Clear WIXFBR-117 Get Started

LET'S GET STARTED
CLEAR Modem with Wi-Fi
SET IT UP
Align the slots at the bottom
of the CLEAR Modem with
Wi-Fi (Modem) with the slots
on the Modem Foot (Foot).
Push gently on the Modem
to snap the Foot into place.
To remove the Foot, press both
tabs outward, at the same time,
and the Foot will release from
the slots.
Follow the diagram to plug in the Power Cord:
After your've plugged the Modem into a power
outlet, the Modem will automatically search for a
CLEAR 4G signal.
SET IT UP
(continued)
As the Modem is searching
for the CLEAR 4G signal,
five LED lights, located on
the side of the Modem, will
blink sequentially and then
in unison. When the Modem
is connected to the CLEAR
4G signal, the LED lights will
stop blinking and remain lit.
NOTE:
The number of lights indicates the CLEAR
4G signal strength. For optimal signal strength,
you should try different locations for the Modem
to ensure a minimum of two lights are lit.
If at least two LED lights are not lit, try moving the
Modem to another room.
• Move just the Modem (not your computer) to
another room, and wait 15-20 seconds after
the LED lights are solid white for an accurate
reading of the CLEAR 4G signal
• To optimize the signal strength in the
Modem's current location, try turning the
Modem by small 1/4" increments
• Once you find the best CLEAR 4G signal,
you're ready to connect your devices
SET IT UP
(continued)
CONNECT TO THE WIRELESS NETWORK:
• Please locate your Modem's default wi-fi
Network name and password located on a
label near the bottom of the device
• From your device, view the available networks
• Select the Modem's wi-fi Network (located on
the label)
• Enter the wi-fi password, exactly as it appears
on the label
• Your device should display a message
indicating it has connected to your Modem's
wi-fi Network
As an alternative to wi-fi, you can use the included
Ethernet Cable to connect to the Modem.
SET IT UP
(continued)
Once your've set up your Modem and connected
to the wi-fi Network, you should change the
Modem's wi-fi Network Name (SSID) and the
Default Password to something easy to remember.
• Log in to your Modem's Home Page
by entering http://192.168.15.1 into your
web browser
• Enter the default Password (CLEAR123)
• From the Menu, select "Basic" then 'Wi-Fi"
• Enter your new wi-fi Network Name and
Password (the wi-fi- Password must be
between 8 and 63 characters)
• Click "apply" to save the changes
• Use your computer's wireless Connection
Manager to find your wi-fi Network Name
and connect using the new wi-fi password
NOTE: If you forgot your wi-fi Network Name
or Password, you can connect to your Modem
with the Ethernet Cable. Log in, using the default
Modem password, to view or change the wi-fi
Network Name or Password.
