Technoline WS 9119 Instruction Manual

Instruction Manual Model WS 9119
Digital Thermo-Hygrometer with Comfort Index
Buttons
F
C
MIN
MAX
RESET (back)

Installation

1. Slide open the battery cover at the back of your unit.
2. Insert 2 x AAA batteries into the battery compartment by observing the
correct + / - polarity signs inside the battery compartment.
3. Replace the battery cover. After few seconds the unit is ready to work for you.

To Select degree C or degree F Temperature Readout

Press C or F button to view the temperature in degree C or degree F.

To Read the Maximum-Minimum Temperature Records

Press MAX or MIN once to view the maximum or minimum temperature and humidity.
When the maximum temperature and humidity are displayed, press and hold the MAX
will clear the maximums and the unit will start to record and display fresh data again.
When the minimum temperature and humidity are displayed, press and hold the MIN will
clear the minimums and the unit will start to record and display fresh data again.

To View the Temperature, Humidity and Comfort Index

This thermo-hygrometer is equipped with an easy-to-read index of temperature, humidity
and the comfort level (which is a combination of temperature and
good and quick indication of how you feel like in the ambient environment.
1. Temperature
5 points 31°C – 45°C
4 points 27°C - 30.9°C
3 points 19°C - 26.9°C
2 points 13°C - 18.9°C
1 point 0°C - 12.9°C
humidity
). It gives a
