ENGLISH
Features
This tool includes some or all of the following features.
1. Variable speed switch
2. Forward/reverse slider
3. Mode selector / torque adjustment collar
4. Chuck
5. Speed selector
6. Bit holder
7. Battery
Fig. A
8. Charger plug
9. Charger
10. Charger receptacle
Assembly
Warning! Before assembly, remove the battery from the
tool.
Fitting and removing the battery (fig. B & C)
•
To fit the battery (7), line it up with the receptacle on the
tool. Slide the battery into the receptacle and push until
the battery snaps into place.
•
To remove the battery, push the release button (11) while
at the same time pulling the battery out of the receptacle.
Fitting the battery cap (fig. C)
Warning! Fit the cap (12) to the battery (7) for transportation
and storage.
8
Fitting and removing a drill bit or screwdriver bit (fig. D)
This tool is fitted with a keyless chuck to allow for an easy
exchange of bits.
•
Lock the tool by setting the forward/reverse slider (2) to
the centre position.
•
Open the chuck by turning the front part (13) with one
hand while holding the rear part (14) with the other.
•
Insert the bit shaft (15) into the chuck and firmly tighten
the chuck.
This tool is supplied with a double-ended screwdriver bit in
the bit holder (6).
•
To remove the screwdriver bit from the bit holder, lift the
bit from the recess.
•
To store the screwdriver bit, firmly push it into the holder.
Removing and refitting the chuck (fig. E)
•
Open the chuck as far as possible.
•
Remove the chuck retaining screw by turning it clockwise
using a screwdriver.
•
Tighten an Allen key into the chuck and strike it with a
hammer as shown.
•
Remove the Allen key.
•
Remove the chuck by turning it counterclockwise.
•
To refit the chuck, screw it onto the spindle and secure it
with the chuck retaining screw.
Residual risks
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
