251 Wedcor Avenue
Phone (260) 563-0641
Email: info@martinyale.com
M-S027123
l
Wabash, Indiana
46992
l
Fax (260) 563-4575
Website: www.martinyale.com
l
Rev. 3 10/08/13
Operating Instructions
BCS200 series
1.0 Introduction
Thank you for your purchase of the Martin Yale line of Business Card Slitters. With proper maintenance
your unit will provide you with years of service. Upon receiving the machine verify that there are no signs of
shipping damage on the exterior. If you feel the product may have been damaged in transit, contact the appro-
priate freight carrier immediately, then contact technical support at Martin Yale Industries, Inc. at 260-563-0641.
Upon opening the machine, verify that you have the following components.
2.0 Inventory of Contents
BCS200 Series
BCS200 Series Unit
Receiver Tray W-ODT0024
Receiver Base Form W-ODT0023
Paper Support W-ODT1124
10 - Up Catch Tray W-ODT0021
12 - Up Catch Tray W-ODT0020
Operating Instructions
8.5" Top Plate W-ODT0100
11.0" Top Plate W-ODT0200
3.0 Specifications
> Units will handle 24# bond to 100# cover stock.
> Min. Sheet Size 4 1/8" X 3 ½"
> Max. Sheet Size 8 ½" X 11"
> Speed: BCS212: 300 finished cards per minute.
BCS210: 375 finished cards per minute.
Model:
Serial No:
Manuf. Date:
SHIPPING WEIGHTS
-MODELS 210 & 212
35 lb#-
Advertisement
Table of Contents
Related Manuals for Martin Yale BCS200 Series
Summary of Contents for Martin Yale BCS200 Series
- Page 1 BCS200 series 1.0 Introduction Thank you for your purchase of the Martin Yale line of Business Card Slitters. With proper maintenance your unit will provide you with years of service. Upon receiving the machine verify that there are no signs of shipping damage on the exterior.
- Page 2 3b. If still no power, check that circuit breaker has not tripped. Find source of machine bind and correct. Allow machine to cool and push breaker in to reset. 3c. Call the technical support division at Martin Yale Industries, Inc. at 260-563-0641. Tray/ Paper Support Installation A paper support is utilized on the in feed of any bin where the sheets overhang the edge of the feed shelf.
- Page 3 BCS 210/212 Parts List 5.0 Setting Registration Note: The registration is preset at the factory and should not be adjusted unless it is determined that it Item Part No. Description Item Part No. Description is not correct for the stock being used. W-ODT0019 Adjustment Block M-S021073...
- Page 4 Should stock still have feed issues call technical support at Martin Yale Industries, Inc. at 260-563-0641. Obtaining Service Should your machine need to be professionally serviced, Martin Yale Industries, Inc. can refer you to the nearest Factory Authorized Technician. Contact us at the phone number given above.
