Gebrauchs- und Montageanweisung
Induktions-Glaskeramik-Kochfeld
Instructions for fitting and use
Glass ceramic induction hob
Instructions de montage et d'utilisation
Table de cuisson vitrocéramique à induction
Gebruiks- en montage-instructies
Keramische inductiekookplaat
Istruzioni per uso e montaggio
Piano di cottura ad induzione in vetroceramica
Instrucciones para el uso y montaje
Encimera vitrocerámica per inducción
Instruções de uso e de montagem
Placa de cozinhar de indução em vitrocerâmica
225985 O11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Teka VRTC954I
Summary of Contents for Teka VRTC954I
- Page 1 Gebrauchs- und Montageanweisung Induktions-Glaskeramik-Kochfeld Instructions for fitting and use Glass ceramic induction hob Instructions de montage et d’utilisation Table de cuisson vitrocéramique à induction Gebruiks- en montage-instructies Keramische inductiekookplaat Istruzioni per uso e montaggio Piano di cottura ad induzione in vetroceramica Instrucciones para el uso y montaje Encimera vitrocerámica per inducción Instruções de uso e de montagem...
-
Page 2: Table Of Contents
Disposing of the packaging For your information... Please dispose of the packaging that came with your appliance in Please read this manual carefully before using your appliance. It an environmentally friendly way. Recycling in this way saves on contains important safety advice; it explains how to use and look resources and cuts down on waste. -
Page 3: Safety Instructions
Safety instructions Connection and operation • Do not put kitchen foil or plastic onto the cooking zones. Keep Safety instructions everything which could melt, such as plastics, foil and in • The appliances are constructed in accordance with the particular sugar and sugary foods, away from the hot cooking relevant safety regulations. -
Page 4: Appliance Description
Appliance description Operating the hob with the sensor keys The decorative design may deviate from the illustrations. 1. Induction cooking zone front left The ceramic glass hob is operated with touch control sensor keys. The sensor keys are operated as follows: lightly touch a 2. -
Page 5: Operation
Operation The hob Operating time limit Operation The hob is equipped with an induction cooking mode. An The induction hob has an automatic time limit function. induction coil underneath the glass ceramic hob generates an The duration of continuous use of each cooking zone depends on electromagnetic alternating field which penetrates the glass the cooking level selected (see chart), provided that the setting of ceramic and induces the heat-generating current in the pot base. -
Page 6: Cookware For Induction Hobs
Operation Cookware for induction hobs How to cut power consumption The cookware used for the induction cooking zone must be made The following are a few useful hints to help you cut your of metal, have magnetic properties and a sufficient base area. consumption of energy and use your new induction hob and the cookware efficiently. -
Page 7: Operating The Buttons
Operation Operating the buttons The controls described here expect the pressing of a (selection) button to be followed by the pressing of a subsequent button. The pressing of a subsequent button must always commence within 10 seconds, otherwise the selection will be deleted. The plus and minus buttons can be touched individually or be permanently pressed. -
Page 8: Stop Function
Operation STOP function The cooking process can be briefly interrupted with the STOP function, e.g. if the doorbell rings. The STOP function must be released in order to continue cooking at the same power level. If a timer has been set it will pause and will then continue. -
Page 9: Automatic Switch-Off (Timer)
Operation Automatic switch-off (timer) The automatic switch-off device is used to automatically switch off any cooking zone after a stipulated period of time. Cooking times ranging from 1 minute to 99 minutes can be set. 1. Switch on the hob. 2. -
Page 10: Automatic Boost Function
Operation Automatic boost function Parboiling takes place at power level 9 with the automatic boost function. After a certain time the power level will switch down automatically to a lower simmering setting (1 to 8). When using the automatic boost function only the simmering setting with which the food is to be cooked through needs to be selected since the electronic unit switches down automatically. -
Page 11: Power Boost Setting (Cooking Zones Marked With A P)
Operation Power boost setting (cooking zones marked with a P) The power boost setting makes additional power available for induction cooking zones. A large quantity of water can be brought to the boil very quickly. The power boost setting operates for 10 minutes, after which the power level is automatically reduced to cooking level 9. -
Page 12: Cleaning And Care
Cleaning and Care Specific soiling Cleaning and Care Heavy soiling and stains (limescaling and shiny, mother-of- pearl-type stains) can best be removed when the hob is still • Before cleaning, switch off the hob and let it cool down. slightly warm. Use commercial cleaning agents to clean the hob. •... -
Page 13: Troubleshooting
What to do if trouble occurs Error code E2 is indicated? What to do if trouble occurs The electronic unit is too hot. Check the installation of the hob. Make sure that there is sufficient ventilation. See the section on thermal cut-off. Interference with and repairs to the appliance by unqualified persons are dangerous as they can result in electric shock, or short circuit. -
Page 14: Instructions For Assembly
Instructions for assembly Safety instructions for kitchen unit fitters Installation Instructions for assembly • Veneers, adhesives and plastic surfaces of surrounding Important furniture must be temperature resistant (>75°C). If the veneers • Remove any transverse strips underneath the worktop at least and surfaces are not sufficiently heat resistant they can in the area of the worktop cut-out. - Page 15 Instructions for assembly Dimensions in mm Bracket • Insert the hob and align it. • From the bottom, insert the brackets with screws in the holes provided for fastening the brackets, align the brackets and screw them tight. • Tighten the screws with a hand screw driver only;...
-
Page 16: Electrical Connection
Instructions for assembly Electrical connection Mains cable available in the factory • The induction hob has been fitted with a temperature-resistant • The electrical connection must be carried out by a connection cable in the factory. qualified electrician who is authorised to carry out such •... -
Page 17: Technical Data
Instructions for assembly Technical data Start of operation Hob dimensions Once the hob has been installed and the power supply has been Height/ Width/ Depth ..mm 50 x 950 x 520 provided (mains connected) an automatic test of the controls will be carried out and information for customer service will be Cooking zones indicated.
