Installation, Maintenance, and Operating Instructions
Feed Speed
3800AP.............................................Variable to 15,800 sheets per hour
3800FC..............................................Variable to 12,000 sheets per hour
Paper Length.......................................3-1/2" min to 22" max
Paper Width........................................3-7/8" min to 18" max
Paper Weight.....................................16# bond to 150# card
Continuous Feed Load Capacity...............1-3/8" of paper
Standard Accessories
3800FC (2) 7-tooth per inch. Perforating wheels. (1) Slitting Wheel. (3) Backup Hubs. (2)
Exit Straps.
3800AP (1) 10-tooth per inch. Perforating Wheel. (2) Scoring Wheels. (1) Stripper. (4)
Backup Hubs. (2) Exit Straps.
Electrical........................................115 V 60 Hz (220 V 50 Hz available)
Working Dimensions...........................36" x 27-1/2" x 13-1/4"
Shipping Weight.................................87 lbs.
Options...........................................960 Machine Stand, Perforating Wheels , Scoring
Wheels, Slitting
Introduction
Thank you for selecting the Martin Yale Model 3800. This unit has been designed for fast, easy
operation and will give you years of trouble-free service.
These instructions are applicable to both the 3800 AutoPerf (AP) and the 3800 Forms Cutter (FC).
Operational and setup procedures are the same for each machine. Since the standard accessories
differ, not all accessory setup procedures will apply to each model. The 3800AP is equipped with
a 10-tooth slot type perforating wheel, two scoring wheels, a stripper and four backup hubs. The
3800FC is equipped with two 7-tooth slit type perforating wheels, one slitting wheel and three
backup hubs.
Office Zone
1-800-543-5454
1-800-543-5454
(
801) 927-3026
Model 3800AP and 3800FC
Model 3800 Specifications
3.5 amp Circuit Breaker
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Martin Yale 3800 AP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Martin Yale Martin Yale 3800 AP

  • Page 1 Office Zone 1-800-543-5454 1-800-543-5454 801) 927-3026 Model 3800AP and 3800FC Installation, Maintenance, and Operating Instructions Model 3800 Specifications Feed Speed 3800AP……………………………………...Variable to 15,800 sheets per hour 3800FC…….……………………………..Variable to 12,000 sheets per hour Paper Length….…………………..…………3-1/2” min to 22” max Paper Width…….…………………..……….3-7/8” min to 18” max Paper Weight……………………….………16# bond to 150# card Continuous Feed Load Capacity…………...1-3/8”...
  • Page 2: Installation

    Please review this publication in its entirety before attempting to setup or operate you new 3800. Thorough understanding of this information will help eliminate most operator-associated errors and ensure years of trouble-free performance. Warning – Never connect power to the machine until you are ready to setup and operate. Installation Carefully unpack the 3800.
  • Page 3: Setup And Operation

    Functional Test Before attempting to process forms with the 3800, perform the following functional test. Make sure the power switch is in the off position and set the depth control indicator (7) to “Open” (at the “Open” position, the upper cutter shaft should be at the highest point). To adjust the depth control, loosen the depth control locking knob (6).
  • Page 4 Loosen the depth control locking knob (6) and turn the control knob (7) so the indicator aligns with “Open” on the depth control scale plate. The two accessory shafts should now be at their maximum open position. Raise the acrylic safety cover (13) to gain access to the perforator wheels and backup hubs (figure 3).
  • Page 5 b. Rotate the depth control knob (7) counterclockwise one line on the depth control scale. Tighten the depth control locking knob (6). Turn the speed control on low and run a few test sheets through the machine. d. Check and repeat steps 2 and 3 if necessary until correct perforation is achieved. Setting the depth control perforation is too shallow: Loosen the depth control lock knob b.
  • Page 6: Troubleshooting

    Note – Each accessory shaft can be removed from the machine so accessories can be added, removed, or changed. The upper shaft and guide fingers must be removed prior to removing the lower shaft. Loosen the depth control lock knob (6) and turn the depth control knob (7) to the maximum open position.
  • Page 7 Caution – Never use detergent or soap and water on the main rubber (black) rollers as it will ruin the rollers and void your warranty. During normal operation, the main rubber rollers will become coated with ink, toner, lint and various other contaminants.
