Part names and their functions

The various parts of the sewing machine have the functions described below.
Extension table
(Accessory Box)
Presser foot lever
8
•
Pull out the extension
table (accessory box)
in the direction of the
arrow.
•
When sewing, lower the presser foot lever to lower
the presser foot. (Position 1 )
• When inserting fabric, lift up the presser foot lever to
raise the presser foot. (Position 2 )
•
The presser foot can be raised even higher by raising
the presser foot lever to position 3 . Since the
presser foot lever does not remain in this position,
hold it in place when inserting the fabric. This position
is useful when sewing thick fabric.
