Summary of Contents for Briteq BTX-SUPREME HYBRID
-
Page 3: Before Use
FEATURES • BTX-SUPREME HYBRID is an extremely bright hybrid moving head for big clubs, concert stages and rental! • The OSRAM SIRIUS HRI 471W SN lamp (CCT: 7500K), combined with Hi-Q optics, make it incredibly bright: •... -
Page 4: Safety Instructions
• Due to safety reasons, it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy. BRITEQ 2/24 BTX-SUPREME HYBRID ®... -
Page 5: Overhead Rigging
15m from the object to be illuminated. Also make sure that the light beam never hits other projectors in the direct surroundings (for example on the same truss), this can cause damage to the housing of the illuminated projectors. BRITEQ 3/24 BTX-SUPREME HYBRID ®... -
Page 6: How To Set Up The Unit
11. FILTER GRIDS: On both sides of the base are metal grids with magnetic closure. These can be opened without tools to clean or replace the dust filter. To be cleaned at regular intervals. 12. LAMP COMPARTMENT: can be opened to change the lamp. See next chapter for more information. BRITEQ 4/24 BTX-SUPREME HYBRID ®... -
Page 7: Lamp Replacement
• Connect the cables to the terminal of the new lamp. Important: ONLY use an original OSRAM “Sirius HRI 471W SN” (order code: 4052899581005), other lamps could result in less performance or even damage the unit. BRITEQ 5/24 BTX-SUPREME HYBRID ®... -
Page 8: General Menu Operation
• Turn and press the jog wheel to select the desired menu item. • Turn the jog wheel to change the parameters or press the touch buttons on the screen to enter the address. • Press the jog wheel to confirm. BRITEQ 6/24 BTX-SUPREME HYBRID ®... - Page 9 ENGLISH USER MANUAL Note: options written in red color are the default values. BRITEQ 7/24 BTX-SUPREME HYBRID ®...
- Page 10 Tx: Receivers Link/UNLink Used to Link / UNLink the connected W-DMX receivers • Turn and press the jog wheel to select the desired menu item. • Turn the jog wheel to select the desired option: BRITEQ 8/24 BTX-SUPREME HYBRID ®...
- Page 11 This function corrects the PAN/TILT positions automatically if someone bumps into the machine. • Turn and press the jog wheel to select the desired menu item. • Turn the jog wheel to select the desired option: ON/OFF • Press the jog wheel to confirm. BRITEQ 9/24 BTX-SUPREME HYBRID ®...
- Page 12 • Off: the setup menu is immediately available when you press the MENU/ESC. button • On: to access the setup menu you have to press the MENU/ESC. button until the countdown bar is full. • Press the jog wheel to confirm. BRITEQ 10/24 BTX-SUPREME HYBRID ®...
- Page 13 The USB-connector is used to update the firmware of the projector. • Format a USB memory stick in FAT32 • Create a subdirectory named SUPREME in the root • Put 1 or more update files (.CKF format) in the SUPREME folder BRITEQ 11/24 BTX-SUPREME HYBRID ®...
- Page 14 Attention: to prevent unwanted altering of the calibrations, this menu is password protected. Without setting the right password (PW= 050) access to all settings is denied. ➔ Don’t forget to set the password back to 000 when the calibrations are done! BRITEQ 12/24 BTX-SUPREME HYBRID ®...
-
Page 15: Electrical Installation
However the number of units in one chain should be limited to ±10 units to avoid unwanted signal delays. In bigger installations you should use the “STAR-topology” using Ethernet switches (or a combination of both). BRITEQ 13/24 BTX-SUPREME HYBRID ®... - Page 16 DMX signal to the first device. This device is the first in a wired DMX chain and acts as a wireless DMX receiver to transfer the entire DMX universe to the other DMX units. BRITEQ 14/24 BTX-SUPREME HYBRID ®...
-
Page 17: Dmx Charts
169 - 172 Congo Blue 173 - 176 White 177 - 215 Color Wheel rot. FAST → SLOW, CW 216 - 216 Color Wheel rot. Stop 217 - 255 Color Wheel rot. SLOW → FAST, CCW BRITEQ 15/24 BTX-SUPREME HYBRID ®... - Page 18 045 - 052 Gobo 1 shake (slow-fast) - Index 053 - 060 Gobo 2 shake (slow-fast) - Index 061 - 068 Gobo 3 shake (slow-fast) - Index 069 - 076 Gobo 4 shake (slow-fast) - Index BRITEQ 16/24 BTX-SUPREME HYBRID ®...
- Page 19 132 - 162 Prism E: indexed 6-facet linear prism 163 - 193 Prism F: indexed 8-facet circular prism 194 - 224 Prism G: indexed 16-facet circular prism 225 - 255 Prism H: indexed 32-facet circular prism BRITEQ 17/24 BTX-SUPREME HYBRID ®...
- Page 20 196 - 200 Reset All Functions Hold 3s 201 - 255 No function Note (*): by default function delay (is set to 3seconds: the selected function will only be active while the corresponding DMX-value is received during at least 3seconds. BRITEQ 18/24 BTX-SUPREME HYBRID ®...
-
Page 21: Replacing Rotating Gobos
• On the gearwheel you will notice a small hole (B2): this small hole indicates the orientation of the top of the gobo. • Rotate the gobo in the holder so that the top of the gobo points to this little hole (B2). BRITEQ 19/24 BTX-SUPREME HYBRID ®... -
Page 22: Maintenance
• Always dry the parts carefully. • Clean the external optics at least once every 30 days. • Clean the internal optics at least every 90 days. Attention: We strongly recommend internal cleaning to be carried out by qualified personnel! BRITEQ 20/24 BTX-SUPREME HYBRID ®... -
Page 23: Specifications
FAN noise: 45dB @ 1m Size: see drawing Weight: 26,5 kg Every information is subject to change without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com DIMENSIONS BRITEQ 21/24 BTX-SUPREME HYBRID ®... - Page 24 • Non-replaceable gobos ROTATING GOBO WHEEL (GOBO 2) • GOBO EXTERNAL DIAMETER: 17mm (IMAGE DIAMETER: 12 mm – THICKNESS: 1,1mm) • Only high temperature resistant glass gobos can be used! (with black and glossy / mirror sides) BRITEQ 22/24 BTX-SUPREME HYBRID ®...
-
Page 25: Animation Wheel
C. Rotating 4-facet linear prism D. Rotating 4-facet circular prism Prism wheel 2: E. Rotating 6-facet linear prism F. Rotating 8-facet circular prism G. Rotating 16-facet circular prism H. Rotating 32-facet circular prism ANIMATION WHEEL Bidirectional animation wheel BRITEQ 23/24 BTX-SUPREME HYBRID ®... -
Page 26: Spot Mode
ENGLISH USER MANUAL LUX CHARTS SPOT MODE BEAM MODE BRITEQ 24/24 BTX-SUPREME HYBRID ®...
