433 MHZ REMOTE THERMO
INTRODUCTION:
Congratulations on purchasing this innovative 433MHz Remote Thermo which displays indoor
and up to three outdoor temperature readings. To enjoy the full benefits of this innovative product,
please read this operating manual.
REMOTE THERMO:
Hanging hole
CH key
MIN/MAX key
Detachable stand
20
Advertisement
Related Manuals for Technoline 433MHz Remote Thermo
Summary of Contents for Technoline 433MHz Remote Thermo
- Page 1 433 MHZ REMOTE THERMO INTRODUCTION: Congratulations on purchasing this innovative 433MHz Remote Thermo which displays indoor and up to three outdoor temperature readings. To enjoy the full benefits of this innovative product, please read this operating manual. REMOTE THERMO: Hanging hole...
- Page 2 TEMPERATURE TRANSMITTER: Holder FEATURES: • Temperature display in degrees Celsius • Indoor temperature display • Outdoor temperature display • MIN/MAX indoor and outdoor temperature display • Can receive up to three outdoor transmitters • Table standing or wall mountable (detachable table stand) SETTING UP: Please follow these steps to ensure that your new Remote Thermo works correctly with the temperature transmitter(s):...
- Page 3 Battery cover Battery compartment Battery cover Battery compartment Flip open the battery cover at the back of the Remote Thermo as indicated above. Checking the correct polarization, insert 2 x AAA, IEC LR3, 1.5V batteries into the battery compartment and replace the cover (all the segments of the LCD screen will light up momentarily).
- Page 4 Checking the correct polarization, insert 2 x AAA, IEC LR3, 1.5V batteries into the battery compartment and replace the cover. If you have purchased additional outdoor transmitter(s) wait until the outdoor temperature has been received from the one transmitter before activating the next transmitter by repeating steps 3 and 4.
-
Page 5: Lcd Screen
In the event of changing batteries in any of the units, all units need to be reset by following the In the event of changing batteries in any of the units, all units need to be reset by following the setting up procedures. - Page 6 USING THE REMOTE THERMO: INDOOR TEMPERATURE: The indoor temperature is displayed on the first line of the LCD. The Remote Thermo’s built in sensor automatically measures the temperature once the batteries are inserted. OUTDOOR TEMPERATURE READING: The outdoor temperature is displayed on the bottom line of the LCD. The Remote Thermo receives the outdoor temperature via 433MHz frequency when the batteries are inserted into the transmitter within the 2-1/2 minutes of the setting up time (See Setting up above).
- Page 7 MIN indoor temperature MAX indoor temperature MIN outdoor temperature MAX outdoor temperature To return to current indoor and outdoor temperature display Remarque: Once a new indoor temperature high or low is reached, it will automatically set into the Remote Thermo’s memory. MAX indoor MIN indoor temperature...
- Page 8 RESETTING THE MINIMUM AND MAXIMUM TEMPERATURE RECORDING: TO RESET THE MIN OR/AND MAX INDOOR TEMPERATURE RECORDS: Press the “MIN/MAX” key to select the indoor MIN or MAX records. Press and hold the “CH” key for 3 seconds. Both the MIN and MAX records will be reset to current indoor temperature.
- Page 9 OUTDOOR TEMPERATURE 1, 2, AND 3 If the more than one transmitter is being used, to alternate between the temperature readings of transmitter 1, 2, and 3, simply press the “CH” key. If the reading is from transmitter 1, then the identification numbers 1 will be displayed in the outdoor temperature section of the LCD.
- Page 10 Neighbours using electrical products operating on the 433MHz signal can also cause interference. In most severe cases, the reception is only possible once all other electrical products using the 433MHz are switched off. Within thick concrete rooms such as basements and tower blocks, the 433MHz signal can be weakened (avoid placing near metal frames and structures).
- Page 11 Note: Remember when resetting, all units have to be reset and to always insert the batteries into the Remote Thermo first and then followed by the transmitter(s). POSITIONING REMOTE THERMO: The Remote Thermo comes complete with a detachable stand that gives the option of table standing or wall mounting.
- Page 12 OUTDOOR TRANSMITTER: The Outdoor Transmitter is supplied with a holder that may be attached to a wall with the three screws or double-sided tape supplied. To attach to the wall using screws, please follow the steps below: Mark the wall using a pen through the holes in the holder to obtain the exact drilling position.
-
Page 13: Care And Maintenance
in any position where a large metal or highly polished surface is in the immediate proximity (garage doors, double-glazing, etc.). Before securing in place, please ensure that the Remote Thermo can receive the 433 MHz signal from the Outdoor Transmitter at the positions that you wish to situate them. BATTERIES REPLACEMENT &... -
Page 14: Specifications
• When cleaning the LCD and casing, use a soft damp cloth only. Do not use solvents or scouring agents. • Do not submerge the units into water. • Immediately remove all low powered batteries to avoid leakage and damage. Replace only with new batteries of the recommended size. - Page 15 • Temperature checking intervals Indoor temperature every 10 seconds • Transmitter every 1 minutes • Transmitting frequency 433.92 MHz • Temperature transmitting range up to 25 meters (Open space and free from interference) • Power source: Remote Thermo 2 x AAA, IEC LR3, 1.5V batteries Transmitter 2 x AAA, IEC LR3, 1.5V batteries •...
-
Page 16: Liability Disclaimer
LIABILITY DISCLAIMER: • The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences that occur should an inaccurate reading take place. • This product is designed for use in the home only as indication of the temperature. •...
