CR> <CR> <CR> "#COM<CR >"to get a response of...
- Page 33 User Guide Basic ASCII Example Example Example Action Variables String Settings String Response Query all < Query all the NULL (return data RCID:1:I1, RCID #RCID<CR> daughter card types reference link) daughter 2:N/A... <CR> card types <CR> Query main < Query main software SVER NULL software...
- Page 34 Warranty Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after. Motorized mechanical parts (Hard Drives, DVD, etc), mechanical parts (buttons, doors, etc), remotes and cables are covered for a period of 1 year.
