Philco PF2908 Service Manual

29” nf tf sf chassis with nicam
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

SERVICE MANUAL

29" NF TF SF CHASSIS
WITH NICAM
CONTENTS
ⅠSAFETY PRECAUTION ......................................................... 1
ⅡSPECIFICATION .................................................................. 2
Ⅲ IC'S GENERAL DESCRIPTION ............................................. 3
Ⅳ SPECIAL IC INTRODUCTION ................................................ 3
Ⅴ CHASSIS BLOCK DIAGRAM ................................................ 12
Ⅵ SERVICE MODE&ADJUSTMENT .......................................... 13
Ⅶ TEST POINT WAVE FORM&SCHEMATIC DIAGRAM ............... 18
COLOR TELEVISION
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF2908 and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PF2908

Summary of Contents for Philco PF2908

  • Page 1: Service Manual

    COLOR TELEVISION SERVICE MANUAL 29” NF TF SF CHASSIS WITH NICAM CONTENTS ⅠSAFETY PRECAUTION ………………………………………………… 1 ⅡSPECIFICATION ………………………………………………………… 2 Ⅲ IC’S GENERAL DESCRIPTION ……………………………………… 3 Ⅳ SPECIAL IC INTRODUCTION ………………………………………… 3 Ⅴ CHASSIS BLOCK DIAGRAM ………………………………………… 12 Ⅵ SERVICE MODE&ADJUSTMENT …………………………………… 13 Ⅶ...

  • Page 2: X-Ray Radiation Precaution

    ⅠSAFETY PRECAUTION 1. X-RAY RADIATION PRECAUTION 1.1 Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards the high voltage must be specified limit. The normal value of the high voltage of this receiver is 29” 29KV ±500V under 230V AC power source.
  • Page 3 COLOR SYSTEM: PAL NTSC RF SYSTEM SOUND SYSTEM:N M VIDEO SYSTEM PAL NTSC4.43 NTSC3.58 TUNING SYSTEM FREQUENCY SYNTHESIS TUNING PROGRAM PRESET 1 Front AV jack IN； 1 Rear AV jack IN； 1 S video jack； 1YUV jack AV JACKS 1 Audio out & 1 Video out ANTENNA INPUT 75Ω（UNBALANCE）...
  • Page 4 2.2 Pin description...
  • Page 6 2.3 Block diagram...
  • Page 7 3. TDA4863AJ The TDA8174A are deflection boosters for use in vertical deflection systems for frame frepuencies up to 200Hz.for the TDA4863AJ the flyback supply voltage will be generated internally by doubling the supply voltage and therefore a separate flyback supply voltage is not needed. 3.1 Main features Power amplifier with differential inputs Output current up to 3A (p-p)

  • Page 8: Pin Description

    High vertical deflection frequency up to 200Hz High linear sawtooth signal amplification Flyback generator Internally doubled supply voltage (two supply voltages only for DC-coupled outputs) 3.2 Pin description 3.3 Block diagram 4. LA42352 The LA42352 is 5W 2-channel AF power amplifier with DC volume control intended for televisions. 4.1 Main feature...
  • Page 9 Po 5W×2ch (RL = 8Ω @THD = 10% VCC = 18V) Built-in DC volume Control Built-in Standby function Built-in overheat protection 4.2 Pin description 4.3 Block diagram 5. TDA9850 5.2 Pin description...
  • Page 10 5.3 Block diagram...

  • Page 11: Power Supply

    Ⅵ SERVICE ADJUSTMENT POWER SUPPLY Receive normal colour bar signal. Connect DC voltmeter to D628- and isolated ground. Adjust potentiometer in power unit to get the voltage as 110V ±1.0V for 21 inch hereinafter, 125V ±0.5V for 29 inch upwards. FOCUS ADJUSTMENT Receive a crosshatch signal.
  • Page 12 Press “FACTORY” or “MENU” key, to exit “B/W BALANCE” mode and enter “ADJUST” mode. In “ADJUST” mode, Press “0” to “7“ key and corresponding on-screen display will be appeared. And press following key, each function will be available. Remote Hand Unit keys V+/V-: volume adjustment Horizontal line...
  • Page 13 C standard UOC for export bus control adjustment item default setting PAGE Items Variable Preset recommendation DRI R White point R Adjustment DRI G White point G Adjustment DRI B White point B Adjustment CUT R Black level offset R Adjustment CUT G Black level offset G Adjustment Brightness of service mode...

  • Page 14: Video Out

    UOC VOL SW On/Off Volume control mode selection Off: By external hardware ( PWM or TDA9859) On: By internal UOC UOC / PWM VOL The volume control of internal UOC(when UOC VOL SW=on) or PWM(when UOC VOL SW=off) VOL10 The 1th point of S-curve VOL25 The 2th point of S-curve VOL50...

  • Page 15: Menu Title

    BAND ON/OFF FS-Tuning band control selection FREQ LH 100.25M~ The frequency of dividing-point between VHFL and 164.25MHz 227.75MHz VHFH FREQ HU 300.50M~ The frequency of dividing-point between VHFH and 428.50MHz 555.50MHz DVD IN OFF/ YC/ The source of DVD signal selection DVD DELAY 0~8S Delay time of black-scren during switching to DVD...

  • Page 16: Keypad Definition

    SUB BRI Sub brightness adjustment SUB COL Sub color adjustment SUB SHA Sub sharpness adjustment SUB TIN Sub tint adjustment YDL PAL Y-delay adjustment for PAL signal YDL NTSC Y-delay adjustment for NTSC signal YDLY AV Y-delay adjustment for AV mode CATHE Athode voltage adjustment 3.KEYPAD DEFINITION...
  • Page 17 T3P03 SCHEMATIC DIAGRAM AV1-IN AV2-IN XS401 CYB-3.2-8DW6-3-100 L1-in R1-in Rout Lout Vout IC701 LA42352 R515 R517 Q512 H-Gnd 220E Q511 R511 2SC2482 R518 V1-in 1.5K Q513 C511 D512 R528 1.5K 330pF BAV21 R420 R514 R516 R538 R527 R525 1.5K Q522 2W/12K 220E Q521...
  • Page 18 LEVEL LOCATION P_PARTS_CODE 1.9.T3P03001110 L301(2) 1.E.71287616300 L302(2) 1.E.71287616300 T604(4) 1.E.71287616300 Q302(3), 1.E.71287625300 Q613(2), 1.E.71287625300 T302(4), 1.E.71287625300 C607(2) 1.E.71287625300 R320 1.R.11051000300 R126, 1.R.11470000300 R521, 1.R.11470000300 R524, 1.R.11470000300 R531, 1.R.11470000300 R534 1.R.11470000300 R130, 1.R.11101000300 R139, 1.R.11101000300 R140, 1.R.11101000300 R204, 1.R.11101000300 R205 1.R.11101000300 R331, 1.R.11221000300 R517,...
  • Page 19 R611 1.R.11562000300 R153, 1.R.11103000300 R335, 1.R.11103000300 R610, 1.R.11103000300 R522, 1.R.11103000300 R532 1.R.11103000300 R106 1.R.11123000300 R622 1.R.11153000300 R618 1.R.11223000300 R304 1.R.11273000300 R131 1.R.11333000300 R118 1.R.11104000300 R319 1.R.11474000300 R324 1.R.12015000300 R705, 1.R.12047000300 R706 1.R.12047000300 R510 1.R.12220000300 R647 1.R.12330000300 R301 1.R.12221000300 R712, 1.R.12331000300 R713 1.R.12331000300 R308...
  • Page 20 C125, 1.C.01501040400 C614, 1.C.01501040400 C705, 1.C.01501040400 C706 1.C.01501040400 C116 1.C.21811040400 C103, 1.C.61164760600 C128, 1.C.61164760600 C138, 1.C.61164760600 C141, 1.C.61164760600 C145, 1.C.61164760600 C205, 1.C.61164760600 C414, 1.C.61164760600 C610, 1.C.61164760600 C612, 1.C.61164760600 C718, 1.C.61164760600 C719 1.C.61164760600 C105, 1.C.61161070600 C127, 1.C.61161070600 C404, 1.C.61161070600 C634, 1.C.61161070600 C717, 1.C.61161070600 C907,...
  • Page 21 C122, 1.C.61504750600 C136, 1.C.61504750600 C148, 1.C.61504750600 C904, 1.C.61504750600 C908, 1.C.61504750600 C912, 1.C.61504750600 C913 1.C.61504750600 C119, 1.C.61501060600 C202, 1.C.61501060600 C401, 1.C.61501060600 C409, 1.C.61501060600 C410, 1.C.61501060600 C417, 1.C.61501060600 C418, 1.C.61501060600 C419, 1.C.61501060600 C424, 1.C.61501060600 C709, 1.C.61501060600 C710, 1.C.61501060600 C711, 1.C.61501060600 C902, 1.C.61501060600 C910, 1.C.61501060600 C917,...
  • Page 22 D522, 1.V.52254220401 D532 1.V.52254220401 D611 1.V.51105330501 D309 1.V.53105261501 D314 1.V.53105261101 D302, 1.V.53155291101 D303, 1.V.53155291101 D304, 1.V.53155291101 D305, 1.V.53155291101 D306, 1.V.53155291101 D308 1.V.53155291101 D307 1.V.53105261101 D603, 1.V.51125330101 D604, 1.V.51125330101 D605, 1.V.51125330101 D606 1.V.51125330101 D617 1.V.53704261501 ZD604 1.V.56335000021 ZD201 1.V.56475000021 ZD602 1.V.56635000021 1.V.56815000021 ZD101, ZD102,...
  • Page 23 J137, 1.W.36200007510 J409, 1.W.36200007510 J422, 1.W.36200007510 J425, 1.W.36200007510 J426, 1.W.36200007510 J427, 1.W.36200007510 J705, 1.W.36200007510 J706 1.W.36200007510 J107, 1.W.36200010010 J119, 1.W.36200010010 J120, 1.W.36200010010 J123, 1.W.36200010010 J126, 1.W.36200010010 J306, 1.W.36200010010 J307, 1.W.36200010010 J308, 1.W.36200010010 J309, 1.W.36200010010 J311, 1.W.36200010010 J404, 1.W.36200010010 J405, 1.W.36200010010 J408, 1.W.36200010010 J415,...
  • Page 24 J406, 1.W.36200012510 J407, 1.W.36200012510 J410, 1.W.36200012510 J411, 1.W.36200012510 J412, 1.W.36200012510 J413, 1.W.36200012510 J416, 1.W.36200012510 J417, 1.W.36200012510 J418, 1.W.36200012510 J419, 1.W.36200012510 J428, 1.W.36200012510 J429, 1.W.36200012510 J431, 1.W.36200012510 J606, 1.W.36200012510 L404, 1.W.36200012510 L405, 1.W.36200012510 L406, 1.W.36200012510 L407 1.W.36200012510 J122, 1.W.36200015010 J133, 1.W.36200015010 J139, 1.W.36200015010 J140,...
  • Page 25 J301, 1.W.36200017510 J414, 1.W.36200017510 J423, 1.W.36200017510 J601, 1.W.36200017510 J614, 1.W.36200017510 J703, 1.W.36200017510 J704 1.W.36200017510 J101, 1.W.36200000010 J115, 1.W.36200000010 J116, 1.W.36200000010 J125, 1.W.36200000010 J130, 1.W.36200000010 J131, 1.W.36200000010 J132, 1.W.36200000010 J134, 1.W.36200000010 J135, 1.W.36200000010 J303, 1.W.36200000010 J430, 1.W.36200000010 J605, 1.W.36200000010 J608 1.W.36200000010 J302, 1.W.36200000010 J424...
  • Page 26 R136, 1.Q.12101000060 R149, 1.Q.12101000060 R150, 1.Q.12101000060 R207, 1.Q.12101000060 R303, 1.Q.12101000060 R411, 1.Q.12101000060 R412, 1.Q.12101000060 R413, 1.Q.12101000060 R427, 1.Q.12101000060 R429, 1.Q.12101000060 R904, 1.Q.12101000060 R905 1.Q.12101000060 R425, 1.Q.12151000060 R432, 1.Q.12151000060 R902 1.Q.12151000060 R121 1.Q.12181000060 R122, 1.Q.12221000060 R318 1.Q.12221000060 R513, 1.Q.12301000060 R523, 1.Q.12301000060 R533 1.Q.12301000060 R516,...
  • Page 27 R115, 1.Q.12272000060 R623 1.Q.12272000060 R101, 1.Q.12332000060 R102, 1.Q.12332000060 R137, 1.Q.12332000060 R138 1.Q.12332000060 R147 1.Q.12392000060 R105, 1.Q.12472000060 R302, 1.Q.12472000060 R330 1.Q.12472000060 R316 1.Q.12512000060 R141, 1.Q.12562000060 R430, 1.Q.12562000060 R434 1.Q.12562000060 R901 1.Q.12822000060 R133, 1.Q.12103000060 R314, 1.Q.12103000060 R407, 1.Q.12103000060 R408, 1.Q.12103000060 R417, 1.Q.12103000060 R701, 1.Q.12103000060 R702,...
  • Page 28 C143 1.D.12503300060 C329, 1.D.12504700060 C411, 1.D.12504700060 C412, 1.D.12504700060 C413, 1.D.12504700060 C427, 1.D.12504700060 C429 1.D.12504700060 C905, 1.D.12501010060 C906 1.D.12501010060 C511, 1.D.12503310060 C521, 1.D.12503310060 C531 1.D.12503310060 C137 1.D.12505610060 C120 1.D.12508210060 C113, 1.D.12501028070 C124, 1.D.12501028070 C131, 1.D.12501028070 C317, 1.D.12501028070 C318, 1.D.12501028070 C405, 1.D.12501028070 C406, 1.D.12501028070 C407,...
  • Page 29 C322 1.D.12504738070 C101, 1.D.12501049090 C111, 1.D.12501049090 C310, 1.D.12501049090 C619, 1.D.12501049090 C620, 1.D.12501049090 C621, 1.D.12501049090 C903, 1.D.12501049090 C916 1.D.12501049090 C104, 1.D.12502249090 C107, 1.D.12502249090 C909 1.D.12502249090 C911 1.D.12504749090 Q101, 1.V.80100020200 Q102, 1.V.80100020200 Q103, 1.V.80100020200 Q104, 1.V.80100020200 Q401, 1.V.80100020200 Q402, 1.V.80100020200 Q403, 1.V.80100020200 Q404, 1.V.80100020200 Q406,...
  • Page 30 R317 1.R.37560000330 VR631 1.J.30920211000 R602 1.R.63401800410 R624 1.R.62427000420 1.R.71090100513 RT601 1.R.71090100512 RL601 1.K.20112000012 C626, 1.C.52887471530 C627 1.C.52887471530 C603, 1.C.52907102520 C605 1.C.52907102520 C323, 1.C.52927471520 C628 1.C.52927471520 C616, 1.C.52927102520 C510 1.C.52927102520 C629 1.C.41032228622 C312, 1.C.13862730430 C315 1.C.13862730430 C311 1.C.13863040420 C313 1.C.33917520420 C314 1.C.33919120430 1.C.42022240521 1.C.42022240522...
  • Page 31 Q521, 1.V.70200010800 Q531 1.V.70200010800 IC101 1.N.11202064141 1.N.13301008011 IC102 1.N.13301008013 IC901 1.N.12402032011 1.N.12101004011 IC601 1.N.12101004012 IC103 1.G.75381100000 T301 1.T.03000000010 T302 1.T.01290000064 T601 1.L.51300000071 T604 1.T.02420000091 L600 1.L.51410400000 L302 1.L.51670403000 X101 1.G.57120550010 SF201 1.Z.64575000001 X901 1.G.30514300101 SF101 1.Z.34504000000 1.U.02000000061 TU201 1.U.02000000062 XS401 1.X.32082001010 XS402 1.X.32032011010...
  • Page 32 FOR IC301 1.8.51107800000 IC301 1.N.12223007021 FOR IC301 1.E.11823308200 FOR IC602 1.8.51104000000 IC602 1.N.11710003020 FOR IC602 1.E.11823306200 FOR IC603 1.8.51104100000 1.N.11710003013 IC603 1.N.11704003014 FOR IC603 1.E.11823306200 R321 1.R.36010000360 R399 1.R.37030000320 L301 1.L.51835300010 1.B.13064800091 1.X.10301860130 1.X.10200245100 1.L.52029001031 1.6.08290300100 1.U.08000010000 1.G.82810000110 1.W.75392320003 附图纸 1.8.80905100000 1.E.72200000030 1.E.72200000060...
  • Page 33 DESCRIPTION T3P03(C00) MAIN CHASSIS AS68-1.6×3 RIVET AS68-1.6×3 RIVET AS68-1.6×3 RIVET AS68-2.5×3.0 RIVET AS68-2.5×3.0 RIVET AS68-2.5×3.0 RIVET AS68-2.5×3.0 RIVET RT13-1/6W-5.1Ω-J CARBON FILM RESISTOR RT13-1/6W-47Ω-J CARBON FILM RESISTOR RT13-1/6W-47Ω-J CARBON FILM RESISTOR RT13-1/6W-47Ω-J CARBON FILM RESISTOR RT13-1/6W-47Ω-J CARBON FILM RESISTOR RT13-1/6W-47Ω-J CARBON FILM RESISTOR RT13-1/6W-100Ω-J CARBON FILM RESISTOR RT13-1/6W-100Ω-J...
  • Page 34 RT13-1/6W-5.6K-J CARBON FILM RESISTOR RT13-1/6W-10K-J CARBON FILM RESISTOR RT13-1/6W-10K-J CARBON FILM RESISTOR RT13-1/6W-10K-J CARBON FILM RESISTOR RT13-1/6W-10K-J CARBON FILM RESISTOR RT13-1/6W-10K-J CARBON FILM RESISTOR RT13-1/6W-12K-J CARBON FILM RESISTOR RT13-1/6W-15K-J CARBON FILM RESISTOR RT13-1/6W-22K-J CARBON FILM RESISTOR RT13-1/6W-27K-J CARBON FILM RESISTOR RT13-1/6W-33K-J CARBON FILM RESISTOR RT13-1/6W-100K-J...
  • Page 35 CL11-50/63/100V-104-J POLYESTER FILM CAPACITOR CL11-50/63/100V-104-J POLYESTER FILM CAPACITOR CL11-50/63/100V-104-J POLYESTER FILM CAPACITOR CL11-50/63/100V-104-J POLYESTER FILM CAPACITOR CH11-100V-104-J POLYPROPYLENE FILM METAL FOIL CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M ELECTROLYTIC CAPACITOR CD110-16V-47uF-M...
  • Page 36 CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR CD110-50V-10uF-M ELECTROLYTIC CAPACITOR...
  • Page 37 BAV21(DO-35G)(Galaxy) DIODE BAV21(DO-35G)(Galaxy) DIODE 1N4007(DO-41)(Galaxy) DIODE FR104(DO-41)(Galaxy) DIODE RGP10G(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP15J(DO-15)(Galaxy) DIODE RGP10G(DO-15)(Galaxy) DIODE ZRM11C(DO-15)(Galaxy) DIODE ZRM11C(DO-15)(Galaxy) DIODE ZRM11C(DO-15)(Galaxy) DIODE ZRM11C(DO-15)(Galaxy) DIODE ES1(DO-41)(Galaxy) DIODE HZ3C2(3.2-3.4)(DO-35G)(Galaxy) ZENER DIODE HZ5B1(4.6-4.8)(DO-35G)(Galaxy) ZENER DIODE HZ6C3(6.1-6.4)(DO-35G)(Galaxy) ZENER DIODE HZ9A2(7.9-8.3)(DO-35G)(Galaxy)
  • Page 38 φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER φ0.6 WIRE BARE JUMPER 7.5mm JUMPER...
  • Page 39 φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER φ0.6 WIRE BARE JUMPER 12.5mm JUMPER...
  • Page 40 φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 WIRE BARE JUMPER 17.5mm JUMPER φ0.6 镀锡CP线...
  • Page 41 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-100Ω-J SMD RESISTOR 0603-1/10W-150Ω-J SMD RESISTOR 0603-1/10W-150Ω-J SMD RESISTOR 0603-1/10W-150Ω-J SMD RESISTOR...
  • Page 42 0603-1/10W-2.7K-J SMD RESISTOR 0603-1/10W-2.7K-J SMD RESISTOR 0603-1/10W-3.3K-J SMD RESISTOR 0603-1/10W-3.3K-J SMD RESISTOR 0603-1/10W-3.3K-J SMD RESISTOR 0603-1/10W-3.3K-J SMD RESISTOR 0603-1/10W-3.9K-J SMD RESISTOR 0603-1/10W-4.7K-J SMD RESISTOR 0603-1/10W-4.7K-J SMD RESISTOR 0603-1/10W-4.7K-J SMD RESISTOR 0603-1/10W-5.1K-J SMD RESISTOR 0603-1/10W-5.6K-J SMD RESISTOR 0603-1/10W-5.6K-J SMD RESISTOR 0603-1/10W-5.6K-J SMD RESISTOR 0603-1/10W-8.2K-J SMD RESISTOR...
  • Page 43 0603-50V-NPO-330-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-470-J SMD CAPACITOR 0603-50V-NPO-101-J SMD CAPACITOR 0603-50V-NPO-101-J SMD CAPACITOR 0603-50V-NPO-331-J SMD CAPACITOR 0603-50V-NPO-331-J SMD CAPACITOR 0603-50V-NPO-331-J SMD CAPACITOR 0603-50V-NPO-561-J SMD CAPACITOR 0603-50V-NPO-821-J SMD CAPACITOR 0603-50V-X7R-102-K SMD CAPACITOR...
  • Page 44 0603-50V-X7R-473-K SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-104-Z SMD CAPACITOR 0603-50V-Y5V-224-Z SMD CAPACITOR 0603-50V-Y5V-224-Z SMD CAPACITOR 0603-50V-Y5V-224-Z SMD CAPACITOR 0603-50V-Y5V-474-Z SMD CAPACITOR 2SC1815LT1(SOT-23)(Changdian)/2SC1815M-Y(SOT-23)(Blue Rocket) SMD TRANSISTOR 2SC1815LT1(SOT-23)(Changdian)/2SC1815M-Y(SOT-23)(Blue Rocket) SMD TRANSISTOR...
  • Page 45 RY18-3W-56Ω-J(F=17.5,H=12,P=4) OXYEN FILM RESISTOR WI06-B-2K-M VARIABLE RESISTOR RX27-3A-5W-1.8Ω-K CEMENT RESISTOR RGCW-5W-27Ω-K(F=12.5,P=4) CEMENT RESISTOR MZ72BL-9RM(Hongming) PTC RESISTOR MZ72-9RM(Gallo) PTC RESISTOR JZC-36F/012-HS(Hongfa) RELAY CT1-Y5P(B)-500V-471-K(F=7.5,P=4) CERAMIC CAPACITOR CT1-Y5P(B)-500V-471-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-1KV-102-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-1KV-102-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-2KV-471-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-2KV-471-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-2KV-102-K(F=7.5,P=4) CERAMIC CAPACITOR CT81-Y5P(B)-2KV-102-K(F=7.5,P=4) CERAMIC CAPACITOR...

  • Page 46: Line Filter

    2SC2688L(TO-126C)(Blue Rocket)/3DA2688(TO-126C)(Huajing) TRANSISTOR 2SC2688L(TO-126C)(Blue Rocket)/3DA2688(TO-126C)(Huajing) TRANSISTOR OM8373-1545(SDIP64)(Philips) M24C08-WBN6P(DIP8)(ST) AT24C08-10PI-2.7(DIP8)(Atmel) TDA9850(SDIP32)(Philips) H11A817C(DIP4)(Fairchild) PC817C(DIP4)(Sharp) HS0038A2(Vishay) IR INFRARED RECEIVER JDT1924 HORIZONTAL DRIVE TRANSFORMER BSC25-N0301(Yinyang) ET-LB-2868(Yong Xing) LINE FILTER BCK-65-10L30(ChuangXing) #N/A 100uH COIL LGB1520-701K(F=7.5,P=4) PEAKING COIL 12MHz(HC-49U)(20pF) CRYSTAL M1859M30(Bao ke) SAW FILTER ZT503F58(BAOTONG) CERAMIC TRAP X4.5B CERAMIC TRAP TDQ-BFSNS2/2(Qing Jia)
  • Page 47 SPEAKER WIRE TJC2-6-4Y-450 DEFLECTION YOKE XCL-74L-1400(Jin Yang) DEGAUSSING COIL 29" ASS'-CRT GROUNDING WIRE (TJC2) GROUNDING SPRING PPQ-2-75/300 ANTENNA MATCHING DEVICE RC-A1-02 I "PHILCO"阿根廷 REMOTE CONTROL MT-52-2300-TJC2-2B(New Square) POWER CORD PHILCO(60×6) NAMEPLATE 消磁线挂钩 DEGAUSSING COIL HOLDER Wire Saddle(H=45.5) FBT LEAD WIRE HOLDER...
  • Page 50 AL FOIL CAPACITOR...
  • Page 60 NE FILM CAPACITOR NE FILM CAPACITOR NE FILM CAPACITOR POLYPROPYLENE FILM CAPACITOR POLYPROPYLENE FILM CAPACITOR NE FILM AC CAPACITOR NE FILM AC CAPACITOR NE FILM AC CAPACITOR NE FILM AC CAPACITOR NE FILM AC CAPACITOR...
  • Page 61 D/WHITE/RED/WHITE/GREEN/BLUENESS/YELLOW) /WHITE/RED)
  • Page 63 NO LEVEL LOCATION OR P_PARTS_CODE C_PARTS_CODE QTY 编号 级别 位号 物料号 数量 A013 00000000000000 013F5SM L901 013F5SM 1LB4L81B01200 Q901 013F5SM BXXAVB150IBD- SP901 013F5SM 1LB4A10B04600 W901 013F5SM 1AV4W10B11400 W902 013F5SM 1LB4W30B04300 A100 00000000000000 1AA0B10E695A0 A100 1AA0B10E695A0 1AA0B10E695AA A101 1AA0B10E695AA 1AV4F1BAM0340 10 3 A1901 1AA0B10E695AA 1AV4U20B40500...
  • Page 64 57 3 C202 1AA0B10E695AA CF1H153JADANN 58 3 C202 1AA0B10E695AA CF1H153JBEANN 59 3 C203 1AA0B10E695AA CK1H103KGQBNZ 60 3 C204 1AA0B10E695AA CEXLB1H100VDN 61 3 C204 1AA0B10E695AA CEXLB1H100WAN 62 3 C204 1AA0B10E695AA CE1H100M4UANN 63 3 C205 1AA0B10E695AA CEXLB1H100VDN 64 3 C205 1AA0B10E695AA CEXLB1H100WAN 65 3 C205 1AA0B10E695AA...
  • Page 65 115 3 C442 1AA0B10E695AA CM2E224JAPAQN 116 3 C442 1AA0B10E695AA CM2E224JAPA0N 117 3 C450 1AA0B10E695AA CK1H102KGQBNG 118 3 C469 1AA0B10E695AA CEXLB1H100VDN 119 3 C469 1AA0B10E695AA CEXLB1H100WAN 120 3 C469 1AA0B10E695AA CE1H100M4UANN 121 3 C471 1AA0B10E695AA CPXLB2A2R2YAN 122 3 C486 1AA0B10E695AA CEXLB2E220UCN 123 3 C486 1AA0B10E695AA...
  • Page 66 173 3 C652 1AA0B10E695AA CEXLB1V102WAN 174 3 C652 1AA0B10E695AA CE1V102M4UANN 175 3 C654 1AA0B10E695AA CE1E222M4UANN 176 3 C655 1AA0B10E695AA CK3A471KANHNN 177 3 C655 1AA0B10E695AA CK3A471KCRDNN 178 3 C656 1AA0B10E695AA CK3A102KANHNN 179 3 C656 1AA0B10E695AA CK3A102KCRDNN 180 3 C657 1AA0B10E695AA CK3A471KANHNN 181 3 C657 1AA0B10E695AA...
  • Page 67 231 3 D102 1AA0B10E695AA DZMTZJ6.8A--N 232 3 D102 1AA0B10E695AA DZRD6.8EB1--N 233 3 D102 1AA0B10E695AA DZXLBZA6.8A-N 234 3 D103 1AA0B10E695AA DZMTZJ36A---N 235 3 D103 1AA0B10E695AA DZRD36EB1---N 236 3 D106 1AA0B10E695AA DZUDZS10B---G 237 3 D107 1AA0B10E695AA DZUDZS10B---G 238 3 D1201 1AA0B10E695AA DD1SS355----G 239 3 D1202 1AA0B10E695AA...
  • Page 68 289 3 D646 1AA0B10E695AA DD1S2076A---N 290 3 D651 1AA0B10E695AA DDRU3AM-----N 291 3 D652 1AA0B10E695AA DDEU2Z------N 292 3 D652 1AA0B10E695AA DDXLBB018---N 293 3 D653 1AA0B10E695AA DDRU3YX-----N 294 3 D653 1AA0B10E695AA DDXLBB022---N 295 3 D654 1AA0B10E695AA DDRU3YX-----N 296 3 D654 1AA0B10E695AA DDXLBB022---N 297 3 D655 1AA0B10E695AA...
  • Page 69 347 3 JP004 1AA0B10E695AA 8YDX3R0 348 3 JP006 1AA0B10E695AA 8YDX3R0 349 3 JP007 1AA0B10E695AA 8YDX3R0 350 3 JP029 1AA0B10E695AA 8YDX3R0 351 3 JP056 1AA0B10E695AA 8YDX3R0 352 3 JP1201 1AA0B10E695AA RGGR000ZTCANZ 353 3 JP1202 1AA0B10E695AA RGGR000ZTCANZ 354 3 JP1901 1AA0B10E695AA RGGR000ZTCANZ 355 3 JP202 1AA0B10E695AA...
  • Page 70 405 3 J046 1AA0B10E695AA 8YDX3R0 406 3 J047 1AA0B10E695AA 8YDX3R0 407 3 J048 1AA0B10E695AA 8YDX3R0 408 3 J049 1AA0B10E695AA 8YDX3R0 409 3 J050 1AA0B10E695AA 8YDX3R0 410 3 J051 1AA0B10E695AA 8YDX3R0 411 3 J052 1AA0B10E695AA 8YDX3R0 412 3 J053 1AA0B10E695AA 8YDX3R0 413 3 J054 1AA0B10E695AA...
  • Page 71 463 3 J107 1AA0B10E695AA 8YDX3R0 464 3 J108 1AA0B10E695AA 8YDX3R0 465 3 J109 1AA0B10E695AA 8YDX3R0 466 3 J110 1AA0B10E695AA 8YDX3R0 467 3 J111 1AA0B10E695AA 8YDX3R0 468 3 J112 1AA0B10E695AA 8YDX3R0 469 3 J113 1AA0B10E695AA 8YDX3R0 470 3 J114 1AA0B10E695AA 8YDX3R0 471 3 J115 1AA0B10E695AA...
  • Page 72 521 3 KDY-5 1AA0B10E695AA 1AV4J30B0250N 522 3 KDY-5 1AA0B10E695AA 1LB4J30B0040N 523 3 KE-1 1AA0B10E695AA 1AV4J30B0250N 524 3 KE-1 1AA0B10E695AA 1LB4J30B0040N 525 3 KE-2 1AA0B10E695AA 1AV4J30B0250N 526 3 KE-2 1AA0B10E695AA 1LB4J30B0040N 527 3 KG-1 1AA0B10E695AA 1AV4J30B0250N 528 3 KG-1 1AA0B10E695AA 1LB4J30B0040N 529 3 KG-2 1AA0B10E695AA...
  • Page 73 579 3 Q261 1AA0B10E695AA 7T200221 580 3 Q431 1AA0B10E695AA T2SC3332-R--N 581 3 Q431 1AA0B10E695AA T2SC3332-S--N 582 3 Q432 1AA0B10E695AA TXXGA0127522M 583 3 Q432A 1AA0B10E695AA 1LG2HEF0046-- 584 3 Q432B 1AA0B10E695AA SM2PB30100SV- 585 3 Q432C 1AA0B10E695AA ZAV6120KE24-- 586 3 Q432C 1AA0B10E695AA ZB13 587 3 Q432C 1AA0B10E695AA...
  • Page 74 637 3 R006 1AA0B10E695AA RDD4R70JPAANN 638 3 R010 1AA0B10E695AA RGG5601JTCANZ 639 3 R011 1AA0B10E695AA RGG1802JTCANZ 640 3 R019 1AA0B10E695AA RDA1500JPCANN 641 3 R029 1AA0B10E695AA RDA1500JPCANN 642 3 R041 1AA0B10E695AA RDB1001JPBANN 643 3 R1004 1AA0B10E695AA RDD75R0JPAANN 644 3 R1011 1AA0B10E695AA RGG1001JTCANZ 645 3 R1013 1AA0B10E695AA...
  • Page 75 695 3 R263 1AA0B10E695AA RGG1002JTCANZ 696 3 R264 1AA0B10E695AA RDD1200JPAANN 697 3 R265 1AA0B10E695AA RGG33R0JTCANZ 698 3 R267 1AA0B10E695AA RDD4700JPAANN 699 3 R271 1AA0B10E695AA RGG1000JTCANZ 700 3 R272 1AA0B10E695AA RGG1000JTCANZ 701 3 R280 1AA0B10E695AA RGG1000JTCANZ 702 3 R286 1AA0B10E695AA RGG4701FTCANZ 703 3 R289 1AA0B10E695AA...
  • Page 76 753 3 R602H2 1AA0B10E695AA 2400010 754 3 R611 1AA0B10E695AA RDB4700JPBANN 755 3 R613 1AA0B10E695AA RFXAAB6800JPN 756 3 R613 1AA0B10E695AA RFXAVB681JFNN 757 3 R614 1AA0B10E695AA RDD2202JPAANN 758 3 R615 1AA0B10E695AA RDD2200JPAANN 759 3 R616 1AA0B10E695AA RDD1202JPAANN 760 3 R619 1AA0B10E695AA RDB22R0JPBANN 761 3 R620 1AA0B10E695AA...
  • Page 77 811 3 R804 1AA0B10E695AA RGGR000ZTCANZ 812 3 R805 1AA0B10E695AA RGGR000ZTCANZ 813 3 R811 1AA0B10E695AA RGG4702JTCANZ 814 3 R812 1AA0B10E695AA RGG1002JTCANZ 815 3 R813 1AA0B10E695AA RGG1002JTCANZ 816 3 R814 1AA0B10E695AA RGG1002JTCANZ 817 3 R818 1AA0B10E695AA RDD1001JPAANN 818 3 R819 1AA0B10E695AA RGG1002JTCANZ 819 3 R830 1AA0B10E695AA...
  • Page 78 869 3 SW601H1 1AA0B10E695AA 2400010 870 3 SW601H2 1AA0B10E695AA 2400010 871 3 SW601H3 1AA0B10E695AA 2400010 872 3 SW601H4 1AA0B10E695AA 2400010 873 3 TP-A 1AA0B10E695AA 1AV4J30B0250N 874 3 TP-A 1AA0B10E695AA 1LB4J30B0040N 875 3 T431A 1AA0B10E695AA 1LB4L18B0070N 876 3 T471 1AA0B10E695AA 1LB4L40B05900 877 3 T471H1 1AA0B10E695AA...
  • Page 79 927 3 Q741 1AA0B10E695AB 7T200221 928 3 Q751 1AA0B10E695AB 7T200221 929 3 R701 1AA0B10E695AB RGG3300JTCANZ 930 3 R703 1AA0B10E695AB RGG2200JTCANZ 931 3 R704B 1AA0B10E695AB RSXAV1123JDAK 932 3 R705 1AA0B10E695AB RDA2701JPCANN 933 3 R711 1AA0B10E695AB RGG3300JTCANZ 934 3 R713 1AA0B10E695AB RGG2200JTCANZ 935 3 R714B 1AA0B10E695AB...
  • Page 80 985 2 009F8FP 1AA6P1P4607-- 986 2 009F8FP 320311 987 1 00000000000000 010F8FE 988 2 010F8FE SFPAY30100SV- 989 2 010F8FE STXAANX1002A- 990 2 010F8FE ST2AN40120SV- 991 2 010F8FE ST2AN40140SV- 992 1 019Z 00000000000000 019ZF5SM 993 2 019ZF5SM 1AA9W0330005- 994 3 1AA9W0330005- 1AV4J11EL030N 995 3 1AA9W0330005-...
  • Page 81 DESCRIPTION MATERIAL_SPEC 规格型号 材料规格型号 ELECTRICAL PARTS DIRECTORY COIL,DEGAUSSING CJA(0.21T30L920W260) CRT A34EJL01X21 A34EJL01X21 SPEAKER,8 5X9-32-2W-8 CORD,POWER-2.4MK-A5102 16311101,B075C0201N ASSY,WIRE GND CONNECTOR F5SM H-1 ASSY,PWB,CTV C4CM ASSY,PWB,MAIN F8FP TUNER,U/V USA-181-PLL-MA UNIT,REMOCON RECEIVER GP1UM281QK(38K) ELECT 4.7 U M 50V ELECT 4.7U M 50V ELECT 100U M 25V ELECT 100U M 25V...
  • Page 82 POLYESTER 0.015U J 50V POLYESTER 0.015U J 50V CERAMIC 0.01U K 50V ELECT 10U M 50V ELECT 10U M 50V ELECT 10U M 50V 50ME10HC ELECT 10U M 50V ELECT 10U M 50V ELECT 10U M 50V 50ME10HC ELECT 0.47 U M 50V ELECT 0.47U M 50V ELECT...
  • Page 83 MT-POLYPRO 0.22U J 250V MT-POLYPRO 0.22U J 250V ECWF2224JSQ CERAMIC 1000P K 50V ELECT 10U M 50V ELECT 10U M 50V ELECT 10U M 50V 50ME10HC NP-ELECT 2.2U M 100V ELECT 22U M 250V ELECT 22U M 250V 250ME22HPC ELECT 4.7 U M 50V ELECT 4.7U M 50V...
  • Page 84 ELECT 1000U M 35V ELECT 1000U M 35V 35ME1000HC ELECT 2200U M 25V 25ME2200HC CERAMIC 470P K CERAMIC 470P K CERAMIC 1000P K CERAMIC 1000P K CERAMIC 470P K CERAMIC 470P K CERAMIC 470P K CERAMIC 470P K ELECT 1U M 50V ELECT 1U M 50V ELECT...
  • Page 85 ZENER DIODE MTZJ6.8A MTZJ6.8A ZENER DIODE RD6.8EB1 RD6.8EB1 ZENER DIODE MTZJ6.8A MTZJ6.8A ZENER DIODE MTZJ36A MTZJ36A ZENER DIODE RD36EB1 RD36EB1 ZENER DIODE UDZS-TE-1710B UDZS10B TE-17 ZENER DIODE UDZS-TE-1710B UDZS10B TE-17 DIODE 1SS355-TE-17 1SS355 TE-17 DIODE 1SS355-TE-17 1SS355 TE-17 LED SLP-181B-51 SLP-181B-51 LED HOLDER LED HOLDER-G2CA-A...
  • Page 86 DIODE 1S2076A-E 1S2076A-E DIODE RU3AM RU3AM DIODE EU2Z EU2Z DIODE EU2 DIODE RU3YX RU3YX DIODE RU3YX RU3YX DIODE RU3YX RU3YX DIODE RU3YX RU3YX DIODE 1SS133 1SS133 DIODE 1S2076A-E 1S2076A-E ZENER DIODE MTZJ6.2C MTZJ6.2C ZENER DIODE RD6.2EB3 RD6.2EB3 ZENER DIODE MTZJ6.8A MTZJ6.8A ZENER DIODE MTZJ6.8A MTZJ6.8A...
  • Page 87 CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX...
  • Page 88 CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX...
  • Page 89 CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX...
  • Page 90 TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG PLUG,3P VD-2.500-W(LF,SN) SOCKET,5P VD-2.500-W SOCKET,3P VD-2.500-W JACK,RCA-2 TERMINAL,BOARD JACK,RCA-2 YL(SW)-WT(SW) JACK,PHONE D3.6 TRANS,OSC,45.75MHZ CUTTING WIRE 30-0000-FX CUTTING WIRE 30-0000-FX INDUCTOR,1U K A-4.5X14-3800-0.022 CORE,PIPE CORE,PIPE...
  • Page 91 TR 2SA1037K(P)-4 TR 2SC3332-R 2SC3332-R TR 2SC3332-S 2SC3332-S TR TT2140LS-YB11 H-HEAT SINK-C4BL CHN TS 1.0 SCR PAN+SW+W 3X10 Sos,3X10 G-FLOIL GREASE*SY-600 JPN-KANTO-K*WT SILICON GREASE G-746 h G-746 SILICON GREASE h- YG6260 WASHER EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET...
  • Page 92 CARBON 4.7 JA 1/6W 1/6-FPJ4R7B-0K MT-GLAZE 5.6K JA 1/16W 1/16-NEJ562B-0T1 MT-GLAZE 18K JA 1/16W 1/16-NEJ183B-0 CARBON 150 JA 1/2W 1/2-FPJ151B-0 CARBON 150 JA 1/2W 1/2-FPJ151B-0 CARBON 1K JA 1/4W 1/4-FPJ102B-0K CARBON 75 JA 1/6W 1/6-FPJ750B-0K MT-GLAZE 1K JA 1/16W 1/16-NEJ102B-0 MT-GLAZE 1K JA 1/16W 1/16-NEJ102B-0...
  • Page 93 MT-GLAZE 10K JA 1/16W 1/16-NEJ103B-0 CARBON 120 JA 1/6W 1/6-FPJ121B-0K MT-GLAZE 33 JA 1/16W 1/16-NEJ330B-0T1 CARBON 470 JA 1/6W 1/6-FPJ471B-0K MT-GLAZE 100 JA 1/16W 1/16-NEJ101B-0T1 MT-GLAZE 100 JA 1/16W 1/16-NEJ101B-0T1 MT-GLAZE 100 JA 1/16W 1/16-NEJ101B-0T1 MT-GLAZE 4.7K FA 1/16W 1/16-NEF472B-0T1 MT-GLAZE 100 JA 1/16W 1/16-NEJ101B-0T1...
  • Page 94 EYELET T0.2 BSP CARBON 470 JA 1/4W 1/4-FPJ471B-0K FUSIBLE RES 680 J- 1/4W 1/4-NPJ681Z-0 FUSIBLE RES 680 J- 1/4W CARBON 22K JA 1/6W 1/6-FPJ223B-0K CARBON 220 JA 1/6W 1/6-FPJ221B-0K CARBON 12K JA 1/6W 1/6-FPJ123B-0K CARBON 22 JA 1/4W 1/4-FPJ220B-0K CARBON 470K JA 1/2W 1/2-FPJ474B-0 CARBON...
  • Page 95 MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 MT-GLAZE 0.000 ZA 1/16W 1/16-NEJ000B-0T1 MT-GLAZE 47K JA 1/16W 1/16-NEJ473B-0T1 MT-GLAZE 10K JA 1/16W 1/16-NEJ103B-0 MT-GLAZE 10K JA 1/16W 1/16-NEJ103B-0 MT-GLAZE 10K JA 1/16W 1/16-NEJ103B-0 CARBON 1K JA 1/6W 1/6-FPJ102B-0K MT-GLAZE 10K JA 1/16W 1/16-NEJ103B-0 CARBON 1K JA 1/6W 1/6-FPJ102B-0K...
  • Page 96 EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP TERMINAL,PLUG (LEAD FREE) TERMINAL,PLUG TRANS,DRIVE 8X11 TRANS,FLYBACK BAILI B3 EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP EYELET T0.2 BSP TRANS,POWER,PULSE EER28...
  • Page 97 TR 2SA1037K(P)-4 TR 2SA1037K(P)-4 MT-GLAZE 330 JA 1/16W 1/16-NEJ331B-0T1 MT-GLAZE 220 JA 1/16W 1/16-NEJ221B-0T1 OXIDE-MT 12KJB CARBON 2.7K JA 1/2W 1/2-FPJ272B-0 MT-GLAZE 330 JA 1/16W 1/16-NEJ331B-0T1 MT-GLAZE 220 JA 1/16W 1/16-NEJ221B-0T1 OXIDE-MT 12KJB CARBON 2.7K JA 1/2W 1/2-FPJ272B-0 MT-GLAZE 330 JA 1/16W 1/16-NEJ331B-0T1 MT-GLAZE 220 JA 1/16W...
  • Page 98 INSTRUCTION MANUAL-F8FP ARG PAPER ENVELOPE HW-SR T0.05 SCREWS-CABINET- SCR S-TPG BRZ+FLG 3.0X10.0 V SPECIAL SCREW SWCH18A SCR TPG BRZ 4X12V Sj2,4X12 SCR TPG BRZ 4X14 Sj2,4X14,Z1 LEAD WIRES DIRECTORY2 NONSTANDARD WIRE ASSY 280-0335-FY 2PNUKI SOCKET,HOUSING 3P VX-2.500-X TERMINAL,SOCKET CUTTING WIRE 280-0000-FY NONSTANDARD WIRE ASSY 320-0515-FR 2,4NUKI...
