Philco PD2015 Service Manual

Colour television

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

SERVICE MANUAL Colour Television

Specifications

Power Source . . . . . . . . .AC220V, 50Hz / 60Hz

Receiving System . . . . . .PAL (M/M, N/N), NTSC (M/M)

Channel Coverage

Antenna mode VHF: CH02-CH13, UHF: CH14-CH69

CATV mode

VHF band: CH01-CH13, Mid band: CH14-CH22

Super band: CH23-CH36, Hyper band: CH37-CH64

Ultra band: CH65-CH94 and CH100-CH125

Low mid band: CH95-CH99

Video IF . . . . . . . . . . . . . 45.75MHz

Aerial Input Impedance . . 75Ω

Ext. Terminals

Video inputs: Phono jack

Audio inputs: Phono jack

Headphone Jack (Mono):

Sound Output (RMS) . . . . 2W

Speakers . . . . . . . . . . . 5 cm x 9 cm x 2 pc.

Dimensions . . . . . . . . . 606 (W)

Weight . . . . . . . . . . . . . approx. 18.6 Kg

Specifications subject to change without notice.

F5ZS

2 (1Vp - p, 75Ω)

2 (436mVrms, more than 40KΩ)

Mini jack

479 (H)

483 (D)mm

FILE NO.

Model No. PD2015

Service Ref. No. PD2015-00

JXMRR

Product Code: 111339914

Original Version

Chassis Series: LA5-A

Give complete "SERVICE REF. NO." for parts

order or servicing. It is shown on the rating

plate at the cabinet back of the unit.

This T.V. receiver will not work properly in

foreign countries where the television trans-

mission system and power source differ from

the design specifications. Refer to the specifi-

cation table.

(Argentina)

Table of Contents

Need help?

Do you have a question about the PD2015 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philco PD2015

Page 1 FILE NO. SERVICE MANUAL Colour Television Model No. PD2015 (Argentina) Service Ref. No. PD2015-00 JXMRR Specifications Product Code: 111339914 Power Source ..AC220V, 50Hz / 60Hz Receiving System ..PAL (M/M, N/N), NTSC (M/M)
Page 2: Table Of Contents
Contents Safety Notice ............... . 2 Chassis Block Diagram .
Page 3: Chassis Block Diagram
Chassis Block Diagrams MAIN SIGNAL PROCESSING CIRCUIT...
Page 4 Chassis Block Diagrams SYSTEM CONTROL...
Page 5: Ic Block Diagrams
IC Block Diagrams IC201 < IF/Video/Chroma/Def. > LA76818A Audio Output SIF Input FM Output/Selected SIF APC Filter Audio Output SIF Output PIF AGC Ext. Audio Input RF AGC Output PIF Input1 APC Filter VCO Coil 1 PIF Input 2 VCO Coil 2 IF Ground VCO Filter IF Vcc...
Page 6 IC Block Diagrams IC201 <IF System Block Diagram> LA76818A...
Page 7 IC Block Diagrams IC001 < Audio AMP. > LA4266-E 30KΩ 300Ω POWER FILTER INPUT IC501 < Vertical Output > LA78040N, TDA9302H Thermal Protection Pump...
Page 8: Service Adjustments
Service Adjustments General This set has an On-screen Service Menu system included in the CPU that allows remote operation for most of the service adjustments. IC802 (EEPROM) Replacement When IC802 (EEPROM) is replaced, IC801 (CPU) will automatically write the initial reference data into IC802 for basic TV operation. However, the bus data should be checked and some bus data should be set up before attempting the service adjustments.
Page 9 Service Adjustments On-screen Service Menu Following table shows the initial values which have been stored in the CPU ROM, and items for the service adjustments. When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be checked and be set up or readjusted according to the procedures described in the following pages.
Page 10 Service Adjustments Item Initial value Range Description COOP 00~07 Colour Killer Y-APF 00, 01 Y-APF Select DEEM 00, 01 De-emphasis TC V-LVL 00~07 Video Level FMLVL 00~31 FM Level TTEST 00~07 Trap Test IFOM-S 00, 01 Over Mod. SW IFMN-S 00, 01 Audio Monitor SW, Monitor/FM IFTRPS...
Page 11 Service Adjustments Important Notice: Do not attempt to adjust service adjustments not listed on below otherwise it may cause loss of performance and for correct operation. Item 01 [RFAGC] AGC Item 04 [V-SIZ] VERTICAL SIZE NOTE: Do not attempt this adjustment with weak signal. 1.
Page 12 Service Adjustments Items 16-23 GREY SCALE 1. Receive a monochrome circular pattern. 2. Set the brightness and colour to normal, contrast to maximum. 3. Enter to the service mode. 4. Set each value of Item-16 RBIAS, 17 GBIAS, 18 BBIAS mode to 00. Set each value of Item-19 RDRIV, 21 BDRIV mode to 63, 20 GDRIV to 08.
Page 13 Service Adjustments Service Adjustment-2 FINE TUNING This adjustment is used to do a fine tuning of the channels with poor reception after they have been stored by the automatic tuning. This function is available for one channel only and the fine-tuned channel is memorized into IC802 (EEPROM). 1.
Page 14: Protection Circuit
Service Adjustments Service Adjustment-3 FOCUS ADJUSTMENT HIGH VOLTAGE CHECK 1. Receive the monochrome circular pattern. Note: +B (+130V) Voltage and Grayscale Adjustment must 2. Set the brightness to normal and contrast to maximum. be completed before attempting High Voltage Check. 3.
Page 15: Purity And Convergence Adjustment
Purity and Convergence Adjustment CAUTION: The Convergence and Purity adjustments have been made at the factory. Readjustment should be made only after picture tube or deflection yoke replacement, following the steps below: PURITY ADJUSTMENT 8. Tighten the mounting screw of the Deflection Yoke. Adjust 1.
Page 16: Cabinet Parts List
LATCH PUSH,7.9X6.9BK 610 322 1762 DEC CONTROL SHEET-F5ZS 610 322 1779 CABINET FRONT-F5ZS 610 274 3623 DOOR-F5ZA 610 318 1004 BADGE,PHILCO-C4BS 610 322 1830 CABINET BACK-F5ZS 610 322 1892 LABEL RATING-F5ZS 645 069 4608 ASSY,REMOCON JXMRR 610 297 3723 RC-BATTERY LID JXMRA...
Page 17: Chassis Electrical Parts List
Chassis Electrical Parts List C5ZS Product safety should be considered when a component replacement is made in any area of a receiver. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety.
Page 18 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description Q613 405 171 4107 TR 2SK2647 405 151 8705 TR 2SC536NG-NPA Q625 405 013 6801 TR 2SC2274-E 405 020 7501 TR 2SC945A-PA 405 013 7006 TR 2SC2274-F 405 020 7709 TR 2SC945A-QA Q641 406 000 6804...
Page 19 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description 409 172 1509 IC MC78M05CT C433 403 076 3102 CERAMIC 3900P K 500V 409 320 5700 IC UPC78M05AHF C434 403 051 3103 ELECT 47U M IC801 410 527 1907 IC LC863440W-53Z0-TLM C441 403 346 6901...
Page 20 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description 403 041 8804 ELECT 10U M R212 401 105 1402 MT-GLAZE 150 JA 1/16W C665 403 043 0202 ELECT 220U M R221 401 105 0504 MT-GLAZE 1K JA 1/16W C681 403 040 5408 ELECT...
Page 21 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description R838 401 105 5301 MT-GLAZE 4.7K JA 1/16W R613 402 001 8106 FUSIBLE RES 680 J- 1/4W R839 401 105 4007 MT-GLAZE 330 JA 1/16W R614 401 025 8208 CARBON 22K JA 1/6W...
Page 22 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description D1201 407 149 0807 DIODE 1SS355-TE-17 407 013 4306 DIODE 1S2076A D1202 407 149 0807 DIODE 1SS355-TE-17 407 013 7109 DIODE 1S2473 D1901 407 116 6504 LED SLP-181B-51 D661 407 099 5501 ZENER DIODE MTZJ6.2C D1908...
Page 23 C5ZS Ref. No. Part No. Description Ref. No. Part No. Description 610 317 7564 ASSY,PWB,CRT C4AP R741 401 020 0801 CARBON 470 JA 1/4W R742 401 105 1501 MT-GLAZE 1.5K JA 1/16W 1AA0B10E694EB R744 401 105 1402 MT-GLAZE 150 JA 1/16W R751 401 105 7909 MT-GLAZE...
Page 24 Jan./’05...
Page 25 S: Oxied metalized 8. This circuit diagram covers a basic or representative chassis only. There 12 X 10 =12K SERVICE PD2015-00 Rated wattage (1/2W) W: Wire wounding may be some components or partial circuit differences between the C: Solid REF. NO.
Page 26 Waveforms & Voltages (On the Main Board) CRT BOARD (Component Location) IC001 (AUDIO AMP.) 1AA4B10E6900B Pin-1 1.1V 0.7V 0.7V 0.7V 14.8V Q701 R741 B-OUT D741 D742 J702 IC201 (IF/VIDEO/CHROMA) Q701-L D754 Pin-1 2.3V 2.2V 2.7V 1.7V 2.9V 2.9V 5.0V 2.3V Q711 L700 Q721...
