- Page 1 SELFSAT-H10D/H21D SELFSAT-H10D/H21D SELFSAT-H10D/H21D User’s manual Flat Satellite Antenna with Dual Linear Polarization www.self-sat.com...
-
Page 2: Table Of Contents
Contents What is SELFSAT-H10D/H21D? What is SELFSAT-H10D/H21D? ................ - Page 3 SELFSAT-H10D/H21D...
-
Page 4: What Is Selfsat-H10D/H21D
Small, discreet and easy to use, it can be installed in a few minutes and used as a portable antenna for all satellite receptions. SELFSAT-H10D/H21D can be used for both free to Air and encrypted (requiring a subscrip- tion with an operator) channel reception; it can also receive all High Definition channels with a superior image quality. -
Page 5: Safety Instructions
• All the instructions should be followed in order to avoid any technical problems. • Any electric or magnetic field close to the SELFSAT-H10D/H21D may cause a bad reception or even cut off the signal completely. • Do not drill the plastic cover of the antenna, which seals the antenna from moisture. -
Page 6: Box Content
Box Content Symbol Part name Image Quantity SELFSAT-H10D SELFSAT-H21D Antenna Body Attenuation Angle Bracket Main Support Window Bracket A Window Bracket B Bracket A Bracket B Spanner... - Page 7 Symbol Part name Image Quantity Compass Hex Bolt M4X10 SEMS2 Hex Bolt M6x18 SEMS2 Hex Bolt M6X50 SEMS2 Round Head SquareNeck Bolt M6x30 Round Head SquareNeck Bolt M6x50 U-Bolt M6x85 Flanged Nut Rubber www.self-sat.com...
-
Page 8: Install
Step 1: Where to Install? In order to receive a signal from the Satellite, SELFSAT-H10D/H21D is to be installed in an open loop space (outside the house or the apartment), in the direction of the satellite towards the equator, for which, you will need a compass to exactly orient SELFSAT-H10D/H21D toward the satellite (Note;... -
Page 9: Step 2: Installation Choice
Good Quality Singnal Reception GOOD! GOOD! Step 2: Installation Choice Depending on the choice of installation position for the SELFSAT-H10D/H21D, you can then decide on the mounting type, all parts are included. A) Table Stand Type (on a Horizontal Plain) www.self-sat.com... -
Page 10: B) Wall Mounting Type
B) Wall Mounting Type C) Window Type Attention Part number B6 bracket has 2 holes for H10D model & 4 holes for H21D model respectively. -
Page 11: D) Clamp On Balcony Type
D) Clamp on Balcony Type Step 3: Connecting the Antenna and the Set top box Once you have installed the antenna in an open loop space and mounted the way you want it to be the next step is to connect it all together. In order to be able to watch your favorite satellite programs, you need to connect your satellite antenna to a receiver by a cable. -
Page 12: A) How To Prepare The Cable
A) How to prepare the cable? CONNECTOR COVER 15mm F CONNECTOR B) How to connect the cable to the antenna and the set top box? One side To Antenna Other side To receiver Cable It is important that the coaxial cable does not become damaged or Kinked during the installation procedure. -
Page 13: Step 5 : Pointing And Location The Signal (First Without Attenuation Thin Pad)
Step 5: Pointing and locating the Signal (first without Attenuation Thin Pad) Once all installed and connected, you may take off the Attenuation Thin Pad from the antenna (and keep to one side for step 6) and then start adjusting your antenna in order to receive a signal. For that, you will need to move your antenna in three different ways in order to receive the maximum signal level &... -
Page 14: B) Elevation Angle
B) Elevation Angle : Then obtain the Elevation angle according to the area location of the chosen satellite on the lists in this manual. Then move your antenna up or down according to the angle, (you may use the graduated surface of the bracket in order to make sure that you are on the right position. - Page 15 ASTRA 1 19,2 HOTBIRD ASTRA 2 28,2 The signal level and quality is indicated on the TV screen and will fluctuate and change colour accord- ing to the adjustment & movement of the antenna while you are pointing & finding (azimuth, elevation and Skew angle).
-
Page 16: Step 6: Optimum Pointing & Finding The Signal (With Attenuation Thin Pad)
Attenuation Thin Pad. So during bad weather, you are recommended to skip step 6 for a use of Attenuation Thin Pad. Attenuation Pad SELFSAT-H10D Attenuation Pad SELFSAT-H21D... -
Page 17: Troubleshooting Check List For Initial Installation
Troubleshooting Check List for Initial Installation If the signal is not found, be sure the receiver user manual and the antenna user manual have been followed closely, check the following: √ Make sure all cable connections are correct and each connection is seated/tightened properly √... -
Page 18: Loss Of Signal / Rain Fade
Loss of Signal / Rain Fade The satellite signal may be lost temporarily due to unusually heavy rainfall. An optimally aligned ● antenna, along with the shortest possible cable run, minimizes the chances of “rain fade.” Make sure the antenna is mounted securely to prevent it from being blown out of alignment in a ●... - Page 19 Austria Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 20 Belgium Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 21 France Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 22 Germany Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 23 Great Britain Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1...
- Page 24 Italy Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 25 Luxembourg Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 26 Netherlands Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 27 Spain Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 28 Switzerland Az = Azimuth El = Elevation Sk = Skew Astra Astra Atlantic Hispa Astra Astra Atlantic Hispa Türk Türk 2A-2D 1F-1H/ 2A-2D 1F-1H/ bird bird bird bird Euro 1KR/1L/ Euro 1KR/1L/ 2A, 3A 6/7A/8 1C,1D 2A, 3A 6/7A/8 1C,1D bird 1 bird 1 42.0E...
- Page 29 Denmark Az = Azimuth El = Elevation Sk = Skew Astra Astra Thor 2A-2D 1F-1H/ Astra Eutelsat Hotbird Eutelsat Eutelsat Atlantic Hispasat Sirius 4 Euro 1KR/1L/ 1E/3A 6/7A/8 Intelsat bird 3 1C,1D bird 1 10-02 28.2E 23.5 E 19.2E 16.0E 13.0W 10.0W 7.0E...
- Page 30 Finland Az = Azimuth El = Elevation Sk = Skew Astra Astra Thor 2A-2D 1F-1H/ Astra Eutelsat Hotbird Eutelsat Eutelsat Atlantic Hispasat Sirius 4 Euro 1KR/1L/ 1E/3A 6/7A/8 Intelsat bird 3 1C,1D bird 1 10-02 28.2E 23.5 E 19.2E 16.0E 13.0W 10.0W 7.0E...
- Page 31 Norway Az = Azimuth El = Elevation Sk = Skew Astra Astra Thor 2A-2D 1F-1H/ Astra Eutelsat Hotbird Eutelsat Eutelsat Atlantic Hispasat Sirius 4 Euro 1KR/1L/ 1E/3A 6/7A/8 Intelsat bird 3 1C,1D bird 1 10-02 28.2E 23.5 E 19.2E 16.0E 13.0W 10.0W 7.0E...
- Page 32 Sweden Az = Azimuth El = Elevation Sk = Skew Astra Astra Thor 2A-2D 1F-1H/ Astra Eutelsat Hotbird Eutelsat Eutelsat Atlantic Hispasat Sirius 4 Euro 1KR/1L/ 1E/3A 6/7A/8 Intelsat bird 3 1C,1D bird 1 10-02 28.2E 23.5 E 19.2E 16.0E 13.0W 10.0W 7.0E...
