WPS-100-DVR-8CH Installation and Users Manual
2.3 REMOTE CONTROL
Additional buttons on the remote include:
• Alarm Reset
Press to cancel alarms and return the system to its normal conditions.
• PTZ
Pan/Tilt/Zoom Control when in a full screen view of a camera that supports this feature.
• MUTE/NEXT
Press to mute the audio or to scroll to the next control in the PTZ.
• X2/GOTO
In full screen view, press this button for X2 and X4 digital zoom. In PTZ mode, press this button
to move the camera to a preset position.
• ◄◄ / ►►
Fast foward and fast reverse playback video at 2X, 4X, 8X, 16X, 32X, and 6X speeds
• ► |
In playback, this button will freeze the video and step forward one frame at a time.
• +/- Buttons (by the +/
Increase or decrease the audio output level. In PTZ control, press these buttons to
zoom the camera in or out.
12
The remote control has many of the same functions as the
front panel buttons. See the corresponding numbers
on page 8-9 for descriptions. The functions include:
3. MODE Button
4. SEQ Button
5. CALL Button
6. SEARCH Button
7. MENU / ESC Button
8. ▲/BS (Up/BS Button)
9,13. +/- Buttons by the
10. ENTER Button
*
11. 1-9, 0, , # (Numeric Buttons)
12. ◄ ► (Left/Right Buttons)
14. ▼/DEL (Down/DEL Button)
16. (Copy Button)
17. ■ (Stop Button)
18. ►/II (Play/Pause Button)
19. REC Button
symbols)
symbol (Split Window Control)
