Page 1 DCS 300 Series Digital Cameras User’s Guide for DCS 300 Series Digital Cameras...
Page 3: Table Of Contents
Table of Contents About Your Camera ...1-1 Package Contents ... 1-2 Camera Accessories ... 1-2 Features ... 1-3 Camera Nomenclature ... 1-5 Camera Front ... 1-5 Camera Back ... 1-5 Camera Top ... 1-6 Camera Bottom ... 1-6 Camera Sides ... 1-7 LCD Panels and LEDs ...
Page 4 Inserting Batteries ... 2-4 Removing Batteries ... 2-5 Checking Battery Status ... 2-6 Battery Tips ... 2-7 Kodak-specified AC adapter... 2-8 Connecting the Kodak-specified AC adapter ... 2-9 PowerSave Mode ... 2-10 Waking your Camera from PowerSave Mode ... 2-10...
Page 5 Configuring Your Camera ...3-1 Setting the Date and Time... 3-1 Camera Properties ... 3-3 Setting Camera Properties ... 3-3 Using a PC Card ...4-1 PC Cards ... 4-1 Inserting a PC Card ... 4-2 Removing a PC Card ... 4-3 Formatting a PC Card ...
Page 6 Aperture-Priority Auto Exposure Mode (A) ... 6-13 Manual Exposure Mode (M) ... 6-14 Operating in Auto-Multi Program ... 6-15 Operating in Flexible Program ... 6-17 Operating in Shutter-Priority Auto Exposure Mode... 6-18 Operating in Aperture-Priority Auto Exposure Mode ... 6-21 Operating in Manual Exposure Mode...
Page 7 Self-Timer Operation ... 7-1 Exposure Compensation ... 7-3 Using the Auto Exposure Lock Function ... 7-4 Obtaining a Meter Reading in Manual Exposure Mode ... 7-6 Exposure Compensation Operation ... 7-7 Auto Exposure Bracketing ... 7-9 Using the Quick Recall (QR) Function... 7-12 Saving Customized Settings for Quick Recall ...
Page 8 Slow Sync ... 8-5 Rear-Curtain Sync ... 8-5 Selecting Flash Sync Mode ... 8-6 Tips ... 8-8 Using the Built-in Flash ... 8-9 Built-in Flash Specifications ... 8-9 Tips ... 8-9 Usable Lenses with Built-In Flash ... 8-10 Flash Shooting Distance Range ... 8-11 Shutter Speed/Aperture in Flash Shooting ...
Page 9 Associating Sound Files With Images ... 9-10 Deleting Images ... 9-12 Deleting One Image ... 9-12 Deleting More Than One Image ... 9-13 Connecting your Camera to a Computer ...10-1 Advantages to Using an IEEE 1394 Connection ... 10-1 Advantages to Using a Card Reader ... 10-1 To Connect Your Camera to a Computer ...
Page 10 WARRANTY ... 12-1 KODAK PROFESSIONAL DCS 300 Series Digital Camera ... 12-1 Warranty Time Period ... 12-1 Warranty Repair Coverage ... 12-1 Limitations ... 12-2 Outside the United States... 12-3 How to Obtain Service... 12-3 Product Support Options... 12-4 Software License Agreement... 12-6 LICENSE ...
Page 11 Appendix E - Focal Length Conversion ... E-1 Appendix F - Problem Report ... F-1...
Page 13: About Your Camera
(import) them through a program such as Photoshop, using the Kodak Software (also on the DCS Host Software CD). If you try to open these files in Photoshop or other applications without first acquiring them, only the thumbnail version will be available.
Page 14: Package Contents
DCS 300 Series Quick Start card • Adobe Acrobat Reader to view or print the manuals • ReadMe files DCS Host Software CD containing the following items related to the Kodak Software: • Photoshop Acquire Module for Macintosh • TWAIN Data Source for Windows •...
Page 15: Features
Features Your camera, which integrates Nikon SLR functionality with Kodak digital camera technology, provides a rich set of features that allows you to capture images of the highest quality. The following features are available in both the DCS 315 and 330 cameras: Accessories/Computer Interface: DCS 315: accepts removable Nikon IX-Nikkor AF and F-mount lenses.
Page 16 The table below lists the features that differ for the DCS 315 and DCS 330 cameras: Feature Image Size 1.5 million pixels (1008 x 1520) 2:3 aspect ratio Approximate Finished TIFF - 1.7 MB File Size JPEG Best - 650 KB JPEG Better - 350 KB JPEG Good - 200 KB 100 - 400...
Page 17: Camera Nomenclature
Camera Nomenclature Camera Front Main-Command dial Sub-Command dial Antialiasing filter Camera Back Camera Status LCD Panel Illuminator button Vari-Program (Ps) button Exposure Mode (MDE) button Function (FNC) button Function Set (SET) button PC Card Busy/Record Serial Port jack (DCS 330 only) Self-timer LED Lens Release...
Page 18: Camera Top
Camera Top Flash Lock-release button Self-timer button Neck Strap eyelet BASIC/ADVANCED switch Accessory shoe Camera Bottom Product label Serial number Shutter Release button QR-OUT button Remote Shutter Release terminal Neck/Hand Strap eyelet Main-command dial Power switch Tripod mount rubber pad Tripod mount...
Page 19: Camera Sides
Camera Sides Hand/neck strap eyelet IEEE 1394 Host Interface Connection AC Adapter Connection Hand Strap eyelet Flash Sync Terminal (DCS 330 only) * * The yellow triangle with a black “!” near the flash sync terminal is intended to warn you of the following: WARNING: The Flash Sync terminal is for a flash sync cable system ONLY! DO NOT CONNECT AC MAIN POWER TO THIS CONNECTOR! Doing so can create a hazardous...
Page 20: Lcd Panels And Leds
LCD Panels and LEDs Image LCD Panel Use the Image LCD panel for the following: View status information (page 9-8). PC Card Inserted Images Available Folder Name (#images in folder) Image thumbnail Relative location of current image in folder Review images in Single, Four, or Nine Image Review mode (page 9-1). Select folders to hold images (page 4-6).
Page 21: Camera Status Lcd Panel
Menu Bar You can choose Status information, Single, Four, or Nine Image Review mode, Folders, Main Menu, or Display Contrast by pressing and holding the MENU button and using the Main-Command dial to make your selection from the Menu bar (at the top of the Image LCD panel).
Page 22 Vari-Program Exposure mode Shutter speed AF-S AF-C Aperture Function area indicators Focus area/AF mode AF-S AF-C Drive mode Flash sync mode Compensation value/QR AF-S number, ISO AF-C Metering system Exposure Compensation 1-10 SLOW REAR PRINT TYPE SLOW REAR PRINT TYPE SLOW REAR PRINT...
Page 23: Effects Of Temperature On Lcd Panels
Illuminating the Camera Status LCD Panel RESET BUSY Effects of Temperature on LCD Panels At high temperatures (60° C/140° F or higher), the LCD panels turn black, making it difficult to read displayed information. When the temperature drops, the display can be read normally again.
Page 24: Pc Card Busy/Record Led
PC Card Busy/Record LED Although steps have been taken to safeguard your images, it is possible to corrupt the PC Card or lose images if the PC Card is removed during disk writes. Check that the PC Card Busy light is not blinking before removing a PC Card. 1-12 The PC Card Busy/Record LED appears in different colors...
Page 25: Viewfinder
Viewfinder The DCS 300 series camera is an integration of Eastman Kodak Company electronics and a Nikon Pronea 6i camera body. The camera body was originally designed for use with Advanced Photo System film. Because the electronic imager in your DCS 300 series camera is smaller than a negative of a film frame, the field of view of the camera’s...
Page 26: Dials And Buttons
Dials and Buttons Main-Command Dial You use the Main-Command dial with the digital function buttons (page 1-15) or the non- digital function buttons (page 1-17) to access a variety of digital and SLR camera functions. Sub-Command Dial You use the Sub-Command dial when setting the aperture. 1-14...
Page 27: Digital Function Buttons
Digital Function Buttons There are three buttons associated with your camera’s digital functions (outlined on the next page and described throughout the manual). You can access the digital functions when you use the buttons in conjunction with the Main-Command dial and the Image LCD panel.
Page 28 You can tag images that you do not want deleted. Refer to “Tagging an Image” on page 9-9. You can also tag images that you want to group for operations available in the Kodak Software. Refer to the KODAK PROFESSIONAL DCS Host Software User’s manual on the included DCS Host Software CD.
Page 29: Non-Digital Function Buttons
Non-Digital Function Buttons The table below describes the non-digital buttons: Button Function Vari-Program Exposure mode Select function Set selected function Metering Metering system Exposure Compensation Exposure Compensation Ps and Reset Two-Button Reset Self-timer Self-timer operation QR-OUT QR Recall Vari-Program (PS) button Exposure Mode (MDE) button Function (FNC) button Function Set (SET) button...
Page 30: Shutter Release Button
Shutter Release Button The Imager The imager is the component that records light when you capture an image. It is located behind the lens mount, and under the mirror and shutter. The specifications for the imager are noted below: Horizontal Camera Pixels DCS 315...
Page 31: Lenses
Lenses The following list provides an overview of Nikkor CPU lenses that can be used with your camera. (Refer to Appendix C for a complete list of compatible and incompatible lenses.) D-type AF Nikkor lenses (including AF-I and AF-S Nikkor lenses) Non-D-type AF Nikkor lenses (except AF Nikkor for F3AF) AI-P Nikkor lenses (manual focus only) IX-Nikkor lenses...
Page 32 1-20 Position the lens in the camera’s bayonet mount so that the mounting indexes on the lens and camera body are aligned. Taking care not to press the lens release button, twist the lens counterclockwise until it locks in place. CAUTION: Do NOT use the IX-Nikkor lens with the DCS 330 camera unless...
Page 33: Setting The Lens To The Minimum Aperture
Setting the Lens to the Minimum Aperture For all Exposure modes with lenses other than the IX-Nikkor, set the lens to its minimum aperture. (The minimum aperture will vary, depending on the lens.) Set the lens to its minimum aperture. Slide the lock lever in the direction of the aperture ring so that the white dot on the tab...
Page 34: Removing The Lens
Removing the Lens Non-CPU Lenses and Lens Adapters You should be aware of the following when using non-CPU lenses: If you are using a microscope adapter, you will need to set the camera to Manual Exposure mode (M). In Manual Exposure mode (M), the camera’s exposure meter does not function. For exposure metering, use the camera’s Histogram feature (page 9-5) or use an external exposure meter.
Page 35: Antialiasing Filter
Antialiasing Filter DCS 315: This camera does not have an antialiasing filter. DCS 330: This camera has an antialiasing filter which helps to reduce aliasing at certain focal distances. If you remove the antialiasing filter from your DCS 330 camera, you will need to use a hot mirror (page 1-24).
Page 36: Hot Mirrors (Ir Filters)
Hot Mirrors (IR Filters) DCS 315: We recommend that you use a hot mirror (an IR filter which filters out IR light that the imager is sensitive to). A hot mirror is included in your camera package. DCS 330: This camera has a coated antialiasing filter that makes it unnecessary to use a hot mirror.
Page 37: Flash Sync Terminal
Flash Sync Terminal The flash sync terminal, only available with the DCS 330 camera, will trigger a flash that uses a standard X-Sync cord. Refer to “Flash Sync Terminal” on page 8-26. The Sync flash cord/connector set is not supplied with the camera. Serial Port Jack The Serial Port jack, only available with the DCS 330 camera, is reserved for future applications.
Page 38: Attaching The Hand Strap
Attaching the Hand Strap A hand strap is included with your camera. 1-26 Thread the strap through the hand strap pad. Place the strap through the camera’s top and bottom strap fixtures. Thread both ends of the strap back through the loops on the hand strap pad.
Page 39: Important Safeguards And Precautions
Important Safeguards and Precautions The exclamation point in an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying your camera. Read Instructions—Read all the safety and operating instructions before operating your camera.
Page 40 Attachments—Do not use attachments that are not recommended. The use of such attachments may cause hazards and cause serious damage to your camera. Power Sources—You should operate your camera only from the type of power source indicated on the name plate of the AC adapter. If you are not sure of the type of AC power that will be used, consult a dealer or local power company.
Page 41 Servicing—Do not attempt to service your camera yourself. Opening or removing covers may expose you to dangerous voltage or other hazards and void the warranty. Damage Requiring Service—Unplug your camera from the wall outlet and computer, and refer all servicing to the manufacturer under the following conditions: •...
Page 42: Electromagnetic Emissions
Electromagnetic Emissions This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 43: Vcci Statement
VCCI Statement 1-31...
Page 45: Powering Your Camera
Powering Your Camera Before using your camera, you must insert batteries or connect the camera to the Kodak- specified AC adapter. Two battery trays and a Kodak-specified AC adapter are included with your camera. When shooting outdoor scenes or in any location where AC power isn’t convenient, you will power the camera with batteries.
Page 46: Turning The Camera On And Off
Turning the Camera On and Off Slide the Power switch to On to turn the camera On. Slide the Power switch to Off to turn the camera Off. There may be a short delay before the camera turns Off if there are camera activities such as PC Card updates that need to be completed.
Page 47: Batteries
The number of shots per battery set depends on both the battery chemistry and usage. Kodak does not recommend the use of standard alkaline batteries for this camera. It is expected that you will experience 200 image captures or more, under normal usage, when using high quality/high capacity batteries, for example, NiCAD (nickel-cadmium), NiMH (nickel metal hydride), or High Energy Lithiums.
Page 48: Inserting Batteries
WARNING: Batteries may explode or cause burns if disassembled, shorted, exposed to high temperatures, or incinerated. Be sure to observe all precautions indicated on the battery package. Always keep batteries out of the reach of children and dispose of batteries in accordance with all applicable local and national regulations. Utilize established community battery recycling programs where they are available.
Page 49: Removing Batteries
Removing Batteries Press the Battery Tray Release button down. Pull the tab on the battery tray to remove...
Page 50: Checking Battery Status
(shown at the left). If the batteries are low, replace them or connect your camera to the Kodak-specified AC adapter. You cannot capture images when the Battery insufficient or Battery empty icon is...
Page 51: Battery Tips
You can also check battery power by lightly pressing the Shutter Release button. If the batteries are functioning properly, pressing this button activates the exposure meter, the Camera Status LCD panel, and the viewfinder indications. Autofocusing also begins unless the camera is set for manual focus. Without the flash, if you remove your finger from the Shutter Release button, the LCD readouts go off approximately 2 seconds after the shutter is released.
Page 52: Kodak-Specified Ac Adapter
Kodak-specified AC adapter to conserve your batteries. A Kodak-specified AC adapter is packaged with your camera. You can use the Kodak-specified AC adapter with or without batteries inserted. When using the AC adapter with batteries inserted, power will be supplied by the AC adapter.
Page 53: Connecting The Kodak-Specified Ac Adapter
Connecting the Kodak-specified AC adapter If your camera loses power while the Power switch is in the On position, turn the camera Off and insert new batteries or attach the Kodak-specified AC adapter. Turn the Camera Off. Plug the Kodak-specified AC adapter into the camera.
Page 54: Powersave Mode
This occurs only if the camera is powered by batteries. Your camera will not enter Phase 3 PowerSave mode when it is connected to the Kodak- specified AC adapter or connected to the computer with an IEEE 1394 cable (even if the camera is being powered by batteries).
Page 55: Configuring Your Camera
If you remove the batteries from the camera, a small, rechargeable backup battery will maintain date and time for up to five days. (It is recharged when the camera is powered by batteries or a Kodak-specified AC adapter.) Press the MENU button to turn the Image LCD panel On.
Page 56 The Main Menu appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight the Date / Time choice. Release the SELECT button. Press and hold the SELECT button and rotate the Main- Command dial to change the highlighted field.
Page 57: Camera Properties
Camera Properties You can check the camera’s total actuations since manufacture, and set the following camera properties: Histogram Scale Marks, Antialiasing Filter, Use Empty Folder, Use FOLDER01, Display Off Time, Display Off Using Adapter, PowerSave Time, and Noise Reduction. The list of properties may change as new versions of firmware become available. The wording on the screens may not be exactly as shown here.
Page 58 Determining Total Actuations This property displays the number of images captured by your camera since manufacture. Release the SELECT button. The Properties menu appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight your choice. Release the SELECT button.
Page 59 Specifying Whether the Antialiasing Filter is Installed or Removed With the DCS 330 camera, you must set a camera property which will tell the Kodak Software whether the antialiasing filter was installed or removed when an image was captured. This information can determine whether the Kodak Software applies the Sharpening feature, and the information is also used if the camera performs background image processing to create a JPEG file.
Page 60 Setting the Histogram Scale Marks The Histogram shows the range and distribution of tonal values for an image, and can be used to assess an image’s brightness and contrast levels. Refer to “Viewing Overexposure Areas and Histogram Information” on page 9-5. You can specify that scale marks be displayed on the histogram in the Histogram/Info screen.
Page 61 Save Images in an Empty Folder You can specify that an empty folder is selected when you turn your camera On. Images that you capture will then be stored in an empty folder. If there is more than one empty folder, images will be stored in the first empty folder found on the PC Card.
Page 62 Save Images in Folder 1 You can specify that FOLDER01 is selected when you insert a new PC Card. Setting the Display Off Time You can change the Display Off Time (the length of time before the Image LCD panel turns Off).
Page 63 The Display Off Time screen and the PowerSave screen operate a little differently than the others. Note that you use the horizontal arrows to select a number and the vertical arrows to change the value of a selected number. With the Properties menu displayed, select Display Off Time.
Page 64 3-10 To highlight a different number, press and hold the MENU button. A horizontal arrow appears. Continue to hold the MENU button and rotate the Main- Command dial to highlight a different number (tens, hundreds, etc.). Release the MENU button. The horizontal arrow goes away.
Page 65 Specifying Display Off When Using Adapter By default, the Image LCD panel turns Off even when the camera is powered by an AC adapter. Setting The PowerSave Time You can change the PowerSave time by choosing PowerSave Time from the Properties menu, then using the same procedure described for changing Display Off time to alter the PowerSave time.
Page 66 Specifying Noise Reduction You can specify whether noise reduction is applied to JPEG images when they are processed (page 4-11). 3-12 With the Properties menu displayed, select Noise Reduction. The Noise Reduction screen appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight Yes or No.
Page 67: Using A Pc Card
Using a PC Card As you capture images, they are stored on a PC Card (PCMCIA card) in your camera. Before capturing images, you will want to ensure that the images are stored as needed. This chapter describes the use of the PC Card and provides instructions for processing (compressing) and storing images.
Page 68: Inserting A Pc Card
Inserting a PC Card There are two slots for PC Cards on your camera, however only the rear slot is currently available for use. The front slot is reserved for future applications. Meanwhile, you can use the front slot to store an extra PC Card. It is not necessary to turn the camera Off before inserting a PC Card.
Page 69: Removing A Pc Card
Removing a PC Card It is not necessary to turn the camera Off before removing a PC Card. IMPORTANT: Do not remove a PC Card from the camera if the PC Card is busy (data is being read from or written to the PC Card). You may lose data if you remove a PC Card at this time.
Page 70: Formatting A Pc Card
There are three ways to format a PC Card: Using your camera—described below Using Kodak Software—refer to the Kodak Professional DCS Host Software User’s manual (on the DCS Host Software CD included with your camera). Using your PC (not recommended on Macintosh)—refer to your computer documentation All three methods produce a DOS FAT16 formatted card.
Page 71 RESET BUSY A confirmation screen appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight Yes or No. Release the SELECT button. If you respond Yes, a second confirmation screen appears. Repeat steps 6 and 7. If you respond Yes, a Formatting Card screen appears briefly.
Page 72: Managing Image Files
Managing Image Files To effectively manage image files on a PC Card, you will need to do the following: Select a folder to store images (see below) Specify the type of file (page 4-8) Set processing options (page 4-11) Selecting Folders Images are stored in folders on a PC Card.
Page 73 You cannot rename folders using your camera but you can rename them on your computer using the Kodak Software. (Refer to the KODAK PROFESSIONAL Host Software User’s Manual on the DCS Host Software CD included with your camera.) You...
Page 74: Selecting The File Type
(import) them through a program such as Photoshop, using the Kodak Software (on the DCS Host Software CD). If you try to open these files in Photoshop without first acquiring them, only the thumbnail version will be available.
Page 75 Press the Menu button to turn the Image LCD panel On. Press and hold the Menu button and rotate the Main-Command dial to highlight the Main menu icon. Release the Menu button. The Main menu appears. Press and hold the Select button and rotate the Main-Command dial to highlight File Type.
Page 76 The appearance of the File type of Current Image icon will vary, depending on the current file type setting. File type of Current Image TIFF Custom JPEG Large JPEG Medium JPEG Small 4-10 The currently selected file type is represented by the File Type icon on the Status screen.
Page 77: Setting Processing Options
PC Card or processing user input). You can also process images using the Kodak Software. Refer to the KODAK PROFESSIONAL DCS Host Software User’s Manual on the DCS Host Software CD included with your camera.r...
Page 78 4-12 Press the MENU button to turn the Image LCD panel On. Press and hold the MENU button and rotate the Main- Command dial to highlight the Main Menu icon. Release the MENU button. The Main Menu appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight Processing.
Page 79 On: SAVE original TIF: If processing was On and the original TIFF was being saved, the Main Menu appears. If processing was On and the original TIFF was being deleted, or if processing was Off, the screen at the left appears (showing Noise Reduction ON or OFF).
Page 80 The following circumstances cause processing to stop, requiring you to repeat the previous procedure if you want to start processing again: PC Card becomes full. PC Card is removed from the camera. PC Card is formatted The camera is turned Off. You can evaluate the current file type setting, the number of images that can still be saved at that setting, the background image processing status, and the file type of the current image by viewing the Status screen in the Image LCD panel.
Page 81 The following table illustrates the differences in the way images are handled in the camera (with background image processing turned On) and in the Kodak Software on the computer: In Camera JPEG Files 1 Image captured 2 Image saved as TIFF...
Page 83: Basic Operation
Chapter 5 Preparing to Capture an Image Before capturing images, make sure your camera is ready. Batteries are inserted (page 2-4) or the Kodak-specified AC adapter is connected (page 2-9) A formatted (page 4-4) PC Card is inserted (page 4-2)
Page 84 Host computer connection status (if applicable) The icon appears when the computer is connected and blinks when an application such as the Kodak Software is running. Battery level (fully charged) or AC adapter connected Select the folder to hold images that you capture.
Page 85: Capturing Images In Basic Mode
Capturing Images in BASIC Mode While BASIC mode is available on your camera, ADVANCED mode is recommended for the best results. Set the Focus Mode selector to Slide the BASIC/ADVANCED switch to BASIC.
Page 86 AF-S Function Exposure mode: Auto-Multi Program ( Metering system: DCS 315: Center-Weighted ( DCS 330: 3D Matrix ( Focus area: Wide ( AF mode: Single Servo AF ( Drive mode: Single-Frame ( Flash Sync mode: Normal Auto ( ) - ISO 200 Can be switched to Vari-Program.
Page 87 Look through the viewfinder and position the focus brackets on the main subject. In BASIC mode, Single Servo AF is automatically selected. After focusing is achieved and the in-focus indicator ( ) appears, focus remains locked as long as you lightly press the Shutter Release button.
Page 88 blinks—AF impossible alert: Autofocus is not possible and the shutter locks. Refer to “Special Focusing Situations” on page 7-18. remains on—Too-near- subject alert: If the subject is located closer than the lens’ closest focusing distance, the shutter locks. Move further from the subject and refocus.
Page 89 If one of the following error messages appears on the Image LCD panel, take the appropriate action before proceeding: Message “Unable to take pictures. No card present.” “Unable to take pictures. Card full.” “Unable to take pictures. Camera too hot.” “Unable to take pictures.
Page 91: General Functions
General Functions This chapter describes the various modes of camera operation. Advanced Mode and Basic Mode In BASIC mode, available functions and choices are limited. In ADVANCED mode, you can take advantage of the full range of Pronea 6i features. In general, you will get better results using ADVANCED mode.
Page 92 The following table lists the functions available in each mode. Functions/ In BASIC mode modes Vari-Program Exposure mode* Fixed at Auto-Multi (excluding Vari- Program Program) Metering system* DCS 315: Fixed at Center-Weighted DCS 330: Fixed at Matrix Focus area/AF Fixed at Wide with mode* Single Servo AF Drive mode*...
Page 93: Vari-Program
Vari-Program Programmed auto exposure control automatically adjusts both lens aperture and shutter speed for the correct exposure. Your camera’s Metering system determines the correct exposure, applying appropriate exposure compensations. However, factors such as different shutter speeds and apertures can affect the image. Auto-Multi Program is designed to coordinate the selection of shutter speed and aperture for average situations.
Page 94 Your camera’s Vari-Program control offers six programs. The following symbols appear in the Camera Status LCD panel: Portrait Program Hyperfocal Program Landscape Program Close-Up Program Sport Program Silhouette Program Portrait Program Used to capture images of people, this program creates an artistically out-of-focus background that accentuates your main subject.
Page 95 Hyperfocal Program Used when photographing landscapes and other subjects that encompass great depth. The effect becomes more pronounced if there is an interesting foreground in the scene. This program tends to select a slow shutter speed and smaller aperture to ensure that both subject and background are in focus.
Page 96 Sport Program Used to freeze the action. Recommended for use with Continuous Servo AF (page 6-38). Do not use a flash, as it restricts the available shutter speeds. Recommended AF Nikkor lenses: For a more pronounced out-of-focus background effect, use a telephoto lenses.
Page 97: Setting Vari-Program
Setting Vari-Program RESET BUSY When Vari-Program is set, camera settings are automatically reset as follows: Metering system Focus area Flexible Program Sync mode Exposure Compensation function * Settings can be changed as desired in ADVANCED mode. ** In ADVANCED mode, you can change Flash Sync mode to Red-Eye Reduction, Red-Eye Reduction with Slow Sync, or Slow Sync.
Page 98: Operating In Vari-Program
Operating in Vari-Program PRINT TYPE Press and hold the Ps button and rotate the Main-Command dial until the desired Vari-Program symbol appears. RESET BUSY In the example shown, Portrait Program in ADVANCED mode is selected. Look inside the viewfinder, compose the shot, lightly press the Shutter Release button, then confirm focus.
Page 99 AF-S PRINT TYPE AF-S PRINT TYPE AF-S PRINT TYPE If HI appears in the shutter speed position—Over- exposure alert: Use a Nikon ND or similar filter. If Lo appears in the shutter speed position—Under- exposure alert: Use the built-in flash/a Nikon Speedlight, a higher ISO setting, or a lens with a wider maximum aperture.
Page 100: Exposure Mode
Exposure Mode Light reaching the imager is controlled by shutter speed and lens aperture. The proper combination results in a correct exposure. Shutter speed and lens aperture settings are based on the ISO setting and the operation of the camera’s exposure control system. The relationship between aperture and shutter speed is as follows: one change in either the shutter speed or the aperture either doubles or halves the amount of light transmitted.
Page 101: Setting The Exposure Mode
Setting the Exposure Mode RESET BUSY AF-S PRINT TYPE Press and hold the MDE button, and rotate the Main-Command dial to set P for Auto-Multi Program, S for Shutter-Priority Auto. A for Aperture-Priority Auto, or M for Manual. Use the Ps button to activate Vari-Program.
Page 102: Auto-Multi Program (P)
Auto-Multi Program (P) Shutter-Priority Auto Exposure Mode (S) 6-12 Use Auto-Multi Program for most common picture-taking situations. With your camera choosing the combination of shutter speed and aperture automatically, you can concentrate on image composition, without worrying about exposure. In Programmed Auto Exposure mode, you can use the Flexible Program function to temporarily shift an automatically selected...
Page 103: Aperture-Priority Auto Exposure Mode (A)
Aperture-Priority Auto Exposure Mode (A) Using this mode you can control the depth of field by varying the aperture. Smaller apertures bring both the background and foreground into focus (recommended for landscape pictures). Larger apertures tend to send the background out of focus (recommended for portraits).
Page 104: Manual Exposure Mode (M)
Manual Exposure Mode (M) Using this mode you can adjust both aperture and shutter speed settings independently of each other. For a correct exposure, follow the recommendation of the camera’s light meter as indicated in the viewfinder LCD. To achieve a specific creative effect such as intentional blur, intentional under- or over-exposure, disregard the...
Page 105: Operating In Auto-Multi Program
Operating in Auto-Multi Program RESET BUSY PRINT TYPE Press and hold the MDE button and rotate the Main-Command dial until P appears in the Camera Status LCD panel and viewfinder. If the exposure meter and LCD indications automatically turn Off, turn them On again by lightly pressing the Shutter Release button.
Page 106 AF-S PRINT TYPE AF-S PRINT TYPE 6-16 If HI appears in the shutter speed position—Over- exposure alert: Use a Nikon ND or similar filter. If Lo appears in the shutter speed position—Under- exposure alert: Use built-in flash or a Nikon Speedlight. If a green mark appears in the viewfinder—Use the built-...
Page 107: Operating In Flexible Program
Operating in Flexible Program To change the shutter speed/aperture combination in Auto-Multi Program or Vari- Program, use the Flexible Program function. Flexible Program lets you temporarily shift an automatically set combination of shutter speed/aperture in 1/2 EV steps, while maintaining the correct exposure. In the following procedure, ADVANCED mode indications are used for illustrations.
Page 108: Operating In Shutter-Priority Auto Exposure Mode
Press and hold the MDE button and rotate the Main-Command dial until S appears in the Camera Status LCD panel and viewfinder. BUSY IMPORTANT: The bulb setting does not work on your digital camera as on a film camera. Do not use this setting.
Page 109 AF-S PRINT TYPE Remove your finger from the MDE button and rotate the Main-Command dial to set the desired shutter speed. Shutter speed indications change in 1/2 EV steps as follows: 30” 23” 15” 11” 8” 5.5” 4” 3” 2” 1.5” 1” 1.4 2 3 4 6 8 11 15 23 30 45 60 90 125 180 250 350 500 750 1000 1500 2000 3000 4000...
Page 110 If HI appears with the electronic analog display (lower right corner of viewfinder)*—Over-exposure AF-S alert: Select a higher shutter PRINT TYPE speed or use a Nikon ND filter. +2.1.0.1.2- If Lo appears with the electronic analog display (lower right corner of viewfinder)*—Under- AF-S exposure alert: Select a slower...
Page 111: Operating In Aperture-Priority Auto Exposure Mode
Operating in Aperture-Priority Auto Exposure Mode RESET BUSY PRINT TYPE Press and hold the MDE button and rotate the Main-Command dial until A (for Aperture- Priority Auto) appears in the Camera Status LCD panel and viewfinder. IMPORTANT: If FEE blinks in the Camera Status LCD panel—Lens setting error alert: The lens (other than the IX-Nikkor lens) is not set to...
Page 112 AF-S PRINT TYPE 6-22 Remove your finger from the MDE button and rotate the Sub- Command dial to set the desired aperture. Aperture indications change in 1/2 steps as follows: f1.4 f1.7 f2 f2.4 f2.8 f3.3 f4 f4.8 f5.6 f6.7 f8 f9.5 f11 f13 f16 f19 f22 f27 f32 Available apertures are limited to those of the lens in use.
Page 113 AF-S PRINT TYPE +2.1.0.1.2- AF-S PRINT TYPE +2.1.0.1.2- * Shows the difference in value from a correct exposure. If the difference exceeds +2EV, appears for underexposure and If HI appears with the electronic analog display* —Over-exposure alert: Select a smaller aperture (larger f-number) or use a Nikon ND filter.
Page 114: Operating In Manual Exposure Mode
Operating in Manual Exposure Mode RESET PRINT TYPE +2.1.0.1.2- AF-S PRINT TYPE +2.1.0.1.2- 6-24 Press and hold the MDE button and rotate the Main-Command dial until M appears in the Camera Status LCD panel and viewfinder. BUSY Remove your finger from the MDE button and rotate the Main-Command dial to set the desired shutter speed.
Page 115 AF-S PRINT TYPE +2.1.0.1.2- +2.1.0.1.2- Rotate the Sub-Command dial to set the desired aperture. Refer to the “Operating in Aperture-Priority Auto Exposure Mode” section on page 6-21 for aperture indications and sequence. Look inside the viewfinder, compose the shot, and lightly press the Shutter Release button.
Page 116 Electric Analog Display Examples +2.1.0.1.2- Over +2 EV +2.1.0.1.2- +1 EV +2.1.0.1.2- Under -2 EV The Electronic Analog display in the viewfinder blinks when the subject is too dark for Metering. In this case, use built-in flash or a Nikon Speedlight. 6-26 +2.1.0.1.2- +0 EV...
Page 117: Metering System
Metering System The available exposure Metering systems vary, depending on your camera. Exposure Metering System 3D Matrix Metering Center-Weighted Metering Spot Metering 3D Matrix Metering 3D Matrix Metering is only available with the DCS 330 camera. This system is ideal for quick operation in any exposure mode. With D-type AF Nikkor lenses, 3D Matrix Metering is automatically activated.
Page 118: Center-Weighted Metering
Center-Weighted Metering With approximately 65% of the meter’s sensitivity concentrated on the 8.4 mm-diameter circle in the viewfinder and approximately 35% outside this circle, this meter is useful when you want to base your exposure on a specific area in the scene. In Auto Exposure mode, to measure the brightness of the picture’s off-center portion, use the AE-L button.
Page 119: Selecting The Metering System
Selecting the Metering System RESET BUSY AF-S PRINT TYPE Press and hold the Metering button and rotate the Main-Command dial to set the desired Metering mode. The following indicators appear in the Camera Status LCD panel and viewfinder: 3D Matrix Metering (DCS 330 only) Center-Weighted Metering Spot Metering...
Page 120: Af Mode And Focus Area
AF Mode and Focus Area Your camera features two Autofocus modes, Single Servo AF (AF-S) and Continuous Servo AF (AF-C). The autofocus system offers a choice of two focus areas, Wide ( and Spot ( ). AF mode and focus area are set simultaneously. Refer to “Setting AF Mode and Focus Area”...
Page 121: Wide Area Af
Wide Area AF The Wide-Area focus brackets delineate the focus detecting area in the viewfinder. Subjects of sufficient brightness and detail can be detected within these brackets. In addition to general photography, autofocus with Wide-Area focus brackets is suitable for action photography where the moving subject requires a wide-range focus detection area.
Page 122: Setting Af Mode And Focus Area
Setting AF Mode and Focus Area AF mode and focus area are set simultaneously. RESET AF-S PRINT TYPE 6-32 Set the Focus Mode selector to Press and hold the FNC button and rotate the Main-Command dial until the function set indicator ( ) appears in the Camera Status LCD panel and the symbol beneath it starts...
Page 123 RESET BUSY When the built-in flash is activated or an attached Nikon Speedlight is turned On, Wide Area mode automatically switches to Spot Area mode, Camera Status LCD panel, and appears inside the viewfinder. Press and hold the SET button and rotate the Main-Command dial until the desired combination appears.
Page 124: Single Servo Af Operation
Single Servo AF Operation With a Stationary Subject With a Moving Subject 6-34 Lightly press the Shutter Release button. While autofocusing, a front or rear focus) may appear. When the subject is in focus, the lens stops moving, the in-focus indication appears in the viewfinder, and the focus locks.
Page 125 Tips stays in the viewfinder, the subject is located closer than the closest focusing distance for the lens. Move away from the subject and refocus. blinks in the viewfinder, autofocus is not possible and the shutter locks. Refer to “Special Focusing Situations” on page 7-18. Single Servo AF is convenient for off-center subjects.
Page 126: Autofocus With The Main Subject Off-Center
Autofocus with the Main Subject Off-Center In Single Servo AF, the focus remains locked as long as the Shutter Release button is kept lightly pressed. Use this feature for shooting off-center subjects. 6-36 Center the main subject inside the viewfinder and lightly press the Shutter Release button to start Single Servo AF operation.
Page 127 Tips If there is a substantial difference in brightness between the subject and the background, switch Metering to Center-Weighted or Spot, and use the Auto Exposure Lock function. Refer to “Using the Auto Exposure Lock Function” on page 7-4. With a moving subject, the focus cannot be locked. 6-37...
Page 128: Continuous Servo Af Operation
Continuous Servo AF Operation With a Stationary Subject stays in the viewfinder, the subject is located closer than the closest focusing distance for the lens. Move away from the subject and refocus. blinks in the viewfinder, autofocus is not possible. Refer to “Special Focusing Situations”...
Page 129: Using Drive Mode
Using Drive Mode Drive mode is similar to Film Advance mode in film cameras. There are two automatic Drive modes: Single-Frame ( )and Continuous shooting ( Single-Frame Shooting Fully depressing the Shutter Release button captures one image. After the shutter closes, the image data is read from the imager, then stored on the PC Card.
Page 130: Setting The Drive Mode
Setting the Drive Mode AF-S PRINT TYPE When the built-in flash is activated, Continuous shooting is automatically switched to Single-Frame shooting. In this case, 6-40 Press and hold the FNC button and rotate the Main-Command dial until the Function Set indicator ( ) appears in the Camera Status LCD panel, and blinking.
Page 131: Using Two-Button Reset
Using Two-Button Reset You use the Two-Button Reset function to reset the camera to its original factory settings as shown below: Exposure mode: Metering system: Focus area: Focus mode: Drive mode: Flash Sync mode: Exposure Compensation: Flexible Program: Auto Exposure Bracketing: Flash Exposure Bracketing: Self-timer: * With a built-in flash or accessory Nikon Speedlight turned on,...
Page 133: Special Functions
INSERT PHOTO Special Functions HERE This section describes sophisticated photographic techniques such as Self-timer operation, Exposure Compensation, and Exposure Bracketing. It also explains the Quick Recall function, Manual focus, and special focusing situations. Self-Timer Operation The Self-timer allows you to delay the exposure ten seconds from the time that you press the Shutter Release button.
Page 134 Tips When using any Auto Exposure mode, attach the (provided) eyepiece cover to the viewfinder eyepiece before setting the self-timer. The eyepiece cover prevents stray light from entering the viewfinder and affecting the exposure. In Single Servo AF mode, the Self-timer operates only when the in-focus indicator ( ) appears inside the viewfinder.
Page 135: Exposure Compensation
Your DCS 300 series camera has a useful Histogram feature. Refer to “Viewing Overexposure Areas and Histogram Information” on page 9-5. Developed and patented by Kodak, the Histogram graphically depicts the distribution of gray-scale values among pixels based upon the captured file. It functions as a digital light meter by providing graphic representation of image exposure.
Page 136: Using The Auto Exposure Lock Function
Using the Auto Exposure Lock Function In Auto Exposure mode, when you want to control exposure based on the brightness of a specific area within the scene, use the Auto Exposure Lock function. To use this function, you should first switch to Center-Weighted or Spot Metering. Center the main subject inside the viewfinder or move in closer until the subject fully covers the...
Page 137 AE-L MENU SELECT REC/TAG RESET BUSY Tips In Single Servo AF mode, if recomposing the picture may have changed the subject-to-camera distance, refocus by briefly removing your finger from the Shutter Release button and then lightly press the button again. Continuous Servo AF is not recommended if the subject will move off-center after you recompose with AE-lock.
Page 138: Obtaining A Meter Reading In Manual Exposure Mode
Obtaining a Meter Reading in Manual Exposure Mode To give a particular subject your desired exposure in Manual Exposure mode (page 6-14), switch to Center-Weighted or Spot Metering, then do as follows: +2.1.0.1.2- +2.1.0.1.2- Center the main subject inside the viewfinder and, if necessary, move closer until the subject fully covers the reference circle for Center-Weighted or Spot...
Page 139: Exposure Compensation Operation
Exposure Compensation Operation You can compensate for a background that is too bright or too dark. When a background is too bright, compensate in the + direction; when a background is too dark, compensate in the - direction. In flash photography, the flash output level is also compensated. After capturing your images, be sure to reset the control to “0.0”...
Page 140 AF-S PRINT TYPE PRINT TYPE PRINT TYPE Once set, Exposure Compensation remains fixed until reset. The symbol remains in the Camera Status LCD panel (indicating that Exposure Compensation is On), until you remove your finger from the Exposure Compensation button. symbol disappears from the viewfinder when the exposure meter automatically...
Page 141: Auto Exposure Bracketing
Auto Exposure Bracketing In situations where you might find it difficult to obtain a proper exposure, you can shoot the same subject at three different exposures, using a varying exposure compensation degree of 0.5 EV or 1 EV. Setting a compensation degree of 0.5 EV, for example, lets you capture three images: the first with no compensation, the second with a -0.5 EV compensation, and the third with a compensation of +0.5 EV.
Page 142 RESET PRINT TYPE AF-S PRINT TYPE +2.1.0.1.2- 7-10 Press and hold the SET button and rotate the Main-Command dial until the desired compensation degree (0.5 or 1.0) appears. BUSY Remove your finger from the SET button to complete the setting. 0.0 starts blinking in the Camera Status LCD panel to indicate no compensation, and the...
Page 143 After three shots are taken, Auto Exposure Bracketing is automatically canceled. First shot is taken. Second shot is taken. Third shot is taken. AF-S AF-S PRINT TYPE +2.1.0.1.2- Tips In Programmed Auto Exposure mode, the shutter speed and aperture vary. In Shutter-Priority Auto Exposure mode, the aperture varies.
Page 144: Using The Quick Recall (Qr) Function
Using the Quick Recall (QR) Function You can customize and save the following settings, then quickly recall them: Exposure mode (including Vari-Program) Metering system Focus area/AF mode Drive mode Flash Sync mode Exposure Compensation function Flash Output Level Compensation Auto Exposure/Flash Exposure Bracketing You can save the settings as a group, and save up to three groups.
Page 145 AF-S PRINT TYPE RESET BUSY AF-S PRINT TYPE Tips To cancel memory settings, press and hold the SET button and rotate the Main- Command dial until -- -- appears in the Camera Status LCD panel. If you have already set the QR identification number and then select the same identification number to save another group of settings, the previous settings will be cleared.
Page 146: Recalling Customized Settings
Recalling Customized Settings AF-S PRINT TYPE Tips The Flexible Program function is canceled when you recall any QR identification number. If you have recalled one of the QR identification numbers, the recalled number appears in the Camera Status LCD panel when you press QR-OUT button. After recalling one of the QR identification numbers, you can adjust any or all settings.
Page 147: Changing Iso Settings
Changing ISO Settings In BASIC mode, the ISO is ISO 200 ( ). (While BASIC mode is available on your camera, ADVANCED mode is recommended for the best results.) You can manually set ISO in ADVANCED mode. The range for the DCS 315 is 100-400, and the range for the DCS 330 is 125-400.
Page 148: Manually Setting Iso
Manually Setting ISO AF-S PRINT TYPE 7-16 Press and hold the FNC button and rotate the Main-Command dial until the Function Set indicator ( ) appears in the Camera Status LCD panel and ISO and selected) start blinking. RESET BUSY Remove your finger from the FNC button and confirm that the ISO and...
Page 149 RESET BUSY PRINT TYPE Press and hold the SET button and rotate the Main-Command dial until the desired ISO appears in the Camera Status LCD panel and appears. Remove your finger from the SET button to complete the setting. To confirm the ISO setting, press and hold the FNC button and rotate the Main-Command dial until the Function Set...
Page 150: Using Manual Focus
Using Manual Focus Special Focusing Situations Autofocus operation depends on general lighting, subject contrast and detail, and other technical factors. In situations where autofocus is not possible, viewfinder indicating that you should focus manually with the clear matte field or focus automatically on another subject located at the same distance.
Page 151 Very dark subject: Patterned subject or scene, such as building windows Low-contrast subject Focus manually with the clear matte field, or for Single Servo AF, focus on another brighter subject located at the same distance, then use Focus Lock (page 6-36) or use a Nikon autofocus Speedlight to focus automatically with the Speedlight’s AF illuminator.
Page 152 Strong lighting In the following situations, ignore the In-focus indicator ( ): When subjects are located at different distances (for example, animals inside a cage or a person over a fence), use Spot Area for autofocus (page 6-31), or focus manually with the clear matte field.
Page 153: Flash Photography
Flash Photography Flash can be used in bright conditions as well as dim light to fill in shadows with extra light. This technique is called Fill-Flash. With the camera’s built-in flash or any dedicated Nikon Speedlight, you can perform an advanced Fill-Flash technique, Automatic Balanced Fill-Flash.
Page 154: Situations Where Flash Is Required
Nikon’s TTL flash sensor relies upon the reflected light from the film plane surface, which Kodak has replaced with an imager. The reflectance factor of film is quite different than the imager; this affects the overall performance of the TTL modes.
Page 155: Using Ttl Auto Flash
Using TTL Auto Flash With TTL flash, the camera’s flash light sensor measures the flash illumination reflected by the subject onto the imager, and shuts off the flash when the measurement indicates correct exposure. TTL auto is recommended for most common flash shooting situations. The DCS 315 provides three types of TTL auto flash;...
Page 156: Standard Ttl Flash
Standard TTL Flash Although this mode does not offer automatic flash output levels, your subject will be correctly exposed. TTL Performance The TTL Flash System in the Pronea camera body was optimized to work with the reflectivity of Advanced Photo System (APS) film. Because the imager in your DCS 300 series camera does not have the same reflectivity properties as APS film, the TTL Flash system performance does not demonstrate the same robustness.
Page 157: Red-Eye Reduction With Slow Sync
Red-Eye Reduction with Slow Sync Slow Sync Rear-Curtain Sync Red-eye reduction can be performed with Slow Sync (described below.) When flash pictures are taken in dim light at high shutter speeds, the background may turn out dark. Slow Sync improves background exposures by extending the automatically controlled shutter speed range down to 30 seconds,...
Page 158: Selecting Flash Sync Mode
Selecting Flash Sync Mode RESET AF-S PRINT TYPE PRINT TYPE SLOW SLOW REAR Press and hold the FNC button and rotate the Main-Command dial until the Function Set indicator ( ) appears in the Camera Status LCD panel and the Flash symbol starts blinking. (The different types of flash symbols are shown in the illustration at the bottom of the...
Page 159 RESET BUSY PRINT TYPE SLOW SLOW REAR Press and hold the SET button and rotate the Main-Command dial until the desired flash symbol appears. - Normal Sync - Red-Eye Reduction Red-Eye Reduction with Slow Sync - Slow Sync - Rear-Curtain Sync. When you remove your finger from the FNC button, the flash symbol disappears...
Page 160: Tips
Tips For Normal Sync with a Nikon Speedlight SB-24/SB-25/SB-26, set the Speedlight’s Flash Sync Mode selector to NORMAL. Red-Eye Reduction and Red-Eye Reduction with Slow Sync can be set only with the built-in flash or Nikon Speedlight SB-26/SB-27. Setting Red-Eye Reduction with a Speedlight that does not offer red-eye reduction causes to blink in the Camera Status LCD panel.
Page 161: Using The Built-In Flash
Using the Built-in Flash Your camera includes a built-in flash which you can use when professional flash is not needed or available. For a more sophisticated, longer range flash, you may want to use a Nikon Speedlight. Built-in Flash Specifications Usable ISO DCS 315: 100 - 400 DCS 330: 125 - 400...
Page 162: Usable Lenses With Built-In Flash
Usable Lenses with Built-In Flash Non-Zoom AF Nikkor lenses 20mm to 300mm non-Zoom AF Nikkor lenses (AF-S 300mm f/2.8D cannot be used when shooting a subject within 3.7m/12.1 ft.). AF 300mm f/2.8 ED-IF cannot be used. Zoom AF Nikkor lenses. IX-Nikkor 20-60mm f/3.5-f/5.6 IX-Nikkor 24-70mm f/3.5-f/5.6 IX-Nikkor 60-180mm f/4-f/5.6...
Page 163: Flash Shooting Distance Range
Flash Shooting Distance Range The distance ranges for flash at various combinations of aperture and ISO are shown in the table below: 14/45.9 Guide number (m/ft) Aperture Flash shooting distance range (m/ft) 20/6.5 28/91.9 2.0 - 9.9/6.6 - 32.5 1.4 - 7.0/4.6 - 23 1.0 - 5.0/3.3 - 16.4 0.7 - 3.5/2.3 - 11.5 0.6 - 2.5/2.0 - 8.2...
Page 164: Shutter Speed/Aperture In Flash Shooting
Shutter Speed/Aperture in Flash Shooting The shutter speed/aperture ranges for the various exposures modes in flash shooting are shown in the table below: Exposure mode Automatically controlled from Programmed Auto ( 1/180 second to 1/60 second Manually set as desired from Shutter-Priority Auto ( 1/180 second to 30 seconds Automatically controlled from...
Page 165: Operating The Built-In Flash
Operating the Built-in Flash AF-S PRINT TYPE AF-S PRINT TYPE Press the Flash Lock-release button to release and activate the flash. When Continuous shooting ) is set, the camera automatically switches to Single-Frame shooting ( ) as soon as the flash pops up, and blinks in the Camera Status LCD panel.
Page 166 8-14 Compose the shot and lightly press the Shutter Release button. Confirm that the Focus Confirmation ( ) and Flash Ready light (red ) appear in the viewfinder. If an Electronic Analog display appears in the viewfinder while you are using Shutter-Priority Auto, Aperture-Priority Auto or Manual Exposure mode, the background may be...
Page 167 Confirm that the subject is within the flash shooting distance range (page 8-11), then fully depress the Shutter Release button to capture an image. After shooting, check the Flash- Ready light again. If it blinks for a few seconds after shooting, the light may have been insufficient.
Page 168: Using Flash Exposure Bracketing
Using Flash Exposure Bracketing You can use Flash Exposure Bracketing to shoot the same subject at three different flash output levels with a varying flash output level compensation 0.5 EV or 1 EV. Setting a compensation degree of 0.5 EV, for example, lets you capture three images, the first without compensation, the second with -0.5 EV compensation and the third with +0.5 EV compensation.
Page 169 RESET BUSY AF-S PRINT TYPE Activate the built-in flash or turn on the attached Nikon Speedlight. Press and hold the FNC button and rotate the Main-Command dial until the Function Set indicator ( ) appears in the Camera Status LCD panel and start blinking.
Page 170 RESET PRINT TYPE 8-18 Press and hold the SET button and rotate the Main-Command dial until the desired compensation degree (0.5 or 1.0) appears. Remove your finger from the SET button to complete the setting. To cancel Flash Exposure Bracketing before or during the operation, turn the camera Off and then On again, or press and BUSY...
Page 171 First shot is taken Second shot is taken Third shot is taken AF-S AF-S AF-S AF-S PRINT PRINT PRINT PRINT TYPE TYPE TYPE TYPE +2.1.0.1.2- +2.1.0.1.2- +2.1.0.1.2- 8-19...
Page 172: Using Flash Output Level Compensation
Using Flash Output Level Compensation Use Flash Output Level Compensation to make a flash-illuminated subject brighter or darker. You can manually adjust the flash light output level using Flash Output Level Compensation. Using this function, you can adjust the light output level from -3 EV to +1 EV in 1/2 steps.
Page 173 RESET BUSY PRINT TYPE AF-S PRINT TYPE Press and hold the SET button and rotate the Main-Command dial until the desired compensation value appears in the Camera Status LCD panel. Once set, Flash Output Level Compensation remains fixed until reset. Although remains in the Camera Status LCD panel to indicate Exposure...
Page 174 RESET PRINT TYPE 8-22 Activate the built-in flash or turn the attached Nikon Speedlight To confirm the compensation value in the Camera Status LCD panel, press and hold the FNC button and rotate the Main- Command dial until the Function Set indicator ( ) appears and Press the SET button.
Page 175: Using Accessory Nikon Speedlights
Using Accessory Nikon Speedlights When using a Nikon Speedlight, remove the accessory shoe cover. The table below shows the available Flash modes for each Nikon Speedlight: Speedlight Model Connection SB-27, SB-26, SB-25, Direct SB-24, SB-22, SB-21B SB-20, SB-16B and SB-15 SB-23 Direct Via flash unit coupler...
Page 176: What You Can Do With Nikon Speedlights
What You Can Do With Nikon Speedlights The main features and functions of Nikon Speedlights are listed in the table below: Rear- Slow Speedlight Curtain Model Sync Sync SB-27 SB-26 SB-25 SB-24 SB-23, SB-22 and SB-20 SB-16B, SB-15, SB- 11, SB-14 or SB-140 SB-21B 1 Refer to “Slow Sync”...
Page 177: Notes On Flash Photography
Notes on Flash Photography The available maximum aperture for each ISO in Auto-Multi Program is shown in the table below: ISO Setting 400 (DCS 315 only) If you are using a lens with a maximum aperture smaller than listed, the auto- matically controlled aperture range is from the lens’s maximum aperture to its minimum aperture.
Page 178: Flash Sync Terminal
Flash Sync Terminal The Flash Sync terminal is only available with the DCS 330 camera. The DCS 330 camera has an external Flash Sync terminal located on the camera’s left side. This terminal may also be referred to as a PC Sync jack or X-Terminal and it is compatible with the industry standard sync cords.
Page 179 The following restrictions apply when the Flash Sync terminal is in use: TTL automatic flash exposure control, automatic flash synchronization of the camera shutter speed, and the viewfinder’s flash ready-light indicator do not work. The only Flash modes possible are Manual Flash Exposure control and Non-TTL Automatic Flash Exposure control.
Page 181: Working With Images On The Camera
Kodak Software. You can also record sound files to be associated with images, and delete unwanted images to free up space on a PC Card.
Page 182: Selecting A Review Mode
Selecting a Review Mode Reviewing Images You can review images one folder at a time. Insert a PC Card if you have not already done so. Press the MENU button to turn the Image LCD panel On. Press and hold the MENU button and rotate the Main- Command dial to highlight the icon for the desired viewing...
Page 183 The following examples show how images are selected when you rotate the Main- Command dial clockwise and counter-clockwise in Four Image Review mode: Review sequence with counter-clockwise rotation of the Main Command dial Review sequence with clockwise rotation of the Main Command dial Selecting images in Nine Image Review mode is similar.
Page 184: Adjusting The Display Contrast
Adjusting the Display Contrast You can change the contrast of the images on the Image LCD panel. Changing the contrast affects only the view of the images on the Image LCD panel, not the images themselves. Once you change the contrast setting, the change will be maintained. Press the MENU button to turn the Image LCD panel On.
Page 185: Viewing Overexposure Areas And Histogram Information
Viewing Overexposure Areas and Histogram Information There are two display options available on the Image LCD panel: Highlight and Histogram/Info. The Highlight feature causes overexposed areas of the image to blink. This feature helps you immediately determine how much of the image (or what area of a scene) was overexposed.
Page 186 Image name Date Time Shutter speed ISO setting Aperture Exposure mode Exposure compensation If you turn Highlight On, overexposed areas of the image blink. If you turned Histogram/Info On, the Histogram and image information screen appears. A typical screen is shown. The Histogram only appears in Single Image Review mode.
Page 187: Selecting An Image
Value Description Auto-Multi Program Shutter-Priority Auto Exposure mode Aperture-Priority Auto Exposure mode Manual Exposure mode Portrait Program Hyperfocal Program Landscape Program Close-Up Program Sport Program Silhouette Program Selecting an Image You need to select an image if you want to tag it or record a sound file. When you capture an image, it is automatically selected.
Page 188: Viewing Status Information
Viewing Status Information You can view status information on the currently selected image. Press and hold the MENU button and rotate the Main- Command dial to highlight the Status icon. Release the MENU button. The Status screen appears. Quickly press and release the SELECT button to toggle between the Status screen and Single Image Review mode.
Page 189: Tagging An Image
Kodak Software. On the camera, you can specify that the tagged images deleted. In the Kodak Software you can select tagged (or untagged) images and perform a variety of operations. Refer to the KODAK PROFESSIONAL DCS Host Software User’s Manual on the DCS Host Software CD included with your camera.
Page 190: Associating Sound Files With Images
You can attach one or more sound files to the current image, either immediately after you capture the image, or later when you review it (page 9-2). If you later use the Kodak Software to copy or delete the image, the sound file will also be copied or deleted. (If you copy or delete images without using the Kodak Software, you must also copy or delete the sound (.WAV) files.
Page 191 The PC Card Busy/Record LED turns green while you are recording sound. You can repeat the process if you wish to associate additional sound files with the image. RESET BUSY 9-11...
Page 192: Deleting Images
Deleting Images You can delete images from the PC Card to make space for additional images. If there are sound files associated with an image, they too will be deleted. Deleting One Image 9-12 Press the MENU button to turn the Image LCD panel On.
Page 193: Deleting More Than One Image
Deleting More Than One Image You can delete all images in the current folder, all untagged images in the current folder, all images on a PC Card, or all untagged images on a card. Press the MENU button to turn the Image LCD panel On.
Page 194 IMPORTANT: When you delete all images or all untagged images on a card, images in other folders will also be deleted. Be certain that you don’t need any of them. 9-14 If you chose Yes, this screen appears giving you the opportunity to possibly cancel some of the deletions.
Page 195: Connecting Your Camera To A Computer
Once you have done one of the above, you can access camera images from your computer. You will need to use Kodak Software to acquire images that were not processed on the camera. The Kodak Software, installer software for Macintosh and Windows, and the KODAK PROFESSIONAL DCS Host Software User’s Manual are supplied separately on...
Page 196: To Connect Your Camera To A Computer
Install the Kodak Software for Macintosh or PC if you have not already done so. Refer to the KODAK PROFESSIONAL DCS Host Software User’s Manual on the DCS Host Software CD included with your camera.
Page 197 DCS Host Software CD included with your camera.) The Host Computer Connected icon on the Status screen appears when a valid cable connection is made. It flashes when a host computer application (such as the Kodak Software) is running. 10-3...
Page 198: Disconnecting Your Camera From The Computer
Some computer systems (for example, Windows NT 4.0) require you to reboot each time you insert a PC Card into the reader. You can now access images on the PC Card using the Kodak Software.9 Refer to the KODAK PROFESSIONAL DCD Host Software User’s Manual on the DCS Host Software CD included with your camera.)
Page 199: Camera Care
Camera Care This chapter discusses the cleaning and care of your camera. It also provides instructions for loading new firmware. Handling With careful handling, your camera should produce images of the highest quality for years to come. Tips Do not drop your camera or subject it to shock. While the camera has been designed for durability, it is a precision instrument and should be handled with care.
Page 200: Cleaning The Camera
Cleaning the Camera Turn the camera Off. Disconnect the camera from the AC adapter and from the computer if it is connected. Using a clean, damp cloth, clean only the outside encasement, the Image LCD panel, the Camera Status LCD panel, and the viewfinder. IMPORTANT: Do not use liquid cleaners or aerosol cleaners on the outside of the camera.
Page 201: Antialiasing Filter (Dcs 330 Only)
Antialiasing Filter (DCS 330 Only) The DCS 330 contains an antialiasing filter which helps prevent aliasing at certain focal distances. It may be necessary to remove the antialiasing filter for cleaning. While it is not essential, you can wear lint-free, static-free gloves, available from your camera dealer. CAUTION: If you break the glass on the antialiasing filter while it is in the camera, call your service representative.
Page 202 If you remove the antialiasing filter and don’t re-install it, you should store it in a clean, dust-free space. 11-4 Carefully unscrew the screw at the bottom of the antialiasing filter bracket using a jewelers screwdriver (Phillips #00). Carefully remove the filter bracket from the camera.
Page 203: Checking And Cleaning The Imager
Checking and Cleaning the Imager The imager is the camera component that records light when you capture an image. If it gets dirty, the quality of your images can be affected. Even though it is located inside the camera, it is still possible for the imager to become dirty. To determine whether the imager needs cleaning: Capture a test image of a flat uniform scene, and examine it for imperfections that indicate dirt on the imager.
Page 204: Visually Inspecting The Imager
Refer to “Connecting the Kodak-specified AC adapter” on page 2-9. CAUTION: It is necessary to use the batteries as well as the Kodak- specified AC adapter as a safeguard to prevent the shutter closing unexpectedly and being ruined. Turn the camera On.
Page 205 Press the MENU button to turn the Image LCD panel On. Press and hold the MENU button and rotate the Main- Command Dial to highlight the Main Menu icon. Release the MENU button. The Main menu appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight the Imager Clean choice.
Page 206 11-8 If you chose Cancel, you can turn the camera Off and replace the lens. If you chose OK, the mirror lifts and the shutter opens. The imager is visible through the lens mounting flange. CAUTION: Do not remove the power sources while the mirror is raised.
Page 207: Cleaning The Imager
Cleaning the Imager If the imager is dirty, gently blow off the dust using commercially available “canned air.” If the imager is still dirty, contact your dealer or service representative. Reassembling the Camera Reassemble your camera after inspecting or cleaning the imager. Press and hold the SELECT button and rotate the Main- Command dial to highlight Yes...
Page 208: Storing The Camera
Storing the Camera Wrap the camera in a clean, soft cloth and store it in a well-ventilated, cool, dry, dust-free place. Keep the camera out of direct sunlight, and away from “hot spots” such as the trunk or rear window shelf of a car. Avoid places where chemical agents such as moth balls are used, and use a desiccant when there is extreme humidity.
Page 209: Loading Camera Firmware
As changes are made to the firmware, new versions may become available. You should occasionally check the Kodak web site (http://www.kodak.com) to see if there is a new firmware version. You can download the firmware from the Kodak WWW site or obtain it from your camera dealer.
Page 210 On Windows systems, the firmware file will have been installed in \TWAIN_32\Kodak- dcs in your Windows directory. On Macintosh systems, it will have been installed in the DCS Plugin directory in your root directory.
Page 211 Press the MENU button to turn the Image LCD panel On. Press and hold the MENU button and rotate the Main- Command dial to highlight the Main Menu icon. Release the MENU button. The Main Menu appears. Press and hold the SELECT button and rotate the Main- Command dial to highlight Firmware.
Page 212 11-14 If you choose Update from card, the screen at the left appears briefly. This screen then appears. Choose OK or Cancel. If you choose Cancel, the firmware will not be updated. If you choose OK, the Progress screen appears. If there is a problem loading the firmware, an error message will be displayed.
Page 213: Warranty
THIS WARRANTY APPLIES ONLY TO EQUIPMENT PURCHASED IN THE UNITED STATES. Warranty Time Period Kodak warrants your DCS 300 Series Digital Camera to be free from defects in material and workmanship for 1 year or 60,000 shutter activations from the day of purchase (whichever comes first).
Page 214: Limitations
Kodak representative for return authorization and instructions. Should you need to return equipment to Kodak, Kodak is not responsible for the loss or damage of equipment while in transport to a Kodak authorized service center. You may, at your option, choose to insure equipment for loss or damage with the carrier of your choice.
Page 215: Outside The United States
In Canada, call 1-800-GO-KODAK (1-800-465-6325). In other countries, call your nearest Kodak representative. If service is required, your Kodak representative will instruct you to return the unit to the nearest service center for repair and will issue a return authorization number.
Page 216: Product Support Options
During the warranty period for the DCS 300 Series Digital Camera, you are entitled to product support for both hardware and software, provided your camera is registered with Eastman Kodak Company. You may register with Eastman Kodak via mail, fax, or through Kodak’s WWW (World Wide Web) site (http://www.kodak.com).
Page 217 Out-of-Warranty Support Options There will be a charge for call incidents if you wish to speak to a Kodak support representative. A call incident is defined as only those issues raised during the first telephone contact. Follow-up telephone calls by Kodak’s representative, and callbacks to Kodak’s Support Center to resolve the call incident will not be charged,...
Page 218: Software License Agreement
AGREE WITH THEM, YOU SHOULD PROMPTLY RETURN THE CD PACKAGE UNOPENED, ALONG WITH THE ACCOMPANYING MATERIALS. Eastman Kodak Company (Kodak) provides this software and licenses its use worldwide. You assume responsibility for selection of the software to achieve your intended results, and for installation, use, and results obtained from the software.
Page 219: Term
LIMITED WARRANTY Kodak warrants the CD on which the software is furnished to be free from defects in materials and workmanship under normal use for a period of ninety (90) days from the date of delivery to you as evidenced by a copy of your receipt.
Page 220: Limitations Of Remedies
Kodak or your dealer with a copy of your receipt, or if Kodak or the dealer is unable to deliver a replacement CD that is free of defects in materials or workmanship, you may terminate this Agreement by returning the software.
Page 221: Appendix A - Specifications
Appendix A - Specifications Type of camera Two models are available: DCS 315 and DCS 330. Both are integral-motor autofocus 35 mm single-lens reflex Imager size DCS 315: 1,532,160 million pixels DCS 330: 3,020,032 million pixels Lens mount Nikon F mount Lens Refer to Appendix C for a list of compatible lenses Focus area...
Page 222 Power source Six AA format batteries and/or AC adapter Battery power confirmation On Image LCD panel Kodak-specified AC Adapter An alternative power source that allows you to conserve your battery while working indoors. Dimensions Width: 137 mm, Height: 174 mm, Depth: 76 mm Weight Approximately 3 pounds;...
Page 223: Appendix B - Troubleshooting
Appendix B - Troubleshooting If you run into a problem operating your camera, check the following table to see if you can find the cause of the problem. If the trouble persists, take the camera to your nearest service representative. Symptom Indication The PC Card icon...
Page 224 TTL auto flash. Remedy Refer to “TTL Performance” on page 8-4. Replace the batteries or use the Kodak-specified AC adapter. Refer to “Inserting Batteries” on page 2-4 or “Kodak-specified AC adapter” on page 2-8. Set the lens to the smallest aperture.
Page 225 If the delay is too long, replace the batteries or use an AC adapter. The camera is turned Turn the camera On or Off or there is no insert new batteries (or power source. connect to the Kodak- specified AC adapter). Overexposure possible. Underexposure possible.
Page 226 Symptom Indication The Electronic Analog Display blinks in Manual Exposure mode. The shutter speed indications in the Camera Status LCD panel and viewfinder blink. Green lights up inside the viewfinder. Red blinks inside the viewfinder after flash shooting. The date is not displayed in the Camera Status LCD...
Page 227 No power to camera. Verify battery placement and capacity or check the Kodak-specified AC adapter. Refer to “Batteries” on page 2-3 or “Connecting the Kodak- specified AC adapter” on page 2-9. The camera is Remove batteries and AC “locked up.”...
Page 228 Symptom Indication kLoginErr (-5693) timeoutErr (-4162) Error messages appear on the Macintosh computer screen when the camera is connected to the computer using IEEE 1394 cable. disconnectedErr (-4169) Cause Remedy Another application Quit any applications that is using the camera. may be using the camera (other than the one intended for immediate...
Page 229: Appendix C - Lens Compatibility
Appendix C - Lens Compatibility Compatible Lenses Your camera will work with the following Nikkor lenses. Some work only without the antialiasing filter, and some work both with and without the filter. (Use the table below as a reference.) Manual Single Focal Length Lenses Lens Name Lens Type Ai 6/2.8S...
Page 230 Lens Name Ai 20/4 Ai 24/2 Ai 24/2S Ai 24/2.8 Ai 24/2.8S Ai 28/2 Ai 28/2S Ai 28/2.8 E 28/2.8 Ai 28/2.8S Ai 28/3.5 Ai 28/3.5S Ai 35/1.4 Ai 35/1.4S Ai 35/2 Ai 35/2S E 35/2.5 Series E Ai 35/2.8 Ai 35/2.8S Ai 50/1.2 Ai 50/1.2S...
Page 231 Lens Name Lens Type Ai 58/1.2 Noct Ai 58/1.2S Noct Ai 85/1.4S Ai 85/2 Ai 85/2S E 100/2.8 Ai 105/1.8S Ai 105/2.5 Ai 105/2.5S Ai 105/2.8S Micro Ai 105/4 Micro Ai 105/4S Micro Ai 105/4.5S Ultra Violet Ai 135/2 Ai 135/2S Ai 135/2.8 Ai 135/2.8S E 135/2.8...
Page 232 Lens Name Ai 300/4.5 Ai 300/4.5S Ai 300/4.5 Ai 300/4.5 ED-IF Ai 300/4.5S ED-IF Ai 400/2.8S ED-IF Ai 400/3.5 ED-IF Ai 400/3.5S ED-IF Ai 400/5.6 Ai 400/5.6 ED-IF Ai 400/5.6S ED-IF Ai 500/4S Ai 600/4 ED-IF Ai 600/4S ED-IF Ai 600/5.6 ED-IF Ai 600/5.6S ED-IF...
Page 233: Manual Zoom Lenses
Manual Zoom Lenses Lens Name Lens Type Ai Zoom 25-50/4 Ai Zoom 25-50/4S Ai Zoom 28-45/4.5 Ai Zoom 28-50/3.5S Ai Zoom 28-85/3.5- 4.5S Ai Zoom 35-70/3.3- 4.5S Ai Zoom 35-70/3.5 Ai Zoom 35-70/3.5S Ai Zoom 35-105/ 3.5-4.5S Ai Zoom 35-135/ 3.5-4.5S Ai Zoom 35-200/ 3.5-4.5S...
Page 234: Autofocus Single Focal Length Lenses
Lens Name Lens Type Ai Zoom 100-300/ 5.6S Ai Zoom 180-600/ Ai Zoom 200-400/ Ai Zoom 200-600/ 9.5S Ai Zoom 360-1200/ Ai Zoom 1200- ED-IF 1700/5.6-8S Autofocus Single Focal Length Lenses Lens Name Lens Type AF 16/2.8D Fish Eye AF 18/2.8D AF 20/2.8 AF 20/2.8D AF 24/2.8...
Page 235 Lens Name Lens Type AF 60/2.8 Micro AF 60/2.8D Micro AF 85/1.8 AF 85/1.8D AF 85/1.4D AF 105/2D RF-DC AF 105/2.8 Micro AF 105/2.8D Micro AF 135/2 RF-DC AF 135/2D RF-DC AF 180/2.8 ED-IF AF 180/2.8D ED-IF AF 200/4D ED-IF-MC AF 300/2.8 ED-IF AF 300/4...
Page 236: Autofocus Zoom Lenses
Autofocus Zoom Lenses Lens Name Lens Type AF Zoom 20- 35/ 2.8D AF Zoom 24- 50/ 3.3-4.5 AF Zoom 24- 50/ 3.3-4.5D AF Zoom 24- 120/ 3.5-5.6D AF Zoom 28 - 70/ 3.5-4.5 AF Zoom 28 - 70/ 3.5-4.5D AF Zoom 28- 80/ 3.5-5.6D AF Zoom 28- 85/ 3.5-4.5S...
Page 237 Lens Name Lens Type AF Zoom 35-135/ 3.5-4.5 AF Zoom 70-210/4 AF Zoom 70-210/4- AF Zoom 70-210/4- 5.6D AF Zoom 70-300/ 4.5-5.6D AF Zoom 70-300/ 4.5-5.6 AF Zoom 80-200/ AF Zoom 80-200/ 2.8D AF Zoom 80-200/ 4.5-5.6D AF Zoom 75-180/ ED-MC 4.5-5.6D IX Zoom 20-60/3.5-...
Page 238: Incompatible Lenses
Incompatible Lenses You cannot use non-AI or modified AI lenses with your camera. CAUTIONS: The IX-NIKKOR lens can only be used on the DCS 315 or on the DCS 330 when the antialiasing filter is removed. You will break the antialiasing filter if you attempt to install an IX-NIKKOR lens when the filter is in place.
Page 239: Appendix D - Glossary
Appendix D - Glossary AE (Automatic Exposure) lock Holds an automatically controlled shutter speed and/or aperture. Recommended when you want to control an exposure based on a scene’s particular brightness area with Center-Weighted or Spot metering. Auto Exposure Bracketing Operates using various shutter speeds and/or apertures in all exposure modes. (See also Exposure Bracketing.) Automatic Balanced Fill-Flash A TTL auto flash function integrating exposure meter control of ambient light...
Page 240 CPU (Central Processing Unit) The component that controls an electronic product’s functions. AF Nikkor (including D-type AF Nikkor) and AI-P Nikkor lenses have built-in CPUs. The DCS 300 Series camera has a Motorola 821 Power PC CPU. Depth of field The zone of sharpest focus in front of, behind, and around the subject upon which the lens is focused.
Page 241 Exposure control Programmed Auto: Sets shutter speed and aperture for correct exposure. Two Programmed Auto Exposure controls are applied: Auto-Multi Program and Vari- Program. Shutter-Priority Auto: The user selects the shutter speed and the camera sets the matching lens aperture for correct exposure. Aperture-Priority Auto: The user selects the aperture and the camera sets the matching shutter speed for correct exposure.
Page 242 Flexible Program Temporarily shifts an automatically selected shutter speed/aperture combination while maintaining correct exposure. That is, a desired shutter speed or aperture can be selected with the camera in Programmed Auto Exposure mode. Focus Tracking Enables the camera to assess the speed of a moving subject according to perceived focus data, then set correct focus settings by anticipating subject position--and driving the lens to that position at the exact moment of exposure.
Page 243 Hyperfocal distance The closest point upon which a photographer can focus where depth of field is infinity. When the lens is focused for hyperfocal distance, the deepest depth of field, covering from 1/2 the hyperfocal distance to infinity, can be obtained at each f/stop.
Page 244 Before you use TIFF Custom images, you will first need to acquire (import) them through a program such as Photoshop, using the Kodak Software (on the CD included with your camera). If you try to open these files in Photoshop without first acquiring them, only the thumbnail version will be available.
Page 245 The table on this page and the figures on the next page will help you make your lens selections for your Kodak DCS 300 Series camera. The table shows the relationship between Nikkor 35mm lenses and the DCS 315 and DCS 330 cameras, and the IX-Nikkor lenses and the DCS 315 camera.
Page 247 Appendix F - Problem Report KODAK PROFESSIONAL DCS 300 Series Digital Cameras Customer Return Address Name______________________________________________________________ Company___________________________________________________________ Address____________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ City________________________________State_____Zip_____________--______ Phone ( ) ______________________________________________________ Equipment Description Camera Serial Number -- K____________________________________________ (See the bottom of the camera next to “S/N.” The serial number begins with a “K.”)
Page 249 Numerics 3D matrix metering 6-27 AC adapter 2-8 Connecting 2-9 Accessories 1-2 Accessory shoe 1-24 Actuations 3-4 ADVANCED mode Compared to BASIC mode 6-1 Functions available 6-2 – AF mode 6-32 6-38 Continuous 6-38 Setting 6-32 Single servo 6-34 Alerts Aperture-priority auto exposure mode 6-23 Auto-multi program 6-16...
Page 250 Reassembling after cleaning imager 11-9 Side controls 1-7 – Specifications A-1 Storing 11-10 Top controls 1-6 Turning Off 2-2 Turning On 2-2 – Warranty 12-1 12-8 Camera properties. See Properties – Camera Status LCD panel 1-9 Illuminating 1-11 Card reader 10-1 Using 10-4 Center-weighted fill-flash/spot fill-flash 8- Center-weighted metering 6-28...
Page 251 Features 1-3 File size 4-8 Files. See Image files – Firmware, Loading 11-11 11-14 Flash Built-in. See Built-in flash. When to use 8-2 – Flash exposure bracketing 8-16 8-18 Flash output level compensation 8-20 – 8-22 Flash photography notes 8-25 Flash shooting distance range 8-11 –...
Page 252 Landscape program 6-5 LCD panels – Camera Status 1-9 1-10 Effects of temperature on 1-11 Image 1-8 Lens Autofocus Zoom Lenses C-8 Incompatible C-10 Manual Single Lenses C-1 Manual Zoom Lenses C-5 Mounting 1-19 Non-CPU 1-22 Non-zoom AF Nikkor 8-10 Overview 1-19 Removing 1-22 Setting to the minimum aperture 1-21...
Page 253 PowerSave Time 3-11 Setting 3-3 Total Actuations 3-4 Use Empty Folder 3-7 Use Folder 1 3-8 Ps button 1-17 QR Function 7-12 QR-OUT button 1-17 Quick Recall Function 7-12 Rear-curtain sync 8-5 Reassembling camera 11-9 REC/TAG button 1-16 Recalling customized settings 7-14 Record/Tag button 1-16 –...
Page 254 – Vari-program 6-3 Alerts 6-9 Automatic camera settings 6-7 Cancelling 6-7 Close-up program 6-5 Hyperfocal program 6-5 Landscape program 6-5 Operating 6-8 Portrait program 6-4 – Programs 6-4 Setting 6-7 Silhouette program 6-6 Sport program 6-6 VCCI Statement 1-31 Viewfinder 1-13 Difference between DCS 315 and DCS 330 1-13 –...
Page 255 The camera firmware is based in part on the work of the Independent JPEG group. Kodak and Kodak Professional are trademarks of Eastman Kodak Company © 1999 Eastman Kodak Company. All rights reserved. Adobe, Photoshop, and Acrobat Reader are trademarks of Adobe Systems Inc.
Page 256 EASTMAN KODAK COMPANY Kodak Professional Division Rochester, New York 14650 www.kodak.com/go/professional © Eastman Kodak Company, 1999. Kodak and Kodak Professional are trademarks. P/N 6B0935...
