1 Introducing Your Notebook

1.3 Left Side

The following picture shows the left side of your notebook.
1

Kensington Lock

2 Modem Jack
3 Wireless Kill switch (Wireless Switch ON/OFF)
4 HDMI Port
5 VGA Port
6 RJ-45 LAN Jack
7 3-1 Card Reader
8 Express Card
1.3.1 Kensington Lock
A Kensington Security Slot is a small, metal-reinforced hole found on almost all small or
portable computer and electronics equipment, particularly on expensive and/or relatively
light ones, such as laptops, computer monitors, desktop computers, gaming consoles, and
video projectors. It is used for attaching a lock-and-cable apparatus, in particular those from
Kensington.
1-7
1 2 3 4 5 6 7 8
