In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
ELECTRICAL SPECIFICATIONS ......................................................................................................... 1
IMPORTANT SERVICE SAFETY PRECAUTION .................................................................................2
LOCATION OF USER'S CONTROL .....................................................................................................4
INSTALLATION AND SERVICE INSTRUCTIONS ................................................................................5
CHASSIS LAYOUT ............................................................................................................................. 11
BLOCK DIAGRAM .............................................................................................................................. 12
SCHEMATIC DIAGRAMS ................................................................................................................... 13
PRINTED WIRING BOARD ASSEMBLIES ........................................................................................ 16
REPLACEMENT PARTS LIST ............................................................................................................19
PACKING OF THE SET ......................................................................................................................25
POWER INPUT .................................................... AC 120 V, 60 Hz
POWER RATING ................................................................... 55 W
PICTURE SIZE ........................................... 580cm
CONVERGENCE ............................................................. Magnetic
SWEEP DEFLECTION .................................................... Magnetic
FOCUS ............................................... Hi-Bi-Potential Electrostatic
INTERMEDIATE FREQUENCIES
Picture IF Carrier Frequency ..................................... 45.75 MHz
Sound IF Carrier Frequency ...................................... 41.25 MHz
Color Sub-Carrier Frequency .................................... 42.17 MHz
AUDIO POWER
OUTPUT RATING ..................................................... 1 W (RMS)

SERVICE MANUAL

VIDEO IN AUDIO
MODEL
CONTENTS
ELECTRICAL SPECIFICATIONS
2
( 89.91 sq inch)
(Nominal)
COLOR TELEVISION
Chassis No. SN-010
PH-1470
SPEAKER
SIZE ...................................................................... 8 cm (Round)
VOICE COIL IMPEDANCE ............................ 32 ohm at 400 Hz
ANTENNA INPUT IMPEDANCE
VHF/UHF ..................................................... 75 ohm Unbalanced
TUNING RANGES
VHF-Channels ............................................................... 2 thru 13
UHF-Channels ............................................................ 14 thru 69
CATV Channels ........................................................... 1 thru 125
Specifications are subject to change without
prior notice.
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
1
PH-1470
PH-1470
Page
(EIA, Channel Plan U.S.A.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH-1470 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philco PH-1470

  • Page 1: Table Of Contents

    PH-1470 SERVICE MANUAL PH-1470 COLOR TELEVISION Chassis No. SN-010 VIDEO IN AUDIO — VOL + ME NU PH-1470 MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
