Martin Yale Intimus SP100 Operating Instructions Manual

BCS400 Series
1.0 Introduction
Thank you for your purchase of the intimus
With proper maintenance your unit will provide you with years of service. Upon receiving the machine verify that
there are no signs of shipping damage on the exterior. If you feel the product may have been damaged in tran-
sit, contact the appropriate freight carrier immediately, then contact technical support at Martin Yale Industries,
Inc. at 260-563-0641.
Upon opening the machine, verify that you have the following components.
2.0 Inventory of Contents
SP100
SP100 Unit
Catch Tray W-ODT0021
Paper Support W-ODT1124
3/32" T- Handle Allen M-S012012
Operating Instructions
8.5" Top Plate W-ODT0100
11.0" Top Plate W-ODT0200

3.0 Specifications

> Accessory shafts can be easily disassembled for addition of optional
components.
> Units will handle 24# bond to 100# cover stock.
> Min. Sheet Size 4 1/8" X 3 ½"
> Max. Sheet Size 8 ½" X 11"
> Speed: BCS412: 300 finished cards per minute.
BCS410: 375 finished cards per minute.
SP100: 1400 8 ½" X 11" sheets per hour.
Operating Instructions
SP100, BCS400 series
®
line of Business Card Slitters or Scoring/Perforating machines.
BCS400 Series
BCS400 Series Unit
Receiver Tray W-ODT0024
Receiver Base Form W-ODT0023
Paper Support W-ODT1124
T- Handle 3/32" Allen M-S012012
10 - Up Catch Tray W-ODT0021
12 - Up Catch Tray W-ODT0020
Operating Instructions
8.5" Top Plate W-ODT0100
11.0" Top Plate W-ODT0200
SP100
Model:
Serial No:
Manuf. Date:
SHIPPING WEIGHTS
-MODEL SP100
-MODELS 410&412
23 lb#
44 lb#
