Summary of Contents for Briteq BT-91L3 ZOOM

  • Page 2: Table Of Contents

    ABLE OF CONTENTS PART 1 PRODUCT SPECIFICATIONS..........1. 1.1--PRODUCT SPECIFICATIONS............1. 1.2--DIMENSIONS................2. 1.3--PRODUCT FEATURES..............2. 1.4--SAFETY WARNING..............3. PART 2 INSTALLATION..............4. 2.1--MOUNTING...................4. 2.2--SETTING UP.................5. 2.3--FUSE REPLACEMENT..............5. PART 3 DISPLAY PANEL OPERATION..........6. 3.1-- BASIC ..................6. 3.2-- MENU ..................7. 3.3--INTRO..................8. 3.4--INVERT..................8. 3.5--RANGE..................9. 3.6--SPECIAL..................9. 3.7--EDIT.....................9. 3.8--EXTRA..................11.

  • Page 3: Part 1 Product Specifications

    1 PRODUCT SPECIFICATIONS 1 PRODUCT SPECIFICATIONS 1.1 PRODUCT SPECIFICATIONS Electrical Voltage:AC100~240V 50/60Hz Rated Power:310W LED:91PC(23R+23G+23B+22W) Cooling:Forced air convection Function Color mixing / Custom programs / Strobe / White balance / RGB calibration / Dim 4 / Fan speed Operation Control mode:Master-Slave/Auto/Custom/ Sound LCD display DMX512 Chs:11CHS/ 15CHS Pan/Tilt...

  • Page 4: Dimensions

    DIMENSIONS PRODUCT FEATURES...

  • Page 5: Safety Warning

    SAFETY WARNING IMPORTANT ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA. This product must be installed by a qualified professional. Always operate the equipment as described in the user manual.

  • Page 6: Part 2 Installation

    2 INSTALLATION MOUNTING The LED fixture can be operated in any position at any angle. When mounted on a flat surface, the surface must be strong enough to support 10 times the weight of the fixture and stable so that the will be no damage caused to the fixture or surrounding people or objects because of movements of the fixture on the surface.

  • Page 7: Fuse Replacement

    The LED fixture can be used as a stand alone unit. The stand alone functions AUTO 1, AUTO 2 and CUSTOM can be activated without the need to connect to any controller or connecting to any other equipment. Simply, access the <operation> menu from the DISPLAY and select the target program to activate.

  • Page 8: Part 3 Display Panel Operation

    DISPLAY PANEL OPERATION BASIC MENU ENTER DOWN MENU Scroll through the main menu or exit from the current sub-menu ENTER Enter the currently selected menu or confirm the current function value DOWN Scroll 'DOWN' through the menu list or decrease the value of the current function Scroll 'UP' through the menu list or increase the value of the Current function...
  • Page 9 BlackDelay Special Reset System Normal Power High Color Rgbtow System (000~255) Step Edit (000~255) (000~255) Tilt Speed (000~255) (000~255) Green (000~255) Blue (000~255) White (000~255) (000~255) Dimmer (000~255) Strobe Zoom (000~255) Dimspeed (000~255) Time (000~255) Extra Password 0000 (000~255) Calib 3200K (000~255) GREEN...

  • Page 10: Intro

    (000~255) 8000K (000~255) GREEN (000~255) BLUE 8500K (000~255) (000~255) GREEN (000~255) BLUE 10000K (000~255) (000~255) GREEN (000~255) BLUE (000~255) RBG-W (000~255) GREEN (000~255) BLUE Default Default INTRO MENU (001~512) Intro Address Reset Fans High Normal Auto DMX512 Auto1 Auto2 Custom Slave Test Channels...

  • Page 11: Invert

    Enter Channels to select the DMX channel modes: Basic Advanced Enter to select the lighting time of the LCD display panel. Display Enter the Keylock mode to select whether the access password is on or off. Enter Dimmer to select dimmer mode and dimmer speed. When DIMMER is set to Off , then RGBW and MASTER DIMMER are linear.

  • Page 12: Range

    RANGE (000~255) Range P/start (000~255) P/Finish (000~255) T/start (000~255) T/Finish P/start Set pan start value 000~255 P/Finish Set pan finish value 000~255 T/start Set Tilt start value 000~255 T/Finish Set Tilt finish value 000~255 Enter and select to open the operation of X/Y angle SPECIAL BlackDelay Special...

  • Page 13: Extra

    Time (000~255) Edit Enter the Edit mode to edit the custom programs by adjusting the value of Step , Pan , Tilt , Speed , Color , Gobo , Gobo.rot , Prism , Dimmer , Strobe , Time Enter and select to run the steps user need.

  • Page 14: Default

    5900K (000~255) 8.6 RED (000~255) 8.6 GREEN (000~255) 8.6 BLUE (000~255) 6500K (000~255) GREEN (000~255) BLUE 7200K (000~255) (000~255) GREEN (000~255) BLUE 8000K (000~255) (000~255) GREEN (000~255) BLUE (000~255) 8500K (000~255) GREEN (000~255) BLUE 10000K (000~255) (000~255) GREEN (000~255) BLUE (000~255) RBG-W (000~255)

  • Page 15: Part 4 Using Dmx512 Controller

    4 USING A DMX512 CONTROLLER 4.1 CHANNEL ASSIGNMENT Note: This product have two DMX512 channel configuration: and BASIC . ADVANCED CHANNEL VALUE FUNCTION 000~255 Clockwise rotate 0~ PAN FINE 000~255 Fine control of pan movement 0~3 TILT 000~255 Anti-clockwise rotate 0~270 TILT FINE 000~255 Fine control of tilt movement 0~3...
  • Page 16 CHANNEL VALUE FUNCTION DIMMER 000~255 STROBE NO function 000~009 010~255 ZOOM 000~255 DIMMER SPEED 000~009 PRESET DIMMER SPEED FROM DISPLAY MENU 010~029 LINEAR DIMMER 030~069 NON LINEAR DIMMER 1 fastest 070~129 NON LINEAR DIMMER 2 130~189 NON LINEAR DIMMER 3 190~255 NON LINEAR DIMMER 4 slowest CONTROL...
  • Page 17 CHANNEL VALUE FUNCTION 000~255 Clockwise rotate 0~ TILT Anti-clockwise rotate 0~270 000~255 000~255 GREEN 000~255 BLUE 000~255 WHITE 000~255 COLOR/WHITE MACRO NO FUCNTION 000~005 006~010 011~030 031~050 051~070 071~090 091~110 111~130 131~150 151~170 171~200 201~205 206~210 211~215 216~220 221~225 226~230 231~235 236~240 241~245...
  • Page 18 FUNCTION CHANNEL VALUE DIMMER 000~255 STROBE 000~009 010~255 ZOOM 000~255 CONTROL 000~019 020~039 040~059 060~079 080~099 100~119 120~139 140~149 150~159 160~169 170~179 180~199 200~219 220~255...

  • Page 19: Part 5 Appendix

    5 APPENDIX MAINTENANCE ITEM ITEM ITEM Anti-dust plate Arm cover Base cover Anti-vibrate seal Arm board Display support Display PCB Zoom lens Y-large gear Capture lens plate Tilt belt Capture lens Y-small gear Power supply LED PCB Optical wheel Quick-lock female Head structure Y-motor support Hanging bracket...
