El Installation instructions
Removing transit bolts
1. Before operating the washer, remove the transit
bolts(4ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for correct
installation.
• Do not place or store your washer below 0°C (32°F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer and
bottom of upper plate should be at least 3mm.
Downloaded From WashingMachine-Manual.com Manuals
2. Unscrew the 4 bolts with the 10mm hex wrench
or spanner or cross-tip screwdriver. Keep the 4
bolts for a later time.
• When the appliance is transported, transit bolts
will be re-used.
Washer
approx.
Drain Hose
Laundry
Tub
2cm
E-5
