Model 7000E Commercial Cutter
Installation, Maintenance, & Operating Instructions
Model 7000E Specifications
Thickness Capacity (24# bond) . . . . . . . . .1 1/2"
Width Capacity (With Stop) . . . . . . . . . . . . . .12"
Length Capacity . . . . . . . . . . . . . . . . . . . . . . .12"
Cutting Method . . . . . . . . . . . . . . . . . . . . . .Lever
Clamping Method . . . . . . . . .Manual Handwheel
Dimensions . . . . . . . . . . . . . . .19" x 19" x 13 1/8"
Shipping Weight . . . . . . . . . . . . .48 lbs. (21.8 kg)
INTRODUCTION
Thank you for selecting the Martin Yale Model 7000E Commercial Cutter. The 7000E has been performance-tested at the
Martin Yale factory. With recommended maintenance, the unit will provide years of trouble-free service. Please review
this publication in its entirety before attempting to operate your 7000E. Thorough understanding of this information will
help eliminate most operator-associated errors and ensure years of trouble-free performance.
WARNING!
The cutting blade of the 7000E is extremely sharp. Never place hands or fingers under
the cutting blade or into the cutting area. Serious bodily injury could result. Never allow children to
operate the 7000E unsupervised. The weight of the handle can cause the cutting blade to drop if the
spring-loaded safety arm is not fully engaged. Always make sure the spring-loaded safety arm is fully
engaged upon the completion of each cut by returning the handle to the full upright position. Test for
safety arm engagement before releasing the handle.
Serial # ____________________
Table of Contents
1.0 Parts . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
2.0 Installation . . . . . . . . . . . . . . . . . . . . . Page 2
3.0 Operation. . . . . . . . . . . . . . . . . . . . . . Page 2
4.0 Maintenance . . . . . . . . . . . . . . . . . . . Page 3
5.0 Parts List . . . . . . . . . . . . . . . . . . . . . . Page 6
6.0 Parts Diagram . . . . . . . . . . . . . . . . . . Page 7
7.0 Troubleshooting. . . . . . . . . . . . . . . . . Page 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Martin Yale 7000E
Summary of Contents for Martin Yale 7000E
- Page 1 Serial # ____________________ INTRODUCTION Thank you for selecting the Martin Yale Model 7000E Commercial Cutter. The 7000E has been performance-tested at the Martin Yale factory. With recommended maintenance, the unit will provide years of trouble-free service. Please review this publication in its entirety before attempting to operate your 7000E. Thorough understanding of this information will help eliminate most operator-associated errors and ensure years of trouble-free performance.
- Page 2 The 7000E is shipped completely assembled. Carefully remove the unit from the shipping container. Inspect for damage. If dam- age is found, immediately notify the carrier and then call Martin Yale for instructions. Save the shipping container in case the cutter requires relocation.
- Page 3 8. Raise the paper clamp with counter clockwise rotation of the clamp wheel. 9. Remove all cut material from the 7000E. 4.0 MAINTENANCE Please refer to the diagram and parts list in the back of this instruction booklet to assist you in identifying the parts.
- Page 4 WARNING! The blade is sharp. Use extreme caution when working with or near the blade. 3. Place the short side of the square against the bottom of the blade and slide the square toward the side rail. NOTE: Make sure the side rail is even with or slightly in front of the cut opening in the back plate. Lower the clamp firmly onto the square, making sure it remains against the blade, and align the side rail to the long edge of the square.
-
Page 5: Blade Installation
5. Remove the safety plate by removing the two allen head screws that secure the safety plate to the frame. Loosen, but do not remove, the four allen head screws that hold the short (#6 in parts list) and long (#15 in parts list) spacers in the frames. -
Page 6: Parts List
5.0 Parts List Item. # Part # Qty. Description Item. # Part # Qty. Description WRA007053 Blade Handle Assy. M-S030003 Frame Feet M-S043012 Handle Grip W-A007005 Clamp Mount Plate M-S043046 Vinyl Safety Tip WRA007006 Clamp Assy. M-O007055 Safety Latch Spring M-O007030 Clamp Rubber Strip M-S001157... - Page 7 6.0 7000E Parts Diagram...
-
Page 8: Troubleshooting
7.0 TROUBLESHOOTING 7.1 Paper Not Completely Cut Gradual wearing of the cutting stick is normal during machine operation. As a groove is formed in the stick by the cut- ting action of the blade, the blade may not completely cut through the bottom sheets of the stack. When this condition occurs, rotate the cutting stick, or replace, if necessary.
