Clear Modem Series G
User Guide
Model: WIXB-175
Manual Version: 1.3
Manual Date: July. 16 2009
Page 1 of 21

Advertisement

loading
Need help?

Need help?

Do you have a question about the WIXB-175 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clear WIXB-175

  • Page 1 Clear Modem Series G User Guide Model: WIXB-175 Manual Version: 1.3 Manual Date: July. 16 2009 Page 1 of 21...
  • Page 2: Powerful Features In A Single Unit

    Overview Thank you for purchasing the Clearwire CPE Indoor (WIXB-175) desktop device. The Desktop CPE allows you to connect to the wireless world easily and seamlessly without complicated installation and setup procedures. In addition it offers you the ability to make Voice over Internet Protocol (VoIP) calls.
  • Page 3: Operating Information

    Before you begin installation, check that you have received the following items with your Desktop CPE: In the box with your CPE you should have: Item Description Power Adapter Power adapter connects the Clear Modem to an AC electrical outlet. Page 3 of 21...
  • Page 4: Easy Setup

    Ethernet Cable The Ethernet cable connects the Internet port on your Clear Modem to your PC or laptop computer. Clear Modem Quick Start Guide Provides quick installation instructions for getting your Desktop CPE up and running. Welcome Letter A brief introduction of the stuff inside the packaging and customer service contact window.
  • Page 5 Use the following procedure to log into the Desktop CPE. 1. On a computer that is connected to the Clear Modem Series G, open a web browser. 2. In the Address or Location field, type http://192.168.15.1 and press ENTER to display the login screen.
  • Page 6 Basic Menu The Basic menu provides the following tabs: Password Time Zone Device Name Reset Factory Settings Password Tab The password tab allows you to enable/disable password protection. You can also change your password here. Field or Button Description Enable Login Password Checking this box will require login password Protection protection.
  • Page 7 Time Zone Tab The Device Time Zone tab allows you to establish the time zone for your location. It also allows you to automatically adjust for Daylight Savings Time if necessary. Field or Button Description Current Local Time Shows the current local date and time. Time Zone Select your local time zone from the drop down box.
  • Page 8 Device Name Tab The Device Name tab allows you to re-name your CPE device. This is the Device Name you enter on an internet browser address bar to access your CPE device. Field or Button Description New Device Enter the new name for the CPE device. Name Maximum 20 characters.
  • Page 9 Restore Factory Settings Tab The Restore Factory Settings Tab will reset your CPE to the manufacturers default settings. Be sure to click the GO button if you are sure you want to reset factory settings. The CPE will reboot automatically after the GO button has been clicked. Advanced Menu The Advanced Menu provides the following tabs: Firewall...
  • Page 10 Firewall Tab A firewall helps to protect your home network from unauthorized access. It will also help to manage authorized access from the internet to your CPE Field or Button Description Enable Firewall Check this box to enable the firewall for your home network.
  • Page 11 Internet Protocol Tab Please check with your service provider for these settings. If you are unsure of the settings, leave the default values set and click the Apply button If your service provider has instructed you to change any of these settings, be sure to click the Apply button when you are finished.
  • Page 12 their domain name associated with an ever changing IP address. As an example, DDNS is used when you are hosting your own website Field or Button Description Enable DDNS Check this box to Enable DDNS (default is unchecked). Select DDNS Service Provider that you belong to DDNS Service Provider from the drop down box.
  • Page 13 Field or Button Description Enable UPnP IGD Enables Universal Plug and Play (UPnP) Internet Gateway Device (IGD) profile to allow certain Windows applications to setup the port forwarding rule dynamically when NAT is enabled on this device. DMZ (DeMilitarized Zone) Enter the DMZ IP Address.
  • Page 14 Forwarding Tab Click on the ADD button to create additional Port Fowarding rules Field or Button Description Select Select a box when you want to delete the specific row. Protocol Select TCP (Transmission Control Protocol) or UDP (User Datagram Protocol). WAN Port Start Enter the beginning port range for external network access.
  • Page 15 DHCP Server Lease Status Lease Reservation DHCP Server Tab The DHCP Server tab enables Dynamic Host Configuration Protocol (DHCP) server functionality on the LAN, allowing the router to dynamically assign lease IP addresses to clients that connect to it from the local network. Field or Button Description Enable DHCP Server...
  • Page 16 be 192.168.15.2 (or higher). DHCP Ending IP Sets the final IP address assigned by the DHCP Address server. If the DHCP server runs out of DHCP addresses, users cannot access network resources. If this happens, increase the Ending IP or reduce the Lease Time.
  • Page 17 Field or Button Description Client Host Name Displays the client host name. The Name field is limited to 20 characters (only 5 appear in display). MAC Address Media Access Control (MAC) address. IP Address Shows the IP Address for each active lease. Shows the amount of time, in seconds, remaining Remaining Lease Duration in the lease.
  • Page 18 Check the Clear Modem connection status from the Web Interface; refer to the Connection Status section to verify the connection status. If the Clear Modem connection is down, and the gateway has not received an IP for 5 to 10 minutes: - Reset the Clear Modem using the reset button.
  • Page 19 How do I receive the strongest signal possible? Use the signal strength LEDs on the modem to find the room or location with the strongest signal. Additional Troubleshooting Help Contact your service provider for additional help via Clear Care at 888-888-3113. Page 19 of 21...
  • Page 20: Regulatory Notices

    Regulatory Notices Model No: WIXB-175 WiMAX CPE Operating Frequency Range: 2.5GHz~2.7GHz Bandwidth: 5MHz/10MHz ℃ ℃ Operation temperature: 0 ~40 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 21 transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. Page 21 of 21...
