Owner's Manual
ATTENTION:
Please read the content
of your owner’s manual
before operating your
scooter.
Legend 3-Wheel Scooter
Legend 4-Wheel Scooter
The Ultimate In Style & Performance
®
Exeter, PA
St. Catharines, ON
1-800-800-8586
www.pridemobility.com

Advertisement

Table of Contents
loading

Related Manuals for Pride Mobility Legend 3-wheel

Summary of Contents for Pride Mobility Legend 3-wheel

  • Page 1 Owner’s Manual ATTENTION: Please read the content of your owner’s manual before operating your scooter. Legend 3-Wheel Scooter Legend 4-Wheel Scooter The Ultimate In Style & Performance ® Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
  • Page 2 WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your Scooter. Copyright ©2003 Pride Mobility Products Corp. INFMANU2020 www.pridemobility.com Legend/Rev D/July03...

  • Page 3: Table Of Contents

    C O N T E N T S INTRODUCTION ......................... 4 SAFETY ............................6 III. EMI/RFI ............................15 IV. SPECIFICATIONS ........................17 YOUR LEGEND ......................... 19 VI. BATTERIES AND CHARGING .................... 23 VII. OPERATION ..........................27 VIII. COMFORT ADJUSTMENTS....................29 IX.

  • Page 4: Introduction

    I N T R O D U C T I O N Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride Scooter. Your scooter design combines the most advanced state-of-the-art components with modern, attractive styling.

  • Page 5: I. Introduction

    I N T R O D U C T I O N Pride Owners Club As a Pride product owner, you are invited to register your product’s warranty and enroll in the Pride Owners Club. You may do so by filling out and returning your enclosed registration card or by visiting Pride’s web site at www.pridemobility.com.

  • Page 6: Safety

    I I . S A F E T Y GENERAL WARNING! Do not operate your new scooter for the first time without completely reading and understanding this owner’s manual. Your Scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an exten- sive variety of products to best fit the individual needs of the scooter user.
  • Page 7 I I . S A F E T Y PRE-RIDE SAFETY CHECK Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check before each use to make sure your scooter operates smoothly and safely. For details on how to perform these necessary inspections, see XII.
  • Page 8 I I . S A F E T Y When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the slowest setting and driving in the forward direction only.
  • Page 9 I I . S A F E T Y When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of gravity of you and your scooter toward the front of the scooter for improved stability. Figure 2A.
  • Page 10 I I . S A F E T Y OUTDOOR DRIVING SURFACES Your scooter is designed to provide optimum stability under normal driving conditions—dry, level surfaces com- posed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encoun- ter other surface types.
  • Page 11 I I . S A F E T Y INCLEMENT WEATHER PRECAUTIONS WARNING! Pride recommends that you do not operate your scooter in icy or slippery conditions or on salted surfaces (i.e., walks or roads). Such use may result in an accident, personal injury, or adversely affect the performance and safety of your scooter.
  • Page 12 I I . S A F E T Y STAIRS AND ESCALATORS Scooters are not designed to travel up or down stairs or escalators. Always use an elevator. WARNING! Do not use your scooter to negotiate steps or escalators. You may cause injury to yourself and to others and/or damage your scooter.
  • Page 13 I I . S A F E T Y MOTOR VEHICLE TRANSPORT Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a person while seated in a scooter. Although your scooter may be equipped with a positioning belt, this belt is not designed to provide proper restraint during motor vehicle transport.
  • Page 14 I I . S A F E T Y POSITIONING BELTS Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for determining your requirement for a positioning belt in order to operate your scooter safely. WARNING! If you require a positioning belt to safely operate your scooter, make sure it is fastened securely.
  • Page 15 I I I . E M I / R F I EMI/RFI WARNINGS Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unintended motion of electric mobility vehicles. Radio waves are a form of electromagnetic energy (EM). When electromagnetic energy adversely affects the operation of an electrical device, that adverse effect is called Electro- magnetic Interference (EMI) or Radio Frequency Interference (RFI).

  • Page 16: Iii. Emi/Rfi

    I I I . E M I / R F I Are all electric mobility vehicles susceptible to EMI/RFI? Each make and model of electric mobility vehicle differs in its ability to resist EMI/RFI. Every mobility vehicle has a particular level of resistance to EMI/RFI. This resistance is measured in volts per meter (V/m). A higher resis- tance level offers greater protection against EMI/RFI.

  • Page 17: Specifications

    I V . S P E C I F I C A T I O N S 20" 17" - 21" 3.5" 18" 3-wheel 45.5" 18" 4-wheel 47" 16" 20" 24" 3-wheel 41" 4-wheel 58" Turning Radius Figure 4. Legend Dimensions 24"...
  • Page 18 I V . S P E C I F I C A T I O N S Model Numbers 3-wheel:SC3000, 4-wheel:SC3400 Available Colors Painted: Champagne (Standard)** Overall Length 3-wheel: 45.5 in., 4-wheel: 47 in. Overall Width 24 in. Total Weight Without Batteries 4-wheel: 157 lbs., 4-wheel: 166 lbs.

  • Page 19: Your Legend

    V . Y O U R L E G E N D TILLER CONSOLE The tiller console houses all of the controls needed to drive your scooter. See figure 5. WARNING! Do not expose the tiller console to moisture. In the event that the tiller console does become exposed to moisture, do not attempt to operate your scooter until the tiller console has dried thoroughly.

  • Page 20: V. Your Legend

    V . Y O U R L E G E N D Running Lights Switch This switch controls your scooter’s front (upper) and rear running lights. n Toggle the switch forward to turn on your scooter’s running lights. n Toggle the switch back to turn off your scooter’s running lights. Headlight Switch This switch controls your scooter’s front (lower) light.
  • Page 21 V . Y O U R L E G E N D REAR SECTION The onboard battery charger (not shown), the charger power cord receptacle, the batteries (not shown), the main circuit breaker reset button, the ammeter, the manual freewheel lever, the anti-tip wheels, and the motor/transaxle assembly are located on the rear section of your Legend.
  • Page 22 V . Y O U R L E G E N D Manual Freewheel Lever Whenever you need or want to push your scooter for short distances, you can put it in freewheel mode. n The manual freewheel lever is located on the end of the motor/transaxle assembly at the right rear of the Legend.
  • Page 23 V I . B A T T E R I E S A N D C H A R G I N G Your Legend requires two sealed, maintenance free, 12-volt, deep cycle batteries. n Charge the batteries prior to using your scooter for the first time. n Keeping the batteries fully charged will keep your scooter running smoothly.

  • Page 24: Vi. Batteries And Charging

    V I . B A T T E R I E S A N D C H A R G I N G FREQUENTLY ASKED QUESTIONS (FAQS) How does the charger work? When your scooter’s battery voltage is low, the charger works harder and sends more electrical current to the batteries to bring up their charge.
  • Page 25 V I . B A T T E R I E S A N D C H A R G I N G How can I get maximum range or distance per charge? Rarely will you have ideal driving conditions — smooth, flat, hard driving surfaces with no wind or curves. Often, you will face hills, sidewalk cracks, uneven and loosely packed surfaces, curves, and wind.
  • Page 26 V I . B A T T E R I E S A N D C H A R G I N G BATTERY DISPOSAL AND RECYCLING If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and call your authorized Pride Provider for instructions on disposal.
  • Page 27 V I I . O P E R A T I O N BEFORE GETTING ONTO YOUR SCOOTER n Have you fully charged the batteries? See VI. “Batteries and Charging.” n Is the manual freewheel lever in the drive (down) position? Never leave the manual freewheel lever pulled up unless you are manually pushing your scooter.

  • Page 28: Vii. Operation

    V I I . O P E R A T I O N GETTING OFF OF YOUR SCOOTER 1. Bring your scooter to a complete stop. 2. Remove the key from the key switch. 3. Disengage the seat lock lever and rotate the seat until you are facing toward the side of your scooter. 4.

  • Page 29: Comfort Adjustments

    V I I I . C O M F O R T A D J U S T M E N T S WARNING! Remove the key from the key switch before adjusting the tiller or the seat. Never attempt to adjust the tiller or the seat while the scooter is in motion. TILLER ANGLE ADJUSTMENT Your scooter is equipped with a pivoting tiller that allows adjustment to several positions from the scooter...
  • Page 30 V I I I . C O M F O R T A D J U S T M E N T S SEATBACK ADJUSTMENT WARNING! Do not operate your scooter with the seatback in a reclined position. WARNING! Always keep your back pressed firmly against the seat back while adjusting it. To adjust your Legend's reclining seat, perform these steps.
  • Page 31 V I I I . C O M F O R T A D J U S T M E N T S POWER SEAT (OPTIONAL) Your Legend may be equipped with a power seat. The power seat actuator is designed to raise or lower the seat automatically with minimal effort on the part of the operator.

  • Page 32: Disassembly And Assembly

    I X . D I S A S S E M B LY A N D A S S E M B LY DISASSEMBLY You can disassemble the scooter into seven pieces: the seat, the front section, the rear section, the rear shroud, the basket, and the batteries.
  • Page 33 I X . D I S A S S E M B LY A N D A S S E M B LY 6. Unplug both black and white 2-pin battery harnesses and remove the batteries. See figure 15. 7. Unplug the front-to-rear harness. See figure 16. CAUTION! Failure to unplug both battery harnesses and the front-to-rear harness prior to separating the front and rear sections could result in permanent damage to the scooter.
  • Page 34 I X . D I S A S S E M B LY A N D A S S E M B LY ASSEMBLY 1. Position the front and rear sections of your scooter as shown in figure 21. 2. Align the lower slots of the front section with the cor- responding pegs on the front of the rear section.

  • Page 35: Optional Accessories

    O P T I O N A L A C C E S S O R I E S OPTIONAL ACCESSORIES For information concerning these optional accessories, contact your authorized Pride Provider. •Single Cane/Crutch Holder • Double Cane/Crutch Holder • Walker Holder •...

  • Page 36: Basic Troubleshooting

    X I . B A S I C T R O U B L E S H O O T I N G Any electromechanical device occasionally requires some troubleshooting. However, most of the problems that may arise can usually be solved with a bit of thought and common sense. Many of these problems occur because the batteries are not fully charged or because the batteries are worn down and can no longer hold a charge.
  • Page 37 X I . B A S I C T R O U B L E S H O O T I N G What if the main circuit breaker repeatedly trips? See V. “Your Legend.” n Charge the scooter’s batteries more frequently. See VI. “Batteries and Charging.” n If the problem continues, have both of your scooter’s batteries load tested by your authorized Pride Provider.

  • Page 38: Care And Maintenance

    X I I . C A R E A N D M A I N T E N A N C E Your scooter requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you may schedule inspection and maintenance at your authorized Pride Provider.
  • Page 39 X I I . C A R E A N D M A I N T E N A N C E CONSOLE, CHARGER, AND REAR ELECTRONICS n Allow these areas to dry thoroughly if they have been exposed to moisture before operating your scooter again.

  • Page 40: Warranty

    X I I I . W A R R A N T Y THREE-YEAR LIMITED WARRANTY Three years on all structural frame components; including platform, fork, seat post, and frame. Three-year prorata drive train warranty; including transaxle, motor, and brake. n First year: 100% replacement of parts cost n Second year: 67% replacement of parts cost n Third year: 50% replacement of parts cost...
  • Page 41 N O T E S Legend/Rev D/July03 www.pridemobility.com...
  • Page 42 N O T E S www.pridemobility.com Legend/Rev D/July03...
  • Page 43 N O T E S Legend/Rev D/July03 www.pridemobility.com...
  • Page 44 182 Susquehanna Ave. Exeter, PA 18643 1-800-800-8586 www.pridemobility.com...
