This user's manual is designed to let you easily find the information you need to
get the most from your notebook.
• Introduces you to the features of your notebook.
• Gives you the useful details on using your notebook.
• Tells you how to look after your notebook, whether at home or traveling.
• Talks about Express Card peripherals and how to use them.
• Goes into more detail about power management and explains how to
conserve power while on the move.
• Introduces you to BIOS, the nervous system of your notebook, and how to
change its fundamental settings.
There is no need to read the manual from the beginning to end. Simply find your
way to the section that interests you using the table of contents, or browse
through the manual.
You will come across the following icons in this manual:
Helpful pointers and tricks to get more from your notebook
To help you note and avoid possible damage to your notebook's hardware or
software, or loss of your work
Points out possible damage to property, personal injury or death
Information in this document is subject to change without notice.
© Compal Electronics, Inc. 2009. All rights reserved.
Trademarks used in this document: Microsoft and Windows are registered
trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products.
A
About this User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTUC0 and is the answer not in the manual?

Questions and answers

Related Manuals for Compal NTUC0

Summary of Contents for Compal NTUC0

  • Page 1 Points out possible damage to property, personal injury or death Information in this document is subject to change without notice. © Compal Electronics, Inc. 2009. All rights reserved. Trademarks used in this document: Microsoft and Windows are registered trademarks of Microsoft Corporation.

  • Page 2: Table Of Contents

    Contents ABOUT THIS USER’S MANUAL ......................A SAFETY INSTRUCTIONS........................I SPECIFICATIONS ............................. I CHAPTER 1 INTRODUCING YOUR NOTEBOOK ................① 1.1 F ............................1-1 RONT 1.1.1 Camera ..........................1-1 1.1.2 Caps Lock (Blue) ........................1-2 1.1.3 Num Lock LED (Blue) ......................1-2 1.1.4 Wireless Button ........................1-2 1.1.5 WOW Video Button .......................1-2 1.1.6 WOW Audio Button ......................1-2 1.1.7 Power Buttons ........................1-2...
  • Page 3 Contents 2.1.5 Sleep Mode ...........................2-3 2.2 T ......................2-4 IPS FOR SING INDOWS 2.2.1 Microsoft Windows Vista Help....................2-5 2.2.2 Windows Desktop........................2-6 2.2.3 Start Button...........................2-7 2.2.4 Taskbar ..........................2-8 2.2.5 Notification Area (System Tray) ...................2-8 2.2.6 Recycle Bin ...........................2-9 2.2.7 Control Panel ........................2-9 2.2.8 Computer ..........................2-9 2.3 K ......................2-11...
  • Page 4 Contents 2.8.7 Emptying the Recycle Bin....................2-28 2.8.8 Retrieving Files From the Recycle Bin ................2-28 2.9 P ..........................2-30 LAYING OVIES 2.9.1 Adjusting the Volume ......................2-31 2.9.2 Adjusting the Picture ......................2-31 CHAPTER 3 OPERATING YOUR NOTEBOOK (WINDOWS7)............③ 3.1 T ..................3-1 URNING OTEBOOK N AND 3.1.1 Turning Your Notebook On ....................3-2...
  • Page 5 Contents 3.7 M ........................3-23 ANAGING ROGRAMS 3.7.1 Running Programs......................3-24 3.7.2 Adding Software .........................3-24 3.7.3 Removing Software ......................3-25 3.8 M .........................3-26 ANAGING ILES 3.8.1 Updating Antivirus Software ....................3-27 3.8.2 Backing Up Files ........................3-27 3.8.3 Finding Files ........................3-27 3.8.4 Copying a File on the Hard Drive ..................3-27 3.8.5 Renaming Files........................3-27 3.8.6 Deleting Files ........................3-28 3.8.7 Emptying the Recycle Bin....................3-28...
  • Page 6 Contents 5.1.3 Cleaning the Touch Pad......................5-2 5.1.4 Precautions...........................5-2 5.2 T .............................5-4 RAVELING 5.2.1 Identifying Your Notebook ....................5-5 5.2.2 Packing Your Notebook ......................5-5 5.2.3 Travel Tips ..........................5-5 5.2.4 If Your Notebook is Lost or Stolen ..................5-6 CHAPTER 6 PERIPHERALS......................... ⑥ 6.1 A SD/MMC/MS C ................6-1 DDING AND...
  • Page 7 Contents 8.1.2 Power Management Modes ....................8-2 8.1.2.1 Sleep Mode..........................8-2 8.1.2.2 Hibernate Mode.........................8-3 8.1.3 Power Options Properties ....................8-3 8.1.3.1 Select a power plan........................8-4 8.1.3.2 Power buttons and password protection..................8-4 8.1.3.3 Create a power plan ........................8-5 8.1.4 Speed Step..........................8-5 8.2 B ............................8-7 ATTERY 8.2.1 Battery Performance ......................8-8 8.2.2 Checking the Battery Charge....................8-8...

  • Page 9: Safety Instructions

    NTUC0 User Manual Safety Instructions Use the following safety guidelines to help protect yourself and your notebook. General Warnings • Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base.
  • Page 10 Safety Instructions • If acid leaking from the battery pack contacts your skin or clothing, immediately wash it away with running water. Otherwise, skin inflammation may occur. • Operate the computer at the recommended temperature range of +5oC to +35oC (+41oF to +95oF).
  • Page 11 NTUC0 User Manual • Place the AC adapter in a ventilated area, such as a desktop or on the floor, when you use it to run the computer or to charge the battery. Do not cover the AC adapter with papers or other items that will affect its cooling; also, do not use the AC adapter while it is inside a carrying case.
  • Page 12 Safety Instructions • If the battery pack leaks, gives off a bad odor, generates heat, becomes discolored or deformed, or in any way appears abnormal during use, recharging or storage, immediately remove it from the computer or charger and stop using it. Battery Pack Disposal •...
  • Page 13 NTUC0 User Manual Important Safety Instructions Read these instructions carefully and save them for future reference. • Follow all warnings and instructions given to you for this product. • Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

  • Page 14: Fcc Notice

    Safety Instructions followed, adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal condition. The product has been dropped or the cabinet has been damaged.
  • Page 15 EU Declaration of Conformity BSMI Notice (Taiwan Only) Most Compal computer products are classified by the Bureau of Standards, Meteorology and Inspection (BSMI) as Class B information technology equipment (ITE). This (marked on the product) indicates the product complies with the BSMI standard.
  • Page 16 Safety Instructions 如果您在電腦的底部、側面或背面板上找到一個 標誌，則適用於以下部 份的相關規定： Safety of TV Tuner Note to CATV System Installer - This reminder is provided to call the CATV systems installer's attention to Section 820-93 of the National Electric Code which provide guidelines for proper grounding and, in particular, specify that the Coaxial cable shield be connected to the grounding system of the building as close to the point of cable entry as practical.

  • Page 17: Specifications

    NTUC0 User Manual Specifications • Ultra Low Voltage(ULV) Intel Celeron Processor • Single Core, 1.2/1.3GHz, • FSB 800MHz • On die, up to 1MB L2 cache * Ultra Low Voltage(ULV) Intel ® Pentium® Processor • Single Core, 1.3GHz, • FSB 800MHz, •...
  • Page 18 Specifications • 2.0M Pixel CMOS via USB2.0 interface Keyboard • 86/87 keys support with 100/101 key emulation without stick-point • Windows key, Application key • 285mm, 5.0mm height, 19.05mm pitch, 2.4mm travel length. • Multi-Langue support. Hard Disk Drive (HDD) •...
  • Page 19 NTUC0 User Manual 3G Module • 3G module via USB2.0 interface (option) Bluetooth • Bluetooth v2.1 with USB2.0 interface (option) Mini Card Organization • Two Mini card slots. (WiFi x1, 3Gx1) AC Adapter • Universal AC adapter • 45W with 19V DC, 65W with 19V DC •...

  • Page 21: Chapter 1 Introducing Your Notebook

    Chapter 1 Introducing Your Notebook ①...

  • Page 22: Front Side

    NTUC0 User Manual 1.1 Front Side The following picture shows the front side of your notebook. Camera WOW Audio Microphone Power Button Caps Lock(Blue) Power(Blue) Num Lock(Blue) Battery(Blue/Amber) Wireless Button HDD(Blue) Program DJ Wireless Status WOW Video 1.1.1 Camera...

  • Page 23: Num Lock Led (Blue)

    Chapter1 Introducing Your Notebook The built-in camera supports a 1.3 or 2.0 mega pixels CMOS via USB2.0 interface. 1.1.2 Caps Lock (Blue) Caps lock LED (Blue): Caps Lock State of Keyboard NOTE: In normal mode (Cursor and Num function are disable), when users press Hot Key, the Cursor LED will be on.

  • Page 24: Hdd Accessing State Blue Led ( )

    NTUC0 User Manual Battery states LED is one dual-color LED indicator both of Blue and Amber color. 1.1.10 HDD accessing state Blue LED ( Reflect the activities of Blue LED. Note: LED is controlled directly by hardware. 1.1.11 Wireless Status...

  • Page 25: Right Side

    Chapter1 Introducing Your Notebook 1.2 Right Side HDMI e-SATA USB 2.0 CRT，15-pin RJ-45 Kensington Lock 1.2.1 HDMI Port The High-Definition Multimedia Interface (HDMI) is a compact audio/video connector interface for transmitting uncompressed digital streams. It represents a digital alternative to consumer analog standards such as Radio Frequency (RF) coaxial cable, composite video, S-Video, SCART, component video, D-Terminal, and VGA 1.2.2 USB 2.0 USB is a peripheral expansion standard that supports data-transfer rates up to...

  • Page 26: Kensington Lock

    NTUC0 User Manual 1.2.3 RJ-45 The RJ-45 network jack allows you to connect your notebook to a local area network (LAN). Be careful not to plug the telephone line into the slightly larger network connector. 1.2.4 Kensington Lock A Kensington Security Slot is a small, metal-reinforced hole found on almost all small...

  • Page 27: Left Side

    Chapter1 Introducing Your Notebook 1.3 Left Side DC-in USB 2.0 Microphone Headphone Media Card 1.3.1 DC-in Use this connector to attach the AC adapter to your notebook. You can connect an AC adapter when your notebook is switched on or off. While the AC adapter works with electrical outlets worldwide, power connectors and power strips vary by country.

  • Page 28: Media Card

    NTUC0 User Manual USB is a peripheral expansion standard that supports data-transfer rates up to 480 Mbps. USB peripherals has a single standard for cables and connectors. You can install and remove USB devices while the computer is on. This is called “hot swapping”.

  • Page 29: Bottom Side

    Chapter1 Introducing Your Notebook 1.4 Bottom Side The following picture shows the bottom side of your notebook Battery Latch Battery Knob RAM Door HDD Door 1.4.1 To remove the Battery Pack: Move the Battery Lock Switch to the right (Unlock position). Slide the Battery Release Latch to the left and gently pry the Battery Pack from the computer chassis.

  • Page 30: Chapter 2 Operating Your Notebook (Vista)

    Chapter 2 Operating Your Notebook (Vista) ②...

  • Page 31: Turning Your Notebook On And Off

    Chapter2 Operating Your Notebook (Vista) 2.1 Turning Your Notebook On and Off Turning Your Notebook On Turning Your Notebook Off Logging Off Adding User Accounts Sleep Mode...

  • Page 32: Turning Your Notebook On

    NTUC0 User Manual 2.1.1 Turning Your Notebook On You can configure the computer to start from a specific drive, such as an external floppy disk, or even an external device. See 9.5 The Boot Menu. Press the power button to turn on your notebook.

  • Page 33: Sleep Mode

    Chapter2 Operating Your Notebook (Vista) With Windows Vista installed, the system administrator or a user with administrator rights can create additional user accounts: Click Start > Control Panel > User Accounts and Family Safety > User Accounts > Manage another account. When prompted, click Continue.

  • Page 34: Tips For Using Windows

    NTUC0 User Manual 2.2 Tips for Using Windows Microsoft Windows Vista Help Windows Desktop Start Button Taskbar Notification Area (System Tray) Recycle Bin Control Panel Computer...

  • Page 35: Microsoft Windows Vista Help

    Chapter2 Operating Your Notebook (Vista) 2.2.1 Microsoft Windows Vista Help For Microsoft Windows Vista help, go to Start > Help and Support. The Windows Help and Support dialog box opens.

  • Page 36: Windows Desktop

    NTUC0 User Manual 2.2.2 Windows Desktop Depending on your notebook setup and software, your desktop may have different or additional shortcuts. See 2.4 Personalizing Your Desktop for more information.

  • Page 37: Start Button

    Chapter2 Operating Your Notebook (Vista) 2.2.3 Start Button The Start button allows easy access to your notebook’s programs. The Start menu is designed to adapt to show the programs you use most frequently. To always keep an item on the Start menu, no matter how often it’s used, right-click the item and click Pin to Start menu.

  • Page 38: Taskbar

    NTUC0 User Manual 2.2.4 Taskbar The Start button is on the left and the notification area on the right. Each time you open a program; a button for it appears on the taskbar. To move between programs, simply click the relevant button. Windows Vista groups multiple instances of the same program on a single taskbar button if more space is needed.

  • Page 39: Recycle Bin

    Chapter2 Operating Your Notebook (Vista) 2.2.6 Recycle Bin When you delete a file, it is moved to the Recycle Bin. Files can be restored from the Recycle Bin. Emptying the Recycle Bin deletes files permanently. 2.2.7 Control Panel In the Control Panel, you can change how Windows looks and works. Click the Start button and then Control Panel.
  • Page 40 NTUC0 User Manual You can also use Windows Explorer to see the contents of your notebook and find files. To open Windows Explorer, right-click the Start button and click Explore. Find the drive or folder that you want to view. To find out more about Computer and Windows Explorer, see the Windows Help and Support.

  • Page 41: Keyboard And Touch Pad

    Chapter2 Operating Your Notebook (Vista) 2.3 Keyboard and Touch Pad Numeric Keypad Keyboard Shortcuts Windows Logo Key Functions Sticky Keys Touch Pad Area Customizing the Touch Pad 2-11...

  • Page 42: Numeric Keypad

    NTUC0 User Manual 2.3.1 Numeric Keypad Keypad numbers and symbols are marked in blue on the lower right edge of the keypad keys. To enable the numeric keypad, press indicator will light when the numeric lock is on. To disable the numeric keypad, press again.

  • Page 43: Windows Logo Key Functions

    Chapter2 Operating Your Notebook (Vista) Volume Up Window Mobility Center 3G on/off Wireless/Bluetooth on/off Media Play Media Stop Media Previous Track Media Next Track 2.3.3 Windows Logo Key Functions Opens Windows Explorer Opens the Run dialog box Opens the Search Results dialog box Opens the Search Results - Computers dialog box (when your notebook is connected to a network) Opens the System Properties dialog box...

  • Page 44: Sticky Keys

    NTUC0 User Manual 2.3.4 Sticky Keys The Sticky Keys function lets you use the SHIFT, CTRL, ALT, FN keys or the Windows logo key (referred to as modifier keys) in conjunction with other keys by pressing one key at a time instead of simultaneously.

  • Page 45: Touch Pad Area

    Chapter2 Operating Your Notebook (Vista) Click Turn on Sticky Keys to enable the listed shortcuts to activate Sticky Keys mode. By checking Lock modifier keys when pressed twice in a row, pressing the SHIFT, CTRL, ALT, FN or the Windows logo key twice will ‘lock’ the key until it is pressed again.

  • Page 46: Customizing The Touch Pad

    NTUC0 User Manual The Touch Pad Area responds to the movements and pressure of your finger, allowing you to move the cursor around the screen, in the same way you would with a mouse.(The Touch Pad Area as the red marked in the figure.) Place your fingers on the keyboard in the normal typing position.

  • Page 47: Personalizing Your Desktop

    Chapter2 Operating Your Notebook (Vista) 2.4 Personalizing Your Desktop Choosing a Wallpaper Choosing a Screen Saver Choosing a Desktop Theme Creating a Shortcut on the Desktop 2-17...

  • Page 48: Choosing A Wallpaper

    NTUC0 User Manual 2.4.1 Choosing a Wallpaper To make your notebook reflect your style, you can set background colors, patterns, and the wallpaper on the desktop. Control Panel > Appearance and Personalization > Change desktop background. Choose the picture or color you want for your desktop background.

  • Page 49: Creating A Shortcut On The Desktop

    Chapter2 Operating Your Notebook (Vista) 2.4.4 Creating a Shortcut on the Desktop A shortcut is an icon that is placed on the desktop let you quickly access programs, files, folders, and drivers. To create a shortcut: Open Computer or Windows Explorer, and highlight the file or program you want to create a shortcut to.

  • Page 50: Display

    NTUC0 User Manual 2.5 Display Adjusting the Brightness Using an External Monitor or Television Setting the Display Resolution 2-20...
  • Page 51 Chapter2 Operating Your Notebook (Vista) 2.5.1 Adjusting the Brightness To conserve power when running your notebook from the battery, set the brightness to the lowest comfortable setting using the keyboard shortcuts. Brightness Down Brightness Up 2.5.2 Using an External Monitor When you start your notebook with an external display device such as an external monitor attached and turned on, the image may appear on either the display or the external device.

  • Page 52: Networks

    NTUC0 User Manual 2.6 Networks To access a network: At the office, you can access a network via the built-in PCI-E LAN. For specific information about connecting to the LAN or WAN, consult your systems administrator. If you are working at home or while traveling, you need a dial-up connection. Ask your system administrator for the telephone number of the network.

  • Page 53: Managing Programs

    Chapter2 Operating Your Notebook (Vista) 2.7 Managing Programs Running Programs Adding Software Removing Software 2-23...

  • Page 54: Running Programs

    NTUC0 User Manual 2.7.1 Running Programs Programs are any software that process data - like a word processing program or an email program. They require an operating system - like Windows Vista - to run on. To run a program, click Start > All Programs.
  • Page 55 Chapter2 Operating Your Notebook (Vista) Once you’ve begun removing software, do not interrupt the process. To do so may result in data loss and corruption of your operating system. Start > Control Panel > Programs > Uninstall a program. Select the program that you want to remove and click the Uninstall or Change button. Instructions for removing programs will appear on the screen.

  • Page 56: Managing Files

    NTUC0 User Manual 2.8 Managing Files Updating Antivirus Software Backing Up Files Finding Files Copying a File on the Hard Drive Renaming Files Deleting Files Emptying the Recycle Bin Retrieving Files From the Recycle Bin 2-26...
  • Page 57 Chapter2 Operating Your Notebook (Vista) 2.8.1 Updating Antivirus Software There are thousands of known viruses, and more appear all the time. Installing antivirus software is the only way to protect your data, software and hardware. Regular updates are necessary to ensure protection. Your notebook dealer can advise you regarding purchasing antivirus software.

  • Page 58: Deleting Files

    NTUC0 User Manual Never change a file’s extension (the last three characters after the period). Doing so may render the file unusable. Type the new filename and press Enter. 2.8.6 Deleting Files Never delete files that are part of an installed program. Doing so may render the file unusable.
  • Page 59 Chapter2 Operating Your Notebook (Vista) Select the file you want to retrieve, and click Restore this item. The file disappears from the Recycle Bin and is moved to its original location. You can also recover all the files from the Recycle Bin by clicking Restore all items. 2-29...

  • Page 60: Playing Movies

    NTUC0 User Manual 2.9 Playing Movies Adjusting the Volume Adjusting the Picture 2-30...
  • Page 61 Chapter2 Operating Your Notebook (Vista) 2.9.1 Adjusting the Volume If you do not hear anything when playing a CD or DVD, check that the speakers are not muted. Start > All Programs > Accessories > Windows Mobility Center. In the Windows Mobility Center window, click and drag the bar in the Volume column and slide it left or right to decrease or increase the volume.

  • Page 63: Chapter 3 Operating Your Notebook (Windows7)

    Chapter 3 Operating Your Notebook (Windows7) ③...

  • Page 64: Turning Your Notebook On And Off

    Chapter3 Operating Your Notebook (Windows7) 3.1 Turning Your Notebook On and Off Turning Your Notebook On Turning Your Notebook Off Logging Off Adding User Accounts Sleep Mode...

  • Page 65: Turning Your Notebook On

    NTUC0 User Manual 3.1.1 Turning Your Notebook On You can configure the computer to start from a specific drive, such as an external floppy disk, or even an external device. See 9.5 The Boot Menu. Press the power button to turn on your notebook.

  • Page 66: Adding User Accounts

    Chapter3 Operating Your Notebook (Windows7) 3.1.4 Adding User Accounts Different account options are available when a computer is running Windows 7 operating system and is connected to a domain. With Windows 7 installed, the system administrator or a user with administrator rights can create additional user accounts: Click Start >...

  • Page 67: Tips For Using Windows

    NTUC0 User Manual 3.2 Tips for Using Windows Microsoft Windows 7 Help Windows Desktop Start Button Taskbar Notification Area (System Tray) Recycle Bin Control Panel Computer...

  • Page 68: Microsoft Windows 7 Help

    Chapter3 Operating Your Notebook (Windows7) 3.2.1 Microsoft Windows 7 Help For Microsoft Windows 7 help, go to Start > Help and Support. The Windows Help and Support dialog box opens.

  • Page 69: Windows Desktop

    NTUC0 User Manual 3.2.2 Windows Desktop Depending on your notebook setup and software, your desktop may have different or additional shortcuts. See 3.4 Personalizing Your Desktop for more information.

  • Page 70: Start Button

    Chapter3 Operating Your Notebook (Windows7) 3.2.3 Start Button The Start button allows easy access to your notebook’s programs. The Start menu is designed to adapt to show the programs you use most frequently. To always keep an item on the Start menu, no matter how often it’s used, right-click the item and click Pin to Start menu.

  • Page 71: Taskbar

    NTUC0 User Manual 3.2.4 Taskbar The Start button is on the left and the notification area on the right. Each time you open a program; a button for it appears on the taskbar. To move between programs, simply click the relevant button. Windows 7 groups multiple instances of the same program on a single taskbar button if more space is needed.

  • Page 72: Control Panel

    Chapter3 Operating Your Notebook (Windows7) When you delete a file, it is moved to the Recycle Bin. Files can be restored from the Recycle Bin. Emptying the Recycle Bin deletes files permanently. 3.2.7 Control Panel In the Control Panel, you can change how Windows looks and works. Click the Start button and then Control Panel.
  • Page 73 NTUC0 User Manual You can also use Windows Explorer to see the contents of your notebook and find files. To open Windows Explorer, right-click the Start button and click Explore. Find the drive or folder that you want to view. To find out more about Computer and Windows Explorer, see the Windows Help and Support.

  • Page 74: Keyboard And Touch Pad

    Chapter3 Operating Your Notebook (Windows7) 3.3 Keyboard and Touch Pad Numeric Keypad Keyboard Shortcuts Windows Logo Key Functions Sticky Keys Touch Pad Area Customizing the Touch Pad 3-11...

  • Page 75: Numeric Keypad

    NTUC0 User Manual 3.3.1 Numeric Keypad Keypad numbers and symbols are marked in blue on the lower right edge of the keypad keys. To enable the numeric keypad, press indicator will light when the numeric lock is on. To disable the numeric keypad, press again.

  • Page 76: Windows Logo Key Functions

    Chapter3 Operating Your Notebook (Windows7) Volume Up Window Mobility Center 3G on/off Wireless/Bluetooth on/off Media Play Media Stop Media Previous Track Media Next Track 3.3.3 Windows Logo Key Functions Opens Windows Explorer Opens the Run dialog box Opens the Search Results dialog box Opens the Search Results - Computers dialog box (when your notebook is connected to a network) Opens the System Properties dialog box...

  • Page 77: Sticky Keys

    NTUC0 User Manual 3.3.4 Sticky Keys The Sticky Keys function lets you use the SHIFT, CTRL, ALT, FN keys or the Windows logo key (referred to as modifier keys) in conjunction with other keys by pressing one key at a time instead of simultaneously.

  • Page 78: Touch Pad Area

    Chapter3 Operating Your Notebook (Windows7) Click Turn on Sticky Keys to enable the listed shortcuts to activate Sticky Keys mode. By checking Lock modifier keys when pressed twice in a row, pressing the SHIFT, CTRL, ALT, FN or the Windows logo key twice will ‘lock’ the key until it is pressed again.

  • Page 79: Customizing The Touch Pad

    NTUC0 User Manual Place your fingers on the keyboard in the normal typing position. You can use the Touch Pad by moving either your right or left thumb off the space bar and on to the Touch Pad Area. Gently move your index finger across the Touch Pad Area in the direction you want the cursor to move.

  • Page 80: Personalizing Your Desktop

    Chapter3 Operating Your Notebook (Windows7) 3.4 Personalizing Your Desktop Choosing a Wallpaper Choosing a Screen Saver Choosing a Desktop Theme Creating a Shortcut on the Desktop 3-17...

  • Page 81: Choosing A Wallpaper

    NTUC0 User Manual 3.4.1 Choosing a Wallpaper To make your notebook reflect your style, you can set background colors, patterns, and the wallpaper on the desktop. Control Panel > Appearance and Personalization > Change desktop background. Choose the picture or color you want for your desktop background.

  • Page 82: Creating A Shortcut On The Desktop

    Chapter3 Operating Your Notebook (Windows7) 3.4.4 Creating a Shortcut on the Desktop A shortcut is an icon that is placed on the desktop let you quickly access programs, files, folders, and drivers. To create a shortcut: Open Computer or Windows Explorer, and highlight the file or program you want to create a shortcut to.

  • Page 83: Display

    NTUC0 User Manual 3.5 Display Adjusting the Brightness Using an External Monitor or Television Setting the Display Resolution 3-20...
  • Page 84 Chapter3 Operating Your Notebook (Windows7) 3.5.1 Adjusting the Brightness To conserve power when running your notebook from the battery, set the brightness to the lowest comfortable setting using the keyboard shortcuts. Brightness Down Brightness Up 3.5.2 Using an External Monitor When you start your notebook with an external display device such as an external monitor attached and turned on, the image may appear on either the display or the external device.

  • Page 85: Networks

    NTUC0 User Manual 3.6 Networks To access a network: At the office, you can access a network via the built-in PCI-E LAN. For specific information about connecting to the LAN or WAN, consult your systems administrator. If you are working at home or while traveling, you need a dial-up connection. Ask your system administrator for the telephone number of the network.

  • Page 86: Managing Programs

    Chapter3 Operating Your Notebook (Windows7) 3.7 Managing Programs Running Programs Adding Software Removing Software 3-23...

  • Page 87: Running Programs

    NTUC0 User Manual 3.7.1 Running Programs Programs are any software that process data - like a word processing program or an email program. They require an operating system - like Windows 7 - to run on. To run a program, click Start > All Programs.

  • Page 88: Removing Software

    Chapter3 Operating Your Notebook (Windows7) 3.7.3 Removing Software Once you’ve begun removing software, do not interrupt the process. To do so may result in data loss and corruption of your operating system. Start > Control Panel > Programs > Uninstall a program. Select the program that you want to remove and click the Uninstall or Change button.

  • Page 89: Managing Files

    NTUC0 User Manual 3.8 Managing Files Updating Antivirus Software Backing Up Files Finding Files Copying a File on the Hard Drive Renaming Files Deleting Files Emptying the Recycle Bin Retrieving Files From the Recycle Bin 3-26...
  • Page 90 Chapter3 Operating Your Notebook (Windows7) 3.8.1 Updating Antivirus Software There are thousands of known viruses, and more appear all the time. Installing antivirus software is the only way to protect your data, software and hardware. Regular updates are necessary to ensure protection. Your notebook dealer can advise you regarding purchasing antivirus software.

  • Page 91: Deleting Files

    NTUC0 User Manual Never change a file’s extension (the last three characters after the period). Doing so may render the file unusable. Type the new filename and press Enter. 3.8.6 Deleting Files Never delete files that are part of an installed program. Doing so may render the file unusable.
  • Page 92 Chapter3 Operating Your Notebook (Windows7) Select the file you want to retrieve, and click Restore this item. The file disappears from the Recycle Bin and is moved to its original location. You can also recover all the files from the Recycle Bin by clicking Restore all items. 3-29...

  • Page 93: Playing Movies

    NTUC0 User Manual 3.9 Playing Movies Adjusting the Volume Adjusting the Picture 3-30...
  • Page 94 Chapter3 Operating Your Notebook (Windows7) 3.9.1 Adjusting the Volume If you do not hear anything when playing a CD or DVD, check that the speakers are not muted. Start > All Programs > Accessories > Windows Mobility Center. In the Windows Mobility Center window, click and drag the bar in the Volume column and slide it left or right to decrease or increase the volume.

  • Page 96: Chapter 4 Innovative Product Feature

    Chapter 4 Innovative Product Feature ④...
  • Page 97 Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Features described in this product guide are developed and copyright owned by Compal Electronics, Inc. Some of the features may not be available in certain models.

  • Page 98: Easy Logon

    NTUC0 User Manual • Easy Logon • Easy to launch Compal Innovative Products • Friendly operations to fast select various applications • Enables better control, design, and development from richer user interface • Experience the different impressions on using and controlling applications •...

  • Page 99: Depth Security Control

    Chapter4 Innovative Product Feature • The User Define option provides user an advanced chance to customize their personal scenario. Depth Security Control • When power-on, the system automatically enable the build-in webcam and execute a security check from its database to see if the user had been authorized to allow to get into the system or not.
  • Page 100 How to Launch Innovative product From Start Menu Innovative Product can be launched from start menu Start--> Program DJ--> Innovative Product From Program DJ By clicking on the Innovative Product icon can be launch the Program DJ Scenarios Launch Compal application via Program DJ...

  • Page 101: Easy Logon

    Chapter4 Innovative Product Feature 4.1 Easy Logon 4.1.1 Program DJ Figure 01: Program DJ Main Dialog Operation Procedure To launch Program DJ, the Program DJ mains interface appears for users to select the program they want to use. The sequence of icons depends on what and how much application has been installed. The application quantities may not be the same because some applications need special hardware.
  • Page 102 NTUC0 User Manual User Interfaces, 1. Close button To close Program DJ, click on the close button on the side or press the preset Program DJ launch key to close it. Program DJ will not withdraw back after application software has been selected.

  • Page 103: Power Control

    Chapter4 Innovative Product Feature 4.2 Power Control 4.2.1 Green Charger Scenarios An environmental care concept had been applied to the product by utilizing the mechanism of battery management to keep the earth green as well as extend the life cycle of the battery usage. Main Functions There are 3 modes to choose from when recharging the battery.
  • Page 104 NTUC0 User Manual Battery Full Charged Green Charger will charge the battery to a fully charged status of its capacity. The benefit for this mode is to maintain the battery in its biggest capacity status against to its nature decadency.
  • Page 105 Chapter4 Innovative Product Feature 1. User can click the “Default” button to load the default Green Charger settings. After clicking the “Default” button, it will restore all options to default settings. It will activate the settings only after clicking the “OK” button, or else, discard them by clicking other buttons.

  • Page 106: Joyful Experience

    NTUC0 User Manual 4.3 Joyful Experience 4.3.1 WOW Audio Scenario WOW Audio is a setting assortment for Video conditions preset in Tone, Bass, Balance and Volume that offer users a chance to select the most-fit combination according to their preference. The preset scenarios are Normal, Speech, Classic, Rock and POP...

  • Page 107: Wow Video

    Chapter4 Innovative Product Feature 4.3.2 WOW Video Scenario WOW Video is a setting assortment for Audio conditions preset in Color Defines, Resolutions and Viewing Sizes that offer users a chance to select the most-fit scenario according to their preference. The preset scenarios are Normal, Office, Photo, Movie and User Define. Define. The User Define option provides user an advanced chance to customize their personal scenario.
  • Page 108 NTUC0 User Manual Figure 07: Photo mode (circle left) provides higher details on objects, While Movie mode (circle right) provides lower. 5. User Define: Allows users to have their own unique system setting according their preference. To click the “Right button” of touch pad to setup the detail settings of the Wow video scheme.

  • Page 109: Depth Security Control

    Chapter4 Innovative Product Feature 4.4 Depth Security Control 4.4.1 Entrance Guard Scenario This feature provides an auto logon mechanism to your MS Windows system by utilizing the built-in webcam to recognize the face of users who intend to logon to the system. It secures the exposure of the IDs and passwords, as well as to make the logon very easy and speedy.
  • Page 110 NTUC0 User Manual Account Management (1) Create New Account Users can manage the Entrance Guard accounts via this function. Users can use the webcam to capture new faces, and then setup new security password to create new user account. (2) Delete Account Users can delete the current running Entrance Guard account (Self-delete).
  • Page 111 Chapter4 Innovative Product Feature Advanced Settings In this setting page, users can find more advanced information and settings for experienced users. (1) Password Management Users can see what their preset logon information. Users can do some changes including delete or correct field data. (2) Option Users can change the default setting on some preset Entrance Guard behaviors.
  • Page 112 NTUC0 User Manual Figure 13: Entrance Guard-Setup (1) 2. Input user’s windows password to create a new Account. Press “OK”. (Figure 14) Figure 14: Entrance Guard-Account Training dialog 3. Counting backwards for 5 seconds, System will catch the face information through the webcam used as data of the account.
  • Page 113 Chapter4 Innovative Product Feature Figure 15: Entrance Guard Account Training Dialog 8. After face image verification, users will be asked to key-in the security password. (Figure 16) Figure 16: Security Password Setting Dialog 9. User can store the security password in the proper location. (Default or customized) (Figure 17) Figure 17: Security Password Saving Dialog After the whole new Entrance Guard account creation procedure has been completed,...
  • Page 114 NTUC0 User Manual Figure 18: Account Creation Finish Dialog Delete Account Click on “Delete Account”, Face Authentication will first detect face to verify user identity and then delete account. Figure 19: Face Authentication Dialog Update Account Click on “Update Account” System will catch the face information through the webcam used as data of the account again.

  • Page 115: Smart Watchdog

    Chapter4 Innovative Product Feature 4.4.2 Smart Watchdog Scenario Smart Watchdog is a monitoring application that utilizes webcam function for extended service to users. By using the built-in webcam, the Smart Watchdog can detect the presence of the users for an advanced power management and enhance the security of the data inside the laptop from spying.
  • Page 116 NTUC0 User Manual (5) Hibernate Time Setting This feature is for setting the time period before system will go into Hibernate mode. Figure 21: Smart Watchdog – System Hibernate Screen Operation Procedure 1. Click on “Smart Watchdog” icon under “Smart Watchdog” folder and dialog shown.

  • Page 117: Safety Guard

    Chapter4 Innovative Product Feature 4.4.3 Safety Guard Scenario This is a compound technology by the Video Tracing through webcam through Digital Microphone. Safety only needs webcam and Microphone. Users can utilize this feature for safety assurance or other monitoring applications. Main Functions 1.
  • Page 118 NTUC0 User Manual View Records Mode In “View Records” mode, user can review the abnormal files that were recorded at tracing process. The files are stored in the folder at “C:\Users\{user account}\Documents\Safety Guard\ AVStream\”. Figure 23: Safety Guard View Records Mode Press “...
  • Page 119 Chapter4 Innovative Product Feature condition, then press “Add to List” button. 4. Tracing Settings Press “Tracing Settings” button then shows the “Settings” dialog This page for user to change the following settings: recording setting, user mail setting and SMS setting. Figure 25: Safety Guard Settings Dialog Recording Setting Record time mark: Add time mark on the video frame when recording.
  • Page 120 NTUC0 User Manual Sender: Set the e-mail address as the sender of the mail. SMTP server: Set the SMTP server for sending e-mail. Port: Fill in the port number, which is provided by the SMTP service provider. SSL: Check it if the server requires a secure connection.

  • Page 121: User Friendly

    Chapter4 Innovative Product Feature 4.5 User Friendly 4.5.1 Wireless Switch Scenarios Users set the Wireless Switch preference. Only when Bluetooth and WLAN (802.11x) devices both exist, users can adjust their preference. Figure 26: Wireless Manager Operation Procedure Apply both Bluetooth and WLAN (802.11x) devices. Apply Bluetooth device.

  • Page 122: Project Communication

    NTUC0 User Manual 4.6 Project communication 4.6.1 EzRemote Scenarios EzRemote supports only Windows Vista and later Figure 27: Launch EzRemote from Program DJ Main Functions 1. Configure Free Configure Free function provide user can set two things. • Switch condition, user can select Signal Strength or Preferred Network in switch condition.
  • Page 123 Chapter4 Innovative Product Feature Figure 28: Setting Dialog 2. Scan and Connect System will scan and connect Access Point manually or automatically 3. Location Base Figure 29: Location Base It will display some information as follow (see Figure 29: Location Base) •...
  • Page 124 NTUC0 User Manual Please select the ”SAVE” item when use the Wireless Network User can double click the Wireless Network icon and login it. The logon dialog is provided by OS. (See Figure 30: Logon dialog of Wireless Network) Figure 30: Logon dialog of Wireless Network 4.
  • Page 125 Chapter4 Innovative Product Feature Figure 31: Contact list Figure 32: Talk window 4-29...

  • Page 126: Eztube

    NTUC0 User Manual Figure 33: Invite to the chatting 4.6.2 EzTube Scenarios Need the web site of user when you want to upload image or video to Yahoo. So if this product wants to support it, we need to prepare a web site with 24-hour service for user.
  • Page 127 Chapter4 Innovative Product Feature Figure 34: Main dialog 2. Webbing Allow user can upload video or image to YouTube or Flickr popular web site. Figure35: Upload to special web site 3. File Manager If user record video or capture image via this system, system will follow file naming rule to add file.
  • Page 128 NTUC0 User Manual Figure 36: URL in Video mode 4-32...

  • Page 129: Caring For Your Notebook

    Chapter 5 Caring for Your Notebook ⑤...

  • Page 130: Cleaning Your Notebook And Keyboard

    NTUC0 User Manual 5.1 Caring for Your Notebook Cleaning Your Notebook and Keyboard Cleaning the Display Cleaning the Touch Pad Precautions...
  • Page 131 Chapter5 Caring for Your Notebook 5.1.1 Cleaning Your Notebook and Keyboard Shut your notebook down, turn it off and disconnect it from the electrical outlet and any external devices, such as the printer. Remove the battery pack. Use the brush attachment of your vacuum cleaner to gently remove dust from your notebook’s openings and keyboard.
  • Page 132 NTUC0 User Manual magnetically. Placing the magnet too close to the disk can erase the important files. • Scan all new files for viruses. This precaution is especially important for the files you receive via email, disk or download from the Internet. You will need the special program to scan for viruses.

  • Page 133: Traveling

    Chapter5 Caring for Your Notebook 5.2 Traveling Identifying Your Notebook Packing Your Notebook Traveling Tips If Your Notebook is Lost or Stolen...

  • Page 134: Travel Tips

    NTUC0 User Manual 5.2.1 Identifying Your Notebook Attach a nametag or business card to your notebook, or use the permanent marker or stencil to write a unique identifying mark (such as your driver’s license number) on the case. Create a file on the Desktop called if found. Place information such as your name, address, and telephone number in this file.

  • Page 135: If Your Notebook Is Lost Or Stolen

    Chapter5 Caring for Your Notebook • Check with your credit card company for information about any kinds of emergency travel assistance it offers to the users of the portable computers. • When traveling in the air, please ensure that you have a charged battery available in case you are asked to turn on your notebook.

  • Page 136: Chapter 6 Peripherals

    Chapter 6 Peripherals ⑥...

  • Page 137: Adding And Removing Sd/Mmc/Ms Cards

    Chapter6 Peripherals 6.1 Adding and Removing SD/MMC/MS Cards Before removing an SD/MMC/MS card, stop it running from the configuration utility on the taskbar. Failure to do so could result in the data loss. Insert the SD/MMC/MS card into the card reader slot. To remove the SD/MMC/MS card, please push it in gently and then it ejects automatically.

  • Page 138: Memory Modules

    NTUC0 User Manual 6.2 Memory Modules You can add more memory modules to your notebook to improve its performance. To install a memory module: Make sure the computer is turned off. Remove the screws securing the RAM cover. There are two memory module ports. Place the new memory module in the slot, matching up the notch along its connector rim with the tooth in the connection slot.
  • Page 139 Chapter6 Peripherals Remove screws securing the RAM cover. Pop out both silver latches holding the memory module into place. The module pops Grasp the outer edges of the memory module with the thumb and forefinger, and then gently remove it.

  • Page 141: Chapter 7 The Power System (Vista)

    Chapter 7 The Power System (Vista) ⑦...

  • Page 142: Power Management

    Chapter7 The Power System (Vista) 7.1 Power Management Managing Your Notebook’s Power Power Management Modes Power Options Properties Speed Step...

  • Page 143: Sleep Mode

    NTUC0 User Manual 7.1.1 Managing Your Notebook’s Power See 7.2 Battery for more information on getting the best performance from the battery packs. Use your notebook connected to an electrical outlet as often as possible as the battery life expectancy is affected by the number of times it is charged.

  • Page 144: Hibernate Mode

    Chapter7 The Power System (Vista) • Press the power button • Press the start menu power button The settings can be accessed via Power Options: Advanced settings window. See 7.1.1 Managing Your Notebook’s Power. To exit Sleep Mode, please press the Power Button. You cannot exit Sleep Mode by using any key or the Touch Pad.

  • Page 145: Select A Power Plan

    NTUC0 User Manual 7.1.3.1 Select a power plan Windows Vista provides three preset power plans-Balanced, Power saver, and High performance. Each plan has the different time-out settings for turning off the display and entering Sleep Mode. You do not need to make any further adjustments to set the performance level.

  • Page 146: Create A Power Plan

    Chapter7 The Power System (Vista) • Set the computer to Do nothing / Sleep / Hibernate / Shutdown when you close the laptop lid • Select the password requirement when the computer wakes from sleep. 7.1.3.3 Create a power plan Besides three preset power plans offered in Windows Vista, you can also customize your own power plan.
  • Page 147 NTUC0 User Manual Windows Vista automatically chooses the Speed Step Mode to find the most appropriate speed for your processor according to the type of plan you choose and your current system demands.

  • Page 148: Battery

    Chapter7 The Power System (Vista) 7.2 Battery Battery Performance Checking the Battery Charge Power Meter Low-Battery Warning Charging the Battery Removing a Battery Installing a Battery Storing a Battery Working With Extra Battery Packs Maximizing Battery Life...
  • Page 149 NTUC0 User Manual 7.2.1 Battery Performance The Battery Performance can be varied with on the different operating conditions. Your battery may last less time if you are running power-intensive programs, playing CDs or DVDs, or setting the high display-brightness. The Power Management Options can be set to alert you when the battery charge is low.
  • Page 150 Chapter7 The Power System (Vista) After a low-battery warning, save your work immediately and then connect your notebook to an electrical outlet. Hibernate Mode will begin automatically if the battery runs completely out of power. You will hear the low-battery warning when the battery charge is approximately 90 percent depleted.
  • Page 151 NTUC0 User Manual After a low-battery warning, save your work immediately and then connect your notebook to an electrical outlet. Hibernate Mode will begin automatically if the battery runs completely out of power. You will hear the low-battery warning when the battery charge is approximately 90 percent depleted.
  • Page 152 Chapter7 The Power System (Vista) • If you are not using your notebook for a long period, please remove the battery. • If you have a spare battery pack, please alternate the batteries. • Ensure your notebook is off when replacing the battery. Store the spare battery packs in a cool, dry place, out of the direct sunlight.

  • Page 154: Chapter 8 The Power System (Windows 7)

    Chapter 8 The Power System (Windows 7) ⑧...

  • Page 155: Power Management

    Chapter8 The Power System (Windows 7) 8.1 Power Management Managing Your Notebook’s Power Power Management Modes Power Options Properties Speed Step...

  • Page 156: Sleep Mode

    NTUC0 User Manual 8.1.1 Managing Your Notebook’s Power See 8.2 Battery for more information on getting the best performance from the battery packs. Use your notebook connected to an electrical outlet as often as possible as the battery life expectancy is affected by the number of times it is charged.

  • Page 157: Hibernate Mode

    Chapter8 The Power System (Windows 7) • Press the power button • Press the start menu power button The settings can be accessed via Power Options: Advanced settings window. See 8.1.1 Managing Your Notebook’s Power To exit Sleep Mode, please press the Power Button. You cannot exit Sleep Mode by using any key or the Touch Pad.

  • Page 158: Select A Power Plan

    NTUC0 User Manual 8.1.3.1 Select a power plan Windows 7 provides three preset power plans-Balanced, Power saver, and High performance. Each plan has the different time-out settings for turning off the display and entering Sleep Mode. You do not need to make any further adjustments to set the performance level.

  • Page 159: Create A Power Plan

    Chapter8 The Power System (Windows 7) • Set the computer to Do nothing / Sleep / Hibernate / Shutdown when you close the laptop lid • Select the password requirement when the computer wakes from sleep. 8.1.3.3 Create a power plan Besides three preset power plans offered in Windows 7, you can also customize your own power plan.
  • Page 160 NTUC0 User Manual Windows 7 automatically chooses the Speed Step Mode to find the most appropriate speed for your processor according to the type of plan you choose and your current system demands.

  • Page 161: Battery

    Chapter8 The Power System (Windows 7) 8.2 Battery Battery Performance Checking the Battery Charge Power Meter Low-Battery Warning Charging the Battery Removing a Battery Installing a Battery Storing a Battery Working With Extra Battery Packs Maximizing Battery Life...

  • Page 162: Low-Battery Warning

    NTUC0 User Manual 8.2.1 Battery Performance The Battery Performance can be varied with on the different operating conditions. Your battery may last less time if you are running power-intensive programs, playing CDs or DVDs, or setting the high display-brightness. The Power Management Options can be set to alert you when the battery charge is low.
  • Page 163 Chapter8 The Power System (Windows 7) After a low-battery warning, save your work immediately and then connect your notebook to an electrical outlet. Hibernate Mode will begin automatically if the battery runs completely out of power. You will hear the low-battery warning when the battery charge is approximately 90 percent depleted.

  • Page 164: Removing The Battery

    NTUC0 User Manual After a low-battery warning, save your work immediately and then connect your notebook to an electrical outlet. Hibernate Mode will begin automatically if the battery runs completely out of power. You will hear the low-battery warning when the battery charge is approximately 90 percent depleted.
  • Page 165 Chapter8 The Power System (Windows 7) • If you are not using your notebook for a long period, please remove the battery. • If you have a spare battery pack, please alternate the batteries. • Ensure your notebook is off when replacing the battery. Store the spare battery packs in a cool, dry place, out of the direct sunlight.

  • Page 167: Chapter 9 The Bios Setup Program

    Chapter 9 The BIOS Setup Program ⑨...

  • Page 168: Introduction

    Chapter9 The BIOS Setup Program 9.1 Introduction The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor the operation of your notebook to your individual work needs. A ROM-based configuration utility displays the system’s configuration status and provides you with a tool to set system parameters.

  • Page 169: Navigating Through The Bios Setup Program

    NTUC0 User Manual 9.2 Navigating through the BIOS Setup Program Accessing the BIOS Setup Program Launching Submenus Saving Changes and Exiting the Setup Program...
  • Page 170 Chapter9 The BIOS Setup Program The Setup program has been designed to make it as easy to use as possible. It is a menu driven program, which means you can scroll through the various directories and make your selections among the various predetermined choices. If you accidentally configure a setting, use the BIOS hot keys to return to the previous value.
  • Page 171 NTUC0 User Manual 9.2.1 Accessing the BIOS Setup Program To access the BIOS Setup program, press the [F2] key as soon as your notebook starts up. The Phoenix BIOS screen will display. Phoenix SecureCore(tm) Setup Utility Main Security Boot Exit...
  • Page 172 Chapter9 The BIOS Setup Program To move between menu bar items, use the [◄] and [►] arrow keys until the desired item is highlighted. For example, if you want to move from the Main menu to the Security menu, press the right arrow key [►] once. Item Specific Help To the right of the Setup screen, you will notice an item specific help bar.

  • Page 173: The Main Menu

    NTUC0 User Manual 9.3 The Main Menu When the Setup program is accessed, the Information screen appears. It displays the following pieces of information regarding your current system: Phoenix SecureCore(tm) Setup Utility Main Security Boot Exit Item specific Help System Time: [XX:XX:XX] <Tab>, <Shift-Tab>, or...
  • Page 174 Chapter9 The BIOS Setup Program This field reports the memory size of system base memory. The size is fixed to 640KB. Extended Memory This field reports the memory size of the extended memory with an integer in the system, but 32Bit SMI will occupy 1 MB and UMA frame buffer (Integrated VGA uses only).

  • Page 175: Security Menu

    NTUC0 User Manual 9.4 Security Menu The following is Security menu if both of passwords are disabled, or enter Supervisor password when password is enabled: Phoenix SecureCore(tm) Setup Utility Main Security Boot Exit Item specific Help Supervisor Password Is: Clear...
  • Page 176 Chapter9 The BIOS Setup Program Set Supervisor Password Enter New Password Confirm New Password If there is an old password then setup will prompt with the following window instead and a current password will be required to be entered at first: Set Supervisor Password Enter current password Enter New Password...
  • Page 177 NTUC0 User Manual Characters Alphanumeric keys only. The shift status i.e. Ctrl, Shift, Alt, and Capital are ignored. 9-10...

  • Page 178: The Boot Menu

    Chapter9 The BIOS Setup Program 9.5 The Boot Menu This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices include the diskette drive in module bay, the onboard hard disk drive and the CD-ROM in module bay. Phoenix SecureCore(tm) Setup Utility Main Security...

  • Page 179: The Exit Menu

    NTUC0 User Manual 9.6 The Exit Menu Phoenix SecureCore(tm) Setup Utility Main Security Boot Exit Item specific Help Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Saves Changes ↑↓ Select Item -/+ Change Values Help F9 Setup Defaults ←→...

Table of Contents
