Electrical Wiring
Outdoor unit Dry Contact installation and connection
• Connect wires as below figure at the hole of backside of Outdoor Unit Dry Contact.
• Insert the wire in the connection hole pushing the "Push" button.
• Setting Main PCB Dip SW of Master Outdoor Unit.
Mode Change
Fan
Outdoor Unit
Heating
Cooling
Push Button
Installation Manual 71
