Clear Spot 4G User Manual

LET'S GET STARTED
CLEAR Spot 4G
SET IT UP
Remove the battery cover,
slide the battery in so the
metal pins align, and
replace the battery cover.
The battery comes partially
charged, so you can use your CLEAR Spot 4G
(CLEAR Spot) right away.
Use the Mini USB Cable with the Wall Charger or
with your computer to charge the battery.
You can charge the battery while your're using the
CLEAR Spot.
While the battery is charging, the
Power Button illuminates red.
Mini USB Port
The Power Button turns
green when the battery is
fully charged.
Power Button
SET IT UP
(continued)
To turn on the CLEAR Spot, press and hold the
Power Button for three seconds.
While the CLEAR Spot is searching for the CLEAR
4G network, the 4G indicator flashes red.
Once the CLEAR Spot is connected to the
CLEAR 4G network, the 4G indicator will turn a
solid green, yellow, or red, indicating the signal
strength—a green light means you have an
excellent signal.
Once the wi-fi status indicator turns blue, the
CLEAR Spot is ready for you to connect your
laptop or wi-fi-enabled device.
INDICATORS
4G Signal Status (green)
wi-fi Status (blue)
When indoors, place the CLEAR Spot near a
window or outside wall to receive the strongest
signal. The CLEAR Spot wi-fi signal range is 100
feet, so you don't have to be next to the CLEAR
Spot to connect your devices.
CONNECT TO
THE INTERNET
We recommend you use a laptop to set up your
CLEAR Spot.
In order to identify your CLEAR Spot network
name and network key (password), locate the
MAC ID, which can be found in two places—on
the label on the back of the CLEAR Spot and
under the battery.
Record the network name and password below,
since you will need them to connect to the
internet.
• The network name is "Clear Spot xxx" with
"xxx", being the last 3 digits of the MAC ID
Network Name:
• The password is the last 8 digits of the MAC ID
Password:
Now you are ready to connect to the internet.
From your laptop view the available networks.
• Select the "Clear Spot xxx" network
• Enter the password exactly as it appears,
using lower-case letters
• You will receive a message indicating you
are connected
