Command Start CS-396i User Manual

4-button automatic / manual transmission remote starter
Hide thumbs
Table of Contents

Advertisement

Quick Links

A U T O M A T I C
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (EIRP) is not more than that required for successful communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
DOC. 1.00
- 1W-AM-4B-A-M -
4 - B U T T O N
/
M A N U A L
R E M O T E
CS-396i
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle is
parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL position
and the parking brake is engaged in order to avoid accidents upon remote
starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to avoid
accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled or
put into valet mode before servicing.
- September 12, 2007 -
T R A N S M I S S I O N
S T A R T E R
WARNING
- MO -
Assembled in Canada

Advertisement

Table of Contents
loading

Related Manuals for Command Start CS-396i

Summary of Contents for Command Start CS-396i

  • Page 1 T R A N S M I S S I O N R E M O T E S T A R T E R CS-396i User Guide WARNING It is the responsibility of the vehicle operator to ensure their vehicle is parked in a safe and responsible manner.

  • Page 2: Table Of Contents

    Table of Contents Introduction ............3 Advanced Features: Installation-programmable Options..............7 Basic Remote Operation ........3 Remote Door Locks........... 7 Priority Door Access.......... 8 Vehicle Presets............3 Ignition-controlled Door Locks Option ....8 Secure Lock Option........... 8 Heater and Heated Seat........3 Remote Trunk Release Option......

  • Page 3: Introduction

    Introduction This module is a state-of-the-art remote car starter system. With many advanced functions, this product will satisfy any one of the user’s expectations from high-end commodity systems, without neglecting the standard features commonly offered by entry-level starters. Basic Remote Operation Your remote car starter can operate two independent vehicles equipped with an identical remote car starter (see multi-car operation on page 9).

  • Page 4: Arming The Starter Kill

    switch on certain types of vehicles could cause them to remain even after the remote starter shuts down, resulting in a dead battery. Arming the Starter Kill If installed, the Starter Kill can be programmed to arm in Active Mode (will not arm automatically) or in Passive Mode (will arm automatically).

  • Page 5: Remote Starting

    quickly and remain lit. Remove the key: the engine will continue running. Exit the vehicle and close all doors, hood and trunk. Press for approx. 1 second either: to lock the doors and shut down the engine; LOCK to unlock the doors and shut down the engine; UNLOCK to shut down the engine without affecting the doors.

  • Page 6: Valet Modes

    Ensure that the doors are all closed and that the gearshift lever is in the Neutral position. With the engine already running, apply the parking brake and release the brake pedal. Make sure to release the brake pedal. Within 20 sec. push on the transmitter.

  • Page 7: Panic Mode

    Panic Mode Note: Panic Mode can only be activated if the horn has been adequately configured by your installer. In an emergency situation, you can activate Panic Mode using the button. LOCK UNLOCK This will: • shut down the engine, •...

  • Page 8: Priority Door Access

    The parking lights will flash once and the LED will flash slowly to confirm that the doors have been locked and that the Starter Kill feature is enabled (if it was installed). To UNLOCK your doors and DISARM the Starter Kill: Press and hold the button for approximately 1 sec.

  • Page 9: Engine Run Time

    Engine Run Time (Gas 15 minutes, Diesel 20 minutes by default) If you have a gas engine, your system can be programmed to run the engine for 3, 15, or 25 minutes (15 minutes by default). If you have a diesel engine, it can be programmed to run the engine for 8, 20, or 30 minutes). Multi-car Operation This option allows the owner of two vehicles, both equipped with the same Remote Car Starter model, to control both systems with a single remote control.

  • Page 10: Troubleshooting Poor Transmitting Range Issues

    Troubleshooting Poor Transmitting Range Issues Many factors may affect the operating range of the transmitter. Some of these are: • The condition of the battery in the transmitter. • The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…) •...

  • Page 11: Diagnostics - Parking Light Flash Table

    Diagnostics – Parking Light Flash Table Flashes Description • Doors locked, starter kill armed • Run time has expired • button pressed TRUNK • Start signal received by the module • Cold weather mode cancelled • Reset from manual to automatic 2 slow flashes followed by 8 quick flashes •...
